Advantech ICR-2701 Manual de usuario

LAN Industrial Router

ICR-2701

USER MANUAL

ICR-2701

2023 Advantech Czech s.r.o. No part of this publication may be reproduced or transmitted in any form or

by any means, electronic or mechanical, including photography, recording, or any information storage and retrieval

system without written consent. Information in this manual is subject to change without notice, and does not

represent a commitment on the part of Advantech.

Advantech Czech s.r.o. shall not be liable for incidental or consequential damages resulting from the furnish-

ing, performance, or use of this manual.

All brand names used in this manual are the registered trademarks of their respective owners. The use of

trademarks or other designations in this publication is for reference purposes only and does not constitute an

endorsement by the trademark holder.

ICR-2701

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Document No. MAN-0069-EN, revision from February 23, 2023. Released in the Czech Republic.

ICR-2701

Contents

1 Product Overview 2

1.1 Product Introduction ................................. 2

1.2 Hardware Overview ................................. 3

1.3 Order Codes ..................................... 4

1.4 Package Contents .................................. 5

1.5 Product Dimensions ................................. 7

1.6 Mounting Recommendations ............................ 9

1.7 DIN Rail Mounting .................................. 10

1.8 Product Label ..................................... 11

2 Hardware Functionality 12

2.1 Ethernet Interfaces .................................. 12

2.2 Power Supply ..................................... 13

2.3 Low Power Mode ................................... 14

2.4 USB Port ....................................... 14

2.5 LED Status Indication ................................ 15

2.6 Reset Functions ................................... 16

3 First Use 17

3.1 Accessories Connection ............................... 17

3.2 Router Conﬁguration ................................. 17

4 Technical Speciﬁcations 19

4.1 Basic Parameters ................................... 19

4.2 Standards and Regulations ............................. 20

4.3 Type Tests and Environmental Conditions ..................... 21

4.4 System Conﬁguration ................................ 22

Appendix A: Troubleshooting 23

Appendix B: Customer Support 25

Appendix C: Regulatory & Safety Information 26

Appendix D: Related Documents 28

iii

ICR-2701

List of Figures

1 Hardware Overview of the Router .......................... 3

2 Metal Box – Top, Side and Front View ....................... 7

3 Plastic Box – Top, Side and Front View ....................... 8

4 Position of the DIN Rail Clip ............................. 10

5 Removing Router from the DIN Rail ......................... 10

6 Label Example .................................... 11

7 Ethernet Connector Pinout .............................. 12

8 Connection of Power Supply ............................ 13

9 Position of the Grounding Screw .......................... 13

10 USB Connector Pinout ................................ 15

11 Resetting the Router ................................. 16

12 Router’s Web Interface ................................ 18

ICR-2701

List of Tables

1 Hardware Overview of the Router .......................... 3

2 Order Codes Overview ................................ 4

3 Contents of Package ................................. 5

4 Other Accessories .................................. 6

5 Ethernet Connector Pinout Description ....................... 12

6 Power Supply Pinout ................................. 13

7 USB Connector Pinout ................................ 15

8 LED Status Indication ................................ 15

9 Basic Parameters ................................... 19

10 Standards and Regulations ............................. 20

11 Type Tests and Environmental Conditions ..................... 21

12 System Conﬁguration ................................ 22

ICR-2701

1. Product Overview

1.1 Product Introduction

Industrial router ICR-2701 is LAN Router &Edge Computing Gateway focused on the

global market.

The router, which may have a metal or plastic box, is equipped with two independently

conﬁgurable Ethernet ports, with one USB 2.0 host interface and with LEDs for status indi-

cation.

The router supports the Low Power Mode and hardware watchdog, which monitors the

router status and performs an automatic restart if required.

The router supports VPN tunnel creation using various protocols to ensure safe commu-

nications. The router provides diagnostic functions which include automatic monitoring of the

wireless and wired connections, automatic restart in case of connection losses, and a hard-

ware watchdog that monitors the router status.

With open Linux platform and wide possibilities of programming customer SW applications

in Python,C/C++. The Advantech existing app library Router Apps (formerly User modules)

with apps already developed to enhance speciﬁc router functionality including industrial pro-

tocol conversions and support of IoT platforms such as MS Azure,Cumulocity,ThingWorx,

and others are supported on the router.

Examples of possible applications

•mobile ofﬁce

•security system

•remote monitoring

•vending and dispatcher machines

ICR-2701

1.2 Hardware Overview

The router case preview is shown in Figure 1. A short description of hardware parts of the

router is listed in Table 1, including the links to the chapters with a detailed description. For

a router in a plastic box, the description of the components is similar.

Figure 1: Hardware Overview of the Router

# Item/Caption Type Description

1 LED - Status LED indication; see Chapter 2.5.

2 USB USB-A USB-A type socket connector; see Chapter 2.4.

3 ETH0, ETH1 RJ45 100 MB Ethernet connection for the ﬁrts and second LAN;

see Chapter 2.1.

4 PWR 2-pin

terminal

Power supply socket; see Chapter 2.2.

5 RST - Button to reboot the router or to restore the default

conﬁguration; see Chapter 2.6.

6 DIN clip - DIN rail clip, included as standard accessories; see Chap-

ter 1.7.

7 Grounding

screw

M3 Pay attention to proper grounding of model with metal box;

see Chapter 2.2.

Table 1: Hardware Overview of the Router

ICR-2701

1.3 Order Codes

Order codes overview is shown in the table below.

Order code Conﬁguration

ICR-2701 metal box, ETH0, ETH1, USB

ICR-2701P plastic box, ETH0, ETH1, USB

ICR-2701A01 metal box, ETH0, ETH1, USB, accessories with Ethernet cable, two an-

tennas, and EU power supply

ICR-2701PA01 plastic box, ETH0, ETH1, USB, accessories with Ethernet cable, two

antennas, and EU power supply

ICR-2701A02 metal box, ETH0, ETH1, USB, accessories with Ethernet cable, two an-

tennas, and UK power supply

ICR-2701PA02 plastic box, ETH0, ETH1, USB, accessories with Ethernet cable, two

antennas, and UK power supply

Table 2: Order Codes Overview

ICR-2701

1.4 Package Contents

The standard router set includes items listed in Table 3: For other optional accessories,

see Table 4.

Item# Description Figure Q’ty

1Router in metal or plastic box 1 pcs

2DIN rail clip with screws (screws differ

for metal and plastic versions) 1 set

32-pin terminal block for power supply

(deployed on the router) 1 pcs

4Printed Quick Start Guide Leaﬂet 1 pcs

Table 3: Contents of Package
