Installation/Operation

www.comlaundry.com

Clothes Dryer

Electric and Gas Models

DRY710C

Part No. 513005R5

August 2011

Keep These Instructions for Future Reference.

(If this machine changes ownership, this manual must accompany machine.)

IMPORTANT: Purchaser must consult the local gas supplier for suggested instructions to be followed if the

dryer user smells gas. The gas utility instructions plus the SAFETY and WARNING note directly above

must be posted in a prominent location near the dryer for customer use.

The following information applies to the state of Massachusetts, USA.

• This appliance can only be installed by a Massachusetts licensed plumber or gas fitter.

• This appliance must be installed with a 36 inch (91 cm) long flexible gas connector.

• A “T-Handle” type gas shut-off valve must be installed in the gas supply line to this appliance.

• This appliance must not be installed in a bedroom or bathroom.

• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or

any other appliance.

• WHAT TO DO IF YOU SMELL GAS:

– Do not try to light any appliance.

– Do not touch any electrical switch; do not use any phone in your building.

– Clear the room, building or area of all occupants.

– Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s

instructions.

– If you cannot reach your gas supplier, call the fire department.

• Installation and service must be performed by a qualified installer, service agency or the gas

supplier.

W052

FOR YOUR SAFETY, the information in this manual must be followed to minimize the risk

of fire or explosion or to prevent property damage, personal injury or death. Keep this

manual for future reference. If this machine changes ownership, this manual must

accompany machine.

W755

WARNING

• Installation of unit must be performed by a qualified installer.

• Install clothes dryer according to manufacturer’s instructions and local codes.

• DO NOT install a clothes dryer with flexible plastic venting materials. If flexible metal (foil

type) duct is installed, it must be of a specific type identified by the appliance manufacturer

as suitable for use with clothes dryers. Refer to section on connecting exhaust system.

Flexible venting materials are known to collapse, be easily crushed, and trap lint. These

conditions will obstruct clothes dryer airflow and increase the risk of fire.

W729R1

WARNING

FOR YOUR SAFETY

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or

any other appliance.

W053

means without the expressed written consent of the publisher.

513005

Table of

Contents

Safety Information.............................................................................. 3

Explanation of Safety Messages........................................................... 3

Important Safety Instructions ............................................................... 3

Installation........................................................................................... 5

Dimensions ........................................................................................... 5

Metered Models ............................................................................... 5

Before You Start ................................................................................... 6

Tools ................................................................................................ 6

Card Reader Models ........................................................................ 6

Installing the Dryer ............................................................................... 7

Step 1: Position and Level the Dryer ............................................... 7

Step 2: Connect Dryer Exhaust System ........................................... 9

Exhaust Direction............................................................................. 10

Exhaust System................................................................................ 11

Multi-Dryer Installation Exhaust Requirements.............................. 12

Step 3: (Gas Dryer Only) Connect Gas Supply Pipe ....................... 14

Step 4: (Electric Dryer Only) Connect Electrical Plug.................... 15

Step 5: Reverse Door, if Desired ..................................................... 21

Step 6: Wipe Out Inside of Dryer .................................................... 22

Step 7: Plug In the Dryer ................................................................. 22

Step 8: Recheck Steps 1-7................................................................ 24

Step 9: Check Heat Source .............................................................. 24

Vending................................................................................................ 25

Meter Case............................................................................................ 25

Additional Dryer Security..................................................................... 25

Operation............................................................................................. 26

Operation Instructions .......................................................................... 26

Step 1: Clean Lint Filter................................................................... 26

Step 2: Load Laundry....................................................................... 26

Step 3: Close Loading Door............................................................. 26

Step 4: Set Fabric Selector............................................................... 27

Step 5: Insert Coin(s) or Card .......................................................... 27

Step 6: Start Dryer ........................................................................... 28

Indicator Lights................................................................................ 28

Maintenance ........................................................................................ 29

Lubrication............................................................................................ 29

Care of Your Dryer............................................................................... 29

Dryer Interior ................................................................................... 29

Cabinet ............................................................................................. 29

Control Panel ................................................................................... 29

Exhaust System................................................................................ 29

Lint Filter .............................................................................................. 30

Motor Overload Protector..................................................................... 30

For Energy Conservation...................................................................... 30

Troubleshooting .................................................................................. 31

Contact Information........................................................................... 32

Installer Checklist ............................................................... Back Cover

513005

Safety Information

Explanation of Safety Messages

Throughout this manual and on machine decals, you

will find precautionary statements (“DANGER,”

“WARNING,” and “CAUTION”) followed by specific

instructions. These precautions are intended for the

personal safety of the operator, user, servicer, and

those maintaining the machine.

Additional precautionary statements (“IMPORTANT”

and “NOTE”) are followed by specific instructions.

IMPORTANT: The word “IMPORTANT” is used

to inform the reader of specific procedures where

minor machine damage will occur if the procedure

is not followed.

NOTE: The word “NOTE” is used to communicate

installation, operation, maintenance or servicing

information that is important but not hazard

related.

Important Safety Instructions

Save These Instructions

1. Read all instructions before using the dryer.

2. Refer to the GROUNDING INSTRUCTIONS in

the INSTALLATION manual for the proper

grounding of the dryer.

3. Do not dry articles that have been previously

cleaned in, washed in, soaked in, or spotted with

gasoline, dry-cleaning solvents, other flammable

or explosive substances as they give off vapors

that could ignite or explode.

4. Do not allow children to play on or in the dryer.

Close supervision of children is necessary when

the dryer is used near children. This is a safety

rule for all appliances.

5. Before the dryer is removed from service or

discarded, remove the door to the drying

compartment.

6. Do not reach into the dryer if the cylinder is

revolving.

7. Do not install or store the dryer where it will be

exposed to water and/or weather.

8. Do not tamper with the controls.

9. Do not repair or replace any part of the dryer, or

attempt any servicing unless specifically

recommended in the user-maintenance

instructions or in published user-repair

instructions that you understand and have the

skills to carry out.

10. Do not use fabric softeners or products to

eliminate static unless recommended by the

manufacturer of the fabric softener or product.

11. To reduce the risk of fire, DO NOT DRY plastics

or articles containing foam rubber or similarly

textured rubberlike materials.

12. ALWAYS clean the lint filter after every load. A

layer of lint in the filter reduces drying efficiency

and prolongs drying time.

Indicates an imminently hazardous

situation that, if not avoided, will cause

severe personal injury or death.

DANGER

Indicates a hazardous situation that, if not

avoided, could cause severe personal

injury or death.

WARNING

Indicates a hazardous situation that, if not

avoided, may cause minor or moderate

personal injury or property damage.

CAUTION

To reduce the risk of fire, electric shock,

or injury to persons when using your

dryer, follow these basic precautions:

W034

WARNING

Safety Information

513005

13. Keep area around the exhaust opening and

adjacent surrounding area free from the

accumulation of lint, dust and dirt.

14. The interior of the dryer and the exhaust duct

should be cleaned periodically by qualified

service personnel.

15. If not installed, operated and maintained in

accordance with the manufacturer’s instructions

or if there is damage to or mishandling of this

product’s components, use of this product could

expose you to substances in the fuel or from fuel

combustion which can cause death or serious

illness and which are known to the State of

California to cause cancer, birth defects or other

reproductive harm.

16. Dryer will not operate with the loading door

open. DO NOT bypass the door safety switch by

permitting the dryer to operate with the door

open. The dryer will stop tumbling when the door

is opened. Do not use the dryer if it does not stop

tumbling when the door is opened or starts

tumbling without pressing the START

mechanism. Remove the dryer from use and call

the service person.

17. Do not put articles soiled with vegetable or

cooking oil in the dryer, as these oils may not be

removed during washing. Due to the remaining

oil, the fabric may catch on fire by itself.

18. To reduce the risk of fire, DO NOT put clothes

which have traces of any flammable substances

such as machine oil, flammable chemicals,

thinner, etc., or anything containing wax or

chemicals such as in mops and cleaning cloths, or

anything dry-cleaned at home with a dry-

cleaning solvent in the dryer.

19. Use the dryer only for its intended purpose,

drying clothes.

20. Always disconnect the electrical power to the

dryer before attempting service. Disconnect the

power cord by grasping the plug, not the cord.

21. If supply cord is damaged, it must be replaced by

a special cord or assembly available from the

manufacturer or its service agent.

22. Install this dryer according to the

INSTALLATION INSTRUCTIONS. All

connections for electrical power, grounding and

gas supply must comply with local codes and be

made by licensed personnel when required. Do

not do it yourself unless you know how!

23. Remove laundry immediately after the dryer

stops.

24. Always read and follow manufacturer’s

instructions on packages of laundry and cleaning

aids. Heed all warnings or precautions. To reduce

the risk of poisoning or chemical burns, keep

them out of reach of children at all times

(preferably in a locked cabinet).

25. Do not tumble fiberglass curtains and draperies

unless the label says it can be done. If they are

dried, wipe out the cylinder with a damp cloth to

remove particles of fiberglass.

26. ALWAYS follow the fabric care instructions

supplied by the garment manufacturer.

27. Never operate the dryer with any guards and/or

panels removed.

28. DO NOT operate the dryer with missing or

broken parts.

29. DO NOT bypass any safety devices.

30. Failure to install, maintain, and/or operate this

machine according to the manufacturer’s

instructions may result in conditions which can

produce bodily injury and/or property damage.

IMPORTANT: Solvent vapors from dry-cleaning

machines create acids when drawn through the

heater of the drying unit. These acids are corrosive

to the dryer as well as to the laundry load being

dried. Be sure make-up air is free of solvent vapors.

IMPORTANT: Have your dryer installed properly.

Don’t do it yourself unless you know how!

NOTE: The WARNING and IMPORTANT

SAFETY INSTRUCTIONS appearing in this

manual are not meant to cover all possible

conditions and situations that may occur. Common

sense, caution and care must be exercised when

installing, maintaining, or operating the dryer.

Always contact your dealer, distributor, service agent

or the manufacturer about any problems or conditions

you do not understand.

513005

Installation

Dimensions

Metered Models

NOTE: Side, rear and bottom exhaust openings are

4 inch (10.2 cm) ducting. Gas models cannot be

vented out left side of cabinet because of burner

housing.

IMPORTANT: The dryer should have sufficient

clearance around it for needed ventilation and for

the ease of installation and servicing. For maximum

drying performance, we recommend that more

clearance be allowed around the dryer than the

clearances that are listed throughout this manual.

DRY2353N

*With leveling legs turned into base.

DRY2354N

*With leveling legs turned into base.

13/8 in. N.P.T. Gas Connection

23.5 in.

(59.7 cm)

8.0 in.

(20.3 cm) 0.4 in.

(1.02 cm)

28 in.

(71.1 cm)

*36 in. (91.4 cm)

15.4 in.

(39.1 cm)

ELECTRIC MODELS

4.0 in.

(10.2 cm)

26.9 in.

(68.3 cm)

22.06 in. (56 cm)

*4.5 in. (11.4 cm)

*15.44 in.

(39.2 cm)

*38.19 in. (97 cm)

*43 in. (109.2 cm)

Standard Capacity Meter Case

*43.875 in. (111.44 cm)

High Capacity Meter Case

DRY2254

GAS MODELS

23.5 in.

(59.7 cm)

8.0 in.

(20.3 cm)

28 in.

(71.1 cm)

*38.19 in. (97 cm)

15.4 in.

(39.1 cm)

2.3 in.

(6 cm)

26.9 in.

(68.3 cm)

0.4 in.

(1.02 cm) 2.8 in.

(7 cm)

22.06 in. (56 cm)

*4.5 in. (11.4 cm)

4.0 in.

(10.2 cm)

*15.44 in.

(39.2 cm)

*36 in. (91.4 cm)

*43 in. (109.2 cm)

Standard Capacity Meter Case

*43.875 (111.44 cm)

High Capacity Meter Case

Installation

513005

Before You Start

Tools

For most installations, the basic tools you will need

are:

Figure 1

NOTE: An 8 in. (20.32 cm) coin drawer is required

for coin operated models with standard capacity

meter case and high capacity meter case models

starting with Serial Nos. beginning 1010. High

capacity meter case models with Serial Nos.

beginning 0910 through 1010 require a 7.21 in.

(18.31 cm) coin drawer.

Card Reader Models

The machine is shipped from the factory with the

Electronic Control Diagnostic Harness Assembly

unplugged. To avoid unauthorized manual

programming or vending perform the following steps.

1. Open service door. Refer to Figure 1.

2. Locate diagnostic harness on electronic control.

3. Plug connectors for “white/black” wire and “red/

blue” wire together.

D818I

1Wrench

2Screwdrivers

3Level

4Teflon Tape

5Duct Tape

FLW6R

1 Service Door

Figure 2

Any disassembly requiring the use of

tools must be performed by a suitably

qualified service person.

W299

WARNING

Installation

513005

Installing the Dryer

Step 1: Position and Level the Dryer

Install dryer before washer. This allows room for

attaching exhaust duct.

Install the four rubber feet (in accessories bag).

Select a location with a solid floor. Dryers installed in

residential garages must be elevated 18 inches (46 cm)

above the floor.

No other fuel burning appliance should be installed in

the same closet with the dryer.

The dryer must not be installed or stored in an area

where it will be exposed to water and/or weather.

The dryer needs sufficient clearance and an adequate

air supply for proper operation and ventilation, and for

easier installation and servicing. (Minimum clearances

are shown in Figure 4).

Place the dryer in position, and adjust the legs until the

dryer is level from side to side and front to back.

Leveling legs can be adjusted from inside the dryer

with a 1/4 in. driver. All four legs must rest firmly on

the floor so the weight of the dryer is evenly

distributed. The dryer must not rock.

Figure 3

IMPORTANT: In mobile home installations, gas

dryers MUST be permanently attached to the floor

at the time of installation. Order No. 526P3 Hold

Down Kit (available at extra cost) for a

manufactured (mobile) home installation. Follow

the instructions supplied with the kit.

Installation of unit must conform to the Manufactured

Home Construction and Safety Standards, Title 24

CF4, Part 32-80 or Standard CAN/CSA-Z240 MH.

DRY2355N

1Dryer Base

2Level

3Leveling Leg

4Rubber Foot

Installation

513005

D337I

1Closet Door

2Centered Air Openings (G) (2 Openings

minimum)

3Outer Wall of Enclosure

**NOTE: For new installations, locate top of wall vent 42 inches (106.7 cm) above floor to make venting

easier to connect.

Figure 4

D337I

2 (G)

**42 in.

(106.7 cm)

AA C

FRONT VIEW

(W/O CLOSET DOOR)

SIDE VIEW

(CLOSET DOOR)

FRONT VIEW

(CLOSET DOOR)

Area Description Free Standing/Alcove

Installation Closet Installation

Dryer sides and rear clearance 0 in. (0 cm) 0 in. (0 cm)

Dryer top clearance 12 in. (30.5 cm) 12 in. (30.5 cm)

Dryer front clearance Not Applicable 2 in. (5.1 cm)

Exhaust duct clearance to

combustible material

2 in. (5.1 cm) 2 in. (5.1 cm)

Weather hood to ground clearance 12 in. (30.5 cm) 12 in. (30.5 cm)

Distance from floor or ceiling to

hole edge

Not Applicable 3 in. (7.6 cm)

Area of centered air openings in

closet door

Not Applicable 40 sq. in./open (260 sq. cm)

*Louvered door with equivalent air openings is acceptable. (Minimum clearances are shown.)
