Zte Z6200 Manual de usuario

Z6200

Quick Start Guide

ZTE CORPORATION

NO. 55, Hi-tech Road South, Shenzhen, P.R.China

Postcode: 518057

Getting to Know Your OBD2 Device

Appearance

The following figure is for your reference only.

1. Reset hole

2. micro-SIM card slot

3. Restart key

4. LED 1

5. LED 2

6. OBD interface

4 5

Getting to Know Your OBD2 Device

Indicator lights

Indicator Status

Description

LED 1(Power)

Green

blinking Powered by the internal

battery.

Green

solid Powered by the vehicle

battery.

LED 2(Signal)

Red

solid Turn on but not register.

Green

solid Registered to the 4G

network.

Green

blinking

Connected to the 4G LTE

network and data is being

transferred.

NOTE:

The charging temperature should be lower than 60.

Installing the micro-SIM card

1. Use the tray eject tool to take out the card tray.

2. Put the micro-SIM card into the card tray and slip it into the

card slot.

WARNING!

To avoid damage to the phone, please do not use other kinds of

SIM cards, and do not use a non-standard micro-SIM card cut

from a SIM card. You can get the standard micro-SIM card from

your service provider.

3. Close the micro-SIM card cover.

Installing Your OBD2 Device

1. Make sure your vehicle is parked outside in a safe location

and the engine is turned off.

2. Find your Vehicle’s On-Board Diagnostics (OBD II) connector

port.

NOTES:

The OBD II port is usually located under the driver’s dash

side of your car, often within 18 inches of the steering

wheel (as 1 to 8 shown in the following picture).



If you’re having trouble locating your car’s OBD II port,

reference your vehicle’s manual.

3. Insert your Device into the vehicle’s OBD II port.

Connecting to Your OBD2 Device

Turning on Your OBD2 Device

Start your vehicle’s engine and let it run for at least 30 seconds.

Using Your Wi-Fi Devices

1. Find your OBD2 device's network name in your Wi-Fi device's

list of available wireless networks.

2. Select the Wi-Fi name (SSID) of your OBD2 device.

3. Input the password, and then tap Connect.

NOTE: Refer to the chapter

Getting to Know the Wi-Fi

SSID and Password

to get the default Wi-Fi SSID and

password.

Getting to Know the Wi-Fi SSID and

Password

You can view the label on the device to get the default Wi-Fi

SSID and password.

Logging in to the 4G Mobile

Hotspot Configuration Page

Use 4G Mobile Hotspot configuration on your Wi-Fi device to

manage settings.

1. Ensure that the connection between your OBD2 device and

the Wi-Fi device is correct.

2. Launch the Internet browser and enter http://192.168.0.1 in

the address bar.

3. Enter the username and password to log in to the 4G Mobile

Hotspot configuration page.

NOTE:The default password is admin.

Changing the Wi-Fi SSID and

Password

1. From the connected device, log in to the 4G Mobile Hotspot

configuration page.

2. Select Settings > Wi-Fi Settings.

3. Change the Network Name (SSID) and Password.

4. Click Apply.

Setting up Allowed Devices

Enable Allowed Devices to prevent other device from

connecting to the OBD2 device, only the MAC address listed in

the Allowed Devices Information section can access your OBD2

device.

1. From the connected device, log in to the 4G Mobile Hotspot

configuration page.

2. Select Settings > Wi-Fi Settings.

3. Set Allowed Devices Switch to On, and click Apply.

4. Enter the Nickname and MAC Address.

5. Click Apply.

NOTE: To prevent a device from reconnecting to your

OBD2 device, click Remove next to the device.

Accessing the Internet

After a client device is successfully connected to your device,

you can access the Internet in Automatic or Manual mode. The

default mode is Automatic.

Mode Operation

Automatic Your OBD2 device is automatically connected

to the Internet, and you can surf on the

Internet through the Wi-Fi device.

Manual 1. Log in to the 4G Mobile Hotspot

configuration page.

2. Select Home and click to

disconnect from the Internet.

3. Select Settings > Network Settings >

WAN Connection Mode > Manual, and

then click Apply.

4. Select Home and click to

connect to the Internet.

NOTE:

To modify the parameters of your device, log in to the 4G Mobile

Hotspot configuration page.

LEGAL INFORMATION

No part of this publication may be excerpted, reproduced, translated

or utilized in any form or by any means, electronic or mechanical,

including photocopying and microfilm, without the prior written

permission of ZTE Corporation.

The manual is published by ZTE Corporation. We reserve the right to

make modifications on print errors or update specifications without

prior notice.

Version No.: R1.0

Edition Time: July 1, 2016

Manual No.:

Getting More Help

You can get help by:



Sending an email to [email protected]



Visiting www.ztewelink.com
