Advantech ICR-2701 Manual de usuario
LAN Industrial Router
ICR-2701
USER MANUAL
ICR-2701
c
2022 Advantech Czech s.r.o. No part of this publication may be reproduced or transmitted in any form or
by any means, electronic or mechanical, including photography, recording, or any information storage and retrieval
system without written consent. Information in this manual is subject to change without notice, and does not
represent a commitment on the part of Advantech.
Advantech Czech s.r.o. shall not be liable for incidental or consequential damages resulting from the furnish-
ing, performance, or use of this manual.
All brand names used in this manual are the registered trademarks of their respective owners. The use of
trademarks or other designations in this publication is for reference purposes only and does not constitute an
endorsement by the trademark holder.
i
ICR-2701
Used symbols
Danger – Information regarding user safety or potential damage to the router.
Attention – Problems that can arise in specific situations.
Information, notice – Useful tips or information of special interest.
GPL licence
Source codes under GPL licence are available at https://icr.advantech.cz/source-code
address.
Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic
Document No. MAN-0069-EN, revision from June 28, 2022. Released in the Czech Republic.
ii
ICR-2701
Contents
1 Product Overview 2
1.1 Product Introduction ................................. 2
1.2 Hardware Overview ................................. 3
1.3 Order Codes ..................................... 4
1.4 Package Contents .................................. 5
1.5 Product Dimensions ................................. 7
1.6 Mounting Recommendations ............................ 9
1.7 DIN Rail Mounting .................................. 10
1.8 Product Label ..................................... 11
2 Hardware Functionality 12
2.1 Ethernet Interfaces .................................. 12
2.2 Power Supply ..................................... 13
2.3 USB Port ....................................... 14
2.4 LED Status Indication ................................ 15
2.5 Reset Functions ................................... 16
3 First Use 18
3.1 Powering up the Router ............................... 18
3.2 Router Configuration ................................. 18
4 Technical Specifications 20
4.1 Basic Parameters ................................... 20
4.2 Standards and Regulations ............................. 21
4.3 Type Tests and Environmental Conditions ..................... 22
4.4 System Configuration ................................ 23
Appendix A: Troubleshooting 24
Appendix B: Customer Support 26
Appendix C: Regulatory & Safety Information 27
Appendix D: Related Documents 29
iii
ICR-2701
List of Figures
1 Hardware Overview of the Router .......................... 3
1 Metal box – Front View ................................ 7
2 Metal box – Top View ................................ 7
3 Plastic box – Front View ............................... 8
4 Plastic box – Top View ................................ 8
5 Position of the DIN Rail Clip ............................. 10
6 Removing Router from the DIN Rail ......................... 10
7 Label Example .................................... 11
1 Ethernet Connector Pinout .............................. 12
2 Connection of Power Supply ............................ 13
3 Position of the Grounding Screw .......................... 13
4 USB Connector Pinnout ............................... 14
5 Resetting the Router ................................. 16
6 Router’s Web Interface ................................ 19
iv
ICR-2701
List of Tables
1 Hardware Overview of the Router .......................... 3
2 Order Codes Overview ................................ 4
1 Contents of Package ................................. 5
2 Other Accessories .................................. 6
3 Ethernet Connector Pinout Description ....................... 12
4 Power Supply Pinout ................................. 13
5 USB Connector Pinnout ............................... 14
6 LED Status Indication ................................ 15
7 Overview of Router Reboot and Reset ....................... 17
8 Basic Parameters ................................... 20
9 Standards and Regulations ............................. 21
10 Type Tests and Environmental Conditions ..................... 22
11 System Configuration ................................ 23
1
ICR-2701
1. Product Overview
1.1 Product Introduction
Industrial router ICR-2701 is LAN Router &Edge Computing Gateway focused on the
global market.
The router, which may have a metal or plastic box, is equipped with two independently
configurable Ethernet ports, with one USB 2.0 host interface and with 5 LEDs for status
indication.
The router supports VPN tunnel creation using various protocols to ensure safe commu-
nications. The router provides diagnostic functions which include automatic monitoring of the
wireless and wired connections, automatic restart in case of connection losses, and a hard-
ware watchdog that monitors the router status.
With open Linux platform and wide possibilities of programming customer SW applications
in Python,C/C++. The Advantech existing app library Router Apps (formerly User modules)
with apps already developed to enhance specific router functionality including industrial pro-
tocol conversions and support of IoT platforms such as MS Azure,Cumulocity,ThingWorx,
and others are supported on the router.
Examples of possible applications
•mobile office
•security system
•telematic
•telemetric
•remote monitoring
•vending and dispatcher machines
2
ICR-2701
1.2 Hardware Overview
The router case preview is shown in Figure 1. A short description of hardware parts of the
router is listed in Table 1, including the links to the chapters with a detailed description. For
a router in a plastic box, the description of the components is similar.
Figure 1: Hardware Overview of the Router
# Item/Caption Type Description
1 LED - Status LED indication; see Chapter 2.4.
2 USB USB-A USB-A type socket connector; see Chapter 2.3.
3 ETH0, ETH1 RJ45 100 MB Ethernet connection for the firts and second LAN;
see Chapter 2.1.
4 PWR 2-pin
terminal
Power supply socket; see Chapter 2.2.
5 RST - Button to reboot the router or to restore the default
configuration; see Chapter 2.5.
6 DIN clip - DIN rail clip, included as standard accessories; see Chap-
ter 1.7.
7 Grounding
screw
M3 Pay attention to proper grounding of model with metal box;
see Chapter 2.2.
Table 1: Hardware Overview of the Router
3
ICR-2701
1.3 Order Codes
Order codes overview is shown in the table below.
Order code Configuration
ICR-2701 metal box, ETH0, ETH1, USB
ICR-2701P plastic box, ETH0, ETH1, USB
ICR-2701A01 metal box, ETH0, ETH1, USB, accessories with Ethernet cable, two an-
tennas, and EU power supply
ICR-2701PA01 plastic box, ETH0, ETH1, USB, accessories with Ethernet cable, two
antennas, and EU power supply
ICR-2701A02 metal box, ETH0, ETH1, USB, accessories with Ethernet cable, two an-
tennas, and UK power supply
ICR-2701PA02 plastic box, ETH0, ETH1, USB, accessories with Ethernet cable, two
antennas, and UK power supply
Table 2: Order Codes Overview
4
ICR-2701
1.4 Package Contents
The standard router set includes items listed in Table 1: For other optional accessories,
see Table 2.
Item# Description Figure Q’ty
1Router in metal or plastic box 1 pcs
2DIN rail clip with screws 1 set
32-pin terminal block for power supply
(deployed on the router) 1 pcs
4Printed Quick Start Guide notes 1 pcs
Table 1: Contents of Package
