Agilent Technologies

16753/54/55/56A and 16950A

Logic Analyzers

Service Guide

Publication number 16753-97003

December 2005

For Safety and Regulatory information, see the pages at the end of the book.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Agilent 16753/54/55/56A and 16950A Logic Analyzers—At a

Glance

The 16753A, 16754A, 16755A, and 16756A are 600 MHz logic analyzer modules

for the 16700-series or 16900-series logic analysis system.

The 16950A is 600 MHz logic analyzer module for the 16900-series logic analysis

system.

The 16753/54/55/56A and 16950A logic analyzer modules offer high performance

measurement capability.

Features

Some of the main features of the 16753/54/55/56A and 16950A are as follows:

• 64 data channels

• 4 clock/data channels

• 1 M to 64 M memory depth per channel (depends upon model or option chosen)

• 600 MHz maximum state acquisition speed

• 1.2 GHz, 128 M deep timing analysis on half channels

• “Eye scan” feature

• 4 GHz timing zoom with 64 k memory depth

• Expandable to 340 channels

Service Strategy

The service strategy for this instrument is the replacement of defective

assemblies. This service guide contains information for finding a defective

assembly by testing and servicing the 16753/54/55/56A or 16950A state and

timing analyzer module.

The modules can be returned to Agilent Technologies for all service work,

including troubleshooting. Contact your nearest Agilent Technologies Sales

Office for more details.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Application

This service guide applies to 16753/54/55/56A logic analyzer modules installed in

16700-series or 16900-series logic analysis system mainframes or to 16950A logic

analyzer modules in a 16900-series logic analysis system mainframe.

The 16753/54/55/56A or 16950A Logic Analyzer

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

In This Book

This book is the service guide for the 16753/54/55/56A and 16950A 600 MHz logic

analyzer modules.

This service guide has eight chapters.

Chapter 1, “General Information,” beginning on page 9 contains information

about the module, lists accessories for the module, gives specifications and

characteristics of the module, and provides a list of the equipment required for

servicing the module.

Chapter 2, “Preparing for Use,” beginning on page 15 tells how to prepare the

module for use.

Chapter 3, “Testing Logic Analyzer Performance,” beginning on page 19 gives

instructions on how to verify that the module meets its specifications.

Chapter 4, “Calibrating,” beginning on page 87 contains calibration instructions

for the module (if required).

Chapter 5, “Troubleshooting,” beginning on page 89 contains explanations of self-

tests and flowcharts for troubleshooting the module.

Chapter 6, “Replacing Assemblies,” beginning on page 113 explains how to

replace the module and assemblies of the module and how to return them to

Agilent Technologies.

Chapter 7, “Replaceable Parts,” beginning on page 121 lists replaceable parts,

shows an exploded view, and gives ordering information.

Chapter 8, “Theory of Operation,” beginning on page 127 explains how the logic

analyzer module works.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Contents

1General Information
