Zte MF656A Manual de usuario

Beeline 3G

Quick Guide

MF656A Quick Guide V1.1-1014.indd 1

2011-10-17 8:58:16

Beeline 3G Introduction

The Beeline 3G is a multi-mode 3G modem. With a USB interface connecting to your laptop or desktop computer, it

supports data and SMS services through the mobile phone network, helping you realize mobile communication anytime

and anywhere.

Technical Parameters

Interface Type USB 2.0 HIGH SPEED

Systems supported Supports most types of laptop and desktop PC.

Operating systems supported Windows XP (SP2 and later), Vista, Windows 7

MAC 10.4.11 and later

Functions SMS service, Data service, Applications management, support microSD card, etc.

Network Standards HSUPA/HSDPA/WCDMA/EDGE/GPRS/GSM

Transmission speed (Max) HSUPA: 5.76Mbps UL HSDPA: 14.4Mbps DL

MF656A Quick Guide V1.1-1014.indd 2

2011-10-17 8:58:17

Temperature Storage: -40°C ~ +80°C Operation:-10°C ~ +60°C

Dimension 87.4mm×29.1mm×11.2mm (without cap)

Weight About 24g

microSD capability Support up to 32GB microSD card

Notes: The logo is a trademark.

Hardware Installation

Installing the SIM/USIM Card

1. Remove the back cover on the modem.

MF656A Quick Guide V1.1-1014.indd 3

2011-10-17 8:58:17

2. Hold your SIM/USIM card with the cut corner oriented as shown and then slide it

into the card holder with the metal contacts facing the modem.

3. Replace the back cover.

Installing the Memory Card

Only microSD card is supported by the modem and do not insert other memory cards into the modem.

Insert the microSD card, orientated as shown, into the holder until you hear a click.

Connecting the USB Modem to Your Computer

Remove the modem cap and plug the modem firmly into a USB port on your computer.

MF656A Quick Guide V1.1-1014.indd 4

2011-10-17 8:58:18

Software Installation

On different operating systems, the software installation procedures may be different. Please follow the general guide

below and the system prompts during installation.

• For Windows XP, Vista and Windows 7

When you connect the modem to your PC correctly, the system automatically recognizes it as a CD-ROM and starts the

software installation wizard. If the system does not launch the installation wizard automatically, please start it by

running the executable file in the new CD-ROM directory.

• For Mac OS

The system will automatically display a new CD-ROM icon on the desktop, when you connect the modem to your Mac

correctly. Double click the installation software package in the CD-ROM, and follow the system prompts to complete

the software installation.

Functions

Click the following buttons to access each function.

Connect Connect to the Internet.

SMS Send and receive text messages.

MF656A Quick Guide V1.1-1014.indd 5

2011-10-17 8:58:18

Phonebook Manage contacts information.

Settings Configure the USB modem settings.

Data records Show connection information.

LED Lights

Indication Modem Status

Red Power on, but not registered to a network

Blue solid Registered to a network

Blue blinking Active data transfer on the network

MF656A Quick Guide V1.1-1014.indd 6

2011-10-17 8:58:19

Warning and notice

To the owner

• Some electronic devices are susceptible to electromagnetic interference sent by modem if inadequately shielded,

such as the electronic system of vehicles. Please consult the manufacturer of the device before using the modem if

necessary.

• Operating of laptop and desktop PCs and the modem may interfere with medical devices like hearing aids and

pacemakers. Please always keep them more than 20 centimeters away from such medical devices when they are

turned on. Turn the modem off if necessary. Consult a physician or the manufacturer of the medical device before

using the modem.

• Be aware of the usage limitation when using a modem at places such as oil warehouses or chemical factories,

where there are explosive gases or explosive products being processed. Turn off your modem if required.

• The use of electronic transmitting devices is forbidden in aircrafts, at petrol stations and in hospitals. Please

observe and obey all warning signs and switch off your modem in these conditions.

• Do not touch the inner antenna area if not necessary. Otherwise it will affect your modem’s performance.

• Store the modem out of the reach of little children. The modem may cause injury if used as a toy.

MF656A Quick Guide V1.1-1014.indd 7

2011-10-17 8:58:19

Using your USB Modem

• Please use original accessories or accessories that are authorized. Using any unauthorized accessories may affect

your modem’s performance, and violate related national regulations about telecom terminals.

• Avoid using the modem near or inside metallic structures or establishments that can emit electromagnetic waves.

Otherwise it may influence signal reception.

• The modem is not waterproof. Please keep it dry and store in a shady and cool place.

• Do not use the modem immediately after a sudden temperature change. In such case, it will produce dew inside

and outside the modem, so don’t use it until it becomes dry.

• Handle the modem carefully. Do not drop, bend or strike it. Otherwise the modem will be damaged.

• No dismantling by non-professionals and only qualified technicians can undertake repair work.

• Operating temperature range of -10°C ~ +60°C and humidity range of 5% ~ 95% are recommended.

Limited Warranty

• This warranty does not apply to defects or errors in the Product caused by:

i. Reasonable abrasion.

ii. End User’s failure to follow ZTE’s installation, operation or maintenance instructions or procedures.

iii. End User’s mishandling, misuse, negligence, or improper installation, disassembly, storage, servicing or

operation of the Product.

MF656A Quick Guide V1.1-1014.indd 8

2011-10-17 8:58:19

iv. Modifications or repairs not made by ZTE or a ZTE-certified individual.

v. Power failures, surges, fire, flood, accidents, actions of third parties or other events outside ZTE’s reasonable

control.

vi. Usage of third-party products, or usage in conjunction with third-party products provided that such defects

are due to the combined usage.

vii. Any other cause beyond the range of normal usage intended for the Product.

End User shall have no right to reject or return the Product, or receive a refund for the Product from ZTE under the

above-mentioned situations.

• This warranty is End User’s sole remedy and ZTE’s sole liability for defective or nonconforming items, and is in

lieu of all other warranties, expressed, implied or statutory, including but not limited to the implied warranties of

merchantability and fitness for a particular purpose, unless otherwise required under the mandatory provisions of

the law.

Limitation of Liability

ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages resulting from or

arising out of or in connection with using of this product, whether or not ZTE had been advised, knew or should have

known of the possibility of such damages, including, but not limited to lost profits, interruption of business, cost of

capital, cost of substitute facilities or product, or any downtime cost.

MF656A Quick Guide V1.1-1014.indd 9

2011-10-17 8:58:19

LEGAL INFORMATION

No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means,

electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE

Corporation.

The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update

specifications without prior notice.

For more information, please call 123 or 7780 0123

MF656A Quick Guide V1.1-1014.indd 10

2011-10-17 8:58:19
