Zte MF927U Manual de usuario
1
MF927U
Quick Start Guide
ZTE CORPORATION
NO. 55, Hi
-tech Road South, Shenzhen, P.R.China
Postcode: 518057
2
Getting to Know Your Device
Appearance
The following figure is for your reference only.
3
1. micro-SIM card tray
2.
Charging/micro-USB jack
3.
WPS key
Press and hold for 2 seconds to activate the WPS function.
4.
Power key
l Press and hold for about 2 seconds to power on/off your
device.
l Press and hold for about 10 seconds to power off your
device, if it is in abnormal status. And then press and hold
for about 2 seconds to power on your device again.
5.
Indicator lights
6.
Reset hole
Press and hold for 2 seconds to restore your device to the
factory settings.
4
Getting to Know Your Device
Indicator
lights
Indicator
Status
Description
Battery
Red solid /
blinking
The battery is low. Please
charge the battery.
Green
blinking
The battery is being charged.
Green solid
The battery level is middle or
high.
Light off
Your device is powered off
and not being charged.
Wi-Fi
Blue solid
Wi-Fi is active.
Blue
blinking
WPS is active.
Light off
Wi-Fi is off.
SMS
Blue solid
You have unread messages .
Blue
blinking
You have new messages or
the message storage is full.
Light off
There is neither an unread
message nor a new message.
5
Network
Red
The device is in error status.
l The device is not
registered to the mobile
network.
l There is no micro-SIM
card inserted.
l There is no network
service available.
Green solid
The device is registered to the
2G/3G mobile network.
Green
blinking
The device is connected to
the 2G/3G mobile network
and data is being transferred.
Blue solid
The device is registered to the
4G LTE network.
Blue
blinking
The device is connected to
the 4G LTE network and data
is being transferred.
6
Getting to Know Your Device
Connection Scenario
s
The device uses your
micro-SIM card to access the Internet. It
allows multiple clients to surf on the Internet at the same time.
The following figure is for your reference only.
7
Installing the micro-SIM Card
1.
Insert the tip of the tray eject tool into the hole.
2.
Pull out the card tray and place the micro-SIM card on the tray,
as shown. Carefully slide the tray back into place.
8
Connecting to Your Device
Using Wi
-Fi
1.
Power on your device.
2.
Ensure that your computer or other client devices have
enabled Wi-Fi, and search for available wireless networks.
NOTE:
Refer to your Wi
-Fi-enabled client device manual for further
details on how to
search for wireless networks. If you use a
computer, you need to s
et your computer to obtain an IP address
automatically
.
3.
Select the Wi-Fi name (SSID) of your device, and click
Connect.
4.
Enter the Wi-Fi password if necessary, and click OK.
NOTE:
Refer to
the chapter Getting to Know the Wi-Fi SSID and
Password
to get the default Wi-Fi SSID and password.
5.
Wait until the client device is connected to your device
successfully.
Using a USB Cable
1.
Connect a computer to your device with a USB cable.
2.
Power on your device. The operating system detects and
identifies new hardware, and automatically installs the
software.
9
NOTE:
If the system does not automatically launch installation, you can
double
-click the device installation icon in My Computer >
ZTEMODEM
to install the software.
3.
Wait until the computer is connected to your device
successfully.
10
Getting to Know the Wi-Fi SSID and
Password
You can
view the label on the device to get the default Wi-Fi SSID
and password.
