TRILOGY WINE CELLAR

INSTRUCTION MANUAL

To ensure proper use of this appliance and your safety, please read the following

instruction manual completely before operating this appliance.

WineEnthusiast.com

800.356.8466

Operation Manual

Index

I. General Safety Precautions…………....................... 2

II. Technical Data………………………......................... 3

III. Operation ………………………………………….. …. 4

IV. Particular Precautions……………………………….... 5

V. Maintenance……………………………………………

VI. Troubleshooting……………………………………….. 6

I. GENERAL SAFETY PRECAUTIONS

Before using, make sure wine cellar is in good condition.

If in doubt, do not use it and contact an authorized

service center.

Read the operation manual carefully and check that the

rating data on the rating nameplate corresponds to your

power supply.

This wine cellar can only be used in the manner of which

it was designed. The manufacturer will not be liable for

any damage due to improper use or repairs made by

unqualified personnel.

Before cleaning the wine cellar, make sure it is

unplugged. Never clean the unit with acid, gasoline, oil

or any other kind of chemical substance that could

damage the wine cellar.

Repairs should only be made by authorized service

centers.

Caution

1. Free standing installation only

2. Do not use extension cords.

3. Danger: Risk of child entrapment. Before throwing

away your old refrigerator, you must:

a) Remove all doors.

b) Leave the shelves in place, so that children may

not easily climb inside.

II.TECHNICAL DATA

Type

Volume (liter) 145L

Case Wood

Material Door Wood & Glass

Unit Dimension

(HWD)(inches) 75.75x21x21

Packaging Dimension

(HWD)(inches) 82.75x27x27

Net Weight (lbs) 214

Gross Weight (lbs) 268

Power Consumption

(KW·h/24h) 4.5

Max ambient temperature

range of working 86° F

Temperature Range 52° - 65° F

Rated Voltage AC115V

Rated Frequency 60HZ

Current 2.8A

Input power 210W

III. OPERATION OF WINE CELLAR

Your wine cellar has an electric temperature control

located behind the top door which controls all 3 wine

cellars independently. You may program the temperature

of your wine cellar at any setting you desire. The

temperature range varies from 52 to 65 degrees. When

initially turned on, the LED will display the ambient

temperature and then the internal cabinet temperature.

The zone temperature may have a difference of 5°F (3°C)

from set temperature depending on quantity of bottles

loaded and ambient conditions.

a) You can control each compartment independently

by using the button.

b)Pressing the button on the display will increase

the temperature and the button will lower the

temperature.

c) Once you have set the desired temperature, the

display will flash for 5 seconds and then revert to the

internal cabinet temperature.

d)You can turn the interior light ON or OFF by pressing

the button.

e) You can display the temperature in either Fahrenheit

or Celsius by press the button.

f) You can turn off unused compartments by pressing

the button to highlight the specified compartment

and then the button to shut off the unit.

IV. PARTICULAR PRECAUTIONS

To assure your wine cellar works at the maximum

efficiency it was designed for, you should install it in a

location where there is proper air circulation and

electrical connections.

It is recommended you have 2” of clearance at the back

of the unit to allow for proper airflow.

For proper internal air circulation, do not overfill your

wine cellar.

Avoid direct sunlight.

Do not place heavy articles on the top of the cellar.

V. MAINTENANCE

Shut off power supply before cleaning cabinet.

Take out wines and shelves, and then clean the cabinet

with soda water first, then with clean water.

Do not use soap or detergent for the cabinet.

Clean the cellar regularly.

VI. TROUBLESHOOTING

Symptoms Possible cause Solutions

Not cooling

Not Plugged in

Low voltage

Blown fuse

Plug in the unit

Ensure normal voltage

Replace fuse with one of exact

amperage

Internal

temperature too

high

The wine cellar

is placed too

near a heat

source

Poor ventilation

Fans not working

Door is open

Keep the wine cellar away from

sunshine or other heat source

Place the wine cellar in the area

with good ventilation and keep

things away from the fans

Check whether the unit is plugged

in or change the fan

Close the door tightly

Inside light flashing

Set temperature

higher than inner

temperature

The automatic

defrost function

has turned on

Adjust the temperature

Normal function. No repair needed

Frost inside the

wine cellar

Too much

humidity or too

low temperature

inside the wine

cellar

Unplug the unit and defrost by

hand

Connect power again when the ice

thaws
