LTE Industrial Router

LR77 v2

USER MANUAL

LR77 v2

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

GPL licence

Source codes under GPL licence are available free of charge by sending an email to:

cellularsales@advantech-bb.com.

Advantech B+B SmartWorx s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Manual Rev. 1 released in CZ, February 15, 2017

LR77 v2

Contents

1 Safety Instructions 2

2 WEEE directive 3

3 Router Description 4

4 Contents of Package 5

5 Router Design 6

5.1 Router versions .................................... 6

5.2 Delivery identiﬁcation ................................ 7

5.3 Order codes ...................................... 8

5.3.1 Basic versions ................................ 8

5.3.2 Full version .................................. 8

5.4 Basic dimensions of the router box ......................... 9

5.4.1 Plastic box .................................. 9

5.4.2 Metal box ................................... 9

5.5 Mounting recommendations ............................. 10

5.6 Removing from the DIN rail ............................. 12

5.7 Description of the front panel ............................ 13

5.7.1 Status indication ............................... 14

5.7.2 Power connector PWR ............................ 15

5.7.3 Antenna connector ANT, DIV and GPS (alternatively WIFI or WMBUS) . 16

5.7.4 SIM card reader ............................... 17

5.7.5 Ethernet Port ETH .............................. 18

5.7.6 PORT1 .................................... 19

5.7.7 PORT2 .................................... 19

5.7.8 USB Port ................................... 20

5.7.9 I/O Port .................................... 20

5.7.10 Reset ..................................... 22

6 First Use 23

6.1 Connecting the router before ﬁrst use ....................... 23

6.2 Start .......................................... 24

6.3 Conﬁguration ..................................... 24

6.3.1 Conﬁguration over web browser ....................... 24

6.3.2 Conﬁguration over Telnet .......................... 25

7 Technical Parameters 26

LR77 v2

7.1 Basic parameters ................................... 26

7.2 Standards and regulations .............................. 27

7.2.1 Versions LR77 v2B and LR77 v2F ..................... 27

7.2.2 Versions LR77 v2BG and LR77 v2FG ................... 27

7.2.3 Versions LR77 v2B L45 ........................... 27

7.3 Technical parameters of module .......................... 28

7.3.1 Versions LR77 v2B and LR77 v2F ..................... 28

7.3.2 Versions LR77 v2BG and LR77 v2FG ................... 28

7.3.3 LTE module supports 450 MHz ....................... 29

7.4 Technical parameters of GPS ............................ 30

7.5 Technical parameters of processor ......................... 31

7.6 Technical parameters of I/O port .......................... 31

7.7 Technical parameters of expansion port ...................... 31

8 Recommended Literature 32

9 Troubleshooting 33

9.1 FAQ .......................................... 33

10 Customers Support 35

iii

LR77 v2

List of Figures

1 Contents of package ................................. 5

2 Front panel LR77 v2B(G) .............................. 6

3 Front panel LR77 v2F(G) .............................. 6

4 Front panel LR77 v2B L45 .............................. 6

5 Front panel LR77 v2B(G) SL ............................ 6

6 Front panel LR77 v2F(G) SL ............................ 6

7 Front panel LR77 v2B L45 SL ............................ 6

8 Label LR77 v2B ................................... 7

9 Label LR77 v2B SL .................................. 7

10 Label LR77 v2F .................................... 7

11 Label LR77 v2F SL .................................. 7

12 Basic dimensions of plastic box (bottom and front view) ............. 9

13 Basic dimensions of metal box (bottom and front view) .............. 9

14 Space around antennas (plastic) .......................... 10

15 Space around antennas (metal) ........................... 10

16 Cable routing (plastic) ................................ 11

17 Cable routing (metal) ................................. 11

18 Space in front of connectors (plastic) ........................ 11

19 Space in front of connectors (metal) ........................ 11

20 Default position of DIN holder ............................ 12

21 Removing from the DIN rail ............................. 12

22 Front panel LR77 v2F(G) .............................. 13

23 Power connector ................................... 15

24 Connection of power supply ............................. 15

25 Connecting of the antenna .............................. 16

26 Ejected SIM holder .................................. 17

27 Ethernet connector .................................. 18

28 Connection of ethernet cable ............................ 18

29 PORT1 cable connection .............................. 19

30 PORT2 cable connection .............................. 20

31 USB connector .................................... 20

32 I/O connector ..................................... 21

33 Connection of I/O cable ............................... 21

34 Connection of input and output to the router .................... 21

35 Router reset ...................................... 22

36 Router connection .................................. 23

37 Entering the IP address of the router ........................ 24

38 Entering login information .............................. 24

39 Router web interface ................................. 25

LR77 v2

List of Tables

1 Router versions .................................... 6

2 Delivery identiﬁcation ................................ 7

3 Ordering codes for Basic versions ......................... 8

4 Ordering codes of full version ............................ 8

5 Front panel description ................................ 13

6 Status indication ................................... 14

7 Connection of power connector ........................... 15

8 Connection of Ethernet connector .......................... 18

9 Connection of USB connector ............................ 20

10 Connection of I/O port ................................ 20

11 Description of reset and restart router ....................... 22

12 Basic parameters ................................... 26

13 Versions LR77 v2B and LR77 v2F ......................... 27

14 Versions LR77 v2BG and LR77 v2FG ....................... 27

15 Versions LR77 v2B L45 ............................... 27

16 Versions LR77 v2B and LR77 v2F ......................... 28

17 Versions LR77 v2BG and LR77 v2FG ....................... 29

18 Technical parameters of LTE module 450 MHz .................. 29

19 Technical parameters of GPS ............................ 30

20 Technical parameters of processor ......................... 31

21 Technical parameters of I/O port .......................... 31

LR77 v2

1. Safety Instructions

Please, observe the following instructions:

•The router must be used in compliance with all applicable international and national laws

and in compliance with any special restrictions regulating the utilization of the router in

prescribed applications and environments.

•To prevent possible injury and damage to appliances and to ensure compliance with

all relevant provisions, use only the original accessories. Unauthorized modiﬁcations or

the use of unapproved accessories may result in damage to the router and / or a breach

of applicable regulations. Unauthorized modiﬁcations or use of unapproved accessories

may void the warranty.

•The router can not be opened.

•Turn off the router and disconnect it from power supply before handling the SIM card.

•Caution! The SIM card could be swallowed by small children.

•Input voltage must not exceed 36 V DC max.

•Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture and high temperature.

•The router should not be used in locations where ﬂammable and explosive materials

are present, including gas stations, chemical plants, or locations in which explosives are

used. We remind users of the duty to observe the restrictions concerning the utilization

of radio devices at such places.

•Switch off the router when traveling by plane. Utilization of the router on a plane may

endanger the operation of the plane or interfere with the mobile telephone network, and

may be unlawful. Failure to observe these instructions may result in the suspension or

cancellation of telephone services for the respective client and / or may result in legal

sanctions.

•When using the router in close proximity to personal medical devices, such as cardiac

pacemakers or hearing aids, you must proceed with heightened caution.

•The router may cause interference when used in close proximity to TV sets, radio re-

ceivers or personal computers.

•It is recommended that you create an appropriate copy or backup of all important settings

that are stored in the memory of the device.

LR77 v2

2. Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2002/96/EC) directive was intro-

duced to ensure that electrical/electronic products are recycled using the best available recov-

ery techniques in order to minimize impact on the environment. This product contains high

quality materials and components which can be recycled. At the end of it’s life this product

MUST NOT be mixed with other commercial waste for disposal. Check the terms and condi-

tions of your supplier for disposal information.

LR77 v2

3. Router Description

LTE router LR77 v is used to wirelessly connect various equipments and devices via Ether-

net interface 10/100 to the Internet or Intranet. Thanks to high data transfer speed of up to 100

Mbit/s (download) and upload speed up to 50 Mbit/s it is an ideal wireless solution for trafﬁc

and security camera systems, individual computers, LAN networks, automatic teller machines

(ATM) and other self-service terminals, etc. Routers LR77 v2B L45 are primarily intended for

use in the 450 MHz band whose main advantage is the long range. The lower frequency, the

less transmitters are needed for covering.

As a standard, this LTE cellular router is equipped with one Ethernet 10/100, one USB

Host port, one binary Input/output (I/O) port and one SIM card. To save and backup commu-

nication data a version with two SIM cards is available. The wide range of interface options

of the router further expands Port1 and Port2 expansion ports, which are selected by the cus-

tomer. For Port1 are available: Ethernet port 10/100, serial interface ports RS232, RS485,

RS422, MBUS or inputs/outputs (I/O – CNT). Port2 may be equipped with serial interfaces

RS232, RS485, RS422, MBUS, wireless interfaces WIFI or WMBUS, SDH expansion port or

inputs/outputs (I/O – CNT). Both of ports can be ﬁtted with internal switch (exp. port SWITCH).

This wireless router is supplied either in a plastic or metal casing, based on the requirements

of the customer.

Conﬁguration is done via web interface protected by password. The router supports cre-

ation of VPN tunnels using technologies IPsec, OpenVPN and L2TP to ensure safe commu-

nication. Web interface provides detail statistics about the router activities, signal strength,

detailed log, etc. Cellular router supports functions: DHCP, NAT, NAT-T, DynDNS, NTP, VRRP,

control by SMS and many other function.

Other diagnostic functions ensuring continuous communication include automatic inspec-

tion of PPP connection offering an automatic restart feature – in case of connection losses,

or hardware watchdog which monitors the status of the router. With the help of a special

window (start up script window) you may insert Linux scripts for various actions. For some ap-

plications the key option to create several different conﬁgurations for one LTE wireless router,

the so-called proﬁles (maximum of 4), and the option to switch between them (for example

via SMS, binary input status, etc.) is essential. Cellular routers LR77 v2 may automatically

upgrade conﬁguration and ﬁrmware from server. This allows mass reconﬁguration of many

routers in one time.

The router also supports additional software like R-SeeNet for permanent trafﬁc monitoring

of routers or communication VPN server Digicluster.

Examples of possible applications

•mobile ofﬁce

•ﬂeet management

•security system

•telematic

•telemetric

•remote monitoring

•vending and dispatcher machines

LR77 v2

4. Contents of Package

Basic delivered set of router includes:

•router,

•power supply,

•crossover UTP cable,

•up to three external antennas,

•clip for the DIN rail,

•paper start guide.

Figure 1: Contents of package

Temperature range for power supply is reduced to 0 ◦C to +40 ◦C!

As optional accessories can also be supplied the following expansion ports (one for Basic

version or two for Full version):

•RS232, RS485/422, MBUS, ETHERNET, CNT, SWITCH, WIFI, WMBUS or SDH.

•Separation columns for mounting expansion boards are included.

Otros manuales para B+B SmartWorx LR77 v2

Tabla de contenidos

Otros manuales de Enrutador de red de Advantech

Advantech

Advantech ICR-3231 Manual de usuario

Advantech

Advantech ICR-2436 Manual de usuario

Advantech

Advantech ADAM-6520 Series Manual de usuario

Advantech

Advantech B+B SMARTWORX SmartStart SL302 Manual de usuario

Advantech

Advantech SmartMotion ST355 Manual de usuario

Advantech

Advantech SmartFlex SR303 Manual de usuario

Advantech

Advantech UR5i v2 Libratum Manual de usuario

Advantech

Advantech ICR-4434S Manual de usuario

Advantech

Advantech ICR-2437 Manual de usuario

Advantech

Advantech B&B SmartWorx ESWGP506-2SFP-T Manual de usuario

Advantech

Advantech ESWGP510-2SFP-T Manual de usuario

Advantech

Advantech ICR-2412 Manual de usuario

Advantech

Advantech EDG-6528 Manual de usuario

Advantech

Advantech EKI-2726FHPI Series Manual de instalación y operación

Advantech

Advantech AirborneM2M BB-ABDN-ER-DP553 Manual de usuario

Advantech

Advantech ICR-2432 Manual de usuario

Advantech

Advantech ICR-4401 Manual de usuario

Advantech

Advantech EKI-7626C Manual de usuario

Advantech

Advantech SmartMotion ST352 Manual de usuario

Advantech

Advantech ICR-2030 Manual de usuario

Advantech

Advantech ICR-3201 Series Manual de usuario

Advantech

Advantech ICR-4453W Guía

Advantech

Advantech UR5i v2 Libratum Guía

Advantech

Advantech IMC-150LI Manual de instalación y operación

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
