Agilent ESA-E Series

Spectrum Analyzer

Conﬁguration Guide

This ESA configuration guide will help you determine

which performance options, measurement personali-

ties, accessories, and services to include in your new

ESA-E, or to add as upgrades to an existing ESA-E.

Options for the new EXA signal analyzer are shown

alongside the ESA to help cutomers who wish to

migrate to the latest technology. Customers looking

for increased speed, more application options, or

modern connectivity will benefit by moving to the

new EXA signal analyzer.

Tested. Trusted. Reliable.

Agilent ESA-E Spectrum Analyzer

This step-by-step guide will help you conﬁgure your ESA-E.

Capabilities that are listed as standard come with the

instrument at no additional charge. Tailor the performance,

exterior, and service packages to meet your requirements.

The ESA-E spectrum analyzer is available in three express

conﬁgurations: standard (STD/STG) or communications

test (COM). The express analyzers offer faster delivery by

limiting the number of options that can be ordered together.

The custom conﬁguration allows for maximum ﬂexibility

in ordering the analyzer that best meets your needs by

offering all of the ESA-E options; however, it increases the

delivery timeframe.

For detailed speciﬁcations, refer to the ESA-E Spectrum

Analyzer speciﬁcation guide (E4401-90490). For a summary

of speciﬁcations, refer to the ESA-E data sheet, literature

number 5989-9815EN.

Table of contents:

ESA-E Custom Conﬁguration ...........................................................3

ESA-E Standard Express Spectrum Analyzer (STD/STG) .......6

ESA-E Communications Test Express Spectrum Analyzer

(COM)............................................................................................8

Express Analyzer and Bundle Equivalent Options .....................9

ESA-E Accessory, Calibration, and Warranty Options............10

ESA-E Upgrade Options....................................................................11

Related Literature...............................................................................12

ESA-E Custom Conﬁguration

Step 1. Select your frequency range

Description ESA-E model number1EXA option number

Frequency range, 9 kHz to 3.0 GHz E4402B N9010A-503

EXA Option 503 maximum frequency range is 3.6 GHz

Frequency range, 9 kHz to 6.7 GHz E4404B N9010A-507

EXA Option 507 maximum frequency range is 7.0 GHz

Frequency range, 9 kHz to 13.2 GHz E4405B N9010A-513

EXA Option 513 maximum frequency range is 13.6 GHz

Frequency range, 9 kHz to 26.5 GHz E4407B N9010A-526

Step 2. Included options at no additional charge

Description ESA-E spectrum analyzer EXA signal analyzer

GPIB connection Option A4H2Standard on all EXA signal analyzers; in addition, the EXA offers

seven USB ports and LAN connectivity as standard.

IntuiLink PC connectivity software Connects to Microsoft®Word and Excel The PC-based EXA requires no additional software to connect

to Microsoft applications

Step 3. Choose frequency reference

Description ESA-E spectrum analyzer EXA signal analyzer

Frequency reference (standard aging rate) ±2 x 10–6 / year ±1 x 10–6 / year

High-stability frequency reference

(reduces frequency drift resulting in more accurate

measurements; recommended option)

Option 1D5

Aging rate: ±1 x 10–7 / year

N9010A-PFR

Aging rate: ±1 x 10–7 / year

Step 4. Choose an attenuator

Description ESA-E spectrum analyzer EXA signal analyzer

Mechanical attenuator (standard) 5 dB steps, 0 to 60 dB 10 dB steps, 0 to 60 dB

Fine-step mechanical attenuator Not available N9010A-FSA

Allows 2 dB steps for the full 60 dB range of the mechanical

attenuator

Electronic attenuator up to 3.6 GHz Not available N9010A-EA3

Add to the mechanical attenuator; 1 dB steps, 0 to 24 dB

Step 5. Add a preamplifier

Description ESA-E spectrum analyzer EXA signal analyzer

Preamplifier Option 1DS

1 MHz to 3 GHz

N9010A-P03

100 kHz to 3.6 GHz

1. The E4402B has six available expansion slots for additional hardware options: the E4404/05/07B has five available expansion slots

2. Requires one expansion slot

ESA-E Custom Conﬁguration – continued

Step 6. Add extra options1

Description ESA-E spectrum analyzer EXA signal analyzer

Narrow resolution bandwidths

(recommended option)

Option 1DR Standard

Low-emissions shielding Option 0602Not available

Wide-offset phase noise improvement and

ACPR dynamic range extension

Option 1203Similar performance standard

Replace GPIB with serial port Option 1AX3,4 Serial port unavailable; USB is standard

Time-gated spectrum analysis Options 1D6 Standard

50 Ω tracking generator Option 1DN, 9 kHz to 3 GHz Not available

Fast time domain sweep; IF, sweep,

and video output ports

Option AYX3Fast time domain sweep is standard

External mixing Option AYZ5Not available

Digital demodulation hardware Option B7D/B7E6Standard

APC 3.5 mm input connector Option BAB5Not available

Low frequency extension to 100 Hz Option UKB7Not available

EMI detectors and FM Demodulation Option AYQ3,7 Most EMC adds quasi-peak deletion and basic FM

demodulation

1. If two or more ESA-E options are ordered, memory size may limit the number of options that may be loaded at any one time;

for detailed information about memory size limitations, please see the Web site: http://sa.tm.agilent.com/ESA/memory

2. Not compatible with Option B7B

3. Requires one expansion slot

4. Not compatible with Option A4H

5. E4407B only

6. Requires Option 1D5; occupies two expansion slots, must be ordered jointly

7. Requires Option 1DR

ESA-E Custom Conﬁguration – continued

Step 7. Choose measurement software

Description ESA-E spectrum analyzer EXA signal analyzer

AM demodulation Standard N9063A

FM demodulation/ deviation Option BAA1,2 N9063A

Phase noise measurement Option 2263N9068A

Noise ﬁgure measurement Option 2194,2 N9069A

GSM/GPRS measurement Option BAH5,6 N9071A

Edge upgrade to option BAH Option 2527N9071A

Cable fault location measurement Option 2258Not available

TV trigger on screen measurement Option B7B9Not available

Cable TV ﬁeld service and analog broadcast

measurement

Option 227 Not available

Modulation analysis measurement Option 22910 89601X

Benchlink Web remote software Option 23011 Remote desktop comes standard with the PC-based EXA

ESA to 89601A VSA software link Option 23112 Standard

89601A vector signal analysis (VSA) software 89601A – runs on external PC 89601A – runs internal to the instrument

8566/68 programming code compatibility Option 26613 Not available

8590 series programming code compatibility Option 29013 Not available

856xE/EC programming code compatibility Not available N9061A

Bluetooth®measurement analyzer bundle Option 30414 Not available

cdmaOne measurement Option BAC15 Not available

cdma2000 measurement Not available N9072A

W-CDMA measurement Not available N9073A-1FP

HSDPA / HSUPA measurement Not available N9073A-2FP

802.16 OFDMA measurement Not available N9075A

TD-SCDMA measurement Not available N9079A-1FP

HSDPA/8PSK measurement Not available N9079A-2FP

Step 8. Add special options

Description ESA-E spectrum analyzer EXA signal analyzer

26.5 GHz uncalibrated built in preampliﬁer Option H2618 Not available

70 MHz IF output Options H702,16 Not available

FM deviation personality enhancement Option J3617 Not available

1. Not compatible with Option 304 or 106

2. Occupies one expansion slot

3. If two or more ESA-E options are ordered, memory size may limit the number of options that may be loaded at any one time;

for detailed information about memory size limitations, please see the Web site: http://sa.tm.agilent.com/ESA/memory

4. See ESA Noise Figure Measurement Personality Technical Overview, literature number 5989-0215EN, for recommended options

5. Requires Option B7D/B7E

6. Requires Option 1D5 and 1D6; includes capability of Option 225

7. Requires Option BAH

8. Requires Option 1DN; not compatible with Option BAH; recommended accessory Option B7K

9. Requires BAA; not compatible with Option 060

10. Requires Options B7D/B7E, A4H, and 1D5; includes capability of Option 231

11. Requires Option A4H

12. Requires Options B7D/B7E, A4H, and 1D5

13. Free download on the Web, no license required: http://www.agilent.com/find/esa

14. Includes Options 228, 106, B7D/B7E, 1DS, and 1D5; occupies three expansion slots

15. Requires Options B7D/B7E and 1D5

16. Recommended for use with 89601A VSA software

17. Requires Option BAA

18. Available at time of purchase only. Not upgradable.

ESA-E Standard Express Spectrum Analyzer (STD/STG)

The ESA-E express analyzers offer conﬁgurations that are

typically ordered together to help speed instrument delivery.

The EXA signal analyzer is not offered in an express

conﬁguration, however, the newer technology allows for

faster delivery times, regardless of the conﬁguration. If you

wish to order an EXA conﬁguration equivalent to the ESA-E

express analyzer, please select the individual EXA options

shown in the table below.

Step 1. Select your frequency range

Description ESA-E model number1EXA option number

Frequency range, 9 kHz to 3.0 GHz E4402B

E4402B-STD or

E4402B-STG (adds tracking generator)

N9010A-503

EXA Option 503 maximum frequency is 3.6 GHz

Frequency range, 9 kHz to 6.7 GHz E4404B

E4404B-STD or

E4404B-STG (adds tracking generator)

N9010A-507

EXA Option 507 maximum frequency range is 7.0 GHz

Frequency range, 9 kHz to 13.2 GHz E4405B

E4405B-STD or

E4405B-STG (adds tracking generator)

N9010A-513

EXA Option 513 maximum frequency range is 13.6 GHz

Frequency range, 9 kHz to 26.5 GHz E4407B

E4407B-STD or

E4407B-STG (adds tracking generator)

N9010A-526

Step 2. Included ESA-E options at no additional charge

Description ESA-E spectrum analyzer EXA signal analyzer

GPIB connection Option A4H2Standard on all EXA signal analyzers; in addition, the EXA

offers seven USB ports and LAN connectivity standard

FM demodulation/deviation Option BAA2,3 N9063A

Fast time domain sweep; IF, sweep, and video

output ports

Option AYX2Fast time domain sweep is standard

IntuiLink PC connectivity software Connects to Microsoft®Word and Excel The PC-based EXA requires no additional software to connect

to Microsoft applications

Step 3. Choose frequency reference

Description ESA-E spectrum analyzer EXA signal analyzer

Frequency reference (standard aging rate) ±2 x 10–6 / year ±1 x 10–6 / year

High-stability frequency reference

(reduces frequency drift resulting in more accurate

measurements; recommended option)

Option 1D5

Aging rate: ±1 x 10–7 / year

N9010A-PFR

Aging rate: ±1 x 10–7 / year

1. The E4402B has three expansion slots for additional options; the E4404/5/7B have two expansion slots

2. Requires one expansion slot

3. Not compatible with Options 304 or 106

ESA-E Standard Express Spectrum Analyzer (STD/STG) – continued

Step 4. Add a preamplifier (preamplifiers are not standard)

Description ESA-E spectrum analyzer EXA signal analyzer

Preamplifier Option 1DS

1 MHz to 3 GHz

N9010A-P03

100 kHz to 3.6 GHz

Step 5. Add extra options1

Description ESA-E spectrum analyzer EXA signal analyzer

Narrow resolution bandwidths

(recommended option)

Option 1DR Standard

Time-gated spectrum analysis Options 1D6 Standard

Performance bundle Option B752For equivalency, order N9010A-PFR

Replace GPIB with serial port Option 1AX3,4 Serial port unavailable; USB comes standard

50 Ω tracking generator Option 1DN, 9 kHz to 3 GHz Not available

Step 6. Choose measurement software

Description ESA-E spectrum analyzer EXA signal analyzer

Phase noise measurement Option 2261N9068A

Noise ﬁgure measurement Option 2195,6 N9069A

Cable fault location measurement Option 2257Not available

Cable TV ﬁeld service and analog broadcast

measurement

Option 227 Not available

Benchlink Web remote software Option 2308Remote desktop come standard with the PC-based EXA

89601A vector signal analysis (VSA) software 89601A – runs on external PC 89601A – runs internal to the instrument

8566/68 programming code compatibility Option 2669Not available

8590 Series programming code compatibility Option 2909Not available

856xE/EC programming code compatibility Not available N9061A

Future upgrades for the ESA-E standard express spectrum analyzer (STD/SG)

Available future expansion slots

E4402B – Three additional expansion slots

E4404/5/7B – Two additional expansion slots

1. If more than two ESA-E options are ordered, memory size may limit the number of options that can be loaded at any one time; for detailed

information about memory size limitations, please see the Web site: http://sa.tm.agilent.com/ESA/memory

2. Includes Options 1D5, 1DR and 1DS

3. Requires one expansion slot

4. Not compatible with Option A4H

5. See ESA Noise Figure Measurement Personality Technical Overview, literature number 5989-0215EN, for recommended options

6. Requires one expansion slot

7. Requires Option 1DN; not compatible with Option BAH; recommended accessory Option B7K

8. Requires Option A4H

9. Free download on the Web, no license required: http://www.agilent.com/find/esa

ESA-E Communications Test Express Spectrum Analyzer (COM)

Step 1. Select your frequency range

Description ESA-E model number1EXA option number

Frequency range, 9 kHz to 3.0 GHz E4402B

E4402B-COM

N9010A-503

EXA Option 503 maximum frequency is 3.6 GHz

Frequency range, 9 kHz to 6.7 GHz E4404B

E4404B-COM

N9010A-507

EXA Option 507 maximum frequency range is 7.0 GHz

Frequency range, 9 kHz to 13.2 GHz E4405B

E4405B-COM

N9010A-513

EXA Option 513 maximum frequency range is 13.6 GHz

Frequency range, 9 kHz to 26.5 GHz E4407B

E4407B-COM

N9010A-526

Step 2. Included ESA-E options at no additional charge

Description ESA-E spectrum analyzer EXA signal analyzer

GPIB connection Option A4H2Standard on all EXA signal analyzers; in addition, the EXA

offers seven USB ports and LAN connectivity standard

High-stability frequency reference

(reduces frequency drift resulting in more accurate

measurements; recommended option)

Option 1D5

Aging rate: ±1 x 10–7 / year

N9010A-PFR

Aging rate: ±1 x 10–7 / year

Narrow resolution bandwidths

(recommended option)

Option 1DR Standard

ESA to 89601A VSA

software link

Option 2313, 6 Standard

FM demodulation/

deviation

Option BAA2,3,4 N9063A

Digital demodulation hardware Option B7D/B7E5Standard

IntuiLink PC connectivity software Connects to Microsoft®Word and Excel The PC-based EXA requires no additional software to connect

to Microsoft applications

Step 3. Add a preamplifier (preamplifiers are not standard)

Description ESA-E spectrum analyzer EXA signal analyzer

Preamplifier Option 1DS

1 MHz to 3 GHz

N9010A-P03

100 kHz to 3.6 GHz

Step 4. Add additional options

Description ESA-E spectrum analyzer EXA signal analyzer

Replace GPIB with serial port Option 1AX2,7 Serial port unavailable; USB is standard

Time-gated spectrum analysis Options 1D6 Standard

1. The E4402B has two expansion slots for additional hardware options; the E4404/05/07B has one expansion slot

2. Requires one expansion slot

3. Requires Options B7D/B7E, A4H, and 1D5

4. Not compatible with Option 304 or 106

5. Occupies two expansion slots

6. If more than two or three ESA-E options are ordered, memory size may limit the number of options that can be loaded at any one time;

for detailed information about memory size limitations, please see the Web site: http://sa.tm.agilent.com/ESA/memory

7. Not compatible with Option A4H

ESA-E Communications Test Express Spectrum Analyzer (COM) – continued

Step 5. Choose measurement software1

Description ESA-E spectrum analyzer EXA signal analyzer

Phase noise measurement Option 226 N9068A

Noise ﬁgure measurement Option 2192N9069A

GSM/GPRS measurement Option BAH3,4 N9071A

EDGE upgrade to Option BAH Option 2525N9071A

Cable TV ﬁeld service and analog broadcast

measurement

Option 227 Not available

Modulation analysis measurement Option 229689601X

89601A vector signal analysis (VSA) software 89601A – runs on external PC 89601A – runs internal to the instrument

8566/68 programming code compatibility Option 2667Not available

8590 Series programming code compatibility Option 2907Not available

cdmaOne measurement Option BAC8Not available

Future upgrades for the ESA-E standard express spectrum analyzer (STD/SG)

Available future expansion slots

E4402B – Three additional expansion slots

E4404/5/7B – Two additional expansion slots

1. If more than two or three ESA-E options are ordered, memory size may limit the number of options that can be loaded at any one time;

for detailed information about memory size limitations, please see the Web site: http://sa.tm.agilent.com/ESA/memory

2. See ESA Noise Figure Measurement Personality Technical Overview, literature number 5989-0215EN, for recommended options

3. Requires Option B7D/B7E

4. Requires Options 1D5 and 1D6; includes capability of Option 225

5. Requires Option BAH

6. Requires Options B7D/B7E, A4H, and 1D5; includes capability of Option 231

7. Free download on the Web, no license required: http://www.agilent.com/find/esa

8. Requires Options B7D/B7E and 1D5

Express Analyzer and Bundle Equivalent Options

ESA-E express option or bundle ESA-E equivalent option(s) Additional information

STD- Standard analyzer AYX, BAA

STG- Standard analyzer with tracking generator AYX, BAA, 1DN

COM- Communication test analyzer B7D/B7E, 1D5, 1DR, BAA, 231

B75- Performance bundle 1DR, 1DS, 1D5 Only available with express analyzer STD or STG

304- Bluetooth®premium bundle 228,106, B7D/B7E, 1DS, 1D5 Options 106 and 228 are not available outside the

option bundle 304

The table below shows equivalent options in each bundle

offered for ESA-E spectrum analyzers.

ESA-E Accessory, Calibration, and Warranty Options

Step 6. Select accessories and calibration options

Description ESA-E spectrum

analyzer option

ESA-E notes ESA-E part number EXA signal analyzer option

12 VDC power cable A5D DC power connection

available on every ESA

E4401-60066 Not available

Hard transit case AXT E4401-60101 N9010A-HTC

Gray soft carrying/operation case AYT E4401-60117 Not available

Yellow soft carrying/operation case AYU E4401-60118 Not available

Cable fault measurement kit

(50 Ω)

B7K Requires Option 1DN or STG

and Option 225 or BAH

Not available

Gray backpack carrying case 042 9300-2465 Not available

Yellow backpack carrying case 044 9300-2470 Not available

Rack mount kit with handles 1CP This kit is designed to ﬁt into Agilent

racks only; for non-Agilent racks,

additional end brackets are required

and are available by ordering part

number 1494-0061

E4401-60057 N9010A-1CP

50 to 75 Ω minimum loss pad 1D7 0955-1020 N9010A-MLP

Rechargeable snap-on battery

and charger

E1779B Order as separate model

number, not option number

Not available

Front panel cover UK9 E4401-60193 Standard

Benchlink spectrum analyzer,

PC software

B70 Also orderable as E4444A;

requires Option A4H or 1AX

Remote desktop is a standard

feature on EXA

Benchlink Web remote

control software

230 Requires Option A4H Remote desktop is a standard

feature on EXA

IntuiLink software (shipped

with every instrument)

*** Available on Web site for download Remote desktop is a standard

feature on EXA

Harmonic mixer series (26.5, 40, 50,

60, 75, 110 GHz)

11970 For use in E4407B Option AYZ

Preselected millimeter mixer series

(40, 50, 60, 75 GHz)

11974 For use in E4407B Option AYZ

Low noise ampliﬁer to 1 GHz 11909A

Firmware upgrade UE2 Firmware updates also available

on Web site for free download

(http://www.agilent.com/find/

esa_firmware/)

See

(http://www.agilent.com/

find/exa)

Add extra manual set OB1 Available for Web download Available for Web download

Commercial calibration certiﬁcate

with test data

UK6 N9010A-UK6

Delete manual set

(retains CD-ROM version)

OBO

Service documentation,

component level CLIP

OBV Component level information

package

Service documentation,

assembly level

OBW Performance veriﬁcation and

adjustment software included N9010-90002

For more information visit www.agilent.com/find/accessories

Step 7. Choose warranty length

Description ESA-E spectrum analyzer EXA signal analyzer

1-year return-to-Agilent

warranty and service

Standard (R-51B-001-C) Standard (R-51B-001-C)

3-year return-to-Agilent

warranty and service

R-51B-001-3C

Default conﬁguration option

Recommended upgrade

Otros manuales para ESA-E E4402B

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Instrumento de medición de Agilent Technologies

Agilent Technologies

Agilent Technologies 8564EC Manual de usuario

Agilent Technologies

Agilent Technologies U5303A Guía del usuario

Agilent Technologies

Agilent Technologies 4291B Manual de usuario

Agilent Technologies

Agilent Technologies N1913a Manual de usuario

Agilent Technologies

Agilent Technologies 53147A Manual de usuario

Agilent Technologies

Agilent Technologies 8504B Manual de usuario

Agilent Technologies

Agilent Technologies 77-4 Instrucciones de instalación y funcionamiento

Agilent Technologies

Agilent Technologies U1211A Manual de usuario

Agilent Technologies

Agilent Technologies BioTek Epoch 2 Manual de usuario

Agilent Technologies

Agilent Technologies 85051B Manual

Agilent Technologies

Agilent Technologies E4443A Guía de inicio rápido

Agilent Technologies

Agilent Technologies E5900B Manual de usuario

Agilent Technologies

Agilent Technologies 10400B Series Manual de usuario

Agilent Technologies

Agilent Technologies E5080 Series Manual de usuario

Agilent Technologies

Agilent Technologies ESA-E Series Manual

Agilent Technologies

Agilent Technologies 1670G Series Manual de usuario

Agilent Technologies

Agilent Technologies ENA Series Manual de usuario

Agilent Technologies

Agilent Technologies U1731A Manual de usuario

Agilent Technologies

Agilent Technologies E8362C Manual de usuario

Agilent Technologies

Agilent Technologies Agilent 4396B Instrucciones de funcionamiento

Agilent Technologies

Agilent Technologies N4962A Manual de usuario

Agilent Technologies

Agilent Technologies 54600-Series Manual de usuario

Agilent Technologies

Agilent Technologies E3238S Instrucciones de funcionamiento y mantenimiento

Agilent Technologies

Agilent Technologies PNA Series Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
