Aidapt Solo Bed Transfer Aid Manual

Fixing and Maintenance Instructions

Solo Bed Transfer Aid

N.B. This equipment must be installed by a competent installer/ technician.

Instructions for:

Solo Bed Transfer Aid and Solo Bed Transfer Aid Chrome 127Kg weight limit

Do not exceed the weight limit stated, doing so will put the user at risk.

1. Introduction

Thank you for deciding to purchase the Aidapt Solo Bed Transfer Aid.

The Bed Transfer Aid is manufactured from the nest material and

components available, when installed and used correctly it is designed

to give many years of reliable, trouble-free service.

The Solo Bed Transfer Aid can be tted to single, double, queen and

king size beds. It is available in two nishes, white epoxy and chrome.

2. Before Installation

2.1 Carefully remove all packaging. Avoid using any knives of

other sharp instruments as this may damage the surface of the Bed

Transfer Aid

2.2 Check the product for any visible damage. If you see any

damage or suspect a fault, do not use your product, but

contact your supplier for support.

3. Assembly and Installation

3.1 Your Bed Transfer Aid is shipped ready assembled with

its handle at its lowest setting.

3.2 To install, remove the mattress from the bed where

the Bed Transfer Aid is to be installed and check for any

obstructions.

3.3 Place the Bed Transfer Aid onto the base of the bed with

the large at base on the bed frame and the looped handle

facing upwards level with the side of the bed (See gure 2).

3.4 Move the Bed Transfer Aid up and down the bed to nd

the best position for the user to safely lift themselves.

3.5 Ensure that the frame of the Bed Transfer Aid is square

to the side of the bed and that both of the black feet at the

base of the unit are touching the side of the bed.

3.6 Replace the mattress ensuring that the Bed Transfer

Aid handle is pointing upwards and that the unit is in the

optimum position to suit the client’s needs.

Bed Frame

(Top down view)

Bed Transfer Aid

gure 2

gure 1

4. Height Adjustment

The height of the handle on the Bed Transfer Aid can be adjusted to suit the client’s requirements. To adjust

the handle simply remove the two grey e-clips from the base of the handle and lift the required height ensuring

that you do not exceed the last pre-punched hole on the base of the frame.

Once the desired height is achieved, re-insert the e-clips into the pre-punched holes, ensuring that both clips

pass completely through the tube frame and out the other side and are in place securely. Check that the unit

is properly adjusted by pulling the handle upwards, if there is no movement, then the height adjustment has

been carried out correctly.

5. Cleaning

The Bed Transfer Aid should be cleaned using a non-abrasive cleaner or mild detergent with a soft cloth only

Abrasive cleaners e.g. AJAX and/ or abrasive cleaning pads will seriously damage the product beyond repair

and should not be used. Always ensure that you wipe dry the equipment after cleaning.

6. Reissue

If you reissue or are about to reissue this product, please thoroughly check all components for their safety.

This includes;

Tightness of all nuts/ bolts/ castors and other screw in/ bolt in/ push in components. Also check all upholstery

for security, splits, exposed staples, etc.

If in any doubt, please do not issue or use, but immediately contact your supplier for service support.

7. Important Information

The Bed Transfer Aid hand grips have been designed to meet the latest MHRA guidelines on entrapment,

however you must ensure that there is no risk to the user or carer during the installation and service use of the

Bed Transfer Aid.

8. Further Information

We have attempted to cover most eventualities in this leaet, however if you have any specic queries, please

contact:

Aidapt Bathrooms Limited

Vulcan House, 5 Vulcan Way

New Addington

Croydon

CR0 9UG

Telephone: +44 (0) 1689 800 820

Facsimile: +44 (0) 1689 800 680

E-mail: [email protected]
