Zte MF920U Manual de usuario

MF920U

Quick Start Guide

ZTE CORPORATION

NO. 55, Hi-tech Road South, Shenzhen, P.R.China

Postcode: 518057

Getting to Know Your Device

Appearance

The following figure is for your reference only.

1. Charging/micro-USB jack

2. Indicator light

3. Power key

Press and hold for about 2 seconds to power on/off

your device.

Press and hold for about 10 seconds to power off your

device, if it is in abnormal status. And then press and

hold for about 2 seconds to power on your device

again.

4. WPS key

Press and hold for about 2 seconds to activate the WPS

function.

5. micro-SIM card slot and reset hole

Reset hole: Press and hold for about 2 seconds to restore your

device to the factory settings.

Getting to Know Your Device

Indicator lights

Indicator Status

Description

Battery

Red solid /

blinking

The battery is low. Please

charge the battery.

Green

blinking

The battery is being

charged.

Green

solid

The battery level is middle

or high.

Light off Your device is powered off

and not being charged.

Wi-Fi

Blue solid Wi-Fi is active.

Blue

blinking

WPS is active.

Light off Wi-Fi is off.

SMS

Blue solid You have unread

messages.

Blue

blinking

You have new messages or

the message storage is

full.

Light off There is neither an unread

message nor a new

message.

Network

Red The device is in error

status.

The device is not

registered to the

mobile network.

There is no micro-SIM

card inserted.

There is no network

service available.

Green

solid

The device is registered to

the 2G/3G mobile

network.

Green

blinking

The device is connected to

the 2G/3G mobile network

and data is being

transferred.

Blue solid The device is registered to

the 4G LTE network.

Blue

blinking

The device is connected to

the 4G LTE network and

data is being transferred.

Getting to Know Your Device

Connection Scenarios

The device uses your micro-SIM card to access the Internet. It

allows multiple clients to surf on the Internet at the same time.

The following figure is for your reference only.

Installing Your Device

1. Open the micro-SIM card slot cover.

NOTE:

Do not remove the cover rudely, because it is connected with

the device.

2. Install a micro-SIM card to the micro-SIM card slot.

WARNING!

Your device does not sup port SIM cards, nan o-SIM cards or any

other non-standard micro-SIM cards. To avoid damage to the

device, do not use those cards or any card holders.

3. Close the micro-SIM card slot cover.

Connecting to Your Device

Using Wi-Fi

1. Power on your device.

2. Ensure that your computer or other client devices have

enabled Wi-Fi, and search for available wireless networks.

NOTE:

Refer to your Wi-Fi-enabled client device manual for further

details on how to search for wireless networks. If you use a

computer, you need to set your computer to obtain an IP

address automatically.

3. Select the Wi-Fi name (SSID) of your device, and click

Connect.

4. Enter the Wi-Fi password if necessary, and click OK.

NOTE:

Refer to the chapter

Getting to Know the Wi-Fi SSID and

Password

to get the default Wi-Fi SSID and password.

5. Wait until the client device is connected to your device

successfully.

Using a USB Cable

1. Connect a computer to your device with a USB cable.

2. Power on your device. The operating system detects and

identifies new hardware, and automatically installs the

software.

NOTE:

If the system does not automatically launch installation, you

can double-click the device installation icon in My Computer >

ZTEMODEM to install the software.

3. Wait until the computer is connected to your device

successfully.
