WAGO 750-405 Manual de usuario

Fieldbus Independent

I/O Modules

2 DI AC 230 V 10 ms, High-Side

Switching

750-405

Manual

Version 1.0.5

ii • General

WAGO-I/O-SYSTEM 750

I/O Modules

WAGO Kontakttechnik GmbH & Co. KG

Hansastraße 27

D-32423 Minden

Phone: +49 (0) 571/8 87 – 0

Fax: +49 (0) 571/8 87 – 1 69

E-Mail: [email protected]

Web: http://www.wago.com

Technical Support

Phone: +49 (0) 571/8 87 – 5 55

Fax: +49 (0) 571/8 87 – 85 55

E-Mail: [email protected]

Every conceivable measure has been taken to ensure the correctness and com-

pleteness of this documentation. However, as errors can never be fully ex-

cluded, we would appreciate any information or ideas at any time.

E-Mail: [email protected]

We wish to point out that the software and hardware terms as well as the

trademarks of companies used and/or mentioned in the present manual are

generally trademark or patent protected.

Content • iii

WAGO-I/O-SYSTEM 750

I/O Modules

CONTENT

1Important Comments ................................................................................. 4

1.1 Legal Principles........................................................................................4

1.1.1 Copyright ............................................................................................. 4

1.1.2 Personnel Qualification ....................................................................... 4

1.1.3 Intended Use ........................................................................................ 4

1.2 Symbols .................................................................................................... 5

1.3 Number Notation...................................................................................... 5

1.4 Safety Notes ............................................................................................. 6

1.5 Scope ........................................................................................................ 6

2I/O Modules ................................................................................................. 7

2.1 Digital Input Modules ..............................................................................7

2.1.1 750-405 [2 DI AC 230 V 10 ms, High-Side Switching] ..................... 7

2.1.1.1 View................................................................................................ 7

2.1.1.2 Description...................................................................................... 7

2.1.1.3 Display Elements ............................................................................ 8

2.1.1.4 Schematic Diagram......................................................................... 9

2.1.1.5 Technical Data .............................................................................. 10

2.1.1.6 Process image................................................................................ 11

4 • Important Comments

Legal Principles

WAGO-I/O-SYSTEM 750

I/O Modules

1 Important Comments

To ensure fast installation and start-up of the units described in this manual,

we strongly recommend that the following information and explanations are

carefully read and abided by.

1.1 Legal Principles

1.1.1 Copyright

This manual is copyrighted, together with all figures and illustrations

contained therein. Any use of this manual which infringes the copyright

provisions stipulated herein, is not permitted. Reproduction, translation and

electronic and photo-technical archiving and amendments require the written

consent of WAGO Kontakttechnik GmbH & Co. KG. Non-observance will

entail the right of claims for damages.

WAGO Kontakttechnik GmbH & Co. KG reserves the right to perform

modifications allowed by technical progress. In case of grant of a patent or

legal protection of utility patents all rights are reserved by WAGO

Kontakttechnik GmbH & Co. KG. Products of other manufacturers are always

named without referring to patent rights. The existence of such rights can

therefore not be ruled out.

1.1.2 Personnel Qualification

The use of the product detailed in this manual is exclusively geared to

specialists having qualifications in PLC programming, electrical specialists or

persons instructed by electrical specialists who are also familiar with the valid

standards. WAGO Kontakttechnik GmbH & Co. KG declines all liability

resulting from improper action and damage to WAGO products and third party

products due to non-observance of the information contained in this manual.

1.1.3 Intended Use

For each individual application, the components supplied are to work with a

dedicated hardware and software configuration. Modifications are only

permitted within the framework of the possibilities documented in the

manuals. All other changes to the hardware and/or software and the non-

conforming use of the components entail the exclusion of liability on part of

WAGO Kontakttechnik GmbH & Co. KG.

Please direct any requirements pertaining to a modified and/or new hardware

or software configuration directly to WAGO Kontakttechnik GmbH & Co.

KG.

Important Comments • 5

Symbols

WAGO-I/O-SYSTEM 750

I/O Modules

1.2 Symbols

Danger

Always abide by this information to protect persons from injury.

Warning

Always abide by this information to prevent damage to the device.

Attention

Marginal conditions must always be observed to ensure smooth operation.

ESD (Electrostatic Discharge)

Warning of damage to the components by electrostatic discharge. Observe

the precautionary measure for handling components at risk.

Note

Routines or advice for efficient use of the device and software optimization.

More information

References on additional literature, manuals, data sheets and INTERNET

pages

1.3 Number Notation

Number Code Example Note

Decimal 100 normal notation

Hexadecimal 0x64 C notation

Binary '100'

'0110.0100'

Within ',

Nibble separated with dots

6 • Important Comments

Safety Notes

WAGO-I/O-SYSTEM 750

I/O Modules

1.4 Safety Notes

Warning

Switch off the system prior to working on bus modules!

In the event of deformed contacts, the module in question is to be replaced, as

its functionality can no longer be ensured on a long-term basis.

The components are not resistant against materials having seeping and

insulating properties. Belonging to this group of materials is: e.g. aerosols,

silicones, triglycerides (found in some hand creams).

If it cannot be ruled out that these materials appear in the component

environment, then additional measures are to be taken:

- installation of the components into an appropriate enclosure

- handling of the components only with clean tools and materials.

Attention

Cleaning of soiled contacts may only be done with ethyl alcohol and leather

cloths. Thereby, the ESD information is to be regarded.

Do not use any contact spray. The spray may impair the functioning of the

contact area.

The WAGO-I/O-SYSTEM 750 and its components are an open system. It

must only be assembled in housings, cabinets or in electrical operation

rooms. Access must only be given via a key or tool to authorized qualified

personnel.

The relevant valid and applicable standards and guidelines concerning the

installation of switch boxes are to be observed.

ESD (Electrostatic Discharge)

The modules are equipped with electronic components that may be destroyed

by electrostatic discharge. When handling the modules, ensure that the

environment (persons, workplace and packing) is well grounded. Avoid

touching conductive components, e.g. gold contacts.

1.5 Scope

This manual describes the Digital Input Module 750-405

2 DI AC 230 V 10 ms, High-Side Switching of the modular WAGO-I/O-

SYSTEM 750.

Handling, assembly and start-up are described in the manual of the Fieldbus

Coupler. Therefore this documentation is valid only in the connection with the

appropriate manual.

750-405 [2 DI AC 230 V 10 ms, High-Side Switching] • 7

View

WAGO-I/O-SYSTEM 750

I/O Modules

2 I/O Modules

2.1 Digital Input Modules

2.1.1 750-405 [2 DI AC 230 V 10 ms, High-Side Switching]

2- Channel Digital Input Module AC 230 V 10 ms

2-, 3- or 4- conductor connection; high-side switching

2.1.1.1 View

13 14

750-405

DI 2

Power jumper contacts

Data contacts

DI 2

Status

230V

DI 1

Status

DI 1

+- +-

Fig. 2.1.1-1: View g040500e

2.1.1.2 Description

The digital input module 750-405 receives control signals from digital field

devices (sensors, switches, etc.).

The module is a 2- to 4-conductor device and has two input channels. Two

sensors may be directly connected to the module.

Two 4-conductor sensors with ground (earth) wire may be directly connected

to 230 V, N, PE (earth potential) and signal input DI 1 or signal input DI 2.

Each input module has an RC noise rejection filter with a time constant of

10 ms.

The status of the input channels is indicated via status LEDs.

An optocoupler is used for electrical isolation between the bus and the field

side.

Any configuration of the input modules is possible when designing the

fieldbus node. Grouping of module types is not necessary.

8 • 750-405 [2 DI AC 230 V 10 ms, High-Side Switching]

Display Elements

WAGO-I/O-SYSTEM 750

I/O Modules

Attention

An additional supply module must be added for the field supply with AC

230 V!

The supply voltage for the field side is made automatically through the

individual I/O modules by means of power jumper contacts.

Warning

The maximum current of the internal power jumper contacts is 10 A. When

configuring the system it is important not to exceed the maximum/sum

current. However, if such a case should occur, another supply module must be

added.

The digital input module 750-405 can be used with all couplers/controllers of

the WAGO-I/O-SYSTEM 750.

2.1.1.3 Display Elements

LED Channel Designation State Function

off Input DI 1: Signal voltage (0)

green 1 Status

DI 1 on Input DI 1: Signal voltage (1)

off Input DI 2: Signal voltage (0)

13 14

Fig. 2.1.1-2: Display

Elements g040002x

green 2 Status

DI 2 on Input DI 2: Signal voltage (1)

750-405 [2 DI AC 230 V 10 ms, High-Side Switching] • 9

Schematic Diagram

WAGO-I/O-SYSTEM 750

I/O Modules

2.1.1.4 Schematic Diagram

DI 1 DI 2

230V

100nF

750-405

Fig. 2.1.1-3: Schematic Diagram g040501e

10 • 750-405 [2 DI AC 230 V 10 ms, High-Side Switching]

Technical Data

WAGO-I/O-SYSTEM 750

I/O Modules

2.1.1.5 Technical Data

Module Specific Data

Number of inputs 2

Current consumption (internal) 2 mA

Nominal voltage AC 230 V (-15 % ... +20 %); (+20 % 1.5s)

Signal voltage (0) AC 0 V … 40 V

Signal voltage (1) AC 164 V … 1.1 UN

Input filter 10 ms

Current supply typ. 6.5 mA

Input frequency fNom ±10 %

50 Hz ±10 %

60 Hz ±10 %

Isolation 1.5 KVeff. (System/Field)*)

*)2.5 kV Impulse voltage withstand level

Overvoltage category III

Internal bit width 2 Bit

Dimensions W x H* x L

* from upper edge of 35 DIN rail

12 mm x 64 mm x 100 mm

Weight ca. 50 g

Standards and Regulations (cf. Chapter 2.2 of the Coupler/Controller Manual)

EMC-Immunity to interference (CE) acc. to EN 50082-2 (96)

EMC-Emission of interference (CE) acc. to EN 50081-1 (93)

EMC-Immunity to interference

(Ship building)

acc. to Germanischer Lloyd (97)

EMC-Emission of interference

(Ship building)

acc. to Germanischer Lloyd (97)

Tabla de contenidos

Otros manuales de Unidad de control de WAGO

WAGO

WAGO 750-624/040-00 Series Manual de usuario

WAGO

WAGO 750-517/040-000 Manual de usuario

WAGO

WAGO 750-536 Manual de usuario

WAGO

WAGO 750-537/040-000 Manual de usuario

WAGO

WAGO 750-508/040-000 Manual de usuario

WAGO

WAGO 2789-9080 Manual de usuario

WAGO

WAGO 750-632 Manual de usuario

WAGO

WAGO 750-458 Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

WAGO

WAGO SPEEDWAY 767 Series Manual de usuario

WAGO

WAGO 750-633 Manual de usuario

WAGO

WAGO 753-1630 Manual de usuario

WAGO

WAGO 750-439/040-000 Manual de usuario

WAGO

WAGO WAGO-TO-PASS 761 Manual de usuario

WAGO

WAGO 750-654 Manual de usuario

WAGO

WAGO 753-646 Manual de usuario

WAGO

WAGO I/O-SYSTEM 751-3001 Manual de usuario

WAGO

WAGO 750-363/0040-0000 Manual de usuario

WAGO

WAGO I/O-SYSTEM 750-666/000-003 Manual de usuario

WAGO

WAGO 2789-9023 Manual de usuario

WAGO

WAGO SPEEDWAY 767 Series Manual de usuario

WAGO

WAGO I/O-SYSTEM 751-4001 Manual de usuario

WAGO

WAGO SPEEDWAY 767 Series Manual de usuario

WAGO

WAGO 750-523 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario

Flyron

Flyron FN-BC04 Manual de usuario
