VIA Technologies EPIA-P820 Manual de usuario
Operating Guide
EPIA-P820 Mainboard
EPIA-P820 Operating Guide
June 24, 2013 - i - Version 1.06
Table of Contents
Table of Contents ..................................................................................................................i
VIA EPIA-P820 verview .......................................................................................................2
Layout Diagrams ..................................................................................................................3
EPIA-P820 (top and bottom views) ......................................................................................3
VIA EPIA-P820 Specifications.................................................................................................4
VIA EPIA-P820 Processor SKU................................................................................................5
VIA EPIA-P820 Dimensions & Mounting Holes ..........................................................................6
VIA EPIA-P820 Height Distribution..........................................................................................7
Power Consumption..............................................................................................................8
Tested Configurations ........................................................................................................8
Configuration 1 ..............................................................................................................8
Configuration 2 ..............................................................................................................8
Configuration 3 ..............................................................................................................8
Configuration 4 ..............................................................................................................8
Boot to Idle (XP) ...............................................................................................................9
Stress Tool .......................................................................................................................9
3DMark2003 .....................................................................................................................9
PowerDVD 6.0...................................................................................................................9
Power Specifications ........................................................................................................... 10
VIA EPIA-P820 Microsoft and Linux Driver Support .................................................................11
Microsoft Driver Support...................................................................................................11
Linux Driver Support........................................................................................................ 11
Contact ............................................................................................................................. 12
EPIA-P820 Operating Guide
June 24, 2013 - 2 - Version 1.06
VIA EPIA-P820 Overview
The VIA EPIA-P820 Pico-ITX mainboard is an ultra compact native x86 platform for a wide range of
embedded system applications. The mainboard is based on the VIA VX855 All-in- ne System
Processor featuring the VIA Chrome™ 9 HCM DX9 IGP with video accelerators for rich digital media
performance.
The VIA EPIA-P820 onboard VIA Nano 1.2 GHz NanoBGA2 processor is a green, secure, and
efficient processor with its included VIA Padlock Security Engine, VIA CoolStream™ Architecture,
VIA StepAhead™ Technology Suite, and VIA TwinTurbo™ technology.
The VIA EPIA-P820 delivers the performance levels with its included sizeable support of up to 2 GB
of 800 MHz DDR2 memory and native support for SATA 3Gb/s storage devices.
The VIA EPIA-P820 is fully compatible with Microsoft
®
and Linux operating systems.
EPIA-P820 Operating Guide
June 24, 2013 - 3 - Version 1.06
ayout Diagrams
EPIA-P820
(
TOP AND BOTTOM VIEWS
)
EPIA-P820 Operating Guide
June 24, 2013 - 4 - Version 1.06
VIA EPIA-P820 Specifications
1
Model Name EPIA-P820-12L
Processor VIA Nano 1.2 GHz NanoBGA2 processor
Chipset VIA VX855 All-in- ne System Processor
System Memory - 1 x DDR2 800/667 S DIMM socket
- Up to 2 GB memory size
VGA - VIA Chrome™ 9 HCM DX9 Integrated Graphics with MPEG-2 accelerators
Onboard Storage - 1 x SATA 3Gb/s connector
- 1 x IDE 2.0 mm 44-pin connector
Onboard AN - 1 x VIA VT6122 Gigabit Ethernet Controller
Onboard Audio - VIA VT1708S High Definition Audio Codec
Onboard I/O
Connectors
- 1 x Gigabit LAN pin header
- 1 x Audio pin connector for Line-out, Line-in, and MIC-in
- 1 x Single-channel LVDS connector (5V/3V)
- 1 x Backlight control pin header
- 1 x Sys fan connector
- 1 x PS2 KBMS pin header
- 1 x USB pin header
- 1 x LPC pin connector
- 1 x SMBus pin connector
- 1 x DI pin connector (4 GPI & 4 GP )
- 2 x UART port/VCP pin headers
- 1 x Front panel pin header
- 1 x SATA power connector
- 1 x +12V DC-in power connector
I/O Ports - 1 x HDMI
®
port
- 1 x VGA port
- 1 x GigaLAN port
- 2 x USB ports
BIOS - AMI BI S
- 4 Mbit SPI flash memory
Operating System Windows XP/Windows CE/Windows XPe and Linux
System Monitoring &
Management
- Wake-on LAN and Keyboard-Power-on
- Timer-Power-on
- WatchDog Timer
- System power management, AC Power failure recovery
Operating
Environment
Temperature: 0°C up to 60°C
Humidity: 0% ~ 95% (relative humidity; non-condensing)
Compliance CE/FCC/KC/BSMI/RoHS
Form Factor - Pico-ITX
- 10 cm x 7.2 cm
1
Specifications subject to change without notice.
EPIA-P820 Operating Guide
June 24, 2013 - 5 - Version 1.06
VIA EPIA-P820 Processor SKU
The VIA EPIA-P820 Pico-ITX mainboard is available in the following speed grades:
•1.2 GHz VIA Nano Processor
EPIA-P820 Operating Guide
June 24, 2013 - 6 - Version 1.06
VIA EPIA-P820 Dimensions & Mounting Holes
Note:
The mounting holes at the four corners can only fit M2 size screws (Ø1.86 mm – Ø1.89 mm).
EPIA-P820 Operating Guide
June 24, 2013 - 7 - Version 1.06
VIA EPIA-P820 Height Distribution
EPIA-P820 board shown with P720-A module stacked on top
EPIA-P820 Operating Guide
June 24, 2013 - 8 - Version 1.06
Power Consumption
Power consumption tests were performed on four different configurations. The following tables
show the mainboard’s voltage, amp and wattage values while running common applications in the
Windows XP environment.
T
ESTED
C
ONFIGURATIONS
Configuration 1
•VIA Nano 1.2 GHz NanoBGA2 Processor with 800 MHz FSB
•2.5" Fujitsu 80 GB hard drive
•1 GB Kingston DDR2 800 MHz
Configuration 2
•VIA Nano 1.2 GHz NanoBGA2 Processor with 800 MHz FSB
•2.5"Fujitsu 80 GB, hard drive
•3.5" Seagate 80 GB hard drive
•2 GB Hynix DDR2 800 MHz
Configuration 3
•VIA Nano 1.2 GHz NanoBGA2 Processor with 800 MHz FSB
•4 GB InnoDisk IDE D M
•1 GB Kingston DDR2 800 MHz
Configuration 4
•VIA Nano 1.2 GHz NanoBGA2 Processor with 800 MHz FSB
•4 GB InnoDisk IDE D M
•2 GB Hynix DDR2 800 MHz
EPIA-P820 Operating Guide
June 24, 2013 - 9 - Version 1.06
B
OOT TO
I
D E
(XP)
Measured Voltage (V) Measure Amp (I) Watts (W)
Configuration 1 11.997 1.07 12.84
Configuration 2 11.997 1.56 18.72
Configuration 3 11.997 0.90 10.80
Configuration 4 11.997 0.91 10.92
S
TRESS
T
OO
Measured Voltage (V) Measure Amp (I) Watts (W)
Configuration 1 11.997 1.36 16.32
Configuration 2 11.997 1.81 21.71
Configuration 3 11.997 1.14 13.68
Configuration 4 11.997 1.18 14.16
3DM
ARK
2003
Measured Voltage (V) Measure Amp (I) Watts (W)
Configuration 1 11.997 1.29 15.48
Configuration 2 11.997 1.75 21.00
Configuration 3 11.997 1.19 14.28
Configuration 4 11.997 1.22 14.64
P
OWER
DVD
6.0
Measured Voltage (V) Measure Amp (I) Watts (W)
Configuration 1 11.997 1.05 12.60
Configuration 2 11.997 1.48 17.79
Configuration 3 11.997 0.86 10.32
Configuration 4 11.997 0.89 10.68
