Advantech SmartMotion ST355 Manual de usuario

Twin Cellular Module Router

SmartMotion ST355

USER’S MANUAL

HEADQUARTERS

International Headquarters

Advantech B+B SmartWorx

707 Dayton Road

Ottawa, IL 61350 USA

Phone (815) 433-5100 – General Fax (815) 433-5105

Websites

www.bb-smartworx.com

www.bb-smartsensing.com

suppor[email protected]

Cellular Routers Ofﬁce

Advantech B+B SmartWorx s.r.o.

Sokolska 71

562 04, Usti nad Orlici III,

Czech Republic

Phone +420 465 521 020

Websites

www.bb-smartcellular.eu

cellularsupport@advantech-bb.com

2016 Advantech B+B SmartWorx s.r.o.. No part of this publication may be reproduced or transmitted in any

form or by any means, electronic or mechanical, including photography, recording, or any information storage and

retrieval system without written consent. Information in this manual is subject to change without notice, and does

not represent a commitment on the part of Advantech B+B SmartWorx.

Advantech B+B SmartWorx s.r.o. shall not be liable for incidental or consequential damages resulting from

the furnishing, performance, or use of this manual.

All brand names used in this manual are the registered trademarks of their respective owners. The use of

trademarks or other designations in this publication is for reference purposes only and does not constitute an

endorsement by the trademark holder.

USED SYMBOLS

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

GPL licence

Source codes under GPL licence are available free of charge by sending an email to:

cellularsales@advantech-bb.com.

Advantech B+B SmartWorx s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Manual Rev. 1 released in CZ, April 15, 2016

CONTENTS

Contents

1 Safety Instruction 2

2 WEEE directive 3

3 Router Description 4

3.1 Usage of the Router ................................. 5

4 Contents of Package 8

5 Router Design 9

5.1 Router versions .................................... 9

5.2 Delivery identiﬁcation ................................ 9

5.3 Order codes ...................................... 10

5.4 Basic dimensions of the router box ......................... 12

5.5 Mounting recommendations ............................. 12

5.6 Removing from the DIN rail ............................. 13

5.7 Description of the rear panel ............................. 14

5.8 Description of the front panel ............................ 14

5.8.1 Status indication ............................... 15

5.8.2 Power connector PWR ............................ 16

5.8.3 Antenna connector ANT, DIV, GPS and WiFi ............... 17

5.8.4 SIM card reader ............................... 18

5.8.5 MicroSD card reader ............................. 18

5.8.6 Ethernet Ports (ETH0 and ETH1) ...................... 19

5.8.7 Power over Ethernet (PoE) ......................... 20

5.8.8 USB Port ................................... 22

5.8.9 I/O Port .................................... 22

5.8.10 Reset ..................................... 24

6 First Use 25

6.1 Connecting the router before ﬁrst use ....................... 25

6.2 Start .......................................... 26

6.3 Conﬁguration ..................................... 26

6.3.1 Conﬁguration over web browser ....................... 26

7 Technical Parameters 28

7.1 Basic parameters ................................... 28

7.2 Standards and regulations .............................. 29

CONTENTS

7.3 Type tests and environmental conditions ...................... 30

7.4 Technical parameters of cellular modules ..................... 31

7.4.1 Technical parameters of the ﬁrst cellular module ............. 31

7.4.2 Technical parameters of the second cellular module ........... 32

7.5 Technical parameters of GPS ............................ 33

7.6 Technical parameters of WiFi ............................ 33

7.7 Technical parameters of I/O port .......................... 34

7.8 Technical Parameters of Power over Ethernet (PoE) ............... 34

7.9 Other Technical Parameters ............................. 35

8 Recommended Literature 36

9 Troubleshooting 37

9.1 FAQ .......................................... 37

10 Customers Support 39

10.1 Global Customer Support .............................. 39

10.2 Customer Support for NAM ............................. 39

iii

LIST OF FIGURES

List of Figures

1 Access to the Internet from LAN .......................... 5

2 Backed up access to the Internet .......................... 6

3 Using VPN tunnel .................................. 6

4 Serial Gateway .................................... 7

5 Contents of package ................................. 8

6 Basic version ..................................... 9

7 Version with WiFi module .............................. 9

8 Label examples .................................... 9

9 Basic dimensions of the router box ......................... 12

10 Default position of DIN holder ............................ 13

11 Removing from the DIN rail ............................. 13

12 SmartMotion front panel ............................... 14

13 Power connector ................................... 16

14 Connection of power supply ............................. 16

15 Connecting of the antenna .............................. 17

16 SIM cards ....................................... 18

17 MicroSD card ..................................... 19

18 Ethernet connector .................................. 19

19 Connection of ethernet cable ............................ 20

20 PoE PD usage .................................... 20

21 PoE PSE usage ................................... 21

22 USB connector .................................... 22

23 I/O connector ..................................... 22

24 Binary inputs connection ............................... 23

25 Binary output connection .............................. 23

26 Router reset ...................................... 24

27 Router connection .................................. 25

28 Entering the IP address of the router ........................ 26

29 Entering login information .............................. 26

30 Router web interface ................................. 27

LIST OF TABLES

List of Tables

1 Router versions .................................... 9

2 Delivery identiﬁcation ................................ 9

3 Order codes overview ................................ 10

4 Power over Ethernet ................................. 10

5 Type of router box .................................. 10

6 Type of power supply ................................. 10

7 Examples of order code ............................... 11

8 Front panel description ................................ 14

9 Status indication ................................... 15

10 Connection of power connector ........................... 16

11 Technical speciﬁcations of microSD card ...................... 18

12 Connection of Ethernet connector .......................... 19

13 Insulation strength of Ethernet ports ........................ 20

14 Connection of USB connector ............................ 22

15 Connection of I/O port ................................ 22

16 Characteristics of inputs ............................... 23

17 Description of reset and restart router ....................... 24

18 Basic parameters ................................... 28

19 Standards and regulations .............................. 29

20 Type tests and environmental conditions ...................... 30

21 Technical parameters of the ﬁrst cellular module ................. 31

22 Technical parameters of the second cellular module ............... 32

23 Technical parameters of GPS ............................ 33

24 Technical parameters of WiFi ............................ 33

25 Characteristics of inputs ............................... 34

26 PoE PD: parameters for opposite PSE ....................... 34

27 PoE PSE parameters ................................ 34

28 Other technical parameters ............................. 35

1. SAFETY INSTRUCTION

1. Safety Instruction

Please, observe the following instructions:

•The router must be used in compliance with all applicable international and national laws

and in compliance with any special restrictions regulating the utilization of the router in

prescribed applications and environments.

•To prevent possible injury and damage to appliances and to ensure compliance with

all relevant provisions, use only the original accessories. Unauthorized modiﬁcations or

the use of unapproved accessories may result in damage to the router and a breach of

applicable regulations. Unauthorized modiﬁcations or use of unapproved accessories

may void the warranty.

•The router can not be opened.

•Turn off the router and disconnect it from power supply before handling of the SIM card.

•Caution! The SIM card could be swallowed by small children.

•Power supply must not exceed 60 V DC max.

•Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture and high temperature.

•The router should not be used in locations where ﬂammable and explosive materials

are present, including gas stations, chemical plants, or locations in which explosives

are used. We remind the users of the duty to observe the restrictions concerning the

utilization of radio devices at such places.

•Switch off the router when travelling by plane. Utilization of the router in a plane may

endanger the operation of the plane or interfere with the mobile telephone network, and

may be unlawful. Failure to observe these instructions may result in the suspension

or cancellation of telephone services for the respective client, or, it may result in legal

sanctions; it may also result in both eventualities.

•When using the router in the close proximity of personal medical devices, such as cardiac

pacemakers or hearing aids, you must proceed with heightened caution.

•The router may cause interference when in the close proximity of TV sets, radio receivers

or personal computers.

•It is recommended that you should create an appropriate copy or backup of all the im-

portant settings that are stored in the memory of the device.

2. WEEE DIRECTIVE

2. Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2002/96/EC) directive has been

introduced to ensure that electrical/electronic products are recycled using the best available

recovery techniques to minimize the impact on the environment. This product contains high

quality materials and components which can be recycled. At the end of it’s life this product

MUST NOT be mixed with other commercial waste for disposal. Check the terms and condi-

tions of your supplier for disposal information.

3. ROUTER DESCRIPTION

3. Router Description

SmartMotion ST355 is an industrial cellular router intended for wireless communication

in mobile networks that make use of LTE, HSPA+, UMTS, CDMA, EDGE or GPRS technol-

ogy. The router is equipped with two independent cellular modules for backed up communi-

cation. That’s why SmartMotion router is the ideal solution for the systems with high reliability

needed. The position of the ﬁrst module is reserved for LTE technology with frequency bands

800, 900, 1800, 2100 and 2600 MHz. The second position can be equipped with a module

supporting LTE technology with frequency bands 450, 800, 1800 a 2600 MHz.Due to the high

speed of data transfer and the previously mentioned high reliability of communication is this

router an ideal solution for specialized M2M devices and IoT as well as for wireless connection

of trafﬁc and security camera systems, individual computers, LAN networks, automatic teller

machines (ATM) and other self-service terminals.

The standard conﬁguration includes two Ethernet 10/100 ports, one USB 2.0 Host port,

two binary inputs and one output (I/O connector). The device also has four readers for 3 V and

1.8 V SIM cards, which are located on the rear panel of the router. The router also includes

a microSD card port that supports up to 64 GB card storage (32 GB in the case of SDHC

cards). The router can be equipped with a WiFi module, but this must be part of the initial

conﬁguration – it cannot be added to the router at some point in the future. The router can be

equipped with PoE PD (Power over Ethernet – Powered Device), which allows the router to be

powered via Ethernet. It can also be equipped with PoE PSE (Power over Ethernet – Power

Source Equipment), which lets the router power other devices via Ethernet.

Conﬁguration of the router may be done via a password-protected Web interface. Web in-

terface provides detailed statistics about the router’s activities, signal strength, detailed system

log etc. The router supports the creation of VPN tunnels using IPSec, OpenVPN and L2TP

to ensure safe communication. DHCP, NAT, NAT-T, DynDNS, NTP, VRRP, control by SMS,

backup primary connection and many other functions are supported.

The router provides diagnostic functions which include automatically monitoring the PPP

connection, automatic restart in case of connection losses, and a hardware watchdog that

monitors the router status. The user may insert Linux scripts which are started on various

actions. It is possible to create up to four different conﬁgurations for the same router. These

conﬁgurations can be switched whenever necessary via Web interface, SMS or binary input

status. The router can automatically upgrade its conﬁguration and ﬁrmware from your central

server. This allows for mass reconﬁguration of numerous routers at the same time.

The router also supports additional software like R-SeeNet for permanent trafﬁc monitoring

of routers.

Otros manuales para SmartMotion ST355

Tabla de contenidos

Otros manuales de Enrutador de red de Advantech

Advantech

Advantech IMC-150LI Manual de instalación y operación

Advantech

Advantech SmartStart SL302 Manual de usuario

Advantech

Advantech EKI-2525 Manual de usuario

Advantech

Advantech B+B Smartworx SEC510-2SFP-T Manual de usuario

Advantech

Advantech ICR-1601 Manual de usuario

Advantech

Advantech EKI-1334 Manual de usuario

Advantech

Advantech ICR-3241 Manual de usuario

Advantech

Advantech B+B SmartWorx SmartStart Guía

Advantech

Advantech MIC-3666 Manual de usuario

Advantech

Advantech ICR-2437 Manual de usuario

Advantech

Advantech Bivias v2 Manual de usuario

Advantech

Advantech AirborneM2M BB-ABDN-ER-DP553 Manual de usuario

Advantech

Advantech EKI-7529MI Manual de usuario

Advantech

Advantech B+B SmartWorx SmartMotion ST355 Manual de usuario

Advantech

Advantech SmartFlex SR307 Manual de usuario

Advantech

Advantech B+B SmartWorx ER75i v2 Manual de usuario

Advantech

Advantech ICR-2441 Manual de usuario

Advantech

Advantech Libratum ICR-2834 Guía

Advantech

Advantech EKI-7526I Manual de usuario

Advantech

Advantech ICR-4453 Manual de usuario

Advantech

Advantech ICR-2432 Manual de usuario

Advantech

Advantech UR5i v2 Libratum Manual de usuario

Advantech

Advantech ICR-2412 Manual de usuario

Advantech

Advantech EKI-1222R-CE Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
