Aaeon PCM-8500 Manual de usuario

PCM-8500

Socket 478 based Pentium®4

/ Pentium®4Processor-M

/ Celeron®Processors

Compact Board

With LCD, Ethernet, USB &

PCMCIA / Mini PCI

PCM-8500 Rev. A Manual

Oct. 2003

Compact Board PCM-8500

This document is copyrighted, 2003. All rights are reserved. The original

manufacturer reserves the right to make improvements to the products

described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or transmitted

in any form or by any means without the prior written permission of the

original manufacturer. Information provided in this manual is intended to be

accurate and reliable. However, the original manufacturer assumes no

responsibility for its use, or for any infringements upon the rights of third

parties that may result from its use.

The material inthis document is for product information only and is subject

to change without notice. While reasonable efforts have been made in the

preparation of this document to assure its accuracy, AAEON assumes no

liabilities resulting from errors or omissions in this document, or from the

use of the information contained herein.

AAEON reserves the right to make changes in the product design without

notice to its users.

Compact Board PCM-8500

Acknowledgments

All other products’name or trademarks are properties of their respective

owners.

lAward is a trademark of Award Software International, Inc.

lCompactFlash™is a trademark of the Compact Flash Association.

lIntel® ,Pentium®4 /4 Processor-M and Celeron® are trademarks of

Intel® Corporation.

lMicrosoft Windows®is a registered trademark of Microsoft Corp.

lITE is a trademark of Integrated Technology Express, Inc.

lIBM, PC/AT, PS/2, and VGA are trademarks of International Business

Machines Corporation.

Compact Board PCM-8500

iii

Packing List

Before you begin installing your card, please make sure that the

following materials have been shipped:

•1 PCM-8500 Compact Board

•1 Quick Installation Guide

•1 CD-ROM for manual (in PDF format) anddrivers

•1 Jumper Cap

If any of these itemsshould bemissing or damaged, please contact your

distributor or sales representative immediately.

Compact Board PCM-8500

Contents

Chapter 1 General Information

1.1Introduction..................................................................................1-2

1.2Features .........................................................................................1-4

1.3Specifications ................................................................................1-5

Chapter 2 Quick Installation Guide

2.1 Safety Precautions........................................................................2-2

2.2 Location of Connectors and Jumpers........................................2-3

2.3 Mechanical Drawing.....................................................................2-5

2.4 List of Jumpers .............................................................................2-7

2.5 List of Connectors........................................................................2-8

2.6 Setting Jumpers.............................................................................2-9

2.7 Clear CMOS (JP1)........................................................................2-10

2.8 Audio Out Select (JP2) ................................................................2-10

2.9COM2 Ring/＋5V/＋12V Selection (JP3)...............................2-10

2.10 COM2 RS-232/422/485 Select (JP4＆JP5)............................2-11

2.11 ATX Power simulate AT Power (JP6).....................................2-11

2.12 LCD Voltage Selection (JP7) ....................................................2-11

2.13 IDE Connector (CN1)...............................................................2-12

2.14 CompactFlash Connector (CN2) .............................................2-13

2.15 USB1 Connector(CN3) ............................................................2-14

2.16 USB2 Connector(CN4) ............................................................2-14

2.17 USB3 Connector(CN5) ............................................................2-14

Compact Board PCM-8500

2.18 Audio 5.1 Channel/SPDIF Connector (CN6)........................2-15

2.19 Audio Connector(CN7)............................................................2-15

2.20 Fan Connector (CN8＆CN24).................................................2-16

2.21 LAN LED Connector (CN10) .................................................2-16

2.22 10/100Base-TX Ethernet Connector (CN10)........................2-16

2.23 Option PME Connector (CN12)..............................................2-17

2.24 FloppyConnector (CN13)........................................................2-17

2.25 LPT Port Connector (CN14)....................................................2-18

2.26 IrDAConnector (CN15)...........................................................2-18

2.27 COM1~4 RS-232/422/485 Serial Port Connector(CN16)..2-19

2.28 PS2 Keyboard/Mouse Connector(CN17)..............................2-20

2.29 Digital I/O-2Connector (CN18).............................................2-21

2.30 Digital I/O-1Connector (CN26).............................................2-22

2.31 TV Out Connector (CN19).......................................................2-23

2.32Channel1 LVDS Connector (CN20)........................................2-23

2.33Channel2 LVDS Connector (CN21)........................................2-24

2.34VGA Display Connector (CN22).............................................2-24

2.35Front Panel (CN25)...................................................................2-25

2.36 ATX Power Connector (CN27) ...............................................2-25

2.27 ATX Power 12V Connector (CN28).......................................2-25

Chapter 3 Award BIOS Setup

3.1 System Test and Initialization.....................................................3-2

3.2 Award BIOSSetup.......................................................................3-3

3.3 Standard CMOS Features ............................................................3-6

3.4 Advanced BIOS Features ............................................................3-7

Compact Board PCM-8500

3.5 Advanced Chipset Features.........................................................3-8

3.6 Integrated Peripherals..................................................................3-9

3.7 Power management Setup...........................................................3-10

3.8 PnP/PCI configuration ...............................................................3-11

3.9 PC Health Status...........................................................................3-12

3.10Frequency/Voltage control........................................................3-13

3.11Load Fail-Safe Defaults ..............................................................3-14

3.12Load Optimized Defaults...........................................................3-14

3.13Set Supervisor/User Password ..................................................3-14

3.14Save＆Exit Setup.........................................................................3-15

3.15Exit without saving......................................................................3-15

Chapter 4 Driver Installation

4.1 Installation 1..................................................................................4-3

4.2 Installation 2..................................................................................4-5

Appendix A Programming the WatchDog Timer

A.1 Watchdog timer ......................................................................A-2

A.2 Configuring sequence description........................................A-2

A.3 ITE8712 Watchdog timer initial program ...........................A-5

Compact Board PCM-8500

Chapter 1 General Information 1-1

General

Information

Chapter

Compact Board PCM-8500

Chapter 1 General Information

1.1 Introduction

PCM-8500 is first Pentium® 4 industrial board in AAEON Compact

Board product line. It features a PGA478 socket that can

accommodate Pentium® 4 / Pentium® 4 Processors-M and

Celeron® Processor, supporting FSB up to 400/533MHz.

Best performance for multimedia solution

AAEON's PCM-8500 also supports DDR DRAM up to1GB, 4X

AGP, and 6 channels audio output. It can provide the strong

multimedia functions. Therefore PCM-8500 can be broadly

implemented in several markets, such as Point of sale, point of

information (Kiosk), and gaming markets.

Multi-Function Pentium4 Platform

If you are looking for powerful multi-media applications,

PCM-8500 is the one. PCM-8500 successfully integrates VGA,

Audio and Ethernet function into 5.75” size board; meanwhile

it also supports 6 USB2.0, mini PCI, and PCMCIA (optional

item) slots. PCM-8500 promises you the greatest expansion

possibilities with the most cost-effective expansion standards,

PCMCIA or Mini PCI. Withnumerous off-the-shelf

PCMCIA/Mini PCI modules, you get easy access to solutions

ranging from IEEE 1394, Modem, Storage, Sound Card, SCSI

card, Audio/Video capture card, Wireless LAN module, to

Compact Board PCM-8500

Chapter 1 General Information

Bluetooth module. Especially for customers whom application

is various or changing, PCM-8500 reserves more than enough

flexibility for future expansion.

PCM-8500 provides more CPU optionsfor different applications.

You can choose Pentium® 4 processor up to 3.06G for high

performance application or choose Pentium® 4 processor-M for

thermal concerned operative environment. Low-cost Socket 478

Celeron processors are also supported by PCM-8500 for

cost-intensive projects. Most of all Pentium® 4 Level processors are

suitable for PCM-8500. Talking about the display signal transmission,

PCM-8500 integrated 48-bit dual channel LVDS interface onboard,

which allows long distance display signal transmission. Besides LCD

supports, PCM-8500 also allows customer to show different contents

on CRT and LCD at same time. It meets multi-display demand at

most cost-efficient way.
