Advantech MIC-3820 Manual de instalación y operación

MIC-3820 Startup Manual 1

Before installation, please ensure that the following items

have been included in your shipment:

1. 1 x MIC-3820-A1S1

2. 4 x Screws M3x4L S/S D

If any of the above items are missing or damaged, contact

your distributor or sales representative immediately.

Note : Acrobat Reader is required to view any PDF le.

Acrobat Reader can be downloaded at: www.

adobe.com/Products/acrobat/readstep2. html

(Acrobat is a trademark of Adobe)

MIC-3820

3U CompactPCI®Serial SATA Carrier Board

Startup Manual

Standard Functions

• Backplane Interface: SATA3.0

• Accommodate model: 2.5” SATA SSD/HDD

• Power: +12: VPower consumption depending on plugged

module, supports up to 75W

Mechnical and Environment

• Dimensions (W x H x D): 160.00 x 100.00 mm (6.30” x

3.95”)

• Non-Operate temperature: -40 ~ 85 °C (-40 ~ 185 °F)

• Operating temperature (depending on module): -40 ~

85 °C (-40 ~ 185 °F)

• Operating Humidity: 95% @ 40 °C, non-condensing

• Non-Operate Humidity: 95% @ 60 °C, non- condens-

ing

• Vibration (5~500 Hz): 2.0 Grms (without HDD/SSD

module)

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/epc

For technical support services, please visit our support

website at:

http://support.advantech.com

This manual is for the MIC-3820-A1S1.

Part No. 2041382000

Printed in China

Edition 1

August 2022

Specications

2 MIC-3820 Startup Manual

Pin Number Net Name Pin Type Pin Number Net Name Pin Type

A1 +12V_HOT I B1 NC

A2 GND B2 SMB_CLK I

A3 NC B3 NC

A4 GND B4 USB_H_P+ I/O

A5 PCIE_TX+ O B5 PCIE_TX- O

A6 GND B6 NC

Pin Number Net Name Pin Type Pin Number Net Name Pin Type

C1 GND D1 +12V_HOT I

C2 SMB_DAT I/O D2 GND

C3 GA0 D3 NC

C4 USB_H_P- I/O D4 GND

C5 GND D5 PCIE_RX+ I

C6 NC D6 GND

Pin Number Net Name Pin Type Pin Number Net Name Pin Type

E1 +12V_HOT I F1 GND

E2 NC F2 NC

E3 NC F3 GA1 I

E4 PCIE_CLK+ I F4 PCIE_CLK- I

E5 PCIE_RX- I F5 GND

E6 NC F6 NC

Pin Number Net Name Pin Type Pin Number Net Name Pin Type

G1 +12V_HOT I H1 +12V_HOT I

G2 GND H2 RESET# I

G3 SDI_L I H3 N/A I

G4 GND H4 P_SATA_RX+ I

G5 NC H5 NC

G6 GND H6 NC

Pin Number Net Name Pin Type Pin Number Net Name Pin Type

I1 GND J1 +12V_HOT I

I2 WAKE_OUT# I J2 GND

I3 GA2 I J3 SCLK0 I

I4 P_SATA_RX- I J4 GND

I5 GND J5 NC

I6 NC J6 GND

Pin Number Net Name Pin Type Pin Number Net Name Pin Type

K1 +12V_HOT I L1 GND

K2 PCIE_EN# I L2 NC

K3 SLOAD0 I L3 GA3 I

K4 P_SATA_TX+ O L4 P_SATA_TX- O

K5 NC L5 GND

P1PinDenition

MIC-3820 Startup Manual 3

K6 NC L6 NC

165.13±0.3

177.43±0.3

00.001

0.0+

3.0-

19.98

64.511

09.1

06.1

58.61

P1PinDenition(Cont.)

Block Diagram

Dimension Diagram

4 MIC-3820 Startup Manual

1. Remove the hand screw (Figure 1)

2. Pull out SSD holder bracket (Figure 2)

3. Put the SSD/HDD model in holder bracket. (Figure 3)

4. Push the bracket through the front panel into carrier board.(Figure 4)

5. Lock the hand screw .(Figure 5)

Figure 1 Figure 2

Figure 3 Figure 4

Figure 5

Model Installation
