Aaeon GENE-6310 Manual de usuario

GENE-6310

VIA Eden/ Ezra EBGA

SubCompact Board

With LCD, LVDS, Ethernet,

TV-out & Audio

GENE-6310 Rev. A Manual

July. 2003

SubCompact Board GENE-6310

This document is copyrighted, 2003. All rights are reserved. The original

manufacturer reserves the right to make improvements to the products

described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or

transmitted in any form or by any means without the prior written

permission of the original manufacturer. Information provided in this

manual is intended to be accurate and reliable. However, the original

manufacturer assumes no responsibility for its use, or for any in-

fringements upon the rights of third parties that may result from its use.

The material inthis document is for product information only and is

subject to change without notice. While reasonable efforts have been

made in the preparation of this document to assure its accuracy,

AAEON assumes no liabilities resulting from errors or omissions in this

document, or from the use of the information contained herein.

AAEON reserves the right to make changes in the product design

without notice to its users.

SubCompact Board GENE-6310

Acknowledgments

All other products’name or trademarks are properties of their respective

owners.

lAward is a trademark of Award Software International, Inc.

lCompactFlash™is a trademark of the Compact Flash Association.

lVIA Edenis a trademark of VIA Technology Inc.

lMicrosoft Windows®is a registered trademark of Microsoft Corp.

lPC/AT, PS/2, and VGA are trademarks of International Business

Machines Corporation.

SubCompact Board GENE-6310

iii

Packing List

Before you begin installing your card, please make sure that the

following materials have been shipped:

•1 GENE-6310 All-In-One Single Board Computer

•1Hard disk drive (IDE) interface cable

•1Floppy disk drive interface cable

•16-pin mini-DIN dual outlet adapter for keyboard and PS/2

•1Parallel port mouse & serial portadapter kit

•1USB cable with bracket

•1Audio and 3 RCA jack cables with 4-pin CDIN connector

•1TV-out 8-pin cable with a RCA Jack & S-terminal

•1Accessory for all series jumper

•1Quick Installation Guide

•1Utility CD-ROM

If any of these itemsshould bemissing or damaged, please contact your

distributor or sales representative immediately.

SubCompact Board GENE-6310

Contents

Chapter 1 General Information

1.1Introduction..................................................................................1-2

1.2Features .........................................................................................1-3

1.3Specifications ................................................................................1-4

Chapter 2 Quick Installation Guide

2.1 Safety Precautions........................................................................2-2

2.2 Location of Connectors and Jumpers........................................2-3

2.3 Mechanical Drawing.....................................................................2-5

2.4 List of Jumpers .............................................................................2-7

2.5 List of Connectors........................................................................2-8

2.6 Setting Jumpers.............................................................................2-9

2.7 LCD Voltage (JP1).......................................................................2-10

2.8 RS-232, RS-422 and RS-485 Select (JP2 & JP3).......................2-10

2.9 PC/104 + Power I/O(JP4)........................................................2-10

2.10 Clear CMOS (JP5)......................................................................2-10

2.11 LCD Shift Clock Select (JP6)....................................................2-11

2.12 Hard DriveConnector (CN1)...................................................2-11

2.13 TV-out Connector (CN2)..........................................................2-13

2.14 Fan Connector (CN3)................................................................2-13

2.15 TTL LCD Connector (CN4, CN5)..........................................2-13

2.16 Floppy Drive Connector (CN6) ...............................................2-15

2.17 Front Panel Connector (CN7)..................................................2-15

SubCompact Board GENE-6310

2.18 LVDS Channel 1 Connector(CN11).......................................2-16

2.19 LVDS Channel 2 Connector(CN8).........................................2-16

2.20 Serial Port/ COM 2(CN9) .......................................................2-17

2.21 Parallel Port Connector (CN10) ...............................................2-17

2.22 Audio Connector (CN13)..........................................................2-18

2.23 100 Base-T Ethernet Connector(CN14).................................2-18

2.24 Power Connector (CN15).........................................................2-19

2.25 USB Connector (CN16, CN17)................................................2-19

2.26 Serial Port/ COM 1 (CN18).....................................................2-20

2.27 IrDA Connector(CN19)...........................................................2-20

2.28 PS/2 Keyboard and Mouse Connector (CN20).....................2-21

2.29 VGA Connector (CN21)...........................................................2-21

2.30 CompactFlash Connector (CN22)...........................................2-22

2.31PME# Connector for PCM-3794(CN23)...............................2-23

Chapter 3 Award BIOS Setup

3.1 System Test and Initialization.....................................................3-2

3.2 Award BIOSSetup.......................................................................3-3

3.3Standard CMOS Features ............................................................3-6

3.4Advanced BIOS Features ............................................................3-7

3.5Advanced Chipset Features.........................................................3-8

3.6Integrated Peripherals..................................................................3-9

3.7Power management Setup...........................................................3-10

3.8PnP/PCI Configuration ..............................................................3-11

3.9PC Health Status...........................................................................3-12

3.10 Frequency/ Voltage control......................................................3-13

SubCompact Board GENE-6310

3.11 Load Fail-Safe Defaults.............................................................3-14

3.12 Load Optimized Defaults..........................................................3-14

3.13 Set Supervisor/ User Password ................................................3-14

3.14 Save & Exit Setup.......................................................................3-15

3.15 Exit without saving ....................................................................3-15

Chapter 4 Driver Installation

4.1 Installation 1..................................................................................4-3

4.2 Installation 2..................................................................................4-4

4.3Installation 3..................................................................................4-5

Appendix A Programming the WatchDog Timer

Programming the Watchdog timer..............................................A-2

SubCompact Board GENE-6310

Chapter 1 General Information 1-1

General

Information

Chapter

SubCompact Board GENE-6310

Chapter 1 General Information

1.1 Introduction

TheGENE-6310 is an all-in-one VIA EdenSeries processor based

single board computer (SBC) with an Integrated AGP 4X 2D/3D

Graphics Accelerator, an audio controller, a 10/100 Base-T Ethernet

Controller, Dual channel LVDS interface, and PC/104 plus

expansion capability. This compact (only 5.75”x 4”) unit offers all

the functions of a single board computer, but still fits in the space of

a FDD drive.

Onboard features include two serial ports (one RS-232, one

RS-232/422/485), one multi-mode parallel (ECP/EPP/SPP) port,

pin header for 4 USB (Universal Serial Bus) ports, a floppy drive

controller, and a keyboard/PS/2 mouse interface. The built-in high

speed IDE controller supports Ultra DMA-33 master mode. Up to

two IDE devices can be connected, including large hard disks,

CD-ROM drives, and tape backup drives, etc.

The GENE-6310 also features power management to minimize

power consumption. It complies with the APM standard and

supports three types of power saving features: HDD power down,

Doze mode, and Suspend mode. In addition, the board’s watchdog

timer can be programmed to reset the system or generate an interrupt

in case the system stops due to a program bug or SMI.

Highly Integrated Multi-media SBC

The GENE-6310 is a highly integrated multi-media SBC that

combines audio, video, and network functions on a FDD drive size

single board computer. It provides an AC-97 audio interface 2.0

version. Major onboard devices adopt PCI technology to achieve

outstanding computing performance when used with VIA Eden

(PentiumIII level) processors, making the GENE-6310 one of the

world’s smallest and most powerful all-in-one multimedia boards

SubCompact Board GENE-6310

Chapter 1 General Information

1.2Features

•3.5”FDD SubCompact Form Factor

•Supports VIA EdenCPU (400/667MHz) and VIA Ezra

CPU (800MHz)

•Integrated AGP 4X 2D/3D Graphics Accelerator

•Supports CRT and 36/18-bit TFT/DSTN panels

•Supports NTSC/PAL TV output

•Supports CompactFlashStorage

•Supports one 10/100 Base-T Fast Ethernet

•2 COMs/ 1 Parallel/ 4 USBs/ 1 IrDA Port

•5 volt only operation
