Advantech 3U Compact PCI Manual de usuario

MIC-3321

3U CompactPCI Pentium M

760 2.0G High-performance

Controller

User Manual

MIC-3321 User Manual ii

This document is copyrighted, 2004. All rights are reserved. The original

manufacturer reserves the right to make improvements to the products

described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated or

transmitted in any form or by any means without the prior written

permission of the original manufacturer. Information provided in this

manual is intended to be accurate and reliable. However, the original

manufacturer assumes no responsibility for its use, nor for any

infringements upon the rights of third parties which may result from its

use.

Acknowledgements

Award is a trademark of Award Software International, Inc.

Fast EtherChannel (FEC) is a trademark of Cisco Systems, Inc.

Intel, Pentium, and Celeron are trademarks of Intel Corporation.

Windows is a registered trademark of Microsoft Corporation.

NetWare is a trademark of Novell, Inc.

Symbios is a trademark of Symbios Logic Corporation.

PICMG, CompactPCI and the PICMG, and CompactPCI logos are trade-

marks of the PCI Industrial Computers Manufacturers Group.

All other product names or trademarks are properties of their respective

owners.

Part No. 2003332100 1st Edition

Printed in Taiwan June 2006

iii

Product Warranty

Advantech warrants to you, the original purchaser, that each of its

products will be free from defects in materials and workmanship for two

years from the date of purchase.

This warranty does not apply to any products which have been repaired or

altered by persons other than repair personnel authorized by Advantech,

or which have been subject to misuse, abuse, accident or improper instal-

lation. Advantech assumes no liability under the terms of this warranty as

a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous

testing, most of our customers never need to use our repair service. If an

Advantech product is defective, it will be repaired or replaced at no

charge during the warranty period. For out-of-warranty repairs, you will

be billed according to the cost of replacement materials, service time and

freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For

example, CPU speed, Advantech products used, other hardware and

software used, etc.) Note anything abnormal and list any onscreen

messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your manual,

product, and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return

merchandize authorization) number from your dealer. This allows us

to process your return more quickly.

4. Carefully pack the defective product, a fully-completed Repair and

Replacement Order Card and a photocopy proof of purchase date

(such as your sales receipt) in a shippable container. A product

returned without proof of the purchase date is not eligible for warranty

service.

5. Write the RMA number visibly on the outside of the package and ship

it prepaid to your dealer.

CE Notification

The MIC-3321, developed by Advantech CO., LTD., has passed the CE

test for environment specification when shielded cables are used for

external wiring and sleeve core clamps are added to the USB cables. We

recommend the use of shielded cables and sleeve core clamps.

MIC-3321 User Manual iv

Technical Support and Assistance

Step 1. Visit the Advantech web site at www.advantech.com/support

where you can find the latest information about the product.

Step 2. Contact your distributor, sales representative, or Advantech's cus-

tomer service center for technical support if you need additional

assistance. Please have the following information ready before

you call:

- Product name and serial number

- Description of your peripheral attachments

- Description of your software (operating system, version, appli-

cation software, etc.)

- A complete description of the problem

- The exact wording of any error messages

Packing List

Before setting up the system, check that the items listed below are

included and in good condition. If any item does not accord with the

table, please contact your dealer immediately.

• One MIC-3321 all-in-one single board computer

• One utility CD-ROM

• This user’s manual

If any of these items are missing or damaged, contact your distributor or

sales representative immediately.

Safety Precaution - Static Electricity

Follow these simple precautions to protect yourself from harm and the

products from damage.

1. To avoid electrical shock, always disconnect the power from your

PC chassis before you work on it. Don't touch any components on

the CPU card or other cards while the PC is on.

2. Disconnect power before making any configuration changes. The

sudden rush of power as you connect a jumper or install a card may

damage sensitive electronic components.

v Table of Contents

Contents

Chapter 1 Hardware Configuration ................................ 2

1.1 Introduction ....................................................................... 2

1.2 Specifications .................................................................... 3

1.2.1 Standard SBC Functions ................................................ 3

1.2.2 Display ........................................................................... 4

1.2.3 Mechanical and Environmental Specifications .............. 4

1.3 Function Block Diagram ................................................... 4

Figure 1.1:MIC-3321 Function Block Diagram ............ 4

1.4 Board Dimensions ............................................................. 5

Figure 1.2:MIC-3321 Board Dimensions ...................... 5

1.5 Dip Switch Settings........................................................... 5

1.5.1 Switch Locations ............................................................ 6

Table 1.1:MIC-3321 Switch Descriptions ..................... 6

Figure 1.3:MIC-3321 S1 Location (1F) ......................... 6

Figure 1.4:MIC-3321 S2 Location (2F) ......................... 7

1.6 Safety Precautions ............................................................. 7

Chapter 2 Connecting Peripherals ................................ 10

2.1 Connectors....................................................................... 10

Figure 2.1:MIC-3321 Connector Locations (1F) ......... 10

Figure 2.2:MIC-3321 Connector Locations (2F) ......... 10

Figure 2.3:MIC-3521 Connectors ................................ 11

Table 2.1:MIC-3321 Connectors Overview ................ 12

2.2 Card Installation .............................................................. 13

Figure 2.4:Chassis Installation/Removal ..................... 14

Chapter 3 Software Configuration ................................ 16

3.1 Overview ......................................................................... 16

3.2 Utilities and Drivers ........................................................ 16

3.2.1 Intel Chipset Software Installation Utility ................... 16

3.2.2 Intel VGA Graphics Driver .......................................... 16

3.2.3 Intel Gigabit LAN Driver ............................................ 16

Chapter 4 Award BIOS Setup........................................ 18

4.1 Introduction ..................................................................... 18

Figure 4.1:Setup Program Initial Screen ...................... 18

4.2 Entering Setup ................................................................. 18

4.2.1 Standard CMOS Setup ................................................. 19

Figure 4.2:Standard CMOS Setup Screen. .................. 19

4.2.2 Advanced BIOS Features Setup .................................. 20

Figure 4.3:Advanced BIOS features setup screen ....... 20

4.2.3 Advanced Chipset Features Setup ............................... 24

Figure 4.4:Advanced Chipset Features setup screen ... 24

4.2.4 Integrated Peripherals .................................................. 26

Figure 4.5:Integrated Peripherals Setup ....................... 26

MIC-3321 User Manual vi

4.2.5 PNP/PCI Configuration Setup ..................................... 29

Figure 4.6:PNP/PCI configuration screen ................... 29

4.2.6 PC Health Status .......................................................... 30

Figure 4.7:PC Health Status setup screen .................... 31

4.2.7 Spread Spectrum Control ............................................ 32

Figure 4.8:PC Health Status setup screen .................... 32

4.2.8 Load Optimized Defaults ............................................. 32

4.2.9 Set Password ................................................................ 33

4.2.10 Save & Exit Setup ........................................................ 34

4.2.11 Exit Without Saving ..................................................... 34

Appendix A Watchdog Timer Programming................... 36

Appendix B Pin Assignment .............................................. 38

Table B.1:MIC-3321 Connectors Overview ................ 38

B.1 CompactFlash Interface................................................... 39

Table B.2:CompactFlash Interface Pin Definitions ..... 39

B.2 USB 2.0 Ports.................................................................. 40

Table B.3:USB 1.1 Ports Pin Definitions .................... 40

B.3 VGA Connector............................................................... 40

B.4 COM port ........................................................................ 41

Table B.4:COM Port Pin Definitions .......................... 41

B.5 PS/2 Keyboard and Mouse Connector ............................ 41

Table B.5:PS/2 Keyboard & Mouse Port Pins ............. 41

B.6 Ethernet 10/100/1000Base-T RJ-45 Connector .............. 42

Table B.6:Ethernet Connector Definitions .................. 42

B.7 Secondary IDE 44-pin 2mm Conn. ................................. 42

Table B.7:Secondary IDE Connectors (2.5" HDD) ..... 43

B.8 Serial ATA0 (7pin connector)......................................... 44

CHAPTER

Hardware

Configuration

MIC-3321 User Manual 2

Chapter 1 Hardware Configuration

1.1 Introduction

MIC-3321 is a 3U, all-in-one, controller board, compliant with PICMG

2.0 R2.1 CompactPCI specifications. For high computing performance,

MIC-3321 uses an Intel Pentium M 760 2.0GHz CPU and Intel 915GM

chipset. This CPU provides high performance with its on-chip 2 MB L2

cache and is delivered in a Micro-FCBGA 479 package.

MIC-3321 offers powerful functions on a 3U-sized board for perfor-

mance-demanding applications like real-time machine control and indus-

trial automation.

Compact Mechanical Design

In order to decrease the thermal effect, Advantech provides a heat sink

specially designed for the MIC-3321, so it only needs external cooling air

from the chassis fans for ventilation.

Ordering Information

• MIC-3321S: Pentium M 2.0GHz, 2Mbyte L2 cache,512Mbyte

soldered DDR2 SDRAM, 4HP width

• MIC-3321: Pentium M 2.0GHz, 2Mbyte L2 cache,512Mbyte

soldered DDR2 SDRAM, 8HP width

• MIC-3321CS: Celeron M 1.0GHz, 512Kbyte L2 cache,512Mbyte

soldered DDR2 SDRAM, -25~70° C, 4HP width

• MIC-3321C: Celeron M 1.0GHz, 512Kbyte L2 cache, 512Mbyte

soldered DDR2 SDRAM, -25~70°c, 8HP width

• MIC-3321LS: Celeron M 800MHz, 0Kbyte L2 cache,

256Mbyte soldered DDR2 SDRAM, 4HP width

• MIC-3521-AE: Rear I/O Transition Board for MIC-3321 series

3 Chapter1

1.2 Specifications

1.2.1 Standard SBC Functions

• CPU: MIC-3321 supports Intel Pentium M 2.0 GHz

• Optional: Celeron M 1.0GHz/ Celeron M 800MHz (non cache)

• BIOS: Award 4 Mb flash memory

• Chipset: Intel 915GM Graphics and Memory Controller Hub (GMCH)

Intel 82801FBM I/O Controller Hub (ICH6M)

• System Memory:

Directed Soldered 512MB DDR2 533 SDRAM (MIC-3321/3321S)

Directed Soldered 512MB DDR2 400 SDRAM (MIC-3321C/3321CS)

Directed Soldered 256MB DDR2 400 SDRAM (MIC-3321LS)

Max:1GB

• P-IDE: One Channel IDE CompactFlash socket type II*1(select mas-

ter/slave DIP-SW), UltraDMA/100/66/33*a (2.5"HDD)

• SATA: One external SATA Connector

• Serial Ports: Two RS-232 ports with 16C550UARTs (or compatible)

with 16-byte FIFO buffer. One Front I/O, the other Rear I/O.

• Keyboard and PS/2 Mouse Connector: One 6-pin mini-DIN connec-

tor is located on the mounting bracket for easy connection to a key-

board or PS/2 mouse.

• USB Port: Four USB2.0 Channels up to 480MB, 2 front I/O, 2 rear I/O

• PCI-to-PCI Bridge: PERICOM P17C8150-32-bit/33MHz Compact-

PCI interface

• Watchdog Timer: Provides system reset and software control. Time

interval is programmable from 1 to 255 seconds/minutes.

• Ethernet LAN: 10/100/1000Base-TX Gigabit Ethernet

• Controller Chips: Two Intel 825723E/L PCI Express Gigabit Ethernet

Controllers support Pre-boot Execution Environment(PXE).

• Battery-backup RAM: 512 KB

• Input /Output Bus Interface: PCI 2.2 compliant, 32 bit/33 MHz

• CompactPCI Compliance: PICMG 2.1 CompactPCI Hot Swap R3.0

MIC-3321 User Manual 4

1.2.2 Display

• Controller: Intel Graphics Media Accelerator 900

• VRAM: DVMT3.0 128MB

• Resolution: Up to 2048x1536 with 32-bit color at 75Hz

1.2.3 Mechanical and Environmental Specifications

• Board Size (W x H) : 160 x 100 mm (3U)

• Operating Temperature:0 ~ 50° C (MIC-3321 Pentium M 2.0GHz)

0~50° C (MIC-3321LS Celeron M 800MHz)

-25 ~ 70° C (MIC-3321C Celeron M 1.0G)

• Storage Temperature: -40 ~ 80° C

• Board Weight: 0.6 kg

1.3 Function Block Diagram

Figure 1.1: MIC-3321 Function Block Diagram

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de computadora de Advantech

Advantech

Advantech RSB-4221 Manual de usuario

Advantech

Advantech SOM-6894 Manual de usuario

Advantech

Advantech EWM-W192 Series Manual de usuario

Advantech

Advantech MIC-7 Series Manual de instalación y operación

Advantech

Advantech SOM-6883 Manual de usuario

Advantech

Advantech PCA-6011 Manual de instalación y operación

Advantech

Advantech MIO-9290 Manual de usuario

Advantech

Advantech ARK-1551 Manual de usuario

Advantech

Advantech PCE-5B05V-30B1E Manual de instalación y operación

Advantech

Advantech PCL-841 Series Manual de usuario

Advantech

Advantech PCA-6144S Manual de usuario

Advantech

Advantech PCA-6108P6 Manual de instalación y operación

Advantech

Advantech ASMB-822I Manual de usuario

Advantech

Advantech AIMB-707 Manual de instalación y operación

Advantech

Advantech IPC-610B Manual de usuario

Advantech

Advantech FWA-1211 Manual de instalación y operación

Advantech

Advantech VEGA-2002 Manual de usuario

Advantech

Advantech PCM-26D1DB Manual de instalación y operación

Advantech

Advantech MIC-3820 Manual de instalación y operación

Advantech

Advantech EIS-D210 Manual de usuario

Advantech

Advantech PCM-26R1EC Manual de usuario

Advantech

Advantech SOM-5883 Manual de usuario

Advantech

Advantech PCA-6136 Manual de usuario

Advantech

Advantech Watchdog Timer UNO-2171 Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
