Advantech IPPC-7158 Series Manual de usuario

IPPC-7158 Series

15" XGA TFT LCD Industrial

Panel PC with 14 x ISA/PCI/

PICMG Slots, Passive Backplane

and Membrane Keypad

User Manual

IPPC-7158 User Manual ii

This document is copyrighted 2008, by Advantech Co. Ltd. All rights are

reserved. Advantech Co., Ltd. reserves the right to alter the products

described in this manual at any time without notice. No part of this man-

ual may be reproduced, copied, translated or transmitted in any form or

by any means without the prior written permission of Advantech. Infor-

mation provided in this manual is intended to be accurate and reliable.

However, Advantech assumes no responsibility for use of this manual,

nor for any infringements upon the rights of third parties which may

result from such use. All brand and product names mentioned herein are

trademarks or registered trademarks of their respective holders.

Acknowledgments

IBM and PC are trademarks of International Business Machines Corpora-

tion.

For more information on this and other Advantech products, please visit

our website at: http://www.advantech.com

For technical support and service, please visit our support website at:

http://www.advantech.com.tw/support/

Part No. 2003715800 1st Edition

Printed in Taiwan October 2008

iii

FCC Class A

Note: This equipment has been tested and found to comply with the limits

for a Class A digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environ-

ment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. Opera-

tion of this equipment in a residential area is likely to cause harmful inter-

ference in which case the user will be required to correct the interference

at his own expense.

Warning! Any changes or modifications made to the

equipment which are not expressly approved by

the relevant standards authority could void your

authority to operate the equipment.

IPPC-7158 User Manual iv

Packing List

Before setting up the system, check that the item is among those listed

below and is in good condition. If your Workstation does not match any

of those below, please contact your dealer immediately.

• CD ROM for IPPC Series

• Registration and 2 year Warranty card

• SATA Cable x 2

• SATA Power Cable x 2

• PATA 40 PIN DMA66 Flat Cable

• FDD cable

• D-Sub Flat Cable with bracket

• FAN power cable

• Simplified Chinese Manual

• China RoHs for IPPC-7000 series

• Jumper Bag(mini jumper*20)

IPPC-7158 Industrial Workstations includes the following models:

IPPC-7158B-X1AE: 15" XGA TFT LCD Passive Backplane Industrial

Panel PC with 14 x ISA/PCI/PICMG Slots and Membrane Keypad

IPPC-7158B-R1AE: 15" XGA TFT LCD Passive Backplane Industrial

Panel PC with 14 x ISA/PCI/PICMG Slots and Membrane Keypad and

resistive touchscreen

Additional Information and Assistance

Step 1. Visit the Advantech web site at www.advantech.com where you

can find the latest information about the product.

Step 2. Contact your distributor, sales representative, or Advantech's cus-

tomer service center for technical support if you need additional

assistance. Please have the following information ready before

you call:

• Product name and serial number

• Description of your peripheral attachments

• Description of your software (operating system, version, application

software, etc.)

• A complete description of the problem

• The exact wording of any error messages

IPPC-7158 User Manual vi

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User's Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp

cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or let-

ting it fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment

from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything

over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power

source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service

personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well, or you cannot get it to work according

to the user's manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE

THE STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR

ABOVE 60° C (140° F). THIS COULD DAMAGE THE EQUIPMENT. THE

EQUIPMENT SHOULD BE IN A CONTROLLED ENVIRONMENT.

16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY

REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT

TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD USED

BATTERIES ACCORDING TO THE MANUFACTURER'S INSTRUC-

TIONS.

The sound pressure level at the operator's position according to IEC 704-1:1982 is

no more than 70 dB (A).

DISCLAIMER: This set of instructions is given according to IEC 704-1. Advan-

tech disclaims all responsibility for the accuracy of any statements contained

herein.

vii

Contents

Chapter 1 General Information ....................................... 2

1.1 Introduction ....................................................................... 2

1.2 Specifications .................................................................... 3

1.2.1 General ........................................................................... 3

1.2.2 System Hardware ........................................................... 3

1.2.3 LCD Display .................................................................. 4

1.2.4 Touchscreen (Optional) ................................................. 4

1.2.5 Environment ................................................................... 4

1.3 Dimensions........................................................................ 5

Chapter 2 System Setup.................................................... 8

2.1 A Quick Tour of IPPC-7158 ............................................. 8

Figure 2.1:Open View .................................................... 9

Figure 2.2:Side View ..................................................... 9

2.1.1 USB Ports .................................................................... 10

Figure 2.3:Opening the Front USB Port Cover ........... 10

2.1.2 Adjusting the LCD Brightness ..................................... 10

2.2 Installing Optional Disk Drives....................................... 12

2.3 Rack Mounting................................................................ 12

Chapter 3 Touchscreen ................................................... 14

3.1 Introduction ..................................................................... 14

3.2 Touchscreen Driver Installation & Configuration .......... 14

Appendix A LCD Specifications........................................ 16

A.1 IPPC-7158 LCD Specifications ...................................... 16

Appendix B Pin Assignments ............................................ 18

B.1 Connector Pin Definitions............................................... 19

B.2 PCI Routing Table........................................................... 22

Appendix C Keyboard Translator .................................... 24

C.1 Overview ......................................................................... 24

C.2 Programming the Front Panel Macro Keys..................... 25

IPPC-7158 User Manual viii

CHAPTER

General Information

This chapter gives background

information on the IPPC-7158 series

Sections include:

• Introduction

• Specifications

• Dimensions

IPPC-7158 User Manual 2

Chapter 1 General Information

1.1 Introduction

The IPPC-7158 features a 15" TFT LCD and 14 expansion slots for PCI,

PICMG and ISAand an ATX industrial backplane to support CPU cards.

The IPPC-7158 also provides many powerful features such as detahable

front panel, front-accessible USB port, 53 membrane key & touch pad

with two mouse buttons, 6 OSD control keys, NEMA4/IP65 compliant

front panel, and optional analog resistive touchscreen (USB Interface).

Modularized Side-Open Front Panel Makes Maintenance Easy

The IPPC-7158 makes user can maintain the system fast and easily. First,

if there are problems with the LCD display, the detachable front panel

allows you to replace or service it simply and quickly. This helps saves

downtime costs associated with system crashes. Secondly, the side-open

LCD front panel also make it more convenient when you want to main-

tain the CPU, I/O cards, HDD, CD-ROM and even floppy.

Industrial Design Withstands Harsh Environments

In addition, the IPPC-7158 also features many powerful functions tomeet

the industrial-grade requirements. The front panel is made of Aluminum

and being chemical treated by anode. That prevents the panelfrom dam-

aging by acid and salt. Besides, it's waterproof and IP65/NEMA4 compli-

ant. The IPPC-7158 also offers the stainless steel chassis. It also protects

the chassis. For keeping the system working properly, the IPPC-7158 pro-

vides a fan & filter to avoid overheating & dust. In addition, the IPPC-

7158 also provides three mounting ways to fit different application: 19"

rack, panel or wall mounting.
