Viper 008

Unmanaged 8-port Ethernet Switch

26641-2211

6641-2211

General information

Legal information

The contents of this document are provided “as is”. Except as required by applicable law,

no warranties of any kind, either express or implied, including, but not limited to, the

implied warranties of merchantability and fitness for a particular purpose, are made in

relation to the accuracy and reliability or contents of this document. Westermo reserves

the right to revise this document or withdraw it at any time without prior notice.

Under no circumstances shall Westermo be responsible for any loss of data or income or

any special, incidental, and consequential or indirect damages howsoever caused.

More information about Westermo can be found at the following Internet address:

www.westermo.com

6641-2211

Safety

Before installation:

Read this manual completely and gather all information on the unit. Make sure

that you understand it fully. Check that your application does not exceed the safe

operating specifications for this unit.

This unit should only be installed by qualified personnel.

This unit should be built-in to an apparatus cabinet, or similar, where access is

restricted to service personnel only. The power supply wiring must be sufficiently

fused, and if necessary it must be possible to disconnect manually from all power

supply. Ensure compliance to national installation regulations. This unit relies on

convection cooling. Make sure that it is installed so that the ambient temperature

is within the specified temperature range, e.g. by avoiding obstruction of the

airflow around the unit. Also check chapter EN 45545-2 mounting notes.

The unit has no internal fuse and should be connected via an external fuse. The

fuse should be calculated in accordance with the rated current.

Before mounting, using or removing this unit:

Prevent access to hazardous voltage by disconnecting the unit from all power supply.

WARNING

Do not open connected unit. Hazardous voltage may occur within this unit when

connected to power supply.

Before powering-up, a protective earthing conductor must be connected to the

protective earthing terminal and have a cross-sectional area of at least 1.5 mm².

Note that this unit can be connected to two different power sources.

Be aware of that the surface of this unit may become hot. When this unit is

operated at high temperatures, the External Surface of Equipment may exceed

Touch Temperature Limit according to EN/IEC/UL 60950-1.

To reduce the risk of fire:

1. Use only No. 21 AWG or larger power cable

2. Use only No. 26 AWG or larger telecommunication line cord.

6641-2211

Care recommendations

Follow the care recommendations below to maintain full operation of unit and to fulfill

the warranty obligations:

…This unit must not be operating with removed covers or lids.

…Do not attempt to dissassemble the unit. There are not any user serviceable

parts inside.

…Do not drop, knock or shake the unit. Rough handling above the specification

may cause damage to internal circuit boards.

…Do not use harsh chemicals, cleaning solvents or strong detergents to clean the

unit.

…Do not expose the unit to any kind of liquid (water, beverages, paint etc). The

unit is not waterproof. Keep the unit within the specified humidity levels.

…Do not use or store the unit in dusty, dirty areas, connectors as well as other

mechanical part may be damaged.

…Do not cover or bring mechanical force to the ventilation membrane on the

back of the unit.

If the unit is not working properly, contact the place of purchase, nearest Westermo

distributor office or Westermo Tech support.

Maintenance

No maintenance is required, as long as the unit is used as intended within the specified

conditions.

Product disposal.

This symbol means that the product shall not be treated as

unsorted municipal waste when disposing of it. It needs to

be handed over to an applicable collection point for recy-

cling electrical and electronic equipment.

By ensuring this product is disposed of correctly, you will

help to reduce hazardous substances and prevent potential

negative consequences to both environment and human

health, which could be caused by inappropriate disposal.

6641-2211

Agency approvals and standards compliance

FCC Part 15.105 Notice: This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a partic-

ular installation. If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

… Reorient or relocate the receiving antenna

… Increase the separation between the equipment and receiver

… Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected

… Consult the dealer or an experienced radio/TV technician for help.

Type Approval / Compliance

EMC EN 61000-6-1, Immunity residential environments

EN 61000-6-2, Immunity industrial environments

EN 61000-6-3, Emission residential environments

EN 61000-6-4, Emission industrial environments

EN 50121-3-2, Railway applications - EMC: Rolling stock – Apparatus

EN 50121-4, Railway signalling and telecommunications apparatus

IEC 62236-4, Railway signalling and telecommunications apparatus

Safety EN 60950-1, IT equipment

Environmental EN 50155 Railway applications - Electronic equipment used on rolling stock

Fire protection EN 45545-2, Fire protection on railway vehicles

Simplified EU declaration of conformity

Hereby, Westermo declares that the equipment is in compliance with applicable EU

directives. The full EU declaration of conformity and other detailed information are

available at the respective product page at www.westermo.com.

6641-2211

Type tests and environmental conditions

Phenomena Test Description Test levels

ESD EN 61000-4-2 Enclosure contact ± 6 kV (crit A)

Enclosure air ± 8 kV (crit A)

RF field AM modulated IEC 61000-4-3 Enclosure 20 V/m 80% AM (1 kHz),

80 – 2500 MHz (crit A)

Fast transient EN 61000-4-4 Ethernet ports ± 2 kV (crit A)

Earth port ± 2 kV (crit A)

Surge EN 61000-4-5 Fault port ± 2 kV line to earth (crit A)

Ethernet ports ± 2 kV line to earth (crit A)

Power port ± 2 kV line to earth, ± 2 kV line to line

(crit A)

RF conducted EN 61000-4-6 Ethernet ports 10 V 80% AM (1 kHz), 0.15 – 80 MHz

(crit A)

Power port 10 V 80% AM (1 kHz), 0.15 – 80 MHz

(crit A)

Power frequency magnetic

field

EN 61000-4-8 Enclosure 1000 A/m 50 Hz

300 A/m 16.7 Hz, 60 Hz, DC (crit A)

Pulse magnetic field EN 61000-4-9 Enclosure 300 A/m (crit A)

Voltage dips and interruption EN 50155 DC power ports 10 ms interruption, 100 ms ±40% voltage

variation

Radiated emission CISPR 16-2-3

ANSI C63.4

(FCC part 15)

Enclosure Class B (30 – 6000 MHz)

Conducted emission CISPR 16-2-1 DC power port &

Ethernet ports

Class B

Dielectric strength EN 50155 Ethernet ports to other

isolated ports

707 VDC 1 min

Power & Fault port to

other isolated ports 2121 VDC 1 min

Temperature EN 60068-2-1

EN 60068-2-2

Operating –40 to +70ºC

Storage & Transport –40 to +70ºC

Humidity EN 60068-2-30 Operating 5 to 95% relative humidity

Storage & Transport 5 to 95% relative humidity

Altitude Operating 2000 m / 70 kPa

Reliability prediction (MTBF) MIL-C217F2 Operating Ground Benign:

150 years @ 20 ºC

147 years @ 40 ºC

135 years @ 60 ºC

Ground Mobile:

9,87 years @ 20 ºC

9,85 years @ 40 ºC

9,79 years @ 60 ºC

Ground Fix:

28,54 years @ 20 ºC

28,43 years @ 40 ºC

27,95 years @ 60 ºC

Service life Operating 10 year

Vibration, random simulated

long life

IEC 60068-2-64,

Cat. 1 class B

(EN 61373)

Not Operating Vertical: 7.9 m/s2

Transverse: 7.9 m/s2

Longitudinal: 7.9 m/s2

3 x 5 h

Vibration, random functional IEC 60068-2-64,

Cat. 1 class B

(EN 61373)

Operating Vertical: 1.0 m/s2

Transverse: 1.0 m/s2

Longitudinal: 1.0 m/s2

3 x 10 min

6641-2211

Phenomena Test Description Test levels

Shock, half sine pulses IEC 60068-2-27,

Cat. 1 class B

(EN 61373)

Operating Vertical: 50 m/s2

Transverse: 50 m/s2

Longitudinal: 50 m/s2

30 ms, 3 x 6 shocks

Shock, sawtooth IEC 60068-2-27,

Cat. 1 class B

(IEEE1478-2001)

Operating Vertical: 100 m/s2

Transverse: 100 m/s2

Longitudinal: 100 m/s2

11 ms, 3 x 6 shocks

Enclosure UL 94 Nickel coated zinc Flammability class V-1

Dimension W x H x D 175 x 100 x 53,4 mm

Weight 0.9 kg

Degree of protection IEC 529 Enclosure IP 65 when all ports are protected/

connected else IP 40

Cooling Convection

Mounting DIN Rail or wall mounted

6641-2211

Description

Functional description

Viper 008 is a unmanaged switch developed for rail and industrial applications. To meet

the environmental requirements from rail and harsh industrial applications the switch

has rugged M12 Ethernet connectors and full metal housing. The IP65 sealed metal case

make it robust and allows for the surrounding air temperature to be between –40 to

+70°C. There are no sensitive or fragile components, hardening the product against

shock and vibration making these units suitable for rolling stock usage. The power supply

operates over a wide input range from 24 to 110 VDC.

Interface specifications

Power and fault relay port PWR

Rated voltage 24 to 110 VDC

Operating voltage 16.8 to 143 VDC (14.4 to 154 VDC for 100 ms)

Rated current 110 mA @ 24 VDC

33 mA @ 110 VDC

Rated frequency DC

Inrush current, I2t Max 0.02 A2s @ 24 – 110 VDC

Polarity Reverse polarity protected

Startup current* 300 mA @ 16.8 VDC

Redundant power input No

Isolation to Connections X1 – X8 and to ground, 1500 VAC.

Fault relay belongs to the same isolation group as the power

supply lines (fault relay signals are also contained within

PWR).

Connection 4 pin male M12 connector with A-code

Connector size M12, recommended cable area 0.5 mm2 recommended

(minimum 0.25 mm2), cable dimensions depend on choice of

M12 connector

Shielded cable Not required, twisted pair is recommended

Fault relay resistance < 10 Ω

* If external power supply is used it must meet specified startup current.

M12 A-Coded

Power

Connector

Position Direction Description

1 U+ Positive supply voltage

2 Out Alarm relay (status) +

30 V Negative supply voltage

4 Out Alarm relay (status) –

Housing Shield Chassis of product (ground)

6641-2211

Fault Contact

The Viper switch is equipped with a potential free normally closed fault contact. The

fault contact is a solid state component (relay) that requires power to work and it is

transient protected. Additionally, the fault contact is opened when any of the following

conditions is met:

• No voltage on the power supply pin, a voltage level outside the legal voltage range

or current limitation on the voltage source is applied on the power input.

Description of how connection to the fault contact could be done is shown below. The

relay is closed when the unit is OK and open at failure. The relay is of semiconductor

type (no moving parts). It is specified for max current 250 mA continuous, 500 mA

peak (10 ms), operational voltage up to 110 V, protected by a 150 VDC-varistor,

ON-resistance less than 10 Ohm, and leakage current max 1 µA.

External relay

+24/48 VDC +

1 kΩ

Viper

2 2

4 4

Viper

To logic input

Input on PLC

Service port

The Service Port should not be used by non other than the Westermo Technical Support

team. Do not connect any device or cable to the Service Port.

Otros manuales para Viper 008

Tabla de contenidos

Otros manuales de Enrutador de red de Westermo

Westermo

Westermo Ibex-330 Series Manual de usuario

Westermo

Westermo SDI-550 Manual de usuario

Westermo

Westermo MDI-118 Series Manual de usuario

Westermo

Westermo LA-10 Manual de usuario

Westermo

Westermo Lynx 5600 Series Manual de usuario

Westermo

Westermo DR-250 Manual de usuario

Westermo

Westermo MRD-405 Manual de usuario

Westermo

Westermo Lynx Plus Manual de usuario

Westermo

Westermo Falcon Series Manual de usuario

Westermo

Westermo SDW-541-F1G-T4G Manual de usuario

Westermo

Westermo RedFox Rail Manual de usuario

Westermo

Westermo MRD-415 Manual de usuario

Westermo

Westermo Viper 408 Manual de usuario

Westermo

Westermo RFI-219-T3G Manual de usuario

Westermo

Westermo MRD-350 Manual de usuario

Westermo

Westermo SDW-550 E-mark Manual de usuario

Westermo

Westermo Lynx DSS L208-F2G-S2-EX Manual de usuario

Westermo

Westermo DR-200 Manual de usuario

Westermo

Westermo Lynx L106-F2G Manual de usuario

Westermo

Westermo LRW-112 Series Manual de usuario

Westermo

Westermo SDW-500 Manual de usuario

Westermo

Westermo Viper 108 Manual de usuario

Westermo

Westermo MDI-110-F3G Manual de usuario

Westermo

Westermo RedFox Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
