Zoom X5 Manual de usuario

ADSL Modem

U S E R ’ S M A N U A L

NOTICE

NOTICENOTICE

NOTICE

This document contains proprietary information protected by copyright, and

this Manual and all the accompanying hardware, software, and

documentation are copyrighted. No part of this document may be

photocopied or reproduced by mechanical, electronic, or other means in

any form.

The manufacturer does not warrant that the hardware will work properly in

all environments and applications, and makes no warranty or representation,

either expressed or implied, with respect to the quality, performance,

merchantability, or fitness for a particular purpose of the software or

documentation. The manufacturer reserves the right to make changes to the

hardware, software, and documentation without obligation to notify any

person or organization of the revision or change.

All brand and product names are the trademarks of their respective owners.

Contents

1 INSTALLATION ............................................................. 4

1.1 IMPORTANT! BEFORE YOU BEGIN.......................................... 4

1.2 PACKAGE CONTENTS.......................................................... 4

1.3 QUICK START INSTRUCTIONS............................................... 5

1.4 USING PHONE FILTERS......................................................14

1.5 IF YOU NEED HELP...........................................................15

2 ADVANCED SETUP OPTIONS....................................... 16

2.1 HOW TO USE THE ADVANCED OPTIONS .................................16

2.2 WAN SETTINGS..............................................................17

2.3 LAN SETTINGS................................................................22

2.4 NAT FIREWALL...............................................................23

2.5 VIRTUAL SERVER (PORT FORWARDING).................................24

2.6 DMZ............................................................................27

2.7 DNS ............................................................................30

2.8 ADSL CONFIGURATION.....................................................31

2.9 ROUTE TABLE .................................................................32

2.10 MISCELLANEOUS ............................................................34

3 SYSTEM ADMINISTRATION........................................ 36

3.1 MONITORING SYSTEM STATUS ............................................36

3.2 MONITORING ADSL STATUS ..............................................37

3.3 PERFORMING SYSTEM ADMINISTRATION TASKS........................39

3.4 RESETTING THE UNIT TO ITS DEFAULT SETTINGS.....................40

3.5 UPDATING THE UNIT’S FIRMWARE........................................41

4 REMOVING THE X5 MODEM........................................ 42

APPENDIX A DSL INTERNET SETTINGS TABLES................. 43

APPENDIX B FRONT AND BACK PANEL DESCRIPTIONS....... 45

APPENDIX C ONLINE GAMING AND THE X5....................... 46

APPENDIX D MACINTOSH AND LINUX USERS: CONFIGURING

TCP/IP SETTINGS.............................................................. 49

APPENDIX E TROUBLESHOOTING..................................... 54

APPENDIX F REGULATORY INFORMATION......................... 58

4 X5 ADSL Modem User’s Manual

Installation

1.1 Important! Before You Begin

Before installing your X5 ADSL modem, you must have DSL

service enabled on your telephone line. To do this, you need

to sign up with a DSL service provider.

1.2 Package Contents

In addition to these installation instructions, your package includes

the following items:

•X5 ADSL unit

•Power adapter and power cord

•Straight-through Ethernet cable

•USB cable

•RJ-11 phone cord

•RJ-11-to-wall-jack adapter (certain models only)

•CD with documentation and installation software

•Warranty and Customer Support information (on CD)

•Phone filter(s) (certain models only).

If anything is missing or damaged, contact Zoom’s Customer

Service or your retailer or distributor.

Chapter 1: Installation Instructions 5

You Will Also Need

•A Macintosh, Linux, or Windows 98/98SE/2000/Me/XP

computer equipped with a Network Interface Card (NIC) or a

Windows 98/98SE/2000/Me/XP computer equipped with a

USB port.

•A telephone wall jack to plug the X5 unit into. The associated

phone line must be DSL enabled.

1.3 Quick Start Instructions

Should I Use Ethernet or USB?

Depending on your operating system and preference, follow

the appropriate instructions below.

Windows users: You have the option of connecting the X5 to the

Ethernet port or USB port of your computer. If you have an

Ethernet port, we recommend that you use it. If you would prefer

to use the USB jack to connect to your PC, check to be sure that

the PC has a USB port available.

Macintosh and Linux users: You must use the Ethernet option.

To Connect using Ethernet

1Macintosh and Linux Users:

Skip to Step 2 below.

Windows 98/98SE, Me, 2000, and XP Users:

You MUST install the software BEFORE connecting the

hardware.

aYour computer must be on. Insert the supplied CD into

your computer. The CD should start automatically and the

Main Menu should open. (If the CD does not start

automatically: From the desktop, go to Start, select Run

and then type D:\setup.exe, where Dis the letter of your

CD-ROM drive.)

6 X5 ADSL Modem User’s Manual

bClick the ADSL Modem Installation Wizard button, and

then click the Ethernet option. The software installation

proceeds automatically.

cWhen the process is complete, you will be prompted to click

Finish. Your computer will shut down so you can connect

the hardware.

2Connect the X5.

Your computer should be shut down.

aPlug one end of the supplied phone cord into the unit’s

DSL jack and the other end into the ADSL wall jack.

bPlug one end of the straight-through Ethernet (10BaseT)

cable into one of the modem’s LAN ports (1, 2, 3, or 4) and

plug the other end into your computer’s Ethernet port. (You

can also use the LAN ports to connect an access point,

switch, or hub.)

cPlug the power adapter into a power strip or wall outlet and

then into the X5’s POWER jack.

dTurn the unit on by pushing the ON/OFF switch in. The

PWR light on the unit’s front panel should turn on. If it

doesn’t, make sure that there is power at the power strip or

wall outlet where you plugged in your power adapter.

Chapter 1: Installation Instructions 7

3After a few seconds, the unit’s front panel LINK light should

start to blink. When the LINK light changes from blinking to

solid, turn your computer back on and proceed to Configuring

Internet Explorer on page 8.

To Connect Using USB

1You must install the USB software on your Windows

computer before connecting the hardware.

aInsert the supplied CD into your computer. The CD

should start automatically and the Main Menu should

open. (If the CD does not start automatically, from the

desktop, go to Start, select Run and then type

D:\setup.exe, where Dis the letter of your CD-ROM

drive.)

bClick the ADSL Modem Installation Wizard button

and, if prompted, the USB option. The software

installation proceeds automatically. When the process is

complete, the Main Menu minimizes. You can click on

the Zoom icon to return to the menu at any time.

2Connect the X5.

aPlug the included power adapter into a power strip or

wall outlet and then into the X5’s POWER jack.

bTurn the unit on by pushing the ON/OFF switch in.

The PWR light on the unit’s front panel should turn on.

If it doesn’t, make sure that there is power at the power

strip or wall outlet where you plugged in your power

adapter.

8 X5 ADSL Modem User’s Manual

cPlug one end of the supplied phone cord into the unit’s

DSL jack and the other end into the ADSL wall jack.

dPlug one end of the USB cable into the modem’s USB

jack and the other end into your computer’s USB port.

3After a few seconds, the unit’s front panel LINK light should

start to blink.

Note: You may see a Found New Hardware box indicating

the progression of the installation; typically no user action is

necessary. If you are using Windows XP, however, you may

be required to click Next.

4Depending on your operating system, you may see a

Hardware Installation disclaimer box or a Digital

Signature Not Found dialog box. You can safely ignore

these messages and click Yes or Continue Anyway.

Windows XP Users: If prompted to do so, click Finish.

When the modem’s startup sequence is complete, the LINK

light changes from blinking to solid. Continue below with

Configuring Internet Explorer.

Configuring Internet Explorer

Your browser needs to be set up for a network connection, not a

dial-up connection. The instructions below are for Internet

Explorer. If you are using a different browser, set it up now to use

a network connection.

Internet Explorer 5.x or later

Internet Explorer 5.x or laterInternet Explorer 5.x or later

Internet Explorer 5.x or later

1On the desktop, right-click the Internet Explorer icon, and

select Properties.

If you cannot access Internet Explorer:

Windows XP users: From the desktop, click Start | Control

Panel | Network and Internet Options and then click the

Internet Options icon.

Windows 98/Me/2000 users: From the desktop click Start |

Settings | Control Panel and then click the Internet

Options icon.

Chapter 1: Installation Instructions 9

2In the Internet Properties dialog box, click the Connections

tab.

3On the Connections tab, click Setup.

4In the Internet Connection Wizard dialog box, select “I

want to set up my Internet connection manually, or I

want to connect through a local area network (LAN)”, and

click Next.

5In the Setting up your Internet connection dialog box,

change the selection to “I connect through a local area

network (LAN)” and click Next.

6In the Local area network Internet configuration dialog

box, uncheck the box “Automatic discovery of proxy

server”. Then click Next.

7A dialog box asks if you want to set up an email account. Click

No and then Next.

8When the configuration process is done, you will see a

Completing the Internet Connection Wizard dialog box. Be

sure to uncheck the box that says “To connect to the

Internet immediately, select this box….”

Then click Finish. If Internet Explorer is open, close it.

9Macintosh and Linux users, go to the TCP/IP Settings

Appendix on page 49.

All other users, continue below.

Establishing Communication

1You should have a Zoom icon on your desktop that looks like

this:

2Double-click it to display the Network Password dialog box.

If you do not have an icon like the one shown above on your

desktop, open your Web browser, type http://10.0.0.2, and

press Enter (or Return) to display the Network Password

box.

10 X5 ADSL Modem User’s Manual

Tip: If the Network Password box doesn’t display, perform the

following in this order: Recheck all connections; restart the modem

and computer; perform a hard reset (see page 40).

3Type the following User Name and Password in lower-case letters:

User Name: admin

Password: zoomadsl (the “l” is a lower-case letter, not the

number “1”)

Note: This User Name and Network Password are different from

the ones that your service provider may have given you. They

provide an added level of security that protects your X5’s settings.

These can be changed later if you would prefer to choose them

yourself.

The Basic Setup page should display.

You need to fill in at least three of these boxes: VPI, VCI,

and Encapsulation. Your service provider may have given

you these settings, although most do not. If you have them, it

will make installation a little faster and easier, but don’t worry if

you don’t have them. We’ll tell you how to figure them out.

Otros manuales para X5

Tabla de contenidos

Otros manuales de Módem de Zoom

Manuales populares de Módem de otras marcas

Davicom

Davicom DM562AP Manual de usuario

EpiValley

EpiValley TATA indicom SXC-1080 Manual de usuario

Zte

Zte WiMAX Manual de usuario

Intelimax

Intelimax MA-2060 Manual de usuario

SMC Networks

SMC Networks D3CM1604V Manual de uso y cuidado

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manual de usuario

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manual de usuario

Samsung

Samsung AceLink SAM-335A Manual de usuario

Enfora

Enfora Enabler-G Guía de configuración rápida

iRZ

iRZ ATM2-232 Manual de usuario

Zhone

Zhone 6310 Manual de usuario

Paradyne

Paradyne Hotwire 7976 Manual de usuario

US Robotics

US Robotics 3453C Manual de usuario

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manual de usuario

Zte

Zte MF823 Manual de usuario

Four-Faith

Four-Faith F1403 Manual de usuario

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manual de usuario

Gemtek

Gemtek WiMAX WIXFBR-103 Manual de usuario
