UTC Fire and Security Interlogix VR1500 Instrucciones de instalación

P/N 1062803 • REV B • ISS 01JUL11

VR1500

VR1500-R3

VR1500CC

VR1500CC-R3

VR1500WDM

VR1500WDM-R3

VR1500WDMCC

VR1500WDMCC-R3

IFS Fiber Module

Installation & Operation

Instructions

VT1500

VT1500-R3

VT1500WDM

VT1500WDM-R3

RS232 MODE

DATA OUTPUT

RS422 MODE

DATA OUTPUT

RS232 DATA

GROUND

+ DATA

- DATA

VT1500 Series

VR1500 Series

RS232 MODE

DATAINPUT

and

RELAY CONTACT

RS422 MODE

DATAINPUT

Ground

No Connection

+ Data Input

No Connection

Ground

No Connection

RS232 Data Input

No Connection

Relay Contact*

- Data Input

*For VR1500CC Series Only.

ifs International

Fiber

Systems

Incorporated

VR1500WDMCC

VIDEO RECEIVER

DATA TRANSMITTER

+

CONTACT CLOSURE

-2

+12 VDC-1

NC - 6

NC - 5

RELAY CONTACT- 4

-DATA-3

-2

+DATA-1

OPTICAL

IN/ OUT

VIDEO OUT

POWER

VIDEO OUT / AGC

RS232

RS422

ifs International

Fiber

Systems

Incorporated

VT1500WDM

VIDEO TRANSMITTER + DATA RECEIVER D-4

GND-3

+ D-2

- D-1

12 VAC/ 12 VDC - 3

GRD - 2

12 VAC/ 12 VDC - 1

VIDEO IN

OPTICAL IN/OUT

POWER

RS232

DATA

OUT RS422

POWER

Simplex multimode

fiber optic cable

Coax cable

Video source

Video

monitor

VIDEO PRESENT

DATA RECEIVE

CONTACT CLOSED

DATA IN

POWER

VT1500

Data Receive

Power

ABC

Video Present LED illuminates

BCD

VR1500

Data In

Contact Closed

Video Out / AGC

Power

LED changes from

RED to GREEN.

LED illuminates

NOTE: WITHOUT PROPER FIBER CONNECTION, LED's DO NOT INDICATE

CORRECT OPERATIONAL STATUS OF THE UNIT.

Comprehensive

Lifetime Warranty

(a) Seller warrants to the original End User that products and any

services furnished hereunder will be free from defects in material

and workmanship as of the date of delivery, and will conform to

Seller’s published technical specications. The foregoing shall

apply only to failures to meet said warranties which appear within

that period of time during which the Products are installed in their

original installation for the original End User and operator of such

Products; provided, however, that in the event of product discontin-

uance, warranty support is limited to ve (5) years from the

announcement of discontinuance. Notwithstanding the preceding

sentence, the duration of the warranty period for

products not

manufactured by Seller (e.g., ber optic cabling, test equipment,

power supplies or batteries) shall be the warranty period oered by

the original manufacturer, if any.

(b) The conditions of any tests shall be mutually agreed upon and

Seller shall be notied of, and may be represented at, all tests that

may be made. The warranties and remedies set forth herein are

conditioned upon (a) proper storage, installation, use and mainte-

nance, and conformance with any applicable recommendations of

Seller and (b) Buyer promptly notifying Seller of any defects and,

if required, promptly making the product available for correction.

Seller shall thereupon correct any such failure either at its option,

(i) by repairing any defective or damaged product or parts of the

products, or (ii) by making available any necessary repaired or

replacement products or parts thereof. Any repaired or replacement

part or product shall be warranted for the remaining period of the

original Warranty Period. Seller shall pay, or credit Buyer for, the

cost of freight for all return shipments of products or parts to

Buyer. Where a failure cannot be corrected by Seller's reasonable

eorts, the parties will negotiate an equitable adjustment in price.

(d) The preceding paragraph sets forth the exclusive remedies for

claims based on defect in or failure of products or services,

whether the claim is in contract, indemnity, warranty, tort

(including Seller's negligence), strict liability or otherwise and

however instituted. Upon the expiration of the warranty period,

all such liability shall terminate and BUYER shall have a reason-

able time, within thirty days after the warranty period, to give

written notice of any defects which appeared during the warranty

period. The foregoing warranties are exclusive and in lieu of all

other warranties, whether written, oral, implied or statutory.

NO IMPLIED OR STATUTORY WARRANTY OF

MERCHANTABILITY OR FITNESS FOR PARTICULAR

PURPOSE SHALL APPLY. Seller does not warrant any

products or services of others which BUYER has designated.

NOTE: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the user will be required to cor-

rect the interference at his own expense.

FCC Compliance

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesirable operation.

Changes or modifications not expressly approved by International Fiber Systems, Inc. could void

the user’s authority to operate the equipment.

CLASS 1 LASER PRODUCT

(For purposes of IEC 60825-1)

Complies with FDA Performance Standard for Laser Products

Title 21

Code of Federal Regulations

Subchapter J

Contacting us

For help installing, operating, maintaining, and troubleshooting this product, refer to this document and any

other documentation provided. If you still have questions, contact us during business hours (Monday through

Friday, excluding holidays, between 5 a.m. and 5 p.m. Pacific Time).

Note: Be ready at the equipment before calling.

Online

Another great resource for assistance with your Interlogix product is our online publication library. To access

the library, go to our website at the following location:

http://www.interlogix.com/transmission1

Sales and support contact information

North

America

Toll-free: 855.286.8889 in the US, including Alaska and Hawaii;

Puerto Rico; Canada.

Outside the toll-free area: 503.885.5700.

E-mail: [email protected]

Europe Select Contact Us at www.utcfssecurityproducts.eu

Australia security[email protected]

1. Many Interlogix documents are provided as PDFs (portable document format). To read these documents, you will

need Adobe Reader, which can be downloaded free from Adobe’s website at www.adobe.com.

Product Disassembly Instructions for WEEE

Per European Directive 2002/95/EC Waste Electrical and

Electronic Equipment

Required Tools:

One number 2 Phillips (crosstip) screwdriver.

One number 2 flat screwdriver.

For the enclosed box version:

1. Locate and remove box cover securement screws. Usually, but not limited to, at least

4 screws.

2. Lift off box top cover.

3. Locate and remove securement screws for printed circuit board.

4. If there are multiple boards to the assembly, continue removing securement screws

until none are left.

5. Lift off printed circuit board.

6. Disassembly of box version of product is complete.

For rack version:

1. Locate and remove securement screws for printed circuit board. Usually, but not

limited to, at least 4 screws.

2. If there are multiple boards to the assembly, continue removing securement screws

until none are left.

3. Lift off printed circuit board(s).

4. Disassembly of rack card version of product is complete.

Trademarks and

patents Interlogix and IFS names and logos are trademarks of

UTC Fire & Security.

Other trade names used in this document may be trademarks or

registered trademarks of the manufacturers or vendors of the

respective products.

Manufacture

UTC Fire & Security Americas Corporation, Inc.

2955 Red Hill Avenue, Costa Mesa, CA 92626-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification N4131

ACMA compliance Notice! This is a Class A product. In a domestic environment this

product may cause radio interference in which case the user may be

required to take adequate measures.

Canada This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme

NMB-003 du Canada.

European Union

directives 2004/108/EC (EMC directive): Hereby, UTC Fire & Security

declares that this device is in compliance with the essential

requirements and other relevant provisions of Directive

2004/108/EC.

2002/96/EC (WEEE directive): Products marked with this symbol

cannot be disposed of as unsorted municipal waste in the European

Union. For proper recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.recyclethis.info.

Contact information For contact information, see www.interlogix.com.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unidad de control de UTC Fire and Security

UTC Fire and Security

UTC Fire and Security interlogix VAR14120 Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security interlogix VT7220 Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security interlogix VAD7010A Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security interlogix VT7420 Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security KiddeFire Systems ARIES NETLink BACnet Manual de usuario

UTC Fire and Security

UTC Fire and Security Interlogix VT7420-2DRDT Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security interlogix VT2010 Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security interlogix VR1520WDM Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security interlogix TT3010 Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security Interlogix NX-535N Manual de usuario

UTC Fire and Security

UTC Fire and Security Interlogix NX-535N-V3 Manual de usuario

UTC Fire and Security

UTC Fire and Security interlogix VT14120 Guía

UTC Fire and Security

UTC Fire and Security interlogix VT9930WDM Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security interlogix VT1101M Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security interlogix VR4930WDM Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security Fenwal 35-63J Series Manual de usuario

UTC Fire and Security

UTC Fire and Security Interlogix VR1910 Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security Edwards Signaling E-IDCWS Instrucciones de montaje

UTC Fire and Security

UTC Fire and Security FenwalNET 8000-ML Manual de usuario

UTC Fire and Security

UTC Fire and Security interlogix VT7820 Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security interlogix VT6010-DRDT Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security interlogix VT4010 Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security Interlogix VT72830-R3 Instrucciones de instalación

UTC Fire and Security

UTC Fire and Security Interlogix VR1001 Instrucciones de instalación

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario

UTC Fire and Security interlogix VR1500 Instrucciones de instalación

Manuales populares de Unidad de control de otras marcas
