Argo Orange Manual de usuario

V 06/23

This product is only suitable for well insulated spaces or

occasional use.

OPERATING INSTRUCTIONS

Read the instructions carefully before installing and operating the appliance or performing

maintenance operations. Observe all the safety instructions; failure to observe the instructions may

cause accidents and/or damages. Store these instructions for future reference.

FAN HEATER

V 06/23

GENERAL SAFETY INFORMATION

•Use this fan heater only as outlined in this manual. Any other use

not recommended by the manufacturer may cause fire, electric

shock or injury to people.

•Ensure that the mains power complies with the voltage specified on

the fan heater data plate (220-240V~50Hz).

•This appliance can be used by children aged from 8 years and

above and people with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in a

safe way and understand the hazards involved.

•Children shall not play with the appliance.

•Cleaning and user maintenance shall not be made by children

without supervision.

•This product is not a toy.

•Children under the age of 3 must be kept away unless continuously

supervised.

•Children aged between 3 and 8 must only turn the appliance on / off

as long as it has been placed or installed in its normal operating

position and that they receive surveillance or instructions regarding

the safe use of the appliance and understand the dangers.

•Children between 3 and 8 years of age must not insert the plug,

adjust or clean the appliance or carry out maintenance by the user.

CAUTION - Some parts of this product can become very hot

and cause burns. Particular attention has to be given where

children and vulnerable people are present.

WARNING: In order to avoid hazard due to inadvertent resetting of

the thermal cut-out, this appliance must not be supplied through and

external switching device, such as a timer, or connected to a circuit

that is regularly switched on and off by the utility.

WARNING: do not use the fan heater with a controller or any

other external device that activates the appliance

V 06/23

automatically, as there may be a risk of fire if the fan heater is

covered or incorrectly positioned.

•Do not restrict the air inlet and outlet grilles.

•The appliance heats up slightly when in use. In order to avoid burns,

do not let bare skin touch hot surfaces.

•Ensure that all objects are at least 1 meter from the front and sides

of the appliance.

•Disconnect the mains power when the appliance is not used or for

cleaning operations.

•Avoid using the fan heater in dusty environments or in the presence

of inflammable vapors (e.g. in workshops or garages) or paint

vapors.

•Do not place anything on the appliance, do not use the appliance to

dry clothing.

•Use the appliance in a well-ventilated area.

•Avoid placing fingers or foreign objects in the air inlet/outlet grilles,

as this may lead to electric shock or fire and may damage the

appliance.

•To avoid the risk of fire, do not block the grilles or tamper with them

in any way while the fan heater operates.

•Do not use the appliance if the cord or plug are damaged. If the

power supply cable is damaged, it must be replaced by the

manufacturer or its technical assistance service or in any case by a

person with a similar qualification, in order to prevent any risk.

•Do not operate the appliance if it has fallen from a height or has

suffered damage in any way. Contact qualified technical personnel

to examine the appliance or perform any electrical or mechanical

repairs.

•The most common cause of overheating is the build-up of dust in

the appliance. Remove dust deposits by unplugging the appliance

and cleaning the air outlets and grilles with the aid of a vacuum

cleaner.

V 06/23

•Do not use abrasive detergents for cleaning this appliance. Clean

the appliance with the aid of a damp (not wet) cloth rinsed in hot

soapy water. Always remove the plug from the mains socket before

cleaning.

•To disconnect the fan heater, push the switch to OFF and remove

the plug from the socket. Pull on the plug only. Avoid pulling on the

cord when disconnecting the fan heater.

•Do not place any objects on the cord and do not bend it.

•It is not advisable to use extension cords, as these may overheat

and cause the risk of fire. Do not use a single extension cord to

operate multiple appliances.

•Do not immerse the cord, plug or any other element of the appliance

in water or other liquids.

•Do not touch the plug with wet hands.

•Do not place the fan heater above or near another heat source.

WARNING: AVOID COVERING THE FAN HEATER TO PREVENT

IT FROM OVERHEATING.

The symbol below signals the above warning:

•The fan heater may cause the risk of fire if, while in operation, is

covered by or comes into contact with inflammable material

including curtains, drapery, blankets, etc. KEEP THE FAN HEATER

AWAY FROM THESE MATERIALS.

•Do not connect the appliance to the mains power before it has been

properly assembled and positioned.

•Do not run the cord under carpets. Do not cover the cord with

blankets, carpets or similar materials. Place the cord far away from

busy areas or where it cannot be accidentally pulled-out.

•Do not operate the fan heater in close proximity to bathtubs,

showers, washbasins or pools.

V 06/23

•Do place the appliance in the bathroom.

•The heater should not be placed immediately below a power outlet.

•Do not operate the appliance outdoors.

Upon initial start-up, the fan heater may emit a slight, harmless

smell. This smell is a normal effect of the initial heating up of the

internal heating elements, and should not recur later on.

WARNING: DO NOT DEPEND ON THE ON/OFF BUTTON

SWITCH AS THE SOLE MEANS OF DISCONNECTING POWER.

WHEN SERVICING OR MOVING THE FAN HEATER, ALWAYS

UNPLUG THE POWER CORD.

•A fan heater has hot and arcing or sparkling parts inside. It must not

be used in potentially dangerous locations such as flammable,

explosive, chemical-laden or wet atmosphere.

•Do not place the fan heater on soft surfaces, like a bed, where

openings may become blocked. Always place the fan heater on a

stable, flat, level surface when operating, to avoid the chance of the

fan heater overturning. Locate the power cord so the fan heater or

other objects are not resting on it.

•Always unplug the fan heater when not in use.

•In order to avoid accidents turn unit off if unattended.

•In the event of any problems (abnormal noise or a strange smell)

switch off the appliance immediately, do not attempt to repair it and

take it to your local after sales service.

•Use this heater on a horizontal and stable surface, or fix it to the

wall, as applicable.

•WARNING: Do not use this heater in small rooms when they are

occupied by persons not capable of leaving the room on their own,

unless constant supervision is provided.

V 06/23

DESCRIPTION OF PARTS

1. On/off and selection knob

2. Thermostat knob

3. Air outlet grille

4. Carrying handle

5. Air suction grille

HOW TO USE THE FAN HEATER

Put the fan heater vertically on a flat and stable surface.

Connect the power cord to a suitable electric socket (220-240V~/50Hz).

Turn the thermostat knob clockwise to maximum position “6”.

Turn on the On/off and selection knob and select one of the possible positions:

Cold ventilation , ECO mode (1)(1000W) or COMFORT mode (2) (2000 W).

CONTROL PANEL AND AVAILABLE FUNCTIONS

The thermostat maintains the desired room temperature by automatically switching on/off the fan heater.

As you rotate the knob clockwise, the room temperature increases.

Operate the unit until the room reaches a comfortable temperature, then turn the knob thermostat knob counter-clockwise until

you hear a "click" and the unit will shut down; then turn again slightly (just a little) the thermostat knob clockwise, in this

position the thermostat will maintain the temperature you have chosen.

The appliance is fitted with an anti tip-up device that prevents it from operating when it detects that the product is inclined.

Do not position the appliance on its side or upside down.

COMFORT mode (2): maximum

heating power (2000W).

ECO mode (1): 1000 W

reduced power and

consumption to save energy .

OFF: fan heater off in

position “O”.

Cold

ventilation

Thermostat adjustment

knob: from Minimum “0”

Maximum “6” temperature,

by turning the knob

clockwise.

V 06/23

OVERHEATING SAFETY DEVICE

In case of overheating the safety cut out protecting the heating element will automatically switch off the appliance.

If this happens:

•switch off the fan heater;

•remove the causes of abnormal operation or overheating (i.e. obstacles in front of air inlet or air outlet grille);

•leave the heater cool down for 15/20 minutes;

•switch on again the fan heater.

MAINTENANCE AND STORAGE

ALWAYS UNPLUG THE APPLIANCE BEFORE CLEANING OR MAINTENANCE.

IMPORTANT: DO NOT SUBMERGE THE CERAMIC FAN HEATER IN WATER

Cleaning the outside surface of the appliance

Turn the switch off and unplug before carrying out any maintenance work or moving the appliance.

Use a soft cloth to remove any dust from the fan heater.

If the fan heater is excessively dirty, use a soft cloth moistened with water and a mild detergent at a temperature lower than

50°C. Let the fan heater dry completely before use.

Do not use corrosive detergents or solvents such as petrol. Do not wash the appliance with water. Do not use oils, chemical

substances or other items to clean that may damage the surface.

Use a vacuum cleaner to remove dust from the air inlet/outlet grilles.

STORAGE

If the appliance is not used for prolonged periods, it must be stored together with this manual in its original packaging, in a

cool and dry place.

V 06/23

INFORMATION REQUIREMENTS FOR ELECTRIC LOCAL SPACE HEATERS

Table 2 - Annex II -Ecodesign requirements - Requirements for product information -

COMMISSION REGULATION (EU) 2015/1188 of 28 April 2015 implementing Directive 2009/125/EC of the European

Parliament and of the Council with regard to ecodesign requirements for local space heaters

Model identifier(s): ORANGE - KOBALTO

Item Symbol Value unit Item unit

Heat output Type of heat input, for electric storage local space

heaters only (select one)

Nominal heat output Pnom 1.9 kW manual heat charge control, with

integrated thermostat

[no]

Minimum heat output

(indicative)

Pmin 0.9kW manual heat charge control with room

and/or outdoor temperature feedback

[no]

Maximum continuous

heat output

Pmax,c 1.9 kW electronic heat charge control with room

and/or outdoor temperature feedback

[no]

Auxiliary electricity

consumption

fan assisted heat output [no]

At nominal heat output elmax 0 kW Type of heat output/room temperature control

(select one)

At minimum heat output elmin 0 kW single stage heat output and no room

temperature control

[no]

In standby mode elsb 0 kW Two or more manual stages, no room

temperature control

[yes]

with mechanic thermostat room

temperature control

[no]

with electronic room temperature control [no]

electronic room temperature control plus

day timer

[no]

electronic room temperature control plus

week timer

[no]

Other control options (multiple selections

possible)

room temperature control, with presence

detection

[no]

room temperature control, with open

window detection

[no]

with distance control option [no]

with adaptive start control [no]

with working time limitation [no]

with black bulb sensor [no]

Contact details : ARGOCLIMA SPA - Via A. Varo,35 - Alfianello (BS) - ITALY -

www.argoclima.com

V 06/23

INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH THE EUROPEAN DIRECTIVE

2012/19/EU

At the end of its working life this equipment must not be disposed of as an household waste. It must be taken to special local

community waste collection centres or to a dealer providing this service. Disposing of electrical and electronic equipment

separately avoids possible negative effects on the environment and human health deriving from an inappropriate disposal and

enables its components to be recovered and recycled to obtain significant savings in energy and resources. In order to

underline the duty to dispose of this equipment separately, the product is marked with a crossed-out dustbin.

www.argoclima.com

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Calentador de Argo

Manuales populares de Calentador de otras marcas

oventrop

oventrop Regucor Series Manual de usuario

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manual de usuario

ELMEKO

ELMEKO ML 150 Manual de usuario

BN Thermic

BN Thermic 830T Manual de usuario

KING

KING K Series Guía

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guía de inicio rápido

Well Straler

Well Straler RC-16B Manual de usuario

EUROM

EUROM 333299 Manual de usuario

Heylo

Heylo K 170 Manual de usuario

Eterna

Eterna TR70W Manual de usuario

Clarke

Clarke GRH15 Manual de instrucciones

IRSAP

IRSAP The Radiator Company Ovali Manual de usuario

Empire Heating Systems

Empire Heating Systems WCC65 Manual de usuario

Wetekom

Wetekom 92 86 43 Manual de usuario

Desa

Desa SPC170-F Manual de usuario

Watlow

Watlow Watrod Electric Tubular Heaters Manual de usuario

Haverland

Haverland ECO-DRY GPS Series Manual de lista de piezas

Stelpro

Stelpro ASILVC2060 Series Manual de usuario
