Ameriwood AX1 Manual de usuario

WARNING

ameriwoodhome.com

Follow Ameriwood Home

Keep this Assembly Manual for future reference

- Anchorunit to stud in wall

- Do Not allow children to climb on unit

- Put heavy items on lower shelves ordrawers

- Two people required for assembly

9292096COM

AX1 Round Table With 4 Legs

B349292096COM

Helpful Hints

ameriwoodhome.com

Do NOT return this product!

Contact our friendly customer service team ﬁrst for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy liing.

- Idenfy, sort and count the parts before aempng assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a

(right) and

(le) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

Tube

You

Tube

You

PEOPLE NEEDED FOR ASSEMBLY:1-2

ESTIMATED ASSEMBLY TIME: 1 HOUR

Before You Start

Hardware Assembly Method

ameriwoodhome.com



This Hardware Assembly Method will be used throughout the assembly process

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, Phillips Head

Screwdriver and Hammer

Failure to do so may result in stripping the screw.

Quick

Tip

Board

Not actual size

ameriwoodhome.com

-T9292096010

ROUND TABLE TOP

-T9292096020

WOODEN LEGS

Part List

Not Actual Size

ameriwoodhome.com

x8 TAT0042

WASHER-SPRING M6

TAT0043

NUT-HEX NUT

5/16" (18MM)

TAT0044

ADJUST SCREW

M6 X 25MM X 22MM

TAT0045

WRENCH 13MM

TAT0041

WASHER-FLAT 1/4

ameriwoodhome.com

Use this step if you are fastening the ADJUST SCREW(EH0254) to Wooden Legs.

Step 1

TAT0044

ameriwoodhome.com

Use this step if you are fastening the Wooden Legs to Top Panel

IMPORTANT! Align holes of Wooden Legs with proper holes of Round Table.

Step 2

TAT0042

x81

TAT0041

x8 5

TAT0045

x13

TAT0043

ameriwoodhome.com

Step 3

ameriwoodhome.com

Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is

not approved for use with a television.

Cer of Conformity

1. This cer cate applies to the Dorel Home Furnishings, Inc. product iden ﬁed by this instru manual.

2. This cer cate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).

3. This product is distributed by: Dorel Home Furnishings, Inc.

410 East First Street South

Wright City, MO 63390

636-745-3351

4. Site of Manufacture: Tiﬃn OH

5. See front page of instruc n manual for date of manufacture.

This unit has been designed to support the maximum loads shown. Exceeding these load limits

could cause sagging, instability, product collapse, and/or serious injury.

100 lbs (45 kg).max

Maximum Loads

ameriwoodhome.com

* New trend details -sneak peek on what's new

* Surveys -have a voice within our community

* Exclusive deals and discount codes

* Quick and easy replacement part service

To register your product, visit Ameriwoodhome.com

Visit your local retailer's website, rate your purchased

product and leave us some feedback!

We would like to extend a big "Thank You" to all of

our customers for taking the to assemble this

Ameriwood product, and to give us your valuable

feedback.
