4 • Copyright

View

WAGO-I/O-SYSTEM 750

I/O Modules

1 Important Comments

To ensure fast installation and start-up of the units described in this manual,

we strongly recommend that the following information and explanations are

carefully read and abided by.

1.1 Legal Principles

1.1.1 Copyright

This manual is copyrighted, together with all figures and illustrations con-

tained therein. Any use of this manual which infringes the copyright provi-

sions stipulated herein, is not permitted. Reproduction, translation and elec-

tronic and photo-technical archiving and amendments require the written con-

sent of WAGO Kontakttechnik GmbH & Co. KG. Non-observance will entail

the right of claims for damages.

WAGO Kontakttechnik GmbH & Co. KG reserves the right to perform modi-

fications allowed by technical progress. In case of grant of a patent or legal

protection of utility patents all rights are reserved by WAGO Kontakttechnik

GmbH & Co. KG. Products of other manufacturers are always named without

referring to patent rights. The existence of such rights can therefore not be

ruled out.

1.1.2 Personnel Qualification

The use of the product detailed in this manual is exclusively geared to special-

ists having qualifications in PLC programming, electrical specialists or per-

sons instructed by electrical specialists who are also familiar with the valid

standards. WAGO Kontakttechnik GmbH & Co. KG declines all liability re-

sulting from improper action and damage to WAGO products and third party

products due to non-observance of the information contained in this manual.

1.1.3 Intended Use

For each individual application, the components supplied are to work with a

dedicated hardware and software configuration. Modifications are only per-

mitted within the framework of the possibilities documented in the manuals.

All other changes to the hardware and/or software and the non-conforming use

of the components entail the exclusion of liability on part of WAGO Kon-

takttechnik GmbH & Co. KG.

Please direct any requirements pertaining to a modified and/or new hardware

or software configuration directly to WAGO Kontakttechnik GmbH & Co.

KG.

Intended Use • 5

View

WAGO-I/O-SYSTEM 750

I/O Modules

1.2 Symbols

Danger

Always abide by this information to protect persons from injury.

Warning

Always abide by this information to prevent damage to the device.

Attention

Marginal conditions must always be observed to ensure smooth operation.

ESD (Electrostatic Discharge)

Warning of damage to the components by electrostatic discharge. Observe

the precautionary measure for handling components at risk.

Note

Routines or advice for efficient use of the device and software optimization.

More information

References on additional literature, manuals, data sheets and INTERNET

pages

1.3 Number Notation

Number Code Example Note

Decimal 100 normal notation

Hexadecimal 0x64 C notation

Binary '100'

'0110.0100'

Within ',

Nibble separated with dots

6 • Intended Use

View

WAGO-I/O-SYSTEM 750

I/O Modules

1.4 Safety Notes

Warning

Switch off the system prior to working on bus modules!

In the event of deformed contacts, the module in question is to be replaced, as

its functionality can no longer be ensured on a long-term basis.

The components are not resistant against materials having seeping and insu-

lating properties. Belonging to this group of materials is: e.g. aerosols, sili-

cones, triglycerides (found in some hand creams).

If it cannot be ruled out that these materials appear in the component envi-

ronment, then additional measures are to be taken:

- installation of the components into an appropriate enclosure

- handling of the components only with clean tools and materials.

Attention

Cleaning of soiled contacts may only be done with ethyl alcohol and leather

cloths. Thereby, the ESD information is to be regarded.

Do not use any contact spray. The spray may impair the functioning of the

contact area.

The WAGO-I/O-SYSTEM 750 and its components are an open system. It

must only be assembled in housings, cabinets or in electrical operation

rooms. Access must only be given via a key or tool to authorized qualified

personnel.

The relevant valid and applicable standards and guidelines concerning the

installation of switch boxes are to be observed.

ESD (Electrostatic Discharge)

The modules are equipped with electronic components that may be destroyed

by electrostatic discharge. When handling the modules, ensure that the envi-

ronment (persons, workplace and packing) is well grounded. Avoid touching

conductive components, e.g. gold contacts.

1.5 Scope

This manual describes the Digital Output Module 750-523

1 DO AC 230 V 16 A/Relay 1a/Pot. free of the modular

WAGO-I/O-SYSTEM 750.

Handling, assembly and start-up are described in the manual of the Fieldbus

Coupler. Therefore this documentation is valid only in the connection with the

appropriate manual.

750-523 [1 DO AC 230 V 16 A/Relay 1a/Pot. free] • 7

View

WAGO-I/O-SYSTEM 750

I/O Modules

2 I/O Modules

2.1 Digital Output Modules

2.1.1 750-523 [1 DO AC 230 V 16 A/Relay 1a/Pot. free]

1-Channel Relay Output Module AC 230 V, 16 A,

isolated outputs, 1 make contact, bistable, manual operation

2.1.1.1 View

750-523

DO DO

AUTO

HAND

Status

manual mode

Manual / automatic

Data contacts

Manual operationl

Switched status

Power jumper contacts

DO N

Fig. 2.1.1-1: 2-Channel Relay Output Module 750-523 g052300e

2.1.1.2 Description

A connected actuator or load is switched via the relay output module.

The 24 V supply is derived from the power jumper contacts to trigger the re-

lays.

The module has one output channel and enables the connection of one or two

actuators.

The signal output DO has two parallel connections so that an actuator can be

wired using one or two conductors of cross section > 2.5 mm². It is also possi-

ble to connect two actuators in parallel.

The module is equipped with an isolated contact relay so that only the connec-

tion points of the relay contacts are available on the fieldside.

Due to the isolated contacts, it is possible, for example, to connect several re-

lays in series by grouping these modules.

8 • 750-523 [1 DO AC 230 V 16 A/Relay 1a/Pot. free]

Description

WAGO-I/O-SYSTEM 750

I/O Modules

The relay contact L can be supplied with 230 VAC external voltage.

By closing the relay, the voltage applied to L will be switched to the second

relay contact DO.

The relay contact L is also equipped with two parallel connections.

Therefore, the voltage can be applied via one or two conductors of cross sec-

tion > 2.5 mm². The voltage can also be supplied to the following modules via

the second connection.

The automatic or manual operating mode can be selected using the "man-

ual/automatic" switch.

In the "automatic" operating mode, the relay is operated via the control system

requiring a 24 V power supply fed in via the internal power jumper contacts of

an adjacent supply module.

In this operating mode, manual status transitions which may occur via the red

"manual operation" switch (1/0) will be reset by the control system after less

than 500 ms.

In the "manual" operating mode, the relay cannot be switched via the control

system. Operation can only be performed manually via the red "manual opera-

tion" switch (1/0). Moreover, the actuator can be switched without 24 V

power supply.

Manual

AUTO

HAND

Control system

- Manual operation - Automatic Reset

Supply voltage

Fig. 2.1.1-2: Status-Diagram of the Relay Output Module 750-523 g052303e

The "manual" mode is indicated via the status LED and transmitted as status

bit into the process image.

The switched status "relay closed", "relay open" is indicated via the "manual

operation" switch (1/0).

750-523 [1 DO AC 230 V 16 A/Relay 1a/Pot. free] • 9

Description

WAGO-I/O-SYSTEM 750

I/O Modules

Note

The relay is bistable, i.e. stable in both defined switched status. Therefore, the

current switched status and information about this status remain unchanged in

the event of a loss of voltage.

The relay meets both international standards of IEC and DIN EN 61810 part 1

/ VDE 0435 part 201 as well as overload and short circuit requirements of IEC

and EN 61036 / 61037.

Any configuration of the output modules is possible when designing the field-

bus node. Grouping of module types is not necessary.

Attention

The relay output module 750-523 should not be directly connected to the

following modules: analog input module 750-467 (2 DI DC 0-10 V, up to

version number 3005), 750-468 (4 DI DC 0-10 V, up to version number 3005)

and 750-476 (2 DI DC +/-10 V, up to version number 3005)!

The output module has 24 V and 0 V built-in power jumper contacts. The

24 V power supply is used to trigger the relays.

The module is powered using an adjacent I/O module or a supply module via

power jumper contacts. The power supply to the following I/O modules is

made automatically by means of power contacts.

Warning

The maximum current of the internal power jumper contacts is 10 A. When

configuring the system it is important not to exceed the maximum/sum cur-

rent. However, if such a case should occur, another supply module must be

added.

Attention

A power supply module is required to connect the following I/O modules to

the ground!

Note

For the protection of relay coils and contacts, inductive loads must be damp-

ened with an effective protection circuit!

Examples of protection circuits can be seen in the section 2.1.2 "Contact Pro-

tective Circuit for Relay Modules".

The output module 750-523 can be used with all couplers/controllers of the

WAGO-I/O-SYSTEM 750.

10 • 750-523 [1 DO AC 230 V 16 A/Relay 1a/Pot. free]

Display Elements

WAGO-I/O-SYSTEM 750

I/O Modules

2.1.1.3 Display Elements

AUTO

HAND

Status

manual mode

Manual operation

Switched status

Fig. 2.1.1-3: Display Elements g052302x

LED Channel Designation State Function

off Operating mode: automatic

yellow (flashing) 1 Status

manual operation on Operating mode:

manually operated

LED Channel Designation State Function

0 Relay opened

(1/0) 1 Switching status

1 Relay closed

2.1.1.4 Schematic Diagram

750-523

24 V

10nF

10nF 10nF

Manual

Fig. 2.1.1-4: 1-Channel Relay Output Module 750-523 g052301e

Tabla de contenidos

Otros manuales de Unidad de control de WAGO

WAGO

WAGO 750-430/040-000 Manual de usuario

WAGO

WAGO 750-506 Series Manual de usuario

WAGO

WAGO 750-528 Manual de usuario

WAGO

WAGO 750 Series Manual de usuario

WAGO

WAGO 2789-9080 Manual de usuario

WAGO

WAGO WAGO-I/O-SYSTEM 750 Series Manual de usuario

WAGO

WAGO 750-655 Manual de usuario

WAGO

WAGO WAGO-I/O-SYSTEM 750 Series Manual de usuario

WAGO

WAGO I/O-SYSTEM 750 Manual de usuario

WAGO

WAGO I/O-SYSTEM 751-4001 Manual de usuario

WAGO

WAGO 753-647 Manual de usuario

WAGO

WAGO 750-451 Manual de usuario

WAGO

WAGO 750-539 Manual de usuario

WAGO

WAGO SPEEDWAY 767 Series Manual de usuario

WAGO

WAGO 750-429/040-001 Manual de usuario

WAGO

WAGO 750-495/040-00 Series Manual de usuario

WAGO

WAGO 761-113 Manual de usuario

WAGO

WAGO 751-5202 Manual de usuario

WAGO

WAGO SPEEDWAY 767 Series Manual de usuario

WAGO

WAGO 753-668/000-004 Manual de usuario

WAGO

WAGO SPEEDWAY 767 Series Manual de usuario

WAGO

WAGO I/O-SYSTEM 750-597 Manual de usuario

WAGO

WAGO 750-405 Manual de usuario

WAGO

WAGO 750-486/040-000 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario

Flyron

Flyron FN-BC04 Manual de usuario
