Advantech ICR-1601 Manual de usuario

LTE Industrial Router

ICR-1601

USER MANUAL

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

ICR-1601

Advantech B+B SmartWorx – Americas

Advantech B+B SmartWorx

707 Dayton Road

Ottawa, IL 61350 USA

Website

www.advantech-bb.com

Advantech B+B SmartWorx – Europe

Advantech B+B SmartWorx s.r.o.

Sokolska 71

562 04, Usti nad Orlici,

Czech Republic

Website

www.advantech-bb.com

2019 Advantech B+B SmartWorx s.r.o. No part of this publication may be reproduced or transmitted in any

form or by any means, electronic or mechanical, including photography, recording, or any information storage and

retrieval system without written consent. Information in this manual is subject to change without notice, and does

not represent a commitment on the part of Advantech B+B SmartWorx.

Advantech B+B SmartWorx s.r.o. shall not be liable for incidental or consequential damages resulting from

the furnishing, performance, or use of this manual.

All brand names used in this manual are the registered trademarks of their respective owners. The use of

trademarks or other designations in this publication is for reference purposes only and does not constitute an

endorsement by the trademark holder.

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

ICR-1601

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

GPL licence

Source codes under GPL licence are available free of charge by sending an email to:

[email protected].

Please see http://ep.advantech-bb.cz/devzone for more information.

Advantech B+B SmartWorx s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Document No. MAN-0038-EN, revision from May 10, 2019. Released in the Czech Republic.

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

ICR-1601

Contents

1 Safety Instructions 2

2 WEEE directive 3

3 Router Description 4

3.1 LTE Category 4 (Cat.4) ............................... 4

3.2 Basic HW Information ................................ 4

3.3 Conﬁguration and Diagnostics ............................ 4

3.4 Usage of the Router ................................. 5

4 Contents of Package 7

5 Router Design 8

5.1 Router Versions .................................... 8

5.2 Order Codes ..................................... 8

5.3 Product labels ..................................... 9

5.4 Basic Dimensions of the Router ........................... 10

5.4.1 Left view ................................... 10

5.4.2 Bottom view .................................. 10

5.5 Description of the Right Panel ............................ 11

5.6 Description of the Left Panel ............................. 12

5.6.1 Status Indication ............................... 13

5.6.2 Power Supply ................................. 14

5.6.3 Antenna Connector ANT, DIV and WiFi/GPS ............... 15

5.6.4 SIM Card Reader ............................... 16

5.6.5 MicroSD Card Reader ............................ 17

5.6.6 Ethernet Ports ................................ 18

5.6.7 Factory Reset ................................. 19

5.7 Mounting recommendations ............................. 20

5.8 The DIN rail clip .................................... 21

6 First Use 23

6.1 Connecting the Router ................................ 23

6.2 Start .......................................... 23

6.2.1 Conﬁguration by web browser ........................ 23

7 Technical Parameters 25

7.1 Basic Parameters ................................... 25

iii

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

ICR-1601

7.2 Technical speciﬁcation of user interfaces ...................... 25

7.3 Standards and regulations .............................. 26

7.4 Type Tests and Environmental Conditions ..................... 26

7.5 Technical Parameters of Cellular Module ...................... 27

7.6 Technical Parameters of WiFi ............................ 28

8 Recommended Literature 29

9 Customers Support 30

9.1 Customer Support for NAM ............................. 30

9.2 Customer Support for Europe ............................ 30

9.3 Customer Support for Asia ............................. 30

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

ICR-1601

List of Figures

1 Access to the Internet from LAN .......................... 5

2 Backed up access to the Internet .......................... 6

3 Using a VPN tunnel ................................. 6

4 Product label for GPS version ............................ 9

5 Product label for WiFi version ............................ 9

6 Left view ........................................ 10

7 Bottom view ...................................... 10

8 Right panel ...................................... 11

9 GPS version ..................................... 12

10 WiFi version ...................................... 12

11 Power adapter .................................... 14

12 Connecting the antenna ............................... 15

13 Installation of SIM cards ............................... 16

14 Installation of microSD memory card ........................ 17

15 Ethernet connector .................................. 18

16 Connection of Ethernet cable ............................ 18

17 Router reset ...................................... 19

18 Grounding screw on side of the router ....................... 20

19 Installation of the DIN rail clips ........................... 21

20 Installation to the DIN rail .............................. 21

21 Removing from the DIN rail ............................. 22

22 The default IP address of the router ........................ 23

23 Entering login information .............................. 23

24 Router web interface ................................. 24

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

ICR-1601

List of Tables

1 Contents of package ................................. 7

1 Router versions .................................... 8

2 Order codes overview ................................ 8

3 LED status indication ................................. 13

4 Connection of Ethernet connector .......................... 18

5 Basic parameters ................................... 25

6 Technical speciﬁcation of user interfaces ...................... 25

7 Standards and regulations .............................. 26

8 Type tests and environmental conditions ...................... 26

9 Technical parameters of cellular module ...................... 27

10 Technical parameters of WiFi ............................ 28

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

ICR-1601

1. Safety Instructions

Please, observe the following instructions:

•The router must be used in compliance with all applicable international and national laws

and in compliance with any special restrictions regulating the utilization of the router in

prescribed applications and environments.

•To prevent possible injury and damage to appliances and to ensure compliance with

all relevant provisions, use only the original accessories. Unauthorized modiﬁcations or

the use of unapproved accessories may result in damage to the router and / or a breach

of applicable regulations. Unauthorized modiﬁcations or use of unapproved accessories

may void the warranty.

•The router can not be opened.

•Turn off the router and disconnect it from power supply before handling the SIM card.

•Caution! The SIM card could be swallowed by small children.

•Input voltage must not exceed 18 V DC max.

•Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture and high temperature.

•Only routers with appropriate certiﬁcation and labelling should be used in locations where

ﬂammable and explosive materials are present, including gas stations, chemical plants,

or locations in which explosives are used. We remind users of the duty to observe the

restrictions concerning the utilization of radio devices at such places.

•Switch off the router when traveling by plane. Utilization of the router on a plane may

endanger the operation of the plane or interfere with the mobile telephone network, and

may be unlawful. Failure to observe these instructions may result in the suspension or

cancellation of telephone services for the respective client and / or may result in legal

sanctions.

•When using the router in close proximity to personal medical devices, such as cardiac

pacemakers or hearing aids, you must proceed with heightened caution.

•The router may cause interference when used in close proximity to TV sets, radio re-

ceivers or personal computers.

•It is recommended that you create an appropriate copy or backup of all important settings

that are stored in the memory of the device.

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

ICR-1601

2. Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) directive was in-

troduced to ensure that electrical/electronic products are recycled using the best available

recovery techniques in order to minimize impact on the environment. This product contains

high quality materials and components which can be recycled. At the end of it’s life this pro-

duct MUST NOT be mixed with other commercial waste for disposal. The device contains the

battery. Remove the battery from the device before disposal. The battery in the device needs

to be disposed apart accordingly. Check the terms and conditions of your supplier for disposal

information.

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

ICR-1601

3. Router Description

Cellular router ICR-1601 is designed for wireless communication in the mobile networks

that make use of traditional cellular technologies. The primary purpose of this router is its use

in the newest Category 4 (Cat.4) services on the cellular LTE network.

3.1 LTE Category 4 (Cat.4)

LTE Category 4 (Cat.4) is the next step in 4G LTE device capability. Cat.4 rated ICR-1601

routers are capable of achieving better typical speeds in 4G coverage areas where the network

is enabled with 20 MHz of contiguous spectrum. The peak downlink data rate for a Category

4 is approximately 150 Mbps. Also in the uplink, LTE Category 4 provides a peak data rate of

50 Mbps.

3.2 Basic HW Information

As a standard, the ICR-1601 router is equipped with two Fast Ethernet 10/100 Mbps inter-

faces, two readers for SIM cards and reader for MicroSD card (log storage). The router can

be equipped with WiFi module or with GPS module. This router is supplied in a metal bracket

casing.

3.3 Conﬁguration and Diagnostics

The ICR-1601 router can be conﬁgured using a password-protected Web interface. The

web interface provides detailed statistics about the router activities, signal strength, detailed

system logs etc.

This device supports the creation of VPN tunnels using technologies IPSec (up to 3 tun-

nels), OpenVPN, L2TP, PPTP and GRE for secure communications.

There are also supported functions such as IPv6, DHCP, NAT, DNS, DynDNS, NTP, static

and dynamic routing, packet ﬁltering, URL blocking, MAC control, IPS, primary connection

backups and many other functions. Access using Web, TR-069, SNMP, Telnet and SSH

protocols are supported by the router.

Other diagnostic functions ensuring continuous communication include Packet Analyzer

and Diagnostic Tools. Using the Command Script editor allows administrator to setup the

pre-deﬁned conﬁguration in plain text style and apply the conﬁguration on startup.

The router also supports additional software such as R-SeeNetTM for permanent trafﬁc

monitoring of routers.
