Advantech POC-128 Manual de instrucciones

T he drawings and specifications in this document are property of Advantech and may not be reproduced, copied or used without prior written permission.

Page 1 of 2

POC-128 Quick Start Manual

POC-128 Appearance

Packing List

(1) 1 x POC-W128

(2) 1 x Accessorybox

1 x Quick Start manual

1 x Protek PMP105-13-1-HI (18Vdc/5.84A)adapter

1 x Drivers & manual CD

1 x Tool bag x1: 8 x sparescrews

1 x PE foamfor adapter fix

(1) Function Keys

(2) I/O Ports

(1) Ethernet (network) portslabeledTCP/IP (LAN1)

(2) USB1-USB5 ports*(USB2.0X3, USB3.0 X2)

(3) Line-out,Microphone-in.

(4) HDMI port

(5) COM serialport

(6) VGA port

Front-view

* Please useVESAcompatible mounting only.

VESA Mounting

Rear-view

Front Bezel Screen

(1)

(2)

(4)

(5)

(6)

(3)

I/O Ports

T he drawings and specifications in this document are property of Advantech and may not be reproduced, copied or used without prior written permission.

Page 2 of 2

POC-128 IPX1 Version Quick Start Manual

(3) Easy Setup

Power On Computer:

Make sure Equipotential Terminal is connectedtoequipotential

groundin the hospital.

Connect the adapter to Pow er DC-IN.

NOTE:Usingdifferentadaptors mayput the system atrisk.

PressingPow er On/ Off - buttonw illturngreen.

Driver Installation:

Advantechsupports“one key” driver installation. User cansimply

double click an iconto install all the drivers.

1) Make sure the OS has been successfully installed.If you

havedifficultyinstallingan OS, please follow theinstructions

in the POC-W128 User Manual.

2) Dow nload the “one key” package from the Advantech Support

website:

http://support.advantech.com/support/new_default.aspx.

Open the folderanddouble click “InstallAll.exe.”

3) Follow the instructions showninthedialog to finishthe

installation.

* Please use a clean OS to install this auto installation; otherw ise,

unexpectederrors may occur.

* Should you only want to install specific drivers, pleasefollow the

instructions inthe POC-W152 User Manual.

Notice:

PCIe connectionrequires matchingof specification.Not

every PCIe card assures compatibility.Contact Advantech

regional servicecenter before use.

(3) Cleaning and Disinfecting

During normal use,a POC (Point-of-Care) terminal may become

dirty and shouldbe cleanedregularly.

1) Prepare a cleaning agent per manufacturer’s instruction or

hospital protocol.

2) Prepare a clean cloth that has been moistened in a cleaning

solution.

3) Wipe the POC thoroughly witha cleanw ipe.

Applicable Cleaning AgentsList

Cleaning Agents

Cidex

Virkonand water

(1:100)

Isopropylalcohol

DISPATCH

Green tinctured

soap

SDW 70C

Windex

Trigene

Alcohol

ANTIGONE WIPES

Alcohol70%

SporeClear

Incidin plus

AntiGone

Incidin liquid

MikroBac

Mikrozid liquid

Chloride 1000ppm

* Do not immerse or rinse a POC terminal or its peripherals.

* Do not spray cleaning agents onthe chassis

* Do not usedisinfectants containingphenol
