INSTRUCTION MANUAL

Air Auto Shut-Off Straight Screwdrivers

This product is designed for installing and removing threadedfasteners in wood, metal,

and plastic. The use of spare parts/accessories other than those originally supplied by

the manufacturer may result in a drop in performance and/or increased

maintenance/noise level/vibrations, and as the result, the full cancellation of the

manufacturer’s liability. No other use is permitted. For professional use only.

Air Supply Requirements

1. Supply tool with 90 PSI (6.3 KG/CM2) of clean, dry air. Higher pressure drastically

reduces toollife.

2. Connect the tool to the airline using pipe, hose, and fitting sizes shown in the diagram

below.

Lubrication

1. Use an air line lubricator with SAE #10 oil, adjustedtotwo (2) drops per minute.

If an air line lubricator cannot be used, add air motor oil to the inlet once a day.

2. For gearing and clutch, use Shell-grade grease containingmolybdenum.

3. Grease clutches every 12,000 screws.

Torque Adjustment

Shut Off Clutch: Grip the tool around the handle and press the tool into the fixing

which is to be tightened. The motor will start and tighten the fixing to the required

torque set by adjusting the tensions on the clutch spring. At this point, the internal drive

is disengaged and the air to the motor cut off.

1/2" (12mm)

CA048362 (1/2") NPT

CA048361 (1/2") NPT

0 130

1/2" (12mm)

CA048360 (1/2") NPT

1/4 NPT

3/8" (10mm)

10' (3m) MAX

Torque Cover

Air Inlet

R/L Switch

Bit Retainer Sleeve

1234

Operating Procedures

1. Make sure the air in airline is clean and dry.

2. Make sure the tool is connected correctly with the air compressor.

3. Install a bit (as illustrated below). Before using, do check the bit being installed in the

tool correctly.

4. Torque Adjustment: Take off the torque cover and turn the torque adjustment ring

clockwise to increase the torque. Turn the torque adjustment ring counter-clockwise

to reduce the torque. When the torque is set up, put the torque cover back and

fasten it tightly to avoid changing the set-up accidentally. (as illustrated below)

5. Right/Left Indication: Turn right (clockwise) the switch (marked “R”) for tightening

screws. Turn left (counter-clockwise) the switch (marked “L”) for loosening screws.

6. Push to start: Push the tool to activate the motor.

7. Suggestion: Correct / Re-set torques before operation on a daily basis.

8. If not usedfor a long time, re-set the tool to the lowest torque.

Installation of Bit

Press the sleeve softly

Insert a bit

Make sure the bit

is fixed tightly

Set The Torque

R/L Switch

R Indication –turn right (clockwise) –fastening screw

L Indication –turn left (counter-clockwise) –loosening screw

12 3

678

12 3

678

Turn clockwise to

increase the torque

Take off the

adjustment ring

Put the torque

cover back

Fasten the rear

housing

Release the torque cover

Push Softly

Turn counter clockwise

to lower the torque

UT8933 AUTO SHUT-OFF STRAIGHT SCREWDRIVER - 900rpm/ 0.7~6.5Nm

INDEX# PARTS NO.

PARTS DESCRIPTION

QTY/S

INDEX# PARTS NO.

PARTS DESCRIPTION

QTY/S

17160001PS REAR HOUSING 141 7160039PS FRONT PLATE 1

27160061PS-W TORQUE COVER 142 7160041PS BLADE 5

37160002PS C RING 143 7155040PS ROTOR 1

47160003PS BIT RETAINER SLEEVE 144 7160042PS CYLINDER 1

57160004PS SPRING 145 SPP0208 SPRING PIN 1

67160005PS TORQUE RING 146 7160045PS PIN 1

77160006PS REGULATION WASHER 147 7160043PS END PLATE 1

87160007PS NEEDLE PIN 348 7160046PS PIN 1

97160008PS CLUTCH HOUSING 149 B606ZZ-NMB BALL BEARING 1

10 7160009PS ANVIL BUSHING 150 7160048PS VALVE 1

11 7160010PS WASHER 151 OR1898 O-RING 2

12 7155011PS TORQUE SPRING 152 7160050PS END HOUSING 1

13 7160013PS STEEL BALL 153 7160063PS GRIP 1

14 7160012PS ANVIL 154 7160060PS SCREW HOLDER 1

15 7160014PS STEEL BALL 255 7160052PS SCREW 1

16 7160015PS SPRING 156 7160051PS-RD SWITCH 1

17 7160016PS SLIDE BASE 157 0R283178 O-RING 1

18 7160017PS C RING 258 7160054PS OPERATING ROD 1

19 7160018PS BALL RACE 159 0R0302 O-RING 1

20 7160019PS STEEL BALL 60 60 7160056PS VALVE PLATE 1

21 7160020PS END CLUTCH 161 7160057PS SPRING 1

22 7160021PS CENTER CLUTCH 162 7160058PS SILENCER 2

23 STB3175 STEEL BALL 263 7160059PS EXHAUST DEFLECTOR 1

24 7160023PS REAR CLUTCH 164 ZZ389507 SILENCER 1

25 7160024PS RETAINER 165 7160062PS AIR INLET 1

26 7160025PS PILOT PIN 166 CP1HP60 SUSPENSION RING 1

27 B6001Z-TPI BALL BEARING 1

28 7160027PS CENTER HOUSING 1

29 7160028PS WASHER 1

30 7155029PS GEAR CAGE 1

31 7160030PS PINO3X10.8L 4

32 7155031PS PLANT GEAR 4

33 7155032PS SUN GEAR 1

34 7155033PS GEAR CAGE 1

35 7160034PS PIN 4

36 7155035PS PLANT GEAR 4

37 7160036PS INTERNAL GEAR 1

38 7155065PS 18T SUN GEAR 1

39 7155066PS RETAINING COLLAR 1

40 L-1680HH BALL BEARING 1

7160080PS

DISTINGUISHABLE RING(4)

7160064PS

TORQUE ADJUSTMENT RING

Division of Florida Pneumatic Mfg Corp.,

851 Jupiter Park Lane,

Jupiter, FL 33458, USA.

Ph: (1) 561 744 9500

Fax: (1) 561 575 5574

EC/UKCA DECLARATION OF CONFORMITY

We FLORIDAPNEUMATICMFGCORP,851JUPITERPARKLANE,JUPITER,FL33458,USA

Declareunderoursoleresponsibilitythatthemachinefallswithintheprovisionsofthe directive:

MachineType: UT8933 AirAutoShut-OffScrewdriver

TechnicalData:

ChuckSize: 1/4”HEXQC FreeSpeed: 900rpm

Weight: 0.84kg(1.85lbs) Length: 227 mm(8.9”)

Recommended HoseSize: 10m(3/8”) WorkingAirPressure: 6.3bar(90PSI)

Noise: (soundpressurelevel) 72dB(A) Vibration: 1.81Metres/Sec ²

Spindlesize: N/A Serial No: ________________

Towhichthisdeclarationrelates,isinconformitywiththerequirementsof:TheMachineryDirective2006/42/EC,

GeneralSafetyISO12100:2010,SpecificSafety-ImpactWrenches:ISO11148-6:2012,SpecificVibration- ISO

28927,Noise:ISO15744:2008

Nameandpositionofissuer: TonyLeNeveu:VPEngineering&Development

--------------------------------------------------------------------------------
