Aaeon FSB-866G Manual de usuario
Full-size CPU Card FSB-866G
FSB-866G
Intel®Pentium®4/Celeron®-D
PICMG, Full-size CPU Card
With DDR, Ethernet,
CompactFlash
™
FSB-866G Rev. A Manual 1st Ed.
Aug. 2005
Full-size CPU Card FSB-866G
i
Copyright Notice
This document is copyrighted, 2005. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
Full-size CPU Card FSB-866G
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
Award is a trademark of Award Software International, Inc.
CompactFlash™is a trademark of the Compact Flash
Association.
Intel®, Pentium®4, and Celeron®D are trademarks of Intel®
Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
SoundBlaster is a trademark of Creative Labs, Inc.
Please be notified that all other products’ name or trademarks
not be mentioned above are properties of their respective
owners.
Full-size CPU Card FSB-866G
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 FSB-866G CPU Card
• 1 Floppy Cable
• 1 ATA-100 Cable
• 1 USB Cable
• 1 Keyboard Cable
• 1 Serial + Parallel Cable
• 1 Serial Cable
• 1 ATX Cable
• 4 Serial ATA Cable
• 1 CPU cooler. Fan for LGA 775 Pentium®4
• 1 Quick Installation Guide
• 1 CD-ROM for manual (in PDF format) and drivers
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.
Full-size CPU Card FSB-866G
iv
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Feature......................................................................1-4
1.3 Specification..............................................................1-5
Chapter 2 Quick Installation Guide
2.1 Safety Precautions....................................................2-2
2.2 Location of Connectors and Jumpers .......................2-3
2.3 Mechanical Drawing..................................................2-4
2.4 List of Jumpers..........................................................2-5
2.5 List of Connectors .....................................................2-6
2.6 Setting Jumpers ........................................................2-8
2.7 Clear CMOS (JP1) ....................................................2-9
2.8 Front panel Connector (FP1) ....................................2-9
2.9 Front panel Connector (FP2) ....................................2-9
2.10 RS-232 Serial Port Connector (COM1)...................2-10
2.11 RS-232/422/485 Serial Port Connector (COM2).....2-10
2.12 IrDA Connector (IR1)...............................................2-10
2.13 LPT Port Connector (LPT1) ....................................2-11
2.14 USB Connector (USB1~3) ......................................2-11
2.15 Fan Connector (FAN1)............................................2-12
2.16 ATX Power Control Connector (CN1).....................2-12
2.17 LAN LED Connector (CN2, CN4)............................2-12
Full-size CPU Card FSB-866G
v
2.18 AC97 Connector (CN6)...........................................2-12
2.19 PS/2 Keyboard & Mouse Connector (CN7) ............2-13
2.20 Internal Keyboard Connector (CN8)........................ 2-13
2.21 PCI Express Connector (CN9) ..............................2-13
Chapter 3 CPU, Heatsink and Fan Installation
3.1 CPU Installation and motherboard handling.............3-2
Chapter 4 Award BIOS Setup
4.1 System Test and Initialization. ..................................4-2
4.2 Award BIOS Setup.................................................... 4-3
Chapter 5 Driver Installation
5.1 Installation.................................................................5-3
Appendix A I/O Information
A.1 I/O Address Map.................................................. A-2
A.2 1st MB Memory Address Map ................................A-3
A.3 IRQ Mapping Chart................................................A-4
A.4 DMA Channel Assignments...................................A-5
Appendix B Programming The Watchdog Timer
B.1 Programming .........................................................B-2
B.2 W83627EHG Watchdog Timer Initial Program......B-6
Full-size CPU Card FSB-866G
Chapter1GeneralInformation 1- 1
General
Chapter
1
Information
Full-size CPU Card FSB-866G
Chapter 1 General Information 1 - 2
1.1 Introduction
The FSB-866G utilizes Intel®LGA 775 Pentium®4 CPUs with high
CPU core frequencies up to 3.8GHz with the Front Side Bus (FSB)
running at 533 to 800MHz. Moreover, this model supports dual
channel DDR memory (DDR333/400) providing a maximum
capacity up to 2GB. The VGA controller of FSB-866G is an
integrated GMA900 2D/3D Graphics Accelerator inside the Intel
915GV chipset which enhances VGA performance capability, with a
core frequency up to 333MHz. The chipset is in Intel’s embedded
roadmap that helps ensure this model’s continued production.
In addition to the powerful computing engine, the FSB-866G comes
with seven USB 2.0 ports, one Keyboard and Mouse connector,
one standard FDD port, one IrDA header, CompactFlash™Type II
socket and Ultra ATA100 & SATA channels. This full-function
design makes the FSB-866G a cost-effective industrial CPU card,
ideal for system integrators.
The FSB-866G is also equipped with a PCI-Express LAN control IC,
Marvell 88E8036/88E8053, for supporting 2 10/100 Mb or
full-speed Giga LANs. This flexible feature provides networking
access abilities for high-speed applications such as gateway, VPN,
and Mini-server.
Full-size CPU Card FSB-866G
Chapter 1 General Information 1 - 3
The AAEON FSB-866G full-size CPU card is designed to fulfill the
requirements of tough applications that demand high speed and
stable computing performance. We strongly recommend you to
adopt this leading-edge model – high performance FSB-866G as
one of your integration solutions.
Full-size CPU Card FSB-866G
Chapter 1 General Information 1 - 4
1.2 Features
• Support Intel®Pentium®4 / Celeron®-D CPU up to
3.8GHz
• DDR 333/400 memory support up to 2GB
• Integrated GMA900 2D/3D Graphics Accelerator,
VGA supports
• Integrated AC-97 Codec Audio (Daughter Board
optional)
• 2 PCI-express Connectors Can Support 2 Full-speed
Gigabit LANs
• Supports 4 Full-speed Gigabit LANs (optional)
• Supports Ultra ATA100 & SATA & CompactFlashTM
Type-II Storage
• 4 SATA Connectors support 4 SATA devices
• 1 IDE Slot supports 2 IDE devices
• Adding ITE8211 up can support 3 IDE slots (optional)
• 7 USB2.0/ 1 RS-232, 1 RS-232/422/485/ 1 Parallel/ 1
IrDA Port
• Watchdog Function 1~255 sec.
