ZKTeco X8-BT Manual de usuario

User Manual

X8-BT

Version: 1.0

Date: August 2019

Method 1: Install on the wall

Method 2: Install on the 86 Box

1. Device Installation

Install the device on the fixed

back cover.

Fix the device on the back

cover using screws.

Tamper Alarm Button

Remove the screws from

the bottom of the device.

) Remove the back cover of

the device.

) Fix the back cover on the wall.

(

Drill the wiring hole and fixing

holes according to the back cover)

1) Remove the screw

s from

the bottom of the device.

) Remove the back cover of

the device.

) Fix the back cover to 86 box on

the wall

Install the device on the back

cover.

The back cover is fixed on

the 86

box.

Fix the device on the back

cover using screws.

Warning: No operation when power on!

1. The system supports NO LOCK and NC LOCK. The NO LOCK (normally open at power ON) is

connected with NO terminal, and the NC LOCK is connected with NC terminal.

2. To prevent the generation of self-inductance EMF which would affect the system, when the

electrical lock is linked to the Access Control System, it is required to connect one FR107 diode

(equipped in the package, do not reverse the polarities) in parallel in order to release the

self-inductance EMF.

1) Device shares power with the lock 2) Does not share power with the lock

3. Lock Connection

2. Structure and Function

+12V

GND

BUT

GND

SEN

COM1

NC1

AL-

AL+

BELL

NO1

DC12V

+12V

GND

BUT

GND

SEN

COM1

NC1

AL-

AL+

BELL

NO1

DC12V

The de

vice shares power with the lock,

when U

LOCK=12V and I-ILOCK >1A…①

and the lock is near to the device.

The device does not share power with the lock:

A. When U

LOCK =12V and I-ILOCK ≤1A;

B. When U

LOCK ≠12V;

C. When the lock is far apart from the device.

Lock

Door Senso

Exit Button

Bell

Alarm

NC Lock

Access Control System Function:

1) When a registered user's identity is verified, the

access control device will send out signal to unlock the

door.

2) The door sensor will detect the status of the lock.

If the door is unexpectedly opened or improperly

closed, an alarm will be triggered.

3) It supports the exit button for opening the door

from inside.

4) It supports door bell.

5) If the access control device is dismantled, the alarm

will be triggered.

5. Connection with Power

I: device’s current output, ULOCK: lock voltage, ILOCK: lock current.

3) One device controls two locks 4) Two devices control one lock

+12V

GND

BUT

GND

SEN

COM1

NC1

AL-

AL+

BELL

NO1

+12V

GND

PUSH

GND

通电常闭锁

V1+

V2+

V1-

V2-

出门开关

门禁机

专业门禁电源

+12V

GND

...

COM1

...

NO1

+12V

GND

PUSH

GND

通电常闭锁

V+

V-

+12V

GND

...

COM1

...

NO1

门禁机1

门禁机2

专业门禁电源

Only devices with an alarm consuming ≤ 12V DC can be connected.

Input 12V DC, 500mA (50mA in idle status). Positive is connected with +12V, negative is

connected with GND (do not reverse the polarities).

4. Connection with Other Devices

Access Control Device

Professional Access

Control Power

Access Control Device 2

Access Control Device 1

Professional Access

Control Power

Exit Button

NC Lock

Conventions

Note: After entering password/user ID, user must press【#】to confirm; press【*】to return to initial

state.

Step1: Power ON after the device is completely installed.

Step 2: Verify administrator using default password and register fingerprint immediately. Adjust

access control parameters including 8 passwords, authentication mode, door sensor

mode, alarm etc.

Step 3: You can register user, enroll card, fingerprint or 8 passwords.

To ensure data security of the device, users can operate the device only after the administrator

password is authenticated.

Register Administrator Fingerprint

Press【*】+【#】

Press【*】+【#】Press finger three times

(The indicator turns

green and makes a long

beep)

Press finger three times

(The indicator turns

green and makes a long

beep)

Enter【1234#】

(The indicator turns

green and makes a

long beep)

Enter【1234#】

(The indicator turns

green and makes a

long beep)

Press【*】to exit

(The indicator turns

green and makes a

long beep)

Press【*】to exit

(The indicator turns

green and makes a

long beep)

Note: The default administrator password is 1234. You are advised to change the initial

password at the beginning. After administrator fingerprint (only can register one fingerprint)

registered successfully, the initial password will become invalid.

7. Administrator Operation

6. Instructions

Key

【

#】Confirm

【

*】Cancel

Light

Status

Green

: Success

Red

: Failure

Digit

Password

= 4 digits

User ID

≤5 digits

Hint

tone

Success: A long beep

Fai

lure: Two short beeps

rror: Four short beeps

Changing Administrator Fingerprint

Press【*】+【#】

Verify administrator

fingerprint

(The indicator turns

green and makes a

long beep)

Press new fingerprint

three times

(The indicator turns

green and makes a

long beep)

Press【*】to exit

Press【8】

(The indicator turns

green and makes a long

beep)

Lost Administrator Fingerprint

If the administrator fingerprint is lost, please dismantle the device and wait 30 seconds when

there is a short beep, then press the Tamper Switch three times to reset to the initial

administrator password, note this operation must be done within 30 seconds. It makes a long

beep after resetting successfully.

Note: The initial administrator password is 1234.

Each user can register up to 10 fingerprints and 1 card.

按管理员指纹输入新/已存在工号按指纹三次

/刷卡一次

Press【*】+

【#】

Verify

administrator

fingerprint

Press

【#】

Enter new/existed user

【#】

Press finger three times

or swipe the card once.

(The indicator turns

green and makes a

long beep)

Press【#】to continue

registering/editing

(The indicator turns

green and makes a long

beep)

Press【*】to exit

Note:

①Enter user ID to add new user. If the user ID already exists, the device defaults to edit the user.

②After registering a fingerprint successfully, the indicator turns green and makes a long beep;

you can continue to register other fingerprints, 10 at most.

③If the fingerprint or the card has been registered already or an error occurred while

registering, the indicator turns red and generates four short beeps indicating that the

registration fails. You can start registering the user again when the indicator turns green.

This device supports 8 passwords, each password has a Group ID ranged from 1~8. The default

password value is 0 for all groups, which means those passwords are disabled.

9. Registering Access Passwords

8. Adding/Editing Users

Verify administrator

fingerprint. Press【3】

Enter four digits

password twice, end

with【#】each time

Enter the group ID

（Group IDs：1~8）

Press【*】+【#】

Press【*】to exit.

Note: When a password is changed to 0000, the password is disabled. When a password is

successfully changed, you can immediately change the next password by entering another

group ID.

Fingerprint/ Card /Password Authentication

When the device is powered ON, it enters user authentication state (flash blue light).

1.The device is in user

authentication state.

2.Enter password【#】

/fingerprint/swipe user card

3.User

authentication

succeeds.

Note: The door opens only if the entered password matches with one of the 8 passwords. The

initial eight passwords for opening the door are set to 0.

Deleting One User

Press【2】

(The indicator turns

green and makes a

long beep)

Press【*】to exit

Enter user ID【#】

/fingerprint/swipe user card

(The indicator turns green

and makes a long beep)

Verify administrator

fingerprint

(The indicator turns

green and makes a

long beep)

Press【*】+【#】

Note: After successful deletion, the device will automatically enter the process of deleting next

user. Press [*] to exit.

Deleting All Users

Press【9】+【#】

(The indicator turns

green and makes a

long beep)

Press【*】to exit

(The indicator turns green

and makes a long beep)

Verify administrator

fingerprint

(The indicator turns

green and makes a

long beep)

Press【*】+【#】

11. User Deletion

10. User Authentication

Press【4】

Press【4】Enter the unlocking

duration【#】

(range：1s~10s）

Enter the unlocking

duration【#】

(range：1s~10s）

Press【*】to exit

Verify administrator

fingerprint

Press【*】+【#】

Note: Values greater than 10 will be considered invalid. The indicator turns red and makes four

short beeps. It is recommended to use default settings in access control. User can set according

to actual needs.

Press【5】Enter authentication

mode【#】

Verify administrator

fingerprint

Press【*】+【#】

Press【*】to exit

Note: Details of authentication modes are as follows:

Authentication

Mode

Value Description

Only password verification

Only RF card verification

Only fingerprint verification

FP/PW/RF

fingerprint or password or RF Card verification

RF&PW 5 RF Card and password verification (swipe card before

entering password)

FP&PW 6

fingerprint and password verification (fingerprinting

before entering password)

The door sensor has three modes:

NONE: The door sensor is disabled.

NO (Normally Open): The door sensor will send an alarm signal if it detects the door is

closed.

12. Unlocking Duration Configuration (default duration: 6s)

13. Authentication Mode Configuration (default mode: FP/PW/RF)

14. Door Sensor Mode Configuration (default mode: None)

NC (Normally Closed): The door sensor will send an alarm signal if it detects the door is open.

Note: If an alarm is triggered, when the door status is normal, it will be terminated after the

user is authenticated; when the door is in abnormal state, it will be terminated only after the

administrator is authenticated.

Configuring Alarm Switch

Administrator Authentication Alarm, Tamper Alarm and Door Sensor Alarm will be effective only

if the alarm switch is set to ON status.

Note: The default status of the alarm switch is ON. The alarm will not be triggered if the alarm

switch is set to OFF status.

Press【0】+【1】

Press【*】to exit

Verify administrator

fingerprint

Press【*】+【#】

Configure the alarm

setting【#】

(0:enable，1:disable)

Configuring Administrator Authentication Alarm*

If the administrator fails in authentication in 3 attempts, Administrator Authentication Alarm will

be triggered. No authentication can be made within 20 seconds. The default status of the

administrator authentication alarm is ON.

Press【0】+【2】

Press【*】to exit

Verify administrator

fingerprint

Press【*】+【#】

Configure

administrator

authentication alarm

switch【#】

(0:enable，1:disable)

15. Alarm Configuration

Press【0】+【5】

Press【*】to exit

Verify administrator

fingerprint

Press【*】+【#】

Configure the door

sensor mode【#】

(0:NO 1:NC 2:NONE)

Configuring Tamper Alarm

Press【7】

Press【*】to exit

Verify administrator

fingerprint

Press【*】+【#】

Configure tamper

alarm switch【#】

(0:enable，1:disable)

If this function is enabled, alarms will be raised when the device is dismantled from the wall.

Configuring Door Sensor Delay (default value: 10s)

When the door is not closed well after the set time period, the Door Sensor Alarm will generate

an alarm signal to alert the users.

Press【0】+【4】

Press【*】to exit

Verify administrator

fingerprint

Press【*】+【#】

Configure the door

sensor delay【#】

(range：1s~254s)

Note:

①Values greater than 254 are considered invalid. The indicator turns red and makes four short

beeps.

②When an alarm is triggered, the device interior alarm will be triggered first. After 30 seconds,

the device exterior alarm will be triggered.

Tabla de contenidos

Otros manuales de Controladores de acceso IP de ZKTeco

ZKTeco

ZKTeco G4 Manual de usuario

ZKTeco

ZKTeco SpeedFace-VSL Series Manual de usuario

ZKTeco

ZKTeco SC800 Manual de usuario

ZKTeco

ZKTeco ProBio Manual de usuario

ZKTeco

ZKTeco C2-260/inBio2-260 Manual de usuario

ZKTeco

ZKTeco LockerPad-7B Manual de usuario

ZKTeco

ZKTeco TF1600 ZKTeco Manual de usuario

ZKTeco

ZKTeco F18 Manual de usuario

ZKTeco

ZKTeco MiniAC Plus Manual de usuario

ZKTeco

ZKTeco LF10 Manual de usuario

ZKTeco

ZKTeco ProCapture-T Manual de usuario

ZKTeco

ZKTeco MA500 Guía de solución de problemas

ZKTeco

ZKTeco SpeedFace-V5L Manual de usuario

ZKTeco

ZKTeco Green Label ProCapture-T Manual de usuario

ZKTeco

ZKTeco Ultima Series Manual de usuario

ZKTeco

ZKTeco White LCD Series Manual de usuario

ZKTeco

ZKTeco F19 Manual de usuario

ZKTeco

ZKTeco ProMA Series Manual de usuario

ZKTeco

ZKTeco SpeedFace V5L QR Series Manual de usuario

ZKTeco

ZKTeco F18 Manual de usuario

ZKTeco

ZKTeco F18 Manual de usuario

ZKTeco

ZKTeco SilkID F21-ID Manual de usuario

ZKTeco

ZKTeco C2-260 Manual de usuario

ZKTeco

ZKTeco KF1000-U Manual de usuario

Manuales populares de Controladores de acceso IP de otras marcas

Jantar

Jantar REX A-1-9 Manual de usuario

2N Access Unit Hoja de instrucciones

Kedacom

Kedacom KSCA120 Series Manual de usuario

H3C

H3C WX2880X Manual de usuario

G4S

G4S S870-EX Guía

PRASTEL

PRASTEL M2000PE Manual de usuario

Allegion

Allegion interflex IF-281 Cylinder Manual de usuario

TECOM

TECOM TS1067E Manual de usuario

Fermax

Fermax Memokey 100C Guía del usuario

Fermax

Fermax CITYLINE MEMOKEY Manual de instrucciones

Software House

Software House iSTAR Pro 2U RM Manual de instrucciones

AKCP

AKCP SP+ Manual de usuario

Bpt

Bpt HNA/102 Manual de usuario

Civintec

Civintec CV9601T-T-1F Manual de usuario

BioMax

BioMax N-X90W Manual de usuario

FingerTec

FingerTec s-Kadex Manual de usuario

H3C

H3C WX5002ACCESSCONTROLLER Manual de usuario

C Prox Ltd

C Prox Ltd DPN-2 Manual de usuario
