N’FINITY PRO BEVERAGE CENTER

INSTRUCTION MANUAL

PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLING AND OPERATING.

TABLE OF CONTENTS

Contents ____________________Page #

Beverage Center Package Contents 3

Important Safety & Pre-Use Instructions 3

Installation Instructions

(a) General Installation Instructions 3

(b) Installation of Built-In Unit 4

Operating Your Beverage Center 4

Temperature Settings 5

Removing the Rolling Shelf 6

Care & Maintenance 6

Troubleshooting Guide 7

Technical Information 8

Warranty Information 8

Beverage center Package Contents

•Instruction manual

•6 wine shelves, 4 beverage shelves

•2 keys

IMPORTANT SAFETY INSTRUCTIONS

WARNING To reduce the risk of fire, electrical shock, or injury when

using your appliance, follow these basic precautions:

Read all instructions before using the beverage center.

DANGER: Risk of child becoming trapped in new beverage center, old beverage center/refrigeration unit, or

large boxes.

Junked or abandoned appliances, boxes and other containers are still dangerous, even if they will “just sit in

the garage for a few days”.

Before you throw away your old beverage center or refrigeration unit: 1. Take off the door. 2. Leave the

shelves in place so that children cannot climb inside.

Never allow children to operate, play with, or crawl inside the appliance.

Never clean appliance parts with flammable fluids. The fumes can create a fire hazard or explosion.

Do not store in the vicinity of any other appliance. Do not store near gasoline or any other flammable vapors.

The fumes can create a fire hazard or explosion.

-Save these instructions-

BEFORE USING YOUR BEVERAGE CENTER

Remove the exterior and interior packaging.

Before connecting the beverage center to the power source, let it stand upright for approximately 2 hours.

This will reduce the possibility of a malfunction in the cooling system from handling during transportation.

Clean the interior surface with lukewarm water using a soft cloth.

INSTALLATION INSTRUCTIONS

(a) General Installation Instructions

This appliance is designed for free standing installation or recessed into cabinetry (built-in).

Place your beverage center on a flat, solid floor that is strong enough to support it when it is fully loaded.

To level your beverage center, adjust the front leveling leg at the bottom of the beverage center.

When moving your beverage center, please do not incline it more than 45 degrees.

Locate the beverage center away from direct sunlight and sources of heat (stove, heater, radiator, etc.).

Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption.

Extreme cold ambient temperatures may also cause the unit to perform improperly.

Avoid locating the unit in damp areas.

Plug the beverage center into a dedicated (for this appliance only), properly installed and grounded wall

outlet. Do not under any circumstances cut or remove the third (grounding) prong from the power cord.

Any questions concerning power and/or electrical grounding should be directed to a certified electrician or

authorized product service center.

Built-In Installation

The cutout dimension illustrated in figure (A) allows for door swing and access to the pull-out shelves when

installed as a built-in appliance. If installing between frameless cabinets, a ½” wide filler strip or side panel may

be needed on hinge side. The filler strip will act as a spacer between the appliance case and adjacent cabinet door

swing. The width of the opening must include the filter panels.

OPERATING YOUR BEVERAGE CENTER

Your N’Finity Pro Beverage Center has separate controls for the wine storage compartment and beverage storage

compartment.

Wine Storage Compartment Controls

LOCK: Press the lock button for 3 seconds to unlock the control panel. After 15 seconds of inactivity, the

control panel will lock automatically.

UP/DOWN: Increases or decreases temperature by 1 degree.

C/F: Press both buttons simultaneously for 3 seconds to change the temperature reading to Fahrenheit or

Celsius.

LIGHT: Turns the interior wine cellar light on or off.

ON/OFF: Push the UP and DOWN buttons simultaneously for 3 seconds to turn the appliance on or off.

Beverage Storage Compartment Controls

LOCK: Press the lock button for 3 seconds to unlock the control panel. After 15 seconds of inactivity, the

control panel will lock automatically.

UP/DOWN: Increases or decreases temperature by 1 degree.

C/F: Press both buttons simultaneously for 3 seconds to change the temperature reading to Fahrenheit or

Celsius.

LIGHT: Turns the interior beverage cooler light on or off.

ON/OFF: Push the UP and DOWN buttons simultaneously for 3 seconds to turn the appliance on or off.

TEMPERATURE SETTINGS FOR SERVING WINE

1. Although optimal storage temperature is generally regarded to be 53-57°F, different varietals of wine require

different service temperature settings. The recommended temperature ranges for serving different varietals of

wine are listed below. Your beverage center will indicate when you have set the Upper/Lower zones to the

below temperature ranges.

•Red Wines: 60-66°F

•White Wines 45-52°F

•Sparkling Wines 40-45°F

LAYOUT AND STORAGE

Your cabinet was designed to store a maximum number of bottles securely. We recommend that you observe the

tips below to optimize loading.

•Remove tape from shelves once unit is stable and ready for storage.

•Disperse the bottles evenly to avoid concentrating weight in one place. Bottles must not touch either the back of

the cabinet or the step at the bottom.

•Make sure that the bottles are not all grouped together either at the top or bottom of the cabinet.

•Only pull out one rolling shelf at a time. Never attempt to pull more than one.

•Maximum weight capacity per shelf is 55 lbs.

•You can increase your beverage center’s storage capacity by removing shelves and stacking bottles on top of

one another. Do not stack more than 3 rows of bottles per shelf.

REMOVING THE ROLLING SHELF

To remove a rolling shelf:

1. Remove all bottles.

2. Pull the shelf out as far as it will go.

3. Push the left side lever upwards while pushing the right side lever downwards (as illustrated below).

4. Remove the shelf.

CARE AND MAINTENANCE

Cleaning Your Beverage center.

Turn off the power, unplug the appliance, and remove all items including all shelves.

Wash the inside surfaces with a solution of warm water and baking soda (approximately 2 tablespoons of baking

soda for each quart of water.)

Wash the shelves with a mild detergent solution.

Wring excess water out of the sponge or cloth when cleaning area of the controls, or any electrical parts.

Wash the outside of the cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with a clean soft

cloth.

Vacuum the front grill and back of the unit twice yearly. Make sure the power is off before cleaning.

It is recommended to clean the unit completely inside and out once a year to maximize the longevity of the beverage

center.

Power Loss

Power failures that are corrected within a few hours should not affect the temperature of your appliance if you

minimize the number of times the door is opened. If the power is going to be off for a longer period of time, you need

to take other measures to protect your contents.

If the unit is unplugged, loses power, or is turned off, you must wait 3 to 5 minutes before restarting. Attempting to

restart the beverage center before this time has elapsed may prevent the beverage center from starting.

Absence/Vacation

Short vacations: You may leave the beverage center powered on and unattended for absences of less than three

(3) weeks.

Long vacations: If the appliance will not be used for more than three weeks, remove all items and turn off the

appliance. Clean and dry the interior thoroughly. To prevent mold growth, leave the door open slightly, blocking it

open if necessary.

Moving Your Beverage center

Remove all items.

Securely tape down all loose items (shelves) inside your appliance.

Turn the adjustable leg up to the base to avoid damage.

Tape the door shut.

Be sure the appliance stays secure in the upright position during transportation. Also protect the outside of the

appliance with a blanket or similar item.

Energy saving Tip

The beverage center should be located in the coolest area of the room, away from heat producing appliances, and

away from direct sunlight.

TROUBLESHOOTING GUIDE

Many common issues with your beverage center can be solved very easily. Try the troubleshooting tips below

should you experience any problems.

PROBLEM

POSSIBLE CAUSE

Beverage center does not operate. Not plugged in.

The appliance is turned off.

The circuit breaker tripped or a fuse has blown out.

Beverage center is not cold enough. Check the temperature control setting.

External environment may require a higher setting. (e.g. room

needs to be air conditioned)

The door is opened too often.

The door is not closed completely.

The door gasket is not sealing properly.

Beverage center is turning on and off frequently. The room temperature is hotter than normal.

The door is opened too often.

The door is not closed completely.

The temperature control is not set correctly.

The door gasket does not seal properly.

The light does not work. Not plugged in.

The circuit breaker tripped or a fuse has blown.

The light bulb has burned out.

The light button is “OFF”.

Vibrations. Check to assure that the beverage center is on a level

surface.

The beverage center seems to make too much noise. A faint humming noise

may come from the flow of the

refrigerator, which is normal.

As each cycle ends, you may hear gurgling sounds caused by

the flow of refrigerant in your beverage center.

Contraction and expansion of the

inside walls may cause

popping and crackling noises.

The beverage center is not on a level surface.

The door will not close properly. The beverage center is not on a level surface.

The gasket is dirty.

The shelves are out of position.

The area around the door is hot. Your beverage center comes with a heating element near the

door that keeps frost and condensation off the glass and it’s

normal for t

his area to feel warm. It will not affect the

temperature of your beverage center.

TECHNICAL DATA

WARRANTY INFORMATION

Please speak to your retailer before calling Wine Enthusiast if you did not purchase your beverage center directly from

Wine Enthusiast.

LIMITED WARRANTY

Length of Warranty: This Limited Warranty lasts for one (1) year from date of receipt of purchase of the wine cellar

(“Limited Warranty Period”). Extended warranties may be available for an additional cost at the time of purchase or up to

30 days from date of purchase. These extended warranties would extend this one (1) year limited warranty to two (2), three

(3), or five (5) years. Details about our extended protection plans can be found @ wineenthusiast.com.

Who is Protected: This Limited Warranty protects the original purchaser during the Limited Warranty Period, provided that

such purchaser can present appropriate proof of original purchase.

What is Covered: This Limited Warranty covers any defects in workmanship or materials in your new wine cellar under

normal use.

Art No. 268 02 40 02

Type of cooling Compressor & air-circulated fan cooling

Climate type N

Electricity protection grade I

Nominal voltage/Frequency 115V/60HZ

Rated power(W) 150W

Ambient temperature 60-77 degrees Fahrenheit

Temperature range Wine Storage: 45F - 65F

Beverage Storage: 34F - 43F

Range of inside cabinet humidity 60% RH

What is Not Covered: The following are not covered by this Limited Warranty damage due to such things as accident,

misuse, abuse, mishandling, neglect, unauthorized repair, failure to properly maintain, acts of God or any other cause beyond

the reasonable control of the Wine Enthusiast whether similar or dissimilar to the foregoing.

Purchaser understands and acknowledges that the wine cellar is a wine refrigerator, which houses wine. Purchaser assumes

all the risk of using these units, including risk of spoilage, humidity variations, temperature variations, leaks, fires, water

damage, mold, mildew, dryness and similar perils that may occur.

What We Will Do: During the Limited Warranty Period, Wine Enthusiast and/or the manufacturer will, at its sole discretion,

repair or replace any wine cellar not operating within the manufacturer’s specifications. All costs for labor and materials

thereto shall be covered during the Limited Warranty Period. If Wine Enthusiast deems the wine cellar is not repairable,

Wine Enthusiast will use the value of your original order toward a replacement; provided, however, that the purchaser will be

responsible for all shipping and handling costs with respect to the replacement after the initial ninety (90) days after the date

of receipt of original purchase. After the initial ninety (90) day period after the date of receipt of purchase, purchaser

must pay any shipping and handling charges that are incurred in shipping or transporting the wine cellar for service

under this Limited Warranty. Wine Enthusiast reserves the right to substitute materials of substantially similar quality in

the event that identical materials are not available at the time the Limited Warranty services are performed. Wine Enthusiast

reserves the right to request that purchaser contact a local refrigeration company to service the wine cellar.

How to get Warranty Service: In the event your wine cellar is not operating within the manufacturer’s specifications,

during the Warranty Period, contact customer service by email at custserv@WineEnthusiast.net or by phone 800.648.6058.

Limitation of Implied Warranties: All implied warranties, including warranties of merchantability and fitness for a

particular purpose, are limited in duration to the length of this Limited Warranty.

Exclusion of Certain Damages: Wine Enthusiast’s liability is limited to replacement or repair of the defective wine cellar.

Wine Enthusiast shall not be liable for any damages, whether incidental, consequential or otherwise, because of any defective

wine cellar.

How State Law Applies: Some states do not allow limitations on how long an implied warranty lasts and/or do not allow

the exclusion of incidental or consequential damages, so the above limitations and exclusions may not apply to you.

The Limited Warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

Tabla de contenidos

Otros manuales de Enfriador de vino de WineEnthusiast

WineEnthusiast

WineEnthusiast Q-50-Bottle Manual de usuario

WineEnthusiast

WineEnthusiast 268 68 40 01 Manual de usuario

WineEnthusiast

WineEnthusiast 18-Bottle Silent Wine Refrigerator Manual de usuario

WineEnthusiast

WineEnthusiast 272 03 07 Manual de usuario

WineEnthusiast

WineEnthusiast 268 68 20 01 Manual de usuario

WineEnthusiast

WineEnthusiast N'Finity 273 02 23 Manual de usuario

WineEnthusiast

WineEnthusiast VinoView 269 0X 88 0Y Manual de usuario

WineEnthusiast

WineEnthusiast 236 02 80 02 Manual de usuario

WineEnthusiast

WineEnthusiast NFINITY PRO Manual de usuario

WineEnthusiast

WineEnthusiast 36-Bottle Silent Wine Refrigerator Manual de usuario

WineEnthusiast

WineEnthusiast 259 Bottle Wine Cellar Manual de usuario

WineEnthusiast

WineEnthusiast Q-25-Bottle Manual de usuario

WineEnthusiast

WineEnthusiast S-187i Manual de usuario

WineEnthusiast

WineEnthusiast 6 Bottle Wall Hanging Wine Refrigerator Manual de usuario

WineEnthusiast

WineEnthusiast 264 01 59 03 Manual de usuario

WineEnthusiast

WineEnthusiast Portfolio Collection Manual de usuario

WineEnthusiast

WineEnthusiast 288 02 20 02 Manual de usuario

WineEnthusiast

WineEnthusiast VinoView 269 0X 88 0Y Manual de usuario

WineEnthusiast

WineEnthusiast Q-121-Bottle Manual de usuario

WineEnthusiast

WineEnthusiast Beverage Center Manual de usuario

WineEnthusiast

WineEnthusiast WES-45-SB Instrucciones de montaje

WineEnthusiast

WineEnthusiast Trilogy Manual de usuario

WineEnthusiast

WineEnthusiast 272 03 09 Manual de usuario

WineEnthusiast

WineEnthusiast N'Finity Manual de usuario

Manuales populares de Enfriador de vino de otras marcas

U-Line

U-Line Echelon Wine Captain 2075WC Manual del propietario

Haier

Haier WS50GA Manual de usuario

Cavist

Cavist 62 Manual de usuario

Kenmore

Kenmore 461.99130 Manual de usuario

Miele

Miele KWT 6422 iG Manual de usuario

Danby

Danby DWC113BLSDB Manual de usuario

Caple

Caple Wi6128 Manual de usuario

Avanti

Avanti WC1001 Manual de usuario

Frigidaire

Frigidaire FFWC38F6LS Manual de usuario

Titan

Titan TT-W2454SZ Manual de instalación

Klarstein

Klarstein Botella 166 Uno Manual de usuario

Costway

Costway FP10130WL Manual de usuario

Lemair

Lemair LWC59 Manual de usuario

Haier

Haier JC-125GEA Manual de usuario

Caple

Caple WCi46B Manual de usuario

Climadiff

Climadiff CLI24 Guía rápida

Viking

Viking VCWB301LSS Manual de usuario

Caple

Caple WC6511 Manual de usuario
