Vicon VC-700W Manual de usuario

VC-700W and VC-700WC

COLOR DOME CAMERAS

About this manual

INSTRUCTION MANUAL XX178-10

Before installing and using the camera, please read this manual carefully.

Be sure to keep it handy for later reference.

This installation should be made by a qualified service person and should conform

to the National Electric Code, ANSI/NFPA 70 and all local codes.

Installers should use appropriate hardware mounting materials.

This equipment generates and uses radio frequency energy and if not installed

and used properly, that is, in strict accordance with the manufacturer’s instruction,

may cause interference to radio and television reception. It has been type tested

and found to comply with the limits for a Class A computing device in accordance

with the specification in subpart B of part 15 of the FCC rules, which are designed

to provide reasonable protection against such interference in a commercial

installation. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause interference to radio and

television reception, which can be determined by turning equipment off and on,

the user is encouraged to try and correct the interference by one or more of the

following measures:

FCC Notice

Note: Complies with Federal Communications Commission Rules & Regulations

Part 15, Subpart B for a Class A digital device.

WARNING

• Reorient the receiving antenna.

• Relocate the equipment with respect to the receiver.

• Relocate the equipment away from the receiver.

• Plug the equipment into a different electrical outlet so that the equipment

and receiver are on different branch circuits.

If necessary, the user should consult the dealer or an experienced radio/television

technician for additional suggestions.

Warning: Power must be removed from this unit before removing circuit

modules or cables.

Caution: This unit contains circuit cards with integrated circuit devices that

can be damaged by static discharge. Take all necessary precautions

to prevent static discharge.

The user may find the following booklet prepared by the Federal Communications

Commission helpful:

“Interference Handbook, Bulletin CIB-2”

This booklet is available from the U.S. Government Printing Office, Superintendent

of Documents, Mailstop SSOP, Washington, D.C. 20402-9328, ISBN 0-16-045542-1.

Surface-Mount configuration In-Ceiling configuration

Dimensions : inch (mm)

PRECAUTIONS

■Do not open or modify

Do not open the case except during maintenance and installation, as it may be

dangerous and cause damages.

■Do not put objects inside the unit

Make sure that no metal objects or flammable substances

get inside the camera. This could cause fire, short-circuits or damages.

■Be careful when handling the unit

To prevent damage, do not drop the camera or subject it to strong shock or

vibration.

■Install away from electric or magnetic fields

■Protect from humidity and dust

■Protect from high temperature

Be careful when installing close to the ceiling , in a kitchen or boiler room,

as the temperature may rise to high levels.

■Cleaning

Dirt can be removed from the case only by wiping it with a soft cloth moistened

with a soft detergent solution.

■Mounting Surface

The mounting surface material must be strong enough to support the camera.

TROUBLESHOOTING

Before sending the camera out for repair, check the items below.

If the problem persists after checking these items, contact your service center.

■If no image appears

▪Is the coaxial cable attached securely?

▪Are the power and voltage normal?

▪Has the iris of the lens inside the camera been adjusted correctly

(with the level volume) ?

▪Is there adequate illumination?

■If the image is unclear

▪Is the lens in focus?

▪Is the lens dirty?

▪Dirt or fingerprints on the lens can adversely affect the images.

Gently wipe any dirt or fingerprints off the lens with a soft cloth or lens

cleaning paper and cleaning fluid (commercially available).

▪Is the monitor adjusted correctly?

LENS ADJUSTMENT

1. Adjust the panning (360˚) and tilt (90˚) position.

2. Set the zoom position by using Zoom Lever Screw.

3. Set the focus by using Focus Lever Screw.

4. Loosen set screws (using small M1.0 Hex L-wrench provided) to adjust roll

(turns camera position top/bottom).

PAN ROLL SET

SCREW

(2X)

TILT

90˚ZOOM

FOCUS

SPECIFICATION - VC-700W/C SERIES

General Spec NTSC PAL

HQ Interline Transf er CCD 1/3" 410K Pixels Color 1/3" 470k Pixels Color

Total Number of Pixels 811(H) X 508 (V) 795(H) X 596(V)

Scanning System 525 Lines 625 Lines

Hor iz ontal Res olution

Sensitivity to Light [30IRE]

Gamma Correction

Shutter Speed 1/60 - 1/100,000[NTSC] 1/50 - 1/100,000[PAL]

S/N Ratio

Synchronization

Video Output

Control DIP Switch

BLC

ME/A E

AWB

AGC

Electrical Spec

Operating Voltage

Pow er Consumption

Mechanical Spec

Opertion Temp

Air Humidity

Lens

Connections via

12VDC(11-20V), 24VAC(20-27V)

12VDC - 2.2W, 24VAC - 1.95W

0.45

550TV Lines

> 48dB [AGC off]

Internal / External (Line Lock)

0.04fc, 0.4Lux(Scene) With F1.2 Lens

Up to max.90%

3.3-12mm or 9-22mm

14°F ~ 131°F (-10°C ~ +55°C)

1.0Vp-p/75ohm Composite

BNC(V IDEO) , 2P WIRE(POWER)

DIP Sw itc h Selec t ON/OFF

DIP Sw it c h S ele c t ME/ A E ( ON/OFF)

DIPSw itch Select ATW/AWB (ON/OFF)

SPECIFICATION - VC-700W-IR/C SERIES

General Spec NTSC PAL

HQ Interline Transf er CCD 1/3" 410K Pixels Color 1/3" 470k Pixels Color

Total Number of Pixels 811(H) X 508 (V) 795(H) X 596(V)

Scanning System 525 Lines 625 Lines

Hor iz ontal Res olution

Sensitivity to Light [30IRE]

IR Dis tanc e

Gamma Correction

Shutter Speed 1/60 - 1/100,000[NTSC] 1/50 - 1/100,000[PAL]

S/N Ratio

Synchronization

Video Output

Control DIP Switch

BLC

ME/A E

ATW/AWB

AGC

Electrical Spec

Operating Voltage

Pow er Consumption

Mechanical Spec

Opertion Temp

Air Humidity

Lens

Connections via BNC(VIDEO), 2P WIRE(POWER)

14°F ~ 131°F (-10°C ~ +55°C)

Up to max.90%

3.3-12mm

DIP Sw itc h Selec t ON/OFF

12VDC(11-20V), 24VAC(20-27V)

MAX LED ON (12VDC - 4.1W, 24VAC - 4.7W)

DIP Sw itc h Selec t ON/OFF

DIP Sw it c h Sele c t ME/ A E ( ON/OFF)

DIPSw itch Select ATW/AWB (ON/OFF)

0.45

> 48dB [AGC off]

Internal(12VDC) / External (Line Lock, 24VAC)

1.0Vp-p/75ohm Composite

550TV Lines

20m range

BW, NO LED : 0.004fc, 0.04Lux(Scene) With F1.2 Lens

COLOR : 0.04fc, 0.4Lux(Scene) With F1.2 Lens

SPECIFICATION - VC-700WDN/C SERIES

General Spec NTSC PAL

HQ Interline Transfer CCD 1/3" 410K Pixels Color 1/3" 470k Pixels Color

Total Number of Pixels 811(H) X 508 (V) 795(H) X 596(V)

Scanning System 525 Lines 625 Lines

Horizontal Resolution

Sensitivity to Light [30IRE]

Gamma Correction

Shutter Speed 1/60 - 1/100,000[NTSC] 1/50 - 1/100,000[PAL]

S/N Ratio

Synchronization

Video Output

Control DIP Switch

BLC

ME/A E

ATW/AWB

AGC

Electrical Spec

Operating Voltage

Pow er Consumption

Mechanical Spec

Opertion Temp

Air Humidity

Lens

Connections via

Up to max.90%

3.3-12mm or 9-22mm

BNC( V IDEO), 2P WIRE( POWER)

BW : 0.004fc, 0.04Lux(Scene) With F1.2 Lens

12VDC(11-20V), 24VAC(20-27V)

12VDC - 2.3W, 24VAC - 2.6W

14°F ~ 131°F (-10°C ~ +55°C)

DIP Sw itch Select ME/AE (ON/OFF)

DIP Sw itch Select ATW/A WB (ON/OFF)

Internal(12VDC) / External (Line Lock, 24VAC)

1.0Vp-p/75ohm Composite

DIP Sw itch Select ON/OFF

550TV Lines

Color : 0.04fc, 0.4Lux(Scene) With F1.2 Lens

0.45

> 48dB [AGC off]

DIP Sw itch Select ON/OFF
