Zte MF286C Manual de usuario

Confidential and Proprietary Information of ZTE CORPORATION 1

MF286C

Let’s go

Getting started with your device.

ZTE CORPORATION

NO. 55, Hi-tech Road South, Shenzhen, P.R.China

Postcode: 518057

LEGAL INFORMATION

No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any

means, electronic or mechanical, including photocopying and microfilm, without the prior written

permission of ZTE Corporation.

The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors

or update specifications without prior notice.

Version No. : R1.0

Edition Time: August 30, 2019

Getting to Know Your Device

External View

NOTE:

Please use the original external antenna if necessary.

Indicators

Indicator State Description

POWER

Blue on Power is on and external power supply is

working normally.

Off Power is off or external power supply is

working abnormally.

WIFI

Blue on Wi-Fi works normally with no data

transmission.

Blue Blinking Wi-Fi works normally with data

transmission.

Off Wi-Fi works abnormally or the Wi-Fi

function is disabled.

PHONE

Off The phone is not in use.

Blue Blinking The phone is ringing.

Blue on The phone is in calling.

3G/4G

Red

The device is turned on but not registered to

the mobile network. No (U)SIM card is

inserted or there is no network service

available.

Blue Blinking The device is connected to the 4G network

and data is being transferred.

Blue Solid The device is registered to the 4G network.

Indicator State Description

Green Blinking The device is connected to the 2G/3G

network and data is being transferred.

Green Solid The device is registered to the 2G/3G

network.

SIG

Blue on Signal level panel. Strength is from weak to

strong.

Off There is no signal or no (U)SIM card is

inserted.

NOTE:

The phone function needs the network support.

Buttons

Button Description

RESET Press and hold for about 3 seconds to restore factory default configurations.

WLAN Press to turn off/on the Wi-Fi function.

WPS



Press to activate the WPS function.



Press to wake device up.

Installing the (U)SIM card (optional)

Hold the (U)SIM card with the cut corner oriented as shown and slip it into the card slot until you

hear a click.

WARNINGS!

•Before installing the (U)SIM card, power off your device and remove the external power adapter.

•Your device does not support micro-SIM and nano-SIM card or any other nonstandard (U)SIM cards.

To avoid device damage, please do not use them or any card holders.

Getting Started With Your Device

Connecting Your Device

Follow the number to connect your device.

If you select a different operation mode, the connection of the LAN port will be different. Please

refer to the chapter “Accessing the Internet”. If you want to use the mobile network to connect to

the Internet or use your home phone, you need to insert your (U)SIM card first.

Starting Your Device

CAUTION:

Your device must be placed in a well-ventilated environment. Do not cover the device.

Slide the on/off switch to start your device. After the device is initialized, make sure the LED

indicators are in normal status.

NOTE:

After your device is powered off, if you are called, the caller will hear a prompt tone like “The subscriber

you are dialing cannot be reached now.”

Configuring Your PC

The following procedure describes how to configure the Internet Protocol in Windows for your

Wi-Fi connection.

1. Right-click Network and select Properties.

2. Select Change adapter settings.

3. Right-click Wireless Network Connection and select Properties.

NOTE:

If you use a network cable to connect your PC to your device, you need to right-click Local Area

Connection and select Properties.

4. Select Internet Protocol Version 4 (TCP/IPv4) and click Properties.

5. Select Obtain an IP address automatically and Obtain DNS server address

automatically, and click OK.

Accessing the Internet

Before accessing the Internet, please make sure that the following operations are finished.



Your device is connected to the terminal device via a network cable or Wi-Fi.



The terminal device is set to obtain an IP address automatically.

To access the Internet:

1. Launch the Internet browser and enter http://192.168.0.1 in the address bar. The login page

appears.

2. Input the password and then click Login.

NOTE:

View the label on your device to get the default password.

3. View the current mode and click Change.

4. Select the operation mode which you want to use and then click Apply.



Cable Broadband Mode: You need to connect the WAN to the WAN/LAN1 port via a

network cable and get the WAN information from your service provider.



Wireless Broadband Mode: Your device will use the (U)SIM card to access the Internet.

You need to insert the (U)SIM card first, and then you can set connection mode to

Automatic or Manual. The default connection mode is Automatic.



Automatic: In this mode, your device will choose the operation mode automatically.

NOTE:

If you change the operation mode, the device will be restarted automatically.

5. Setthedetailedparametersfortheoperationmode.

6. Begin to enjoy your Internet service.

Telephone Function

Your device supports the telephone function. Before using the telephone function, connect the

telephone and insert the (U)SIM card.

To make a call:

1. Pick up the handset.

2. Key in the telephone number.

Press the # key on the telephone to send the call, or wait 4～8 seconds for the call to be

dialed automatically.

NOTE:

If there is no SIG indication, the radio signal is unavailable. Change the location of the device and make

sure nothing is blocking it.

WPS Function

Your device supports WPS function. You can use this function to connect the client to your

device.

Power on your device and enable the Wi-Fi function on your device.

Press the WPS button on your device to activate the WPS function.

Enable the WPS function on your client.

Follow the system prompts on your client to finish the connection.

NOTE:

For detailed operations on the client, refer to the corresponding product instructions.

Wireless Connection

If you want to use Wi-Fi to connect to your device, please refer to the following steps.

1. Make sure that the Wi-Fi works normally. Please check the Wi-Fi Settings on the 4G CPE page or

check the WIFI indicator.

2. Use your normal Wi-Fi application on the client to search for the available wireless network.

NOTE:

Please set the client to obtain an IP address automatically, and the client will get an IP address

“192.168.0.101”. For the detailed procedure, refer to Configuring Your PC.

3. Select the SSID (Network Name) of your device, and then click Connect.

NOTE:

Please check the label on your device to get the default SSID.

4. Enter the password and then click OK.

NOTE:

View the label on your device to get the default password.

Wait until the client is connected to your device successfully

Troubleshooting

Voice Related Problems

Symptoms Possible Problems/ Solutions

There is no dial tone.



Please wait for 1~2 minutes after the device is turned

on.



If the SIG indicator is week, you have no good RF

reception. Change the location of the device.

Symptoms Possible Problems/ Solutions

There is a prompt / phone alert / announcement as soon as

I lift the phone off the hook. Make sure your (U)SIM card is inserted correctly and

the PIN number has been entered. If the PIN number has

been entered incorrectly then you will need to enter the

PUK code when prompted.

The line is noisy/distorted when I lift the phone off the

hook. Remove any electrical appliance which is too close to

the phone or your device.

The cable or phone set might be faulty.

I hear a rapid engaged tone as soon as I lift the phone off

the hook. Put the phone on the hook and try again.

Please contact with your servicer provider.

After dialing the last digit I hear nothing/silence. When you have finished dialing you can press the # key

or wait 4-8 seconds to connect the call.

Internet Related Problems

Symptoms Possible Problems/ Solutions

I cannot access the Internet at all. Please check your configuration settings.

Please wait 1~ 2 minutes for the device to initialize.

Check your service indicators.

The download or upload speed is very slow. The speed is dependent on signal strength. Check your

signal strength and network type.

I cannot visit the 4G CPE page. Enter the correct address. The default address is

http://192.168.0.1.

Only use one network adapter in your PC.

Do not use any proxy server.

I cannot establish the Wi-Fi connection between my device

and the client. Make sure the Wi-Fi function is active.

Refresh network list and select the correct SSID.

Check the IP address to make sure your client can

obtain an IP address automatically in the Internet

protocol (TCP/IP) properties.

Type the correct network key (Wi-Fi password) when

you connect to the device.

Others

Symptoms Possible Problems/ Solutions

About the password

For the Wi-Fi connection password, please check the

label on the device.

View the label on your device to get the default

password of the 4G CPE page.

If you changed the password and forgot the new

password, you need to restore the device to the

factory default settings.

Warning and Notice

Safety Precautions

Some electronic devices may be susceptible to electromagnetic interference. Locate the device away

from TV set, radio and other electronic equipment to avoid electromagnetic interference.

The device may interfere with medical devices like hearing aids and pacemakers. Consult a physician

or the manufacturer of the medical device before using your device.

Please keep yourself at least 20 centimeters away from your device.

Do not use your device in dangerous environments such as oil terminals or chemical factories where

there are explosive gases or explosive products being processed.

Please use original accessories or accessories that are authorized by ZTE. Unauthorized accessories

may affect the device performance, damage the device or cause danger to you.

Do not attempt to dismantle the device. There are no user serviceable parts.

Do not allow the device or accessories to come into contact with liquid or moisture at any time. Do not

immerse the device in any liquid.

Do not place objects on top of the device. This may lead to overheating of the device.

The device must be placed in ventilation environment for use.

Do not expose the device to direct sunlight or store it in hot areas. High temperature can shorten the

life of electronic devices.

Do not allow children to play with the device or charger.

Keep the length of the cable between the device and the phone less than 10 meters.

The device is for indoor use only. Do not use the device outside. Do not connect telephone extensions

which run outside of the building. These can result in lightning damage to your unit.

For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be

easily accessible.

Cleaning and Maintaining

Use an antistatic cloth to clean the device. Do not use chemical or abrasive cleanser as these could

damage the plastic case. Turn off your device before you clean it.

Use the router within the temperature range of -20℃～+55℃, and the storage temperature range is

-40℃～+70℃. The humidity range is 5%~95%.

Do not use your device during a thunderstorm. Remove the mains power pack from the wall socket.

Do not take out your (U)SIM card unnecessarily. The (U)SIM card may be easily lost or it can be

damaged by static electricity.

Otros manuales para MF286C

Tabla de contenidos

Otros manuales de Enrutador de red de Zte

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
