VIA Technologies VB7002 Manual de usuario

March 30, 2018 Version 1.01

Operating Guide

VB7002 Mini-ITX Mainboard

VB7002 Operating Guide

March 30, 2018 - i - Version 1.01

Table of Contents

Table of Contents .................................................................................................................. i

VIA VB7002 O er iew ........................................................................................................... 1

VIA VB7002 Layout .............................................................................................................. 2

VIA VB7002 Specifications ..................................................................................................... 3

VIA VB7002 Processor SKUs .................................................................................................. 4

VIA CN896 Chipset O er iew ................................................................................................. 5

VIA VB7002 I/O Back Panel ................................................................................................... 6

VIA VB7002 Dimensions ........................................................................................................ 7

VIA VB7002 Height Distribution ............................................................................................. 8

Power Consumption .............................................................................................................. 9

VIA VB7002-15 ................................................................................................................. 9

A. Playing DVDs with PowerDVD 5.0 ................................................................................. 9

B. Playing MP3s with Windows Media Player ....................................................................... 9

C. Running Network Applications - Copying Files ................................................................. 9

D. Idle State .................................................................................................................. 9

E. Running C.C. Winstone 2004 ...................................................................................... 10

F. S3 Mode .................................................................................................................. 10

Power Specifications ........................................................................................................... 11

VIA VB7002 Microsoft and Linux Dri er Support ..................................................................... 12

Microsoft Dri er Support................................................................................................... 12

Linux Dri er Support ........................................................................................................ 12

Contact ............................................................................................................................. 13

VB7002 Operating Guide

March 30, 2018 - 1 - Version 1.01

VIA VB7002 Overview

The VIA VB7002 Mini-ITX Mainboard is an ultra compact nati e x86 platform optimized for entry

le el systems in embedded and producti ity applications. The mainboard is based on the VIA

CN896 chipset featuring the VIA C-9 HC IGP with 2D/3D graphics and ideo accelerators for rich

digital media performance.

The VIA VB7002 onboard VIA C7

-D NanoBGA2 processor is a powerful, secure, and efficient

processor with its included VIA Padlock Security Engine, VIA CoolStream™ Architecture, VIA

StepAhead™ Technology Suite, and VIA TwinTurbo™ technology.

The VIA VB7002 includes sizeable support of up to 4 GB of 667 MHz DDR2 memory and nati e

support for SATA (3 Gbps) storage de ices. The VIA VB7002 pro ides support for high fidelity

audio with its included VIA VT1708A High Definition Audio codec. High-bandwidth connecti ity is

supported with the included two USB 2.0 ports, Fast Ethernet port, and COM port on the back

panel.

The VIA VB7002 can be implemented in a wide range of embedded and media applications with its

host of included onboard connectors. It supports for up to two SATA (3 Gbps) de ices in RAID and

non-RAID configurations. The VIA VB7002 can be further enhanced with an external PCI Express

graphics card ia its 16-lane PCI Express slot and a host of other expandability options.

The VIA VB7002 is compatible with a full range of Mini-ITX chassis as well as FlexATX and

MicroATX enclosures and power supplies. The VIA VB7002 is fully compatible with Microsoft

and

Linux operating systems and is a ailable in a ariety of configurations.

VB7002 Operating Guide

March 30, 2018 - 2 - Version 1.01

VIA VB7002 Layout

VB7002 Operating Guide

March 30, 2018 - 3 - Version 1.01

VIA VB7002 pecifications

Model Name VB7002-15

Processor VIA C7

-D 1.5 GHz NanoBGA2 processor with FSB 400 MHz

Chipset - VIA CN896 North Bridge

- VIA VT8237S South Bridge

ystem Memory - 2 x DDR2 400 / 533 / 667 DIMM slot

Up to 4 GB memory size

VGA - VIA C-9 HC Integrated Graphics with 2D/3D and ideo accelerators

Expansion lots - 1 x 16-Lane PCI Express slot (Gen 1)

1 x 32

bit Mini PCI slot

Onboard IDE - 1 x UltraDMA 133/100/66 connector

Onboard LAN - 1 x VIA VT6103L 10/100 Mbps Fast Ethernet Controller

Onboard Audio - VIA VT1708A High Definition Audio Codec

Onboard I/O Connectors - 2 x SATA (3 Gbps) connectors

- 2 x Fan pin connectors: CPU / Sys FAN

- 3 x USB pin connectors for six additional USB 2.0 ports (one supports VIA

WLAN module)

- 1 x Serial port pin connector for COM2 (5V / 12V selectable)

- 1 x LPC connector

- 1 x CIR pin connector (switchable with KB / MS)

- 1 x FIR pin connector (IRDA 1.0)

- 1 x SMBus connector

- 1 x S/PDIF out pin connector

- 1 x Front Panel Audio pin connector (MIC and Line-out)

- 1 x Front Panel connector

- 1 x ATX Power connector

Back Panel I/O - 1 x PS2 mouse port

- 1 x PS2 keyboard port

- 1 x Serial port

- 1 x VGA port

- 1 x RJ45 LAN ports

- 2 x USB 2.0 ports

- 3 x Audio jacks: MIC-In, Line-In, and Line-Out

(with Horizontal and Smart 5.1 support)

BIO Award BIOS, SPI 4/8 Mbit flash memory

Operating ystem Windows XP, Linux, Win CE, XPe

ystem Monitoring &

Management

- CPU oltage monitoring

- Wake-on-LAN/Keyboard, RTC Timer power-on, Watch Dog Timer

- AC Power failure reco ery

- Fan monitoring

Operating Temperature

C ~ 50

Operating Humidity 0% ~ 95% (relati e humidity; non-condensing)

Form Factor - Mini-ITX (6-layer)

17 cm x 17 cm

Note: This specification is subject to change without prior notice.

VB7002 Operating Guide

March 30, 2018 - 4 - Version 1.01

VIA VB7002 Processor KUs

The VIA VB7002 is a ailable in two speed grades as follows:

•1.5 GHz VIA C7

-D NanoBGA2 Processor

VB7002 Operating Guide

March 30, 2018 - 5 - Version 1.01

VIA CN896 Chipset Overview

The VIA CN896 Chipset is designed to enable high quality digital ideo streaming and DVD

playback in a new generation of fanless, small form factor PCs and IA de ices. The VIA CN896

North Bridge features the VIA C-9 HC IGP with 2D/3D graphics and ideo acceleration, DDR2

667/533/400 MHz support, motion compensation and dual display support to ensure a rich o erall

entertainment experience. Outstanding connecti ity features include USB 2.0, 10/100 and Gigabit

LAN, SATA (3 Gbps), and ATA/133.

VB7002 Operating Guide

March 30, 2018 - 6 - Version 1.01

VIA VB7002 I/O Back Panel

The VIA VB7002 mainboard comes in the ultra compact 17 cm x 17 cm Mini-ITX form factor. Its

integrated design supports most of the standard legacy x86 connecti ity options including PS/2

mouse port, PS/2 keyboard port, COM port, VGA port, RJ45 LAN ports, USB 2.0 ports, and audio

jacks.

VB7002 Operating Guide

March 30, 2018 - 7 - Version 1.01

VIA VB7002 Dimensions

VB7002 Operating Guide

March 30, 2018 - 8 - Version 1.01

VIA VB7002 Height Distribution
