Zte CDMA2000 1X EVDO Manual de usuario

CDMA2000 1X Wireless Data Terminal User Guide

ZTE Corporation http://www.zte.com.cn

CDMA2000 1X

Wireless Data Terminal

User Guide

This User Guide is used for Wireless Data Terminal of AC8720.

CDMA2000 1X Wireless Data Terminal User Guide

ZTE Corporation http://www.zte.com.cn

No part of this publication may be excerpted, reproduced, translated or utilized in any form or by

any means, electronic or mechanical, including photocopying and microfilm, without the prior

written permission of ZTE Corporation.

ZTE Corporation reserves the right to make modifications on print errors or update specifications

in this manual without prior notice.

CDMA2000 1X Wireless Data Terminal User Guide

ZTE Corporation http://www.zte.com.cn

Table of Contents

1. Introduction.............................................................................................................................1

2. Precautions..............................................................................................................................1

3. Appearance .............................................................................................................................2

3.1 Introduction.........................................................................................................................2

3.2 Insert R-UIM Card ..............................................................................................................2

3.3 Operation Guide of Data Cable...........................................................................................3

4. Install and Uninstall................................................................................................................4

4.1 System Requirements..........................................................................................................4

4.2 Installation Guide...............................................................................................................4

4.3 Uninstall..............................................................................................................................4

5. Run the Application ................................................................................................................5

6. Connect/Disconnect................................................................................................................6

7. Connection Records................................................................................................................7

8. Voice Call...................................................................................................................................7

9. Call History ...............................................................................................................................9

10. Short Message..........................................................................................................................9

11. Phone Book............................................................................................................................10

12. Setting....................................................................................................................................11

13. Help .......................................................................................................................................13

14. Connect to the Website ..........................................................................................................13

15. RF Exposure Information (SAR)...........................................................................................13

16. Trouble-shooting....................................................................................................................14

17. FCC Regulations....................................................................................................................16

CDMA2000 1X Wireless Data Terminal User Guide

ZTE Corporation 1http://www.zte.com.cn

1. Introduction

Thank you for choosing AC8720 CDMA2000 1X Wireless Data Terminal (hereinafter referred to as Data

Terminal) of ZTE Corporation.

The Data Terminal equips with a standard USB interface and supports CDMA2000 1X network. In the area where

there is signal, it allows you to go surfing on the Internet, send&receive short messages, and make&receive phone

calls.

The Data Terminal adopts two designing options: R-UIM and Built-in UIM, which make your operation more

flexible.

The pictures in this guide are only used to demonstrate your Data Terminal’s functions, so they are maybe

different from what you see on your Data Terminal. Please refer to your Data Terminal if they are differences.

2. Precautions

zUse the original accessories or those authenticated by the manufacturer. Using any unauthenticated

accessories may affect the data terminal’s performance, violate the warranty provisions or relevant national

regulations about telecom terminals, or even cause body injury.

zDo not disassemble, modify, frequently pull/plug the antenna, stretch, rotate or bend the antenna with great

force.

zBefore pulling out the data terminal, please use Windows safely removing the hardware and make sure to exit

the application. Do not directly pull out the terminal to avoid the damage of data terminal or the influence on

the normal operation of operating system.

zDo not forcefully plug/pull the data terminal to avoid the damage of connector.

zDo not use your data terminal near weak signal or high-precision electronic devices. Radio wave interference

may cause misoperation of electronic devices or other problems.

zTurn off your data terminal on airplane where it’s forbidden to use it. The data terminal may affect the normal

operation of electronic devices, therefore please follow the relevant regulations when using your mobile

phone on airplane.

zTurn off your data terminal in hospital where it’s forbidden to use it. The data terminal may affect the normal

operation of medical apparatus, therefore please follow the relevant regulations when using your mobile

phone in hospital.

zPlease do not use the data terminal near flammable or explosive materials; otherwise it might cause failure or

fire.

zKeep your data terminal away from water. This may cause overheating or failure if water or any other kind of

liquid enters your mobile phone. Please do not use your data terminal near high temperature, damp or dusty

place.

zKeep your data terminal away from children to avoid shock, plunge or impact. It may cause body injury when

the data terminal is used as a toy.

CDMA2000 1X Wireless Data Terminal User Guide

ZTE Corporation 2http://www.zte.com.cn

3. Appearance

3.1 Introduction

3.2 Insert R-UIM Card

Note: If your data terminal doesn’t need R-UIM card, please skip this section.

1. Pull out the tap；

2. Take out the R-UIM card cover in the direction indicated by the arrow；

CDMA2000 1X Wireless Data Terminal User Guide

ZTE Corporation 3http://www.zte.com.cn

3. Insert R-UIM card as below figure；

4. Push back R-UIM card cover .

3.3 Operation Guide of Data Cable

Generally, the Data Terminal could be directly connected with USB port. You could also connect the Data

Terminal with PC by using the accompanying data cable, as shown in the following figure. Connect Interface ①

with Data Terminal, and interface ②with PC's USB port. If the power supply from USB port is insufficient,

connect both interface ②and ③with USB port together.

CDMA2000 1X Wireless Data Terminal User Guide

ZTE Corporation 4http://www.zte.com.cn

4. Install and Uninstall

4.1 System Requirements

The Data Terminal supports the following operating system:

¾Windows 2000

¾Windows XP

¾Windows Vista

PC minimum configurations:

CPU Pentium-II/233MHz

USB interface 2.0 (USB1.0 and 1.1 compatible)

Optical Drive CD-ROM (for installation only)

Memory 64 MB

Disk Space 50 MB (used for installation of application)

4.2 Installation Guide

Take Windows XP as an example.

1. Please connect Data Terminal to PC through USB interface. You could also use data cable to connect.

2. The installation will automatically start. Please follow installation wizard.

3. The system will automatically find new hardware and install the driver. Wait for a while. Click "Finish"

to complete installation.

4.3 Uninstall

1. Select Start Programs (Appropriate Uninstall), and you will be asked if you want to remove

the program. Click “Yes” to uninstall.

2. Please wait and then click “OK” to complete uninstall.

CDMA2000 1X Wireless Data Terminal User Guide

ZTE Corporation 5http://www.zte.com.cn

5. Run the Application

After the application is installed successfully, the application icon will appear on your desktop. Double-click this

icon or select from Start -> Programs ->(Appropriate Application). Run the application to display the user

interface.

The icons on the interface are used to access the function, which indicate as below:

Connect/Disconnect Open URL

Voice Call Call History

Short Message Phone Book

Connection Record Setting

Help

Status Bar:

1X indication Call indication

Signal strength indication. The

more bars there are, the

stronger signals are.

Missed call indication

CDMA network unavailable Unread message indication

Connection indication Inbox full indication

Sleep indication No R-UIM card inserted indication

Roaming indication R-UIM card inserted indication

Note:

Some features like Voice Call, Call History, Short Message, and Phone Book may not be supported

by your Data Terminal; the corresponding icons will not appear in the main window.

CDMA2000 1X Wireless Data Terminal User Guide

ZTE Corporation 6http://www.zte.com.cn

6. Connect/Disconnect

Connect

Click icon to set the relevant parameters. For details, please refer to Chapter 12 “Setting” for

details.

Click icon at the left-up corner of the interface.

After connecting to Internet, the current network information will appear on the interface. Double-click

any place in the display area to view the connection drawing.

Please connect the Data Terminal and PC with USB extension cable under weak signal to obtain the

optimal performance. If necessary, adjust the Data Terminal's position and the antenna's direction.

Disconnect

After connecting to Internet, click the rotating icon at the left-up corner of the interface.

CDMA2000 1X Wireless Data Terminal User Guide

ZTE Corporation 7http://www.zte.com.cn

7. Connection Records

Click icon to view connection records. Connection records save the previous relevant information

including Start at, Duration and Transmit bytes, which will help you know the status easily.

By switching among “List”, “Monthly” and “Statistic”, you could inquire the records every time, by month or by

time.

Note:

The relevant information contained in connection records are just for user’s reference rather than the charging

basis.

Delete Connection Records

Click button to delete the records you have selected on the interface.

Clear Connection Records

Click button to delete all the records.

Note: If your data terminal doesn’t support Voice Call, Call History, Short Message, and Phone

Book features, please skip 8-11 sections.

8. Voice Call

Click to enter voice call interface.

Make a call

Click the digits in the right side of the interface, or input the digits directly from keyboard. Press

button or press “Backspace” to delete the previous input digit; press button or press “Esc” to

clear all the inputs.

Click button in the right side of the interface or press “Enter” to make a call.

Receive a call

When there is an incoming call, your computer will alert and the incoming caller ID will appear on the

interface.

Click button in the right side of the interface or press “Enter” to receive the call.

Press button or press “Esc” to reject the call.
