AIMC-3422 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

1. AIMC-3422 Bare System x 1 P/N: AIMC-3422-00A1E

2. Driver CD x 1 P/N: 2061302900

3. USB 2.0 Cable x 1 P/N: 1700014398

4. USB 3.0 Cable x 1 P/N: 1700020277-01

5. Four-port USB Cable x 1 P/N: 1700014398

6. LPT Cable x 1 P/N: 1700002223

7. Mounting Bracket x 2 P/N: 1960014487T00C

8. Rubber Foot x 4 P/N: 1990012452S000

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note 1: For detailed contents of AIMC-3422, please refer

to information on the enclosed CD-ROM (in PDF

format).

Note 2: Acrobat Reader is required to view any PDF ﬁle.

Acrobat Reader can be downloaded at: get.

adobe.com/reader (Acrobat is a trademark of

Adobe)

AIMC-3422

Micro Computer, Intel®Core™ i7/i5/i3 CPU, H110,

4 Expansions 2PCI/2PCIe, 300W PSU

Startup Manual

Processor System

• LGA1150 Intel®Core™ i5/i3/Pentium®/Celeron®

4th Gen. (Haswell) Refresh CPU (Support from BIOS V2.XX)

CPU i7-6700 i7-

6700TE i5-6500 i5-

6500TE i3-6100 i3-6100TE G4400 G4400TE G3900 G3900TE

Core 4 4 4 4 2 2 2 2 2 2

Base Frequency

(GHz) 3.4 2.43 3.2 2.3 3.7 2.7 3.3 2.9 2.8 2.6

L3 Cache (MB) 8 6 6 6 4 4 3 3 2 2

Chipset H110

4th Gen. (Haswell) CPU (Support from BIOS V1.XX)

CPU i7-4770S i7-4770TE i5-4570S i5-4570TE i3-4330 i3-4330TE G3420 G3320TE G1820 G1820TE

Base

Frequency

(GHz)

3.1 2.3 2.9 2.7 3.5 2.4 3.2 2.3 2.7 2.2

L3 Cache

(MB) 8 8 6 4 3 3 3 3 2 2

* Part Number iX-XXXXTX & GXXXXXX can use 1U CPU

cooler for 2 expansion slots. The remaining CPUs have to

use 1.5U Cooler for 1 expansion slot.

BIOS

• AMI 128 Mbit SPI Flash

Chipset

• Intel®H110

Memory

• Supports dual channel DDR4 1866/2133 16 GB per

DIMM, Max capacity is 32 GB

Graphic

• Chipset: Intel®HD Graphics

Expansion Slot

• One PCIe x16

• One PCIe x1

• Two PCIs

Ethernet

• Chipset supports:

- LAN 1: Intel®I219V

- LAN 2: Intel®I211AT

• Connection: 2 on-board RJ-45 connector with LED

indicators

SATA

• Max Data Transfer Rate: 600 MB/s (SATA 3.0)

• HDD Bay: 1 internal 3.5”

Specications

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://support.advantech.com.tw/support/default.

aspx

This manual is for the AIMC-3422 Series Rev. A1.

Part No. 2001342200

Printed in China

1st Edition,

December 2016

2 AIMC-3422 Startup Manual

I/O Interface

• Display: VGA

• USB: 3 USB2.0 (2 in front, 1 type-A onboard for software

key), 1 USB3.0 (in rear)

• PS/2: 1

Watchdog Timer

• Programmable 1~255 sec/min

Power Supply

• Output Rating: AC 250W, ATX

• Input Voltage: 100 VAC ~ 240 VAC

Cooling

• System Fan: 2 (6cm / 27.7 CFM)

• Air Filter: Ye s

Environment

• Operating Temperature: 0 ~ 40 °C (32 ~ 104 °F)

• Non-operating Temperature: -20 ~ 60°C (-4 ~ 140 °F)

• Operating Humidity: 10 ~ 85% @ 40 °C, non-condensing

• Non-operating Humidity: 10 ~ 95% @ 40 °C, non-

condensing

Physical Characteristics

• Dimension (WxHxD): 232 x 90 x 232 mm

The board has a number of jumpers that allow you to con-

ﬁgure your system to suit your application. The table below

lists the function of each of the jumpers and connectors.

Connectors

Label Function

LPT1 Parallel port, supports SPP/EPP/ECP mode

LAN1 Intel I219V

LAN2 Intel I211AT

VGA1 VGA connector

KBMS1 External keyboard/mouse connector

COM12 Box header for RS-232*2

FP1 HDD LED, power LED, SNMP SM_Bus,

reset, power on/off

JCASE1 Case open

CPUFAN1 CPU FAN connector (4-pin)

LANLED1 LAN1/2 LED connector

HDAUD1 HD audio extension module connector

USB1 USB port 1 (USB 3.0 port)

USB23 USB port 2, 3 (USB 3.0 port)

USB45 USB port 4, 5 (USB 2.0)

USB67 USB port 6, 7 (USB 2.0)

USB89 USB port 8, 9 (USB 2.0)

USB11 Type A connector on board (USB 2.0)

S ATA 0 Serial ATA1 (SATA 3.0)

S ATA 1 Serial ATA2 (SATA 3.0)

S ATA 2 Serial ATA3 (SATA 3.0)

S ATA 3 Serial ATA4

CPU1 CPU Socket

DIMMA1 Memory connector channel A

DIMMB1 Memory connector channel B

GPIO1 GPIO pin header

LPC1 Low pin count module expansion pin-header

PWR1 12 V, 5 V power connector

DVI1

DVI connector

DP1

Display pin header to stack board (Display

type depends on optional stack board)

EXPCIE1 mini PCIe pin header to stack board

MINIPCIE

MSATA

M-SATA (default) or mini-PCIe connector

Jumpers

Label Function

JCMOS1 CMOS clear

JWDT1+JOBS1 Hardware monitor alarm+watchdog

timer output selection

JME1 Enable ME

JCMOS1: Clear CMOS

Closed Pins Result

1-2 Keep CMOS (Default)

2-3 Clear CMOS

Jumpers and Connectors

(Cont.)

Specications (Cont.)

AIMC-3422 Startup Manual 3

JOBS1+JWDT1: Hardware monitor alarm+watchdog

timer output selection

Function Jumper Setting

2-3 Enable watchdog timer (Default)

4-5 Enable Hardware monitor alarm (Default)

JME1: Enable ME

Closed Pins Result

1-2 Enable ME

(Default)

2-3 Disable ME

1 2 3 4 5

1 2 3

Jumpers and Connectors

(Cont.)

Declaration of Conformity

System I/O Interface

The drivers for the AIMC-3422 are located on the software

installation CD. Please click through to the desired folder

and follow the on screen instructions to install them.

Caution! The computer is supplied with a battery-powered

realtime clock circuit. There is a danger of explo-

sion if battery is incorrectly replaced. Replace

only with same or equivalent type recommended

by the manufacturer. Discard used batteries ac-

cording to manufacturer’s instructions.

This device complies with the requirements in Part 15 of

the FCC rules. Operation is subject to the following two

conditons:

1. This device may not cause harmful interference;

2. This device must accept any interference received,

including interference that may cause undesired opera-

tion.

Software Installation

4 AIMC-3422 Startup Manual

System Dimensions

units: mm (in)

AIMC-3422快速入门手册 1

安装板卡之前，用户需确认包装中含有本设备以及下面所

列各项：

1. AIMC-3422准系统 x 1 P/N：AIMC-3422-00A1E

2. 驱动光盘 x 1 P/N：2061302900

3. USB 2.0线缆 x 1 P/N：1700014398

4. USB 3.0线缆 x 1 P/N：1700020277-01

5. 4端口USB线缆 x 1 P/N：1700014398

6. LPT线缆 x 1 P/N：1700002223

7. 安装支架 x 2 P/N：1960014487T00C

8. 橡胶垫脚 x 4 P/N：1990012452S000

如果其中任何一项缺失或损坏，请立即与经销商或销售代

表联系。

注1：有关AIMC-3422产品的详细信息，请参考CD光盘中

的信息（PDF格式）。

注2：阅读PDF文件需要使用Acrobat Reader。用户可从

以下路径下载Acrobat Reader：www.adobe.com/

Products/acrobat/readstep2.html（Acrobat为

Adobe公司的商标）

AIMC-3422

微计算机，搭载Intel® Core™ i7/i5/i3 CPU、H110、

4扩展2PCI/2PCIe、300W PSU

快速入门手册

BIOS

• LGA1150 Intel® Core™ i5/i3/Pentium®/Celeron®

Haswell Refresh CPU (支持BIOS V2.XX)

CPU i7-6700 i7-

6700TE i5-6500 i5-

6500TE i3-6100 i3-6100TE G4400 G4400TE G3900 G3900TE

Core 4 4 4 4 2 2 2 2 2 2

基频(GHz) 3.4 2.43 3.2 2.3 3.7 2.7 3.3 2.9 2.8 2.6

L3缓存(MB) 8 6 6 6 4 4 3 3 2 2

芯片组 H110

Haswell CPU (支持BIOS V1.XX)

CPU i7-4770S i7-4770TE i5-4570S i5-4570TE i3-4330 i3-4330TE G3420 G3320TE G1820 G1820TE

基频(GHz) 3.1 2.3 2.9 2.7 3.5 2.4 3.2 2.3 2.7 2.2

L3缓存(MB) 8 8 6 4 3 3 3 3 2 2

* 料号iX-XXXXTX & GXXXXXX的2个扩展插槽可使用1U CPU冷

却器。其它CPU的扩展插槽需使用1.5U冷却器。

BIOS

• AMI 128 Mbit SPI Flash

芯片组

• Intel H110

内存

• 支持双通道DDR4 1866/2133 16 GB per DIMM，最大容量

为32 GB

图形

• 芯片组：Intel® HD Graphics

扩展插槽

• 1 x PCIe x16

• 1 x PCIe x1

• 2 x PCI

以太网

• 芯片组支持：

- LAN 1：Intel® I219V

- LAN 2：Intel® I211AT

• 连接：2 x板载RJ-45接头，带LED指示灯

SATA

• 最大数据传输速率：600 MB/s (SATA 3.0)

• HDD磁盘盒：1 x 内置3.5”

I/O接口

• 显示：VGA

• USB：3 x USB2.0 (2前置, 1 type-A板载用于软件按键)

，1 x USB3.0(后部)

• PS/2：1

产品规格

包装清单

如需了解有关本产品及研华其它产品的详细信息，请访

问我们的网站：

http://www.advantech.com

http://www.advantech.com/eplatform

如需技术服务与支持，请访问我们的技术支持网站：

http://support.advantech.com.cn

本手册适用于AIMC-3422系列。

Part No. 2001342200

中国印刷

第一版

2016年12月

2 AIMC-3422快速入门手册

看门狗定时器

• 可编程1~255 sec/min

电源

• 额定输出：AC 250W, ATX

• 输入电压：100 VAC ~ 240 VAC

冷却

• 系统风扇：2 (6cm / 27.7 CFM)

• 空气过滤器：有

环境

• 工作温度：0 ~ 40°C (32 ~ 104°F)

• 非工作温度：-20 ~ 60°C (-4 ~ 140°F)

• 工作湿度：10 ~ 85% @ 40°C，非凝结

• 非工作湿度：10 ~ 95% @ 40°C，非凝结

物理特性

• 尺寸(WxHxD)：232 x 90 x 232 mm

接口

接口功能

LPT1 并行端口，支持SPP/EPP/ECP模式

LAN1 Intel I219V

LAN2 Intel I211AT

VGA1 VGA接口

KBMS1 外部键盘/鼠标接口

COM12 RS-232*2排针

FP1 HDD LED、电源LED、SNMP SM_Bus、重

启、电源开关

JCASE1 机箱打开

CPUFAN1 CPU FAN接口（4针）

LANLED1 LAN1/2 LED接口

HDAUD1 HD音频扩展模块接口

USB1 USB接口1 (USB 3.0接口)

USB23 USB接口2、3 (USB 3.0接口)

USB45 USB接口4、5 (USB 2.0)

USB67 USB接口6、7 (USB 2.0)

USB89 USB接口8、9 (USB 2.0)

USB11 板载Type A接口 (USB 2.0)

SATA0 串行ATA1 (SATA 3.0)

SATA1 串行ATA2 (SATA 3.0)

SATA2 串行ATA3 (SATA 3.0)

SATA3 串行ATA4

CPU1 CPU插槽

DIMMA1 内存接口通道A

DIMMB1 内存接口通道B

GPIO1 GPIO排针

LPC1 低引脚数模块扩展排针

PWR1 12 V, 5 V电源接口

DVI1

DVI接口

DP1

显示排针，用于堆叠板卡（显示类型取决

于堆叠板卡）

EXPCIE1 mini PCIe排针，用于堆叠板卡

MINIPCIE MSATA

M-SATA（默认）或mini-PCIe接口

跳线

跳线功能

JCMOS1 清除CMOS

JWDT1+JOBS1 硬件监视器警报 + 看门狗第四期输

出选择

JME1 启用ME

JCMOS1: 清除CMOS

闭合针脚结果

1-2 保持CMOS（默认）

2-3 清除CMOS

JOBS1+JWDT1：硬件监视器警报 + 看门狗第四期输出选择

功能跳线设置

2-3 启用看门狗定时器（默认）

4-5 启用硬件监视器警报（默认）

JME1: 启用ME

闭合针脚结果

1-2 启用ME（默认）

2-3 禁用ME

1 2 3 4 5

1 2 3

跳线和接口（续）

产品规格

（续）

跳线和接口

AIMC-3422快速入门手册 3

AIMC-3422的驱动位于软件安装光盘中。请点击文件夹后并按

照屏幕指示进行操作。

注意！计算机配置了由电池供电的实时时钟电路，如果电

池更换不正确，将有爆炸的危险。因此，只可以

使用制造商推荐的同一种或者同等型号的电池进

行替换。请按照制造商的指示处理旧电池。

本品符合FCC规则第15款限制。操作符合下列两种情况：

1. 此设备不可产生干扰，且

2. 此设备必须接受任何干扰，包括可能导致非预期造作的

干扰。

软件安装

符合性声明

系统I/O接口

系统尺寸

units: mm(in)

Tabla de contenidos

Otros manuales de Hardware de computadora de Advantech

Advantech

Advantech ECU-150 Series Manual de usuario

Advantech

Advantech AMAX-4870 Manual de instalación y operación

Advantech

Advantech MIO-9290 Manual de usuario

Advantech

Advantech PCE-5133 Manual de instalación y operación

Advantech

Advantech PCA-6178VE Manual de usuario

Advantech

Advantech FWA-3033-00A1R Manual de instalación y operación

Advantech

Advantech UNO-2484G V2 Manual de usuario

Advantech

Advantech TREK-550-A00E Manual de usuario

Advantech

Advantech MIC-710AIL Manual de usuario

Advantech

Advantech PCA-6003 Manual de usuario

Advantech

Advantech PCA-6011 Manual de instalación y operación

Advantech

Advantech RSB-4221 Manual de usuario

Advantech

Advantech ASMB-H90 Manual de instalación y operación

Advantech

Advantech PCE-5B12-07 Manual de instalación y operación

Advantech

Advantech PCL-734 Manual de usuario

Advantech

Advantech PCE-5B05V-30B1E Manual de instalación y operación

Advantech

Advantech UNO-1251G Manual de usuario

Advantech

Advantech AMAX-5400 Series Manual de usuario

Advantech

Advantech PPC-IPS Manual de usuario

Advantech

Advantech PCE-5B06V-04A1E Manual de instalación y operación

Advantech

Advantech EVA-X4300 Manual de usuario

Advantech

Advantech AIMC-3421 Manual de instalación y operación

Advantech

Advantech SOM-9590 Manual de usuario

Advantech

Advantech MIC-3365 Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
