Zte ZXHN H368C Manual de usuario

ZXHN H368C

ZTE CORPORATION

NO. 55, Hi-tech Road South, ShenZhen, P.R.China

Postcode: 518057

Tel: (86) 755 26771900

Fax: (86) 755 26770801

URL: http://ensupport.zte.com.cn

E-mail: [email protected]

ZXHN H368C

User’sManual

Document version: 2012-06-22 R1.0

No part of this documentation may be excerpted, reproduced,

translated, annotated or duplicated, in any form or by any

means without the prior written permission of ZTE

Corporation.

ZTE CORPORATION reserves the right to modify this manual

for product upgrade or other causes without notifying users in

advance.

Limited warranty

ZTE warrants that, for one year from the date of delivery by ZTE to

purchaser's designated carrier, the Equipment will remain free from

defects in design, material and workmanship under normal use and

service and will conform in all material respects to the applicable

specifications set forth in purchase order or agreement; ZTE does not

warrant that operation of the Equipment will be error-free or

uninterrupted.

In accordance with ZTE's standard, warranty terms, ZTE shall, at its

option, repair or replace any defective or nonconforming item, provided

that (a) purchaser/End User gives ZTE written notice of the defect or

nonconformity within the warranty period specified above promptly after

Reseller is notified by the End User of the same; and (b) End User

returns the defective item at its expense to ZTE’s nominated Customer

Service Department in accordance with ZTE’s standard parts exchange

procedures.

This warranty does not apply to defects or errors in the Equipment

caused by:(a) reasonable abrasion of equipments; (b)End User’s failure

to follow ZTE’s installation, operation or maintenance instructions or

procedures; (c) End User’s mishandling, misuse, negligence, or

improper installation, deinstallation, storage, servicing or operation of

the Equipment; (d) modifications or repairs not made by ZTE or a

ZTE-certified individual;(e) power failures, surges, fire, flood, accident,

actions of third parties or other events outside ZTE’s reasonable control.

(f) usage of products of third Parties, or usage conjunction with third

parties provided that such defects is due to the conjunction;(g) any

other cause beyond the range of normal usage for equipments. End

User shall assure that Equipment is installed and maintained by ZTE or

ZXHN H368C User’sManual

ZTE-certified individuals in accordance with ZTE’s certification

procedures; provided that if End User causes or permits services to be

provided by individuals who are not ZTE-certified, the Warranty shall be

void as to all Equipment serviced in breach of this sentence. End User

shall have no right to reject, return, or receive a refund for any

Equipment from ZTE. Any item repaired or replaced by ZTE shall

continue to be warranted for the longer of the remainder of the original

warranty period or 90 days from the date the repaired or replaced part

is delivered to the carrier.

THIS WARRANTY (1) IS END USER'S SOLE REMEDY AND ZTE’S

SOLE LIABILITY FOR DEFECTIVE OR NONCONFORMING ITEMS ,

AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED,

IMPLIED OR STATUTORY, INCLUDING BUT NOT LIMITED TO THE

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR

A PARTICULAR PURPOSE, UNLESS OTHERWISE REQUIRED

UNDER THE MANDATORY PROVISIONS OF THE CHINESE LAW,

AND (2) IS BETWEEN ZTE AND END USER (AS THE ORIGINAL

PURCHASER FOR END USE) AND MAY NOT BE TRANSFERRED

OR ASSIGNED, BY OPERATION OF LAW OR OTHERWISE,

WITHOUT ZTE’S PRIOR WRITTEN CONSENT.

Limitation of Liability

ZTE SHALL NOT BE LIABLE FOR ANY LOSS OF PROFITS OR

INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES

RESULTING FROM OR ARISING OUT OF OR IN CONNECTION

WITH USING OF THIS PRODUCT, WHETHER OR NOT ZTE HAD

BEEN ADVISED, KNEW OR SHOULD HAVE KNOWN OF THE

POSSIBILITY OF SUCH DAMAGES, INCLUDING, BUT NOT LIMITED

TO, LOST PROFITS, COST OF CAPITAL, COST OF SUBSTITUTE

FACILITIES OR EQUIPMENT, ANY DOWNTIME COSTS OR CLAIMS

ZXHN H368C User’s Manual

iii

OF END USERS. THE LIABILITY OF EACH PARTY UNDER THIS

AGREEMENT, WHETHER ARISING OUT OF BREACH OF

CONTRACT (INCLUDING BUT NOT LIMITED TO BREACH OF

WARRANTY) OR TORT (INCLUDING BUT NOT LIMITED TO

NEGLIGENCE AND STRICT LIABILITY) OR UNDER AN

INDEMNIFICATION PROVISION SHALL IN NO EVENT EXCEED THE

AGGREGATE AMOUNT BENIFITED BY ZTE IN THE PRODUCTS

FROM WHICH SUCH LOSS OR DAMAGE DIRECTLY AROSE.

Confidentiality

End User agrees that End User will receive confidential or

proprietary information (“Confidential Information”) in connection

with the purchase and deployment of ZTE Equipment. End User

will not disclose ZTE’s Confidential Information, will use it only

for purposes for which it was disclosed, and must treat it with the

same degree of care as it does its own similar information, but with

no less than reasonable care. End User agrees that the terms herein,

the Equipment and all ZTE documentation is ZTE Confidential

Information.

Contents

Chapter 1 Safety Guidance............................................................1

1.1 Safety Check......................................................................................... 1

1.2 Safety Cautions..................................................................................... 1

Chapter 2 Overview .......................................................................3

2.1 Features................................................................................................. 3

2.2 Product Specifications.......................................................................... 3

2.3 Package Check...................................................................................... 4

2.4 System Requirement............................................................................. 5

Chapter 3 Installation Preparation...............................................6

3.1 Hardware Description........................................................................... 6

3.2 Hardware Connection........................................................................... 9

Appendix A FAQs.........................................................................12

Chapter 1 Safety Guidance

1.1 Safety Check

Before installing the VDSL2 equipment, check all the below listed items:

1 Electric safety

Ensure no inflammable, conductive or moist objects and no

ageing-cables around the equipment. Place all electrical appliances

safely.

2 Equipment position

Install the equipment in a ventilated environment avoid of any electric

devices nearby.

Place the equipment on a stable and flat surface.

The equipment must be protected from sunshine. It must be kept away

from electro-magnet interference.

The equipment must be protected from heat and water sources.

Ensure the power supply is available. The fluctuation range of input

voltage should be in the range of ±10%. Do not share the power

socket with other electrical devices.

1.2 Safety Cautions

Please pay attention to the following cautions:

Read the user’s manual carefully before using the equipment.

Note all Cautions in the user’s manual and product guide.

Do not use any accessory or components that are not belonging to the

equipment.

ZXHN H368C User’sManual

Use the power adapter, which is provided in the package.

Connect the phone with the VDSL2 line directly, and lead the line out

from the phone interface of the splitter.

Do not place any object on the equipment.

The equipment must be kept dry and clean. Ensure the equipment

environment has ventilation and rainproof capability.

To protect the equipment against lightning and thunderstorm, please

remove the power plug and all connection cables.

Use a soft and dry cloth to clean the equipment. Ensure the equipment

is power OFF before cleaning.

Power OFF the idle equipment.

Keep the ventilation-hole clean and unblocked. Otherwise, it may

cause short circuit, fire or damage the equipment. Do not spray liquid

on the equipment surface.

Do not open the equipment especially in power ON state.

Confirm the power is OFF before plugging/unplugging the power.

Keep all components and accessories of the equipment away from the

children.

Note:

Please read the above safety guidance carefully before equipment use. Users

should assume responsibilities for any accidents due to incompliance with the

above instructions.

Chapter 2 Overview

The ZXHN H368C is a VDSL gateway, which provides high-speed VDSL

Internet access. It is designed with triple WAN function: VDSL, ADSL, and

Gigabyte WAN. The ZXHN H368C also features a built-in 802.11n WLAN

and an embedded MoCA for multimedia over coaxial cable. In addition, the

ZXHN H368C has a USB interface for file sharing and printer server.

2.1 Features

The ZXHN H368C is a VDSL2 MODEM. It supports the following features:

ITU-T G.993.2 VDSL2 standard and ITU-T G.992.5 DSL2+ standard.

It supports WLAN with high-speed data transfer rates up to 300 Mbps,

compatible with IEEE 802.11b/g/n, 2.4 GHz compliant equipment.

It supports IEEE802.3 and IEEE802.3u.

It supports speed auto-negotiation.

It supports Half duplex/Full duplex.

It supports user-friendly GUI for web configuration.

It supports IPSec for virtual private network (VPN).

It supports parental control function to restrict children usage.

It supports self-learning bridge (IEEE 802.1D Transparent Bridging).

It supports virtual server, IP filter, and demilitarized military zone (DMZ)

host.

It supports USB 2.0 host.

2.2 Product Specifications

Environmental requirements

ZXHN H368C User’sManual

Environmental temperature: -5°C-45°C (23 °F-113°F)

Humidity: 5% - 95% (non-condensing)

Power specification

Power adapter: Input: AC 100-240V, 50/60 Hz

Output: DC 12V, 1.5A

Certification

FCC

WiFi

2.3 Package Check

ZXHN H368C 1

Micro Filter 1

Power Adapter 1

RJ-11 telephone cable 2

RJ-45 Ethernet cable 1

User’sManual&QualityWarrantyCard 1

CertificateofQuality 1

Note: for your information only, please refer to the actual product.

Caution: to reduce the risk of fire, use only NO.26AWG or larger (e.g.,

24AWG) UL Listed or CSACertified Telecommunication Line Cord.

Note:

Please use a power adapter that matches the ZXHN H368C package.
