Advantech SKY-MXM-A500 Manual de usuario

User Manual

SKY-MXM-A500

MXM 3.1 Type A NVIDIA®

Quadro® Embedded A500

SKY-MXM-A500 User Manual ii

The documentation and the software included with this product are copyrighted 2023

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated, or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. The information provided in this manual is intended to be accurate and reliable.

However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any

infringements of the rights of third parties that may result from its use.

Acknowledgments

Quadro, RTX, and CUDA are trademarks of NVIDIA Corporation.

All other product names or trademarks are properties of their respective owners.

A Message to the Customer

Advantech Customer Service

Each and every Advantech product is built to the most exacting specifications to

ensure reliable performance in the harsh and demanding conditions typical of indus-

trial environments. Whether your new Advantech equipment is destined for the labo-

ratory or the factory floor, you can be assured that your product will provide the

reliability and ease of operation for which the name Advantech has come to be

known.

Your satisfaction is our primary concern. Here is a guide to Advantech’s customer

services. To ensure you get the full benefit of our services, please follow the instruc-

tions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions,

you can easily find answers in your product documentation. These answers are nor-

mally a lot more detailed than the ones we can give over the phone.

So please consult this manual first. If you still cannot find the answer, gather all the

information or questions that apply to your problem, and with the product close at

hand, call your dealer. Our dealers are well trained and ready to give you the support

you need to get the most from your Advantech products. In fact, most problems

reported are minor and are able to be easily solved over the phone.

In addition, free technical support is available from Advantech engineers every busi-

ness day. We are always ready to give advice on application requirements or specific

information on the installation and operation of any of our products.

Part No. 2001A50000 Edition 1

Printed in China March 2023

iii SKY-MXM-A500 User Manual

Declaration of Conformity

FCC Class A

This equipment has been tested and found to comply with the limits for a Class A dig-

ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-

vide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. However, there is no guarantee that interfer-

ence will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one

or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for assistance.

Product Warranty (2 years)

Advantech warrants the original purchaser that each of its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products that have been repaired or altered by

persons other than repair personnel authorized by Advantech, or products that have

been subject to misuse, abuse, accident, or improper installation. Advantech

assumes no liability under the terms of this warranty as a consequence of such

events.

Because of Advantech’s high quality-control standards and rigorous testing, most

customers never need to use our repair service. If an Advantech product is defective,

it will be repaired or replaced free of charge during the warranty period. For out-of-

warranty repairs, customers will be billed according to the cost of replacement mate-

rials, service time, and freight. Please consult your dealer for more details.

If you believe your product to be defective, follow the steps outlined below.

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages displayed when the prob-

lem occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain a return merchandise authori-

zation (RMA) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a completed Repair and Replacement

Order Card, and a proof of purchase date (such as a photocopy of your sales

receipt) into a shippable container. Products returned without a proof of pur-

chase date are not eligible for warranty service.

5. Write the RMA number clearly on the outside of the package and ship the pack-

age prepaid to your dealer.

SKY-MXM-A500 User Manual iv

Initial Inspection

Before you begin installing your GPU, please make sure that the following materials

have been shipped:

SKY-MXM-A500 GPU card x 1

China RoHS Doc x 1

If any of these items are missing or damaged, contact your distributor or sales repre-

sentative immediately. We have carefully inspected the SKY-MXM-A500 mechani-

cally and electrically before shipment. It should be free of marks and scratches and in

perfect working order upon receipt. As you unpack the SKY-MXM-A500, check it for

signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is

damaged or it fails to meet the specifications, notify our service department or your

local sales representative immediately. Also notify the carrier. Retain the shipping

carton and packing material for inspection by the carrier. After inspection, we will

make arrangements to repair or replace the unit.

v SKY-MXM-A500 User Manual

Contents

Chapter 1 Hardware Configuration......................1

1.1 Introduction ............................................................................................... 2

1.2 Features .................................................................................................... 2

1.3 Specifications ............................................................................................ 2

1.3.1 Processor System......................................................................... 2

Table 1.1: Processor System ...................................................... 2

1.3.2 Memory ......................................................................................... 2

Table 1.2: Memory....................................................................... 2

1.3.3 Display Support and Options ........................................................ 3

Table 1.3: Display Support and Options...................................... 3

1.3.4 Operating Systems ....................................................................... 3

Table 1.4: Operating Systems ..................................................... 3

1.3.5 Software Support .......................................................................... 3

1.3.6 Physical......................................................................................... 3

1.3.7 Environment................................................................................. 3

1.4 Block Diagram........................................................................................... 4

1.5 Board Dimensions..................................................................................... 4

1.6 MXM 3.1 Connector Pin Definitions .......................................................... 5

Table 1.5: Connector Pin Definitions ........................................... 5

1.7 Safety Precautions.................................................................................... 7

Chapter 2 System Requirements.........................9

2.1 Power Sequencing .................................................................................. 10

Figure 2.1 Power Sequencing ................................................... 10

Table 2.1: Signals Exempted from Power Sequencing ............. 10

2.2 Input Voltage Requirements.................................................................... 11

Table 2.2: Input Voltage Requirements ..................................... 11

2.3 Module Power Down and Power Up ....................................................... 11

Figure 2.2 Power Sequencing .............................11

2.4 Reset Requirements ............................................................................... 12

Figure 2.3 Reset Sequencing .............................12

2.5 Mechanical and Environmental Specifications........................................ 12

Table 2.3: DVI-I DDC Mapping.................................................. 12

2.6 GPU Thermal Policy................................................................................ 14

Table 2.4: GPU Thermal Policy ................................................. 14

2.7 System BIOS Requirements ................................................................... 14

SKY-MXM-A500 User Manual vi

Chapter 1

1Hardware

Configuration

SKY-MXM-A500 User Manual 2

1.1 Introduction

As an NVIDIA Elite Partner, Advantech offers MXM GPU cards powered by NVIDIA’s

embedded GPUs, perfect for image processing and Edge AI acceleration in manu-

facturing, medical, and gaming industries. Built on NVIDIA's latest architectures,

Advantech MXM GPUs deliver state-of-the-art performance and responsive capabili-

ties for systems, as well as reduced latency, which is ideal for deployment in applica-

tions such as auto-optical inspection, driver-assistance, and surgical systems.

The Advantech SKY-MXM-A500 MXM module is a high-performance MXM graphics

module based on the NVIDIA Ampere GA107 chip. The module epitomizes both per-

formance and stability. On one hand, it has 2048 CUDA cores, 2GB or 4GB GDDR6,

and 6.54 TFLOPS of Single-Precision Performance; it’s powerful enough to handle

professional CAD drawing, medical applications, and even image processing. On the

other hand, the small form factor allows for easier system integration. The lower

power requirement allows it to run cool. All these features make this module an ideal

choice for an embedded solution with a need for high-end graphics capability.

1.2 Features

NVIDIA® Quadro® A500 with MXM 3.1 TYPE A form factor (82 x 70 mm)

Up to 2048 CUDA cores, 6.54 TFLOPS

GDDR6 2GB/4GB memory, 64-bit, bandwidth 112 GB/s

Headless design, supports MS-Hybrid mode only

Long life cycle, supports 5+ years of availability

1.3 Specifications

1.3.1 Processor System

1.3.2 Memory

Table 1.1: Processor System

GPU Quadro® A500

Graphics Architecture NVIDIA® Ampere™ GA107-910

CUDA Parallel-Processing Cores 2048 CUDA® cores

GPU Base/Boost Clock 652 MHz / 1597 MHz

FP32 Performance 6.54 TFLOPS

Table 1.2: Memory

Technology GDDR6 2GB/4GB memory

Interface Width 64-bit

Bandwidth 112 GB/s

Max Clock 7000 MHz

3 SKY-MXM-A500 User Manual

Chapter 1 Hardware Configuration

1.3.3 Display Support and Options

1.3.4 Operating Systems

1.3.5 Software Support

CUDA Toolkit 8.0 and higher

CUDA Compute version 6.1 and higher

OpenCL™ 1.2

DirectX® 12

OpenGL 4.5

Vulcan 1.0

1.3.6 Physical

Dimensions: 82 (W) x 70 (D) mm

Form Factor: MXM 3.1 Type A

1.3.7 Environment

Operating: 0 ~ 55 °C (Depending on the CPU and cooler solution)

Non-Operating: -40 °C ~ 85 °C

Table 1.3: Display Support and Options

Display Headless design, no display function, supports MS-

Hybrid mode only

Table 1.4: Operating Systems

Microsoft Windows 10/11, 64-bit

Linux Linux Drivers, 64-bit

SKY-MXM-A500 User Manual 4

1.4 Block Diagram

1.5 Board Dimensions

NVIDIA

Quadro A500

EN20-M02-A1

GDDR6 x32

memory down

GDDR6 memory, 64-bit

16Mb

+VPWR_SRC (7~20V)

+5V

+3.3V

PCIe x4

DP_A: Display Port

DP_B: Display Port

DP_C: Display Port

DP_D: Display Port

PCIe x4 Gen3

SPI

Reserved (MS-hybrid only)

Power Management (PWR_EN, PWR_GOOD)

GDDR6

GDDR6 x32

memory down

SPI - VBIOS

VBIOS GDDR6 PWM

NVIDIA

Quadro A500

MXM V3.1 G/F

MXM V3.1 Gold Finger

P_+3.3V

P_+12V (7~20V)

PCIe x4 gen3

IFPA

IFPB

IFPC

IFPE

DP_A

DP_B

DP_C

DP_D

PCIe x4PCIe x4

IFPA

IFPB

IFPC

IFPE

FBA

I2CS

SPI

P_+5V

82.00

70.00

59.80

1.50

39.00

Ø3.25

9.0046.00

12.2546.00

1.20

2.05

3.00

23.00

14.54

13.62

3.5023.50

12.00

14.00

22.97

23.00

Unit: mm

8QLWPP

Tabla de contenidos

Otros manuales de Hardware de computadora de Advantech

Advantech

Advantech PCL-818L Manual de usuario

Advantech

Advantech ASMB-610 Manual de usuario

Advantech

Advantech PCL-846 Series Manual de usuario

Advantech

Advantech PCL-734 Manual de usuario

Advantech

Advantech AMAX-4870 Manual de instalación y operación

Advantech

Advantech PCA-6154 Manual de instalación y operación

Advantech

Advantech POC-824 Manual de usuario

Advantech

Advantech UNO-238 V2 Manual de usuario

Advantech

Advantech SOM-E780 Manual de usuario

Advantech

Advantech PCM-3864 Manual de instalación y operación

Advantech

Advantech MIO-2361 Series Manual de instalación y operación

Advantech

Advantech PCA-6154 Manual de usuario

Advantech

Advantech AIMB-707 Manual de instalación y operación

Advantech

Advantech USB-4750-AE Manual de usuario

Advantech

Advantech SOM-7583 Manual de usuario

Advantech

Advantech HPC-7420 Manual de usuario

Advantech

Advantech UNO-1251G Manual de usuario

Advantech

Advantech PCE-5B09-06 Manual de instalación y operación

Advantech

Advantech FWA-6510 Manual de instalación y operación

Advantech

Advantech AIMB-788 Manual de usuario

Advantech

Advantech ADAM-3956 Manual de instalación y operación

Advantech

Advantech ECU-P1528PE Manual de instalación y operación

Advantech

Advantech PCE-3026 Manual de instalación y operación

Advantech

Advantech HPC-7282 Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
