Agilent Technologies 3200D Manual de usuario

Agilent Technologies

⋠࡬





⋠࡬





Agilent 3200D 

Dissolved Oxygen Meter

溶解氧测定仪

Operating Guide

用户手册

3200D Dissolved Oxygen Meter Operating Guide

Notices

No part of this manual may be reproduced in

any form or by any means (including elec-

tronic storage and retrieval or translation

into a foreign language) without prior agree-

ment and written consent from Agilent

Technologies, Inc. as governed by United

States and international copyright laws.

Manual Part Number

5973-1779

Edition

First edition, March 2012

Printed in China

Agilent Technologies, Inc.

412 Ying Lun Road

Waigaoqiao Free Trade Zone 

Shanghai 200131 P.R.China

Warranty

The material contained in this docu-

ment is provided “as is,” and is sub-

ject to being changed, without notice,

in future editions. Further, to the max-

imum extent permitted by applicable

law, Agilent disclaims all warranties,

either express or implied, with regard

to this manual and any information

contained herein, including but not

limited to the implied warranties of

merchantability and fitness for a par-

ticular purpose. Agilent shall not be

liable for errors or for incidental or

consequential damages in connec-

tion with the furnishing, use, or per-

formance of this document or of any

information contained herein. Should

Agilent and the user have a separate

written agreement with warranty

terms covering the material in this

document that conflict with these

terms, the warranty terms in the sep-

arate agreement shall control.

Safety Notices

CAUTION

A CAUTION notice denotes a 

hazard. It calls attention to an oper-

ating procedure, practice, or the

like that, if not correctly performed

or adhered to, could result in 

damage to the product or loss of

important data. Do not proceed

beyond a CAUTION notice until the

indicated conditions are fully

understood and met.

WARNING

A WARNING notice denotes a

hazard. It calls attention to an

operating procedure, practice, or

the like that, if not correctly per-

formed or adhered to, could result

in personal injury or death. Do not

proceed beyond a WARNING

notice until the indicated condi-

tions are fully understood and

met.

3200D Dissolved Oxygen Meter Operating Guide 3

Contents

1 Installation 7

Tools and Components for Installation 8

Installing the 3200D Dissolved Oxygen Meter 9

Installing the electrode holder 9

Installing the probe 12

Installing the power adaptor 12

Installing the optional ground line 13

Installing Optional Software 14

2 Operation 15

Introduction 16

Where to find information 16

Term definitions 16

Proper use 17

Features 18

Specifications 19

Physical overview 20

Instrument Control 23

Turn on the Meter 25

Setup 26

Measuring Mode 26

Set Condition 30

System Setup 31

Language select 34

To set the air pressure (barometric pressure) 34

To set the salinity value (SALI Value) 35

4 3200D Dissolved Oxygen Meter Operating Guide

Contents

Auto power off 35

Set Default 36

Prepare the DO Probe 37

To use the DO probe 37

Calibrate the DO Probe 39

Zero oxygen calibration (Calib Zero) 39

Full scale calibration (Calib Full) 40

Perform another calibration 40

Perform a Measurement 41

To measure DO 41

To measure saturation 42

To measure temperature 42

To view other parameters while measuring 42

Managing Data 44

To save data 44

To delete data 44

To output data 44

To view data 45

Turn off the 3200D Dissolved Oxygen Meter 50

Software Operation 51

To use the optional G4390A Electrochemical Data Collecting

software 51

To use the Data Printing software 51

3 Troubleshooting and Maintenance 53

Troubleshooting the 3200D Dissolved Oxygen Meter 54

General Troubleshooting Procedure 56

Check the current response 56

Check the DO probe 56

Check the temperature measurement 57

Contents

3200D Dissolved Oxygen Meter Operating Guide 5

Check other possible causes 57

Meter Self-Diagnostics and Messages 58

Severe errors 58

Error warning 59

Maintenance 61

Probe maintenance 61

Short term storage 61

Long term storage 61

Consumables and Ordering Information 62

6 3200D Dissolved Oxygen Meter Operating Guide

Contents

Agilent Technologies

Agilent 3200D Dissolved Oxygen Meter

Operating Guide

Installation

Tools and Components for Installation 8

Installing the 3200D Dissolved Oxygen Meter 9

Installing Optional Software 14

The tools and accessories necessary for installation are shipped

with the 3200D Dissolved Oxygen Meter.

8 3200D Dissolved Oxygen Meter Operating Guide

1 Installation



Tools and Components for Installation

Agilent provides the tools needed for installation. The following

accessories are included in the shipping case.

•Multifunction electrode holder (G4389A)

•D6111 DO Probe (5190-3997)

•Power adaptor (5185-8389)

Installation 1

3200D Dissolved Oxygen Meter Operating Guide 9

Installing the 3200D Dissolved Oxygen Meter

Open the 3200D Dissolved Oxygen Meter shipping case. Remove

the meter, electrode holder, and other accessories.

Installing the electrode holder

1Place the electrode holder near the meter and move the arm

into position. Use the thumbscrews shown in Figure 1 to

secure the arm in place.

2Clip the DO (dissolved oxygen) probe into the electrode

fixture shown in Figure 1.

Figure 1 The electrode holder

Electrode fixture

Thumbscrew

Cable tabs

Thumbscrew

Base

Setscrew

NOTE

The DO probe includes an ATC probe.

10 3200D Dissolved Oxygen Meter Operating Guide

1 Installation



3Route the probe cable as shown Figure 2.

Figure 2 Installed meter and probes

Probes

Meter

Probe socket
