Winmate GC Series Manual de usuario

Please read these instructions carefully before using this product, and save this manual for future use.

19”~23.8” G-WIN Panel PC

Intel® Core™ i3/ i5/ i7

Model No. R19IK7T-GCM1

W22IK7T-GCA3

W24IK7T-GCA2

GC Series

Quick Start Guide

Document Version 1.0

Document Part No. 91521110105N

2 19”~23.8” G-WIN GC Series Panel PC Quick Start Guide

Contents

Preface 3

Chapter 1: Introduction 6

1.1 Introduction 7

1.2 Features 7

1.3 Package Content 7

1.4 Product Overview 8

1.5 Physical Buttons and LED Indicators 10

Chapter 2: Getting Started 11

2.1 Wiring Requirements 12

2.2 Turning On and Off Your Device 12

2.3 Connecting to Other Devices 13

Chapter 3: Mounting 16

3.1 VESA Mount 17

3.2 Panel Mount 17

Chapter 4: Operating the Device 18

4.1 Operating System 19

4.2 Multi-Touch 19

4.3 How to Enable Watchdog 20

4.4 Using Recovery Wizard to Restore Computer 21

Appendix 22

Appendix A: Product Specifications 22

Preface

FCC Statement

This device complies with part 15 FCC rules.

Operation is subject to the following two conditions:

This device may not cause harmful interference.

This device must accept any interference received including interference that

may cause undesired operation.

This equipment has been tested and found to comply with the limits for a class "B" digital device,

pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at him own expense.

European Union

This equipment is in conformity with the requirement of the following EU legislations and harmonized

standards. Product also complies with the Council directions.

Electromagnetic Compatibility Directive (2014/30/EU)

•EN55024: 2010/ A1: 2015

oIEC61000-4-2: 2009

oIEC61000-4-3: 2006+A1: 2007+A2: 2010

oIEC61000-4-4: 2012

oIEC61000-4-5: 2014

oIEC61000-4-6: 2014

oIEC61000-4-8: 2010

oIEC61000-4-11: 2004

•EN55032: 2012/AC:2013

•EN61000-3-2:2014

•EN61000-3-3:2013

Low Voltage Directive (2014/35/EU)

•EN 60950-1:2006/A11:2009/A1:2010/A12:2011/ A2:2013

4 19”~23.8” G-WIN GC Series Panel PC Quick Start Guide

No part of this document may be reproduced, copied, translated, or transmitted in any form or by any

means, electronic or mechanical, for any purpose, without the prior written permission of the original

manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks of their respective owners.

Disclaimer

Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or

software described or contained in this manual in order to improve design and/or performance. We

assume no responsibility or liability for the use of the described product(s) conveys no license or title

under any patent, copyright, or masks work rights to these products, and make no representations or

warranties that these products are free from patent, copyright, or mask work right infringement, unless

otherwise specified. Applications that are described in this manual are for illustration purposes only. We

make no representation or guarantee that such application will be suitable for the specified use without

further testing or modification.

Warranty

Winmate Inc. warranty guarantees that each of its products will be free from material and workmanship

defects for a period of one year from the invoice date. If the customer discovers a defect, we will, at

his/her option, repair or replace the defective product at no charge to the customer, provide it is

returned during the warranty period of one year, with transportation charges prepaid. The returned

product must be properly packaged in its original packaging to obtain warranty service. If the serial

number and the product shipping data differ by over 30 days, the in-warranty service will be made

according to the shipping date. In the serial numbers the third and fourth two digits give the year of

manufacture, and the fifth digit means the month (e. g., with A for October, B for November and C for

December).

For example, the serial number 1W16Axxxxxxxx means October of year 2016.

Customer Service

We provide a service guide for any problem by the following steps: First, visit the website of our

distributor to find the update information about the product. Second, contact with your distributor, sales

representative, or our customer service center for technical support if you need additional assistance.

You may need the following information ready before you call:

•Product serial number

•Software (OS, version, application software, etc.)

•Description of complete problem

•The exact wording of any error messages

In addition, free technical support is available from our engineers every business day. We are always

ready to give advice on application requirements or specific information on the installation and

operation of any of our products.

Preface

Advisory Conventions

Four types of advisories are used throughout the user manual to provide helpful information or to alert

you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and

Warnings. The following is an example of each type of advisory.

Note:

A note is used to emphasize helpful information

Important:

An important note indicates information that is important for you to know.

Caution A Caution alert indicates potential damage to hardware and explains how to

avoid the potential problem.

Attention Une alerte d’attention indique un dommage possible à l’équipement et

explique comment éviter le problème potentiel.

Warning!

An Electrical Shock Warning indicates the potential harm from electrical

hazards and how to avoid the potential problem.

Avertissement! Un Avertissement de Choc Électrique indique le potentiel de chocs sur

des emplacements électriques et comment éviter ces problèmes.

Safety Information

Warning!

Always completely disconnect the power cord from your chassis whenever

you work with the hardware. Do not make connections while the power is on. Sensitive

electronic components can be damaged by sudden power surges. Only experienced

electronics personnel should open the PC chassis.

Avertissement! Toujours débrancher le cordon d’alimentation du chassis lorsque

vous travaillez sur celui-ci. Ne pas brancher de connections lorsque l’alimentation est

présente. Des composantes électroniques sensibles peuvent être endommagées par

des sauts d’alimentation. Seulement du personnel expérimenté devrait ouvrir ces

chassis.

Caution Always ground yourself to remove any static charge before touching the

CPU card. Modern electronic devices are very sensitive to static electric charges. As a

safety precaution, use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded bag when they are not in

the chassis.

Attention Toujours verifier votre mise à la terre afin d’éliminer toute charge statique

avant de toucher la carte CPU. Les équipements électroniques moderns sont très

sensibles aux décharges d’électricité statique. Toujours utiliser un bracelet de mise à

la terre comme précaution. Placer toutes les composantes électroniques sur une

surface conçue pour dissiper les charge, ou dans un sac anti-statique lorsqu’elles ne

sont pas dans le chassis.

General Guideline

It is recommended to reboot the device when some functions are defect or inactive. If it still can't solve the

problems please contact your dealer or agent.

Alternating Current

The Protective Conductor Terminal (Earth Ground) symbol indicates the potential risk of

serious electrical shock due to improper grounding.

Mise à le terre !Le symbole de Mise à Terre indique le risqué potential de choc

électrique grave à la terre incorrecte.

6 19”~23.8” G-WIN GC Series Panel PC Quick Start Guide

Chapter 1: Introduction

This chapter gives you product overview, describes features and hardware

specification. You will find all accessories that come with the panel PC in

the packing list. Mechanical dimensions and drawings included in this

chapter.

0BChapter 1: Introduction

1.1 Introduction

Congratulations on purchasing Winmate® G-WIN GC Series Panel PC. The elegantly designed, yet

rugged, industrial grade G-WIN GC series is designed for heavy duty applications.

With rugged construction, ultimate computing power, G-WIN GC Series Panel PC are guaranteed to

meet "heavy duty" needs. This series feature high computing power and user-friendly interface with

projected capacitive multi-touch (PCAP) technology and support Windows® operating systems. Rugged

housing provides front IP65 protection against outer dust and water splash.

1.2 Features

Winmate® GC Series Panel PC features:

•19”/ 21.5”/ 23.8” PCAP touchscreen

•High performance Intel® Core™ i3/i5/i7 processor

•Front IP65 for protection against water and dust

•A true flat, easy-to-clean front surface with edge-to-edge design

•Plenty of I/O, including 2 x LAN, 1 x RS232/422/485,2 x RS232, 4 x USB 3.0, 1 x HDMI 1.4a,

1 x DP 1.2, Line-Out, Mic in

•DP Support 4096 x 2304@60Hz

•HDMI Support 4096 x 2304@24Hz

1.3 Package Content

Carefully remove the box and unpack your device. Please check if all the items listed below are inside

your package. If any of these items are missing or damaged contact us immediately.

Standard factory shipment list:

•Panel PC

•Quick Start Guide

(Hardcopy)

•Driver CD & User Manual

Varies by product specifications Part No. 91521110105N Part No. 91521110105I

•AC Adapter 12V/ 84W

•

Power Cable

Part No. 922D084W12V0 Varies by country

8 19”~23.8” G-WIN GC Series Panel PC Quick Start Guide

1.4 Product Overview

19”, R19IK7T-GCM1

Unit: mm

21.5”, W22IK7T-GCA3

Unit: mm

№

Description

№

Description

①

Power On Button

⑥

2 x RJ45-10/100/1000 Mbps

②

Reset Button

⑦

DP 1.2

③

1 x RS-232/422/485, 2 x RS-232

⑧

HDMI 1.4

④

Mic in/ Line out

⑨

12V DC IN

⑤

4 x USB 3.0

⑩

Brightness Adjustment Knob

90BChapter 1: Introduction

23.8”, W24IK7T-GCA2

Unit: mm

№

Description

№

Description

①

Power On Button

⑥

2 x RJ45-10/100/1000 Mbps

②Reset Button ⑦DP 1.2

③

1 x RS-232/422/485, 2 x RS-232

⑧

HDMI 1.4

④

Mic in/ Line out

⑨

12V DC IN

⑤

4 x USB 3.0

⑩

Brightness Adjustment Knob

№

Description

№

Description

①

Power On Button

⑥

2 x RJ45-10/100/1000 Mbps

②Reset Button ⑦DP 1.2

③

1 x RS-232/422/485, 2 x RS-232

⑧

HDMI 1.4

④

Mic in/ Line out

⑨

12V DC IN

⑤

4 x USB 3.0

⑩

Brightness Adjustment Knob

10 19”~23.8” G-WIN GC Series Panel PC Quick Start Guide

1.5 Physical Buttons and LED Indicators

Physical buttons and LED indicators located on the rear side of the panel PC.

Physical Buttons

Icon

Button

Description

Reset Press to reset the system

Power On/ Off Press to power on or power off the

device

LED Indicators

LED Type

Status

Description

On Power is on

Off

Power is off

Blinking

Storage activity

(Data is being read or written)

Off System is idle

Otros manuales para GC Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Panel táctil de Winmate

Winmate

Winmate W10FA3S-GCH1 Manual de usuario

Winmate

Winmate W04FA3S-EHT1 Manual de usuario

Winmate

Winmate W07IB3S-EHT1 Manual de usuario

Winmate

Winmate W10IB3S-PCH2AC-PoE S-Series Manual de usuario

Winmate

Winmate W07IB3S-PCO1-POE Manual de usuario

Winmate

Winmate R17IW3S-SPM1 Manual de usuario

Winmate

Winmate M185D Manual de usuario

Winmate

Winmate W10RK3S-PCH2LB Manual de usuario

Winmate

Winmate R15IH3S-67A3HB Manual de usuario

Winmate

Winmate R15ID3S-65A1FTE Manual de usuario

Winmate

Winmate R15IB3S-PCC3-PoE Manual de usuario

Winmate

Winmate R15IB3S-65EX Manual de usuario

Winmate

Winmate R15IK3S-POC3 Manual de usuario

Winmate

Winmate W27FA3S-CHC1 Manual de usuario

Winmate

Winmate 7'' S-Series Manual de usuario

Winmate

Winmate R10IBWS-MHP1 Manual de usuario

Winmate

Winmate W10IE3S-MRH2FP Manual de usuario

Winmate

Winmate ATEX R19IHAT-66EX-T Manual de usuario

Winmate

Winmate W07IB3S-GCM1(HB) Manual de usuario

Winmate

Winmate W07IB3S-POT1 Manual de usuario

Winmate

Winmate W15IB3S-PTA3 Manual de usuario

Winmate

Winmate W10IB3S-GSH1 Manual de usuario

Winmate

Winmate W07FA3S-EHT1 Manual de usuario

Winmate

Winmate R15IB3S-SPC369 Manual de usuario

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

AMX

AMX AXP-PPC Guía

Sartorius

Sartorius X3 PR 5410 Manual de usuario

AMX

AMX Modero X Series Manual de usuario

Advantech

Advantech TPC-30 Series Manual de usuario
