Agilent Technologies 8751A Guía de inicio rápido

8751A-17

SUPERSEDES: None

Continued

DATE: 15 April 1995

8751A Network Analyzer

Serial Numbers: 0000J00000 / 3146J00696

0000A00000/3146A00212

Duplicate Service Notes: None

Modification to fix unexptected spurious problem.

To Be erformed By: Agilent-Qualified Personnel

arts Required:

1 of 3

AUTHOR: MT ENTITY: 3355

PRINTED IN U.S.A.

SERVICE NOTE

ADMINISTRATIVE INFORMATION

MODIFICATION RECOMMENDED

SERVICE NOTE CLASSIFICATION:

ACTION

CATEGORY:

LOCATION

CATEGORY:

CUSTOMER INSTALLABLE

ON-SITE

SERVICE CENTER

RESPONSIBILE UNTIL: 15 Apr l 1995

ADDITIONAL INFORMATION:

IMMEDIATELY

ON SPECIFIED FAILURE

AGREEABLE TIME

AVAILABILITY: PRODUCT’S SUPPORT LIFE

RETURN

SCRAP

SEE TEXT

SERVICE

INVENTORY:

RETURN

SCRAP

SEE TEXT

USED

PARTS:

STANDARDS:

Labor 2.0 hrs

art No. Qty Description

1901-0050 1 Diode

0757-02 0 1 Resistor 1K

069 -3444 1 Resistor 316

9100-354 1 Inductor 470 NH

1 54-1073 1 Transistor

0160-4 32 1 Capacitor 0.01 UF

069 -3441 1 Resistor 215

Page 2 Serv ce Note 8751A-17

Situation:

The 751A may show the unexpected spurious response due to the parasitic oscillation

of the source signal.

Solution:

This is caused by the breakdown of A3Q2 transistor. This symptom can be confirmed

using the following procedures:

1. Set the 751A as follows:

CENTER --> 500 MHz

SPAN --> 0 Hz

2. Connect the Spectrum Analyzer to the 751A’s “RF OUT”, and observe the signal

with 1 MHz frequency span.

3. Connect the Signal Generator to “EXT REF IN” on the rear panel. Set the Signal

Generator to 10 MHz.

4. Change the frequency of Signal Generator from 9.999 MHz to 10.0002 MHz.

Observer the 751A’s ouput signal using the Spectrum Analzyer. If a spurious is

observed, the A3Q2 transistor is broken.

Action:

Modify the A3 board with referring the following procedures:

1. Turn the 751A off. Remove the top cover and the shield plate.

2. Remove the A3 board.

3. Modify the A3 board with referring Figure 1:

a. Replace the A3Q2 transistor (P/N 1 54-1073) with the new one.

b. Replace the R3 resistor. 464 ohm --> 1 kohm (P/N 0757-02 0)

c. Replace the R6 resistor. 464 ohm --> 316 ohm (P/N 069 -3444)

d. Replace the L2 inductor. 6 0 nH --> 470 nH (P/N 9100-354 )

e. Replace the location of C5 (0.01 uF, P/N 0160-4 32) and R19 (215 ohm, P/N

069 -3441).

f. Add the diode (P/N 1901-0050) with referring Figure 1.

4. Perform the following adjustments:

100 MHz VCXO Frequency

Fractional N Osc Spurious

1st IF Offset Osc Frequency

LF power linearity

5. Reinstall the A3 board.

Page 3Serv ce Note 8751A-17
