Zte MF971L Instrucciones de instalación

MF971L

Let’s go

Getting started with your device.

1

1. Prepare

yA valid micro-SIM card.

yView the label on your device to get the default



only.

2

2. Insert the micro-SIM Card

1. Take out the card sticker from the packing box.

2. Align the card sticker with the micro-SIM area on the

metal-free side of the micro-SIM card and then stick it.

3. Open the micro-SIM card slot cover.

NOTE:

Do not remove the cover rudely, because it is connected

with the device.

3

4. Insert your micro-SIM card.

WARNING!

To avoid damage to the device, do not use any other kind

of SIM cards, or any non-standard micro-SIM card cut from

a SIM card. You can get a standard micro-SIM card from

your service provider.

5. Close the micro-SIM card slot cover.

4

3. Start Your Device

Press and hold the Power key for about 1.5

seconds to power on the device. After a moment the device

will connect to the Internet automatically.

NOTE:

If the battery is extremely low, you may be unable to power



5

4. Access the Internet

yWi-Fi: Get the default SSID and password on the label

and connect to the Wi-Fi network with your mobile

device, and then access the Internet.

ymicro-USB cable: Connect with the computer via USB

port and then access the Internet.

NOTE:

If the operating system does not automatically launch

installation, you can double-click the device installation

icon in the virtual CD-ROM to install the software.

6

5. Change Your Device Settings

You can change the device settings by logging in to the



1. View the label on your device to get the default Device

Manager Website IP address and Password.

2. Launch the Internet browser. Enter the Device Manager

Website IP address in the Address bar.

3. Input the password and then click Login.

 

change the Wi-Fi SSID, password or other settings.

7

Indicator Icons and Interfaces

8

1 Power key

yPress and hold for about 1.5

󰀨

device.

yPress and hold for about 8

seconds to restart your device

2 WPS key Press and hold for 1.5 seconds to

activate the WPS function.

3 Battery Red solid / blinking: The battery is

low. Please charge the battery.

Green blinking: The battery is being

charged.

Green solid: The battery level is

middle or high.

󰀨󰀨

and not being charged.

Wi-Fi Blue solid: Wi-Fi is active.

Blue blinking: WPS is active.

󰀨󰀨

SMS Blue solid: You have unread

messages.

Blue blinking: You have new

messages or the message storage is

full.

󰀨

message nor a new message.
