Universal Remote Control, Inc.

www.universalremote.com

UR3L-SR4

Operating Manual

For Easy Clicker

This remote control is designed to operate most Digital

and Analog Cable Boxes, as well as TVs, and a VCR or

DVD player.

Introduction

Before you program or operate the remote control, you must

install two new AAA alkaline batteries.

STEP1 Remove the battery compartment cover from the

back of your remote control.

STEP2 Check battery polarity carefully, and install the batter-

ies as shown in the illustration below.

STEP3 Replace the battery compartment cover.

Replacing Batteries

Button Functions

Programming the Remote Control.

*Note : In this section, when you are instructed to press a

[DEVICE] button, that means you should press either

the CBL, TV, or DVD button, depending on which

device you are programming the remote to operate.

Manual Pr

Manual Programming

ogramming

The remote control can be programmed by entering a three-

digit code number that corresponds to particular brands and

models of equipment. The three-digit code numbers are listed

in the code tables sections of this instruction manual.

STEP1 Turn on the equipment that you want the remote con-

trol to operate Cable Box, TV and DVD.

STEP2 Press the [DEVICE] button and the [OK/SEL] button

simultaneously for three seconds. The corresponding

device LED will turn on indicating that it is ready to be

programmed. The LED will remain on for 30 seconds.

The next step must be entered while the LED is on.

STEP3 Point the remote control toward the equipment and

enter the three-digit code number assigned to your

brand from the code tables. If there are more than

one three-digit number listed for your brand, try one

code number at a time until your equipment turns off.

*Note : You can verify that you have selected the correct code

by pressing the [POWER] button. The equipment

should turn on or off.

STEP4 Store the three-digit code by pressing the same

[DEVICE] button once again. The device LED will blink

twice to confirm that the code has been stored.

*Note : Try all the functions on the remote control. If any of the

functions do not operate as they should, repeat the

instructions from Step 2 using the next three-digit code

number from the same brand list.

Auto Sear

Auto Search Method

ch Method

If none of the three digit code numbers assigned to your brand

of equipment works, or the code table does not list your brand,

you can use the Auto Search Method to find the correct

three-digit code number for your equipment by following

steps:

STEP1 Turn on the equipment that you want the remote con-

trol to operate (Cable Box, TV or DVD).

STEP2 Press the [DEVICE] button and the [OK/SEL] button

simultaneously for three seconds. The device LED

will turn on indicating that it is ready to be pro-

grammed. The LED will remain on for 30 seconds.

The next step must be entered while the LED is on.

STEP3 Press the [CH+] or [CH-] button one at a time or keep

it pressed. The remote will emit a series of Power

ON/OFF code signals. Release the [CH+] or [CH-] but-

ton as soon as the equipment turns off.

*Note : You can verify that you selected the correct code by pressing

the [POWER] button. The equipment should turn On or Off.

STEP4 Press the same [DEVICE] button to store the code.

The Device LED will blink twice to confirm that the

code has been stored.

To find the Thr

o find the Three-Digit Code that W

ee-Digit Code that Was

Programmed using the Auto Sear

ogrammed using the Auto Search Method

ch Method

STEP1 Press the appropriate [DEVICE] button and the

[OK/SEL] button simultaneously for three seconds.

The device LED will turn on for 30 seconds. The next

step must be performed while the LED is on.

STEP2 Press the [INFO] button. The device LED will blink a

number of times indicating the number of each digit

for the code. Each digit is separated by a one second

interval of the LED being off.

Example : One blink, then three blinks, then eight blinks indi-

cates the code number 138.

*Note : Ten blinks indicates the number 0.

D. Pr

Programming a Second TV to the DVD Button

ogramming a Second TV to the DVD Button

STEP1 Press the [DVD] button and the [OK/SEL] button

simultaneously for 3 seconds. The DVD LED will turn

on for 30 seconds. The next step must be performed

while the LED is on.

STEP2 Press the [TV] button.

STEP3 Point the remote control toward the TV and enter the

three-digit code for your TV from the TV codes table.

STEP4 Store the three-digit code by pressing the [DVD] but-

ton. The device LED will blink twice to confirm that

the code has been stored.

The Lear

The Learning Method

ning Method

STEP1 Press the [COMPONENT] button (CBL, TV or DVD) to

be programmed and the [INPUT] buttons simultane-

ously for 3 seconds until the Component LED light

turns on.

STEP2 Line up the UR3L-SR4 to the other remote, head-to-

head, 1 or 2 inches apart.

STEP3 Press any button on the UR3L-SR4 that you want to

teach a command to. For example, if you want to

teach the [MUTE] button, press the [MUTE] button.

STEP4 Press and hold the [MUTE] button on the other remote

until the UR3L-SR4 Component LED light blinks twice.

*Note : The LED will blink 5 times if there was an error in the

learning process. In so, repeat STEPS 3 and 4. Continue

learning other buttons by repeating STEPS 3 and 4.

STEP5 Once you have completed teaching UR3L-SR4 all

desired commands for that Component, save the

learned commands by pressing the [COMPONENT]

and [INPUT] buttons simultaneously until the

Component LED blinks 3 times. Now test all the but-

tons to make sure they learned correctly.

. Erasing a Single Lear

Erasing a Single Learned Command

ned Command

STEP1 Press the [COMPONENT] and [INPUT] buttons simul-

taneously for 3 seconds until the Component LED

light turns on.

STEP2 Press and hold the button you want to erase for 3

seconds. The Component LED will blink twice to con-

firm the erasure.

STEP3 To exit, press and hold both the [COMPONENT] and

[INPUT] buttons simultaneously until the Component

LED blinks 3 times.

G. Erasing All Lear

Erasing All Learned Commands fr

ned Commands from

One Component

STEP1 Press the [COMPONENT] and [INPUT] buttons simul-

taneously for 3 seconds until the Component LED

light turns on.

STEP2 Press and hold both the [COMPONENT] button you

want to erase and the [PAUSE] button for 5 seconds.

The Component LED will blink twice to confirm the

erasure.

STEP3 To exit, press and hold both the [COMPONENT] and

[INPUT] buttons simultaneously until the Component

LED blinks 3 times.

H. Pr

H. Programming the All Of

ogramming the All Off Button

f Button

This allows you to program the All Off button so it can send up

to three power On/Off commands with one button press.

STEP1 Press the [CBL] button.

STEP2 Press the [All OFF] button and the [OK/SEL] button

simultaneously for 3 seconds. The [CBL] button will

turn on for 30 seconds.

STEP3 Press the first [COMPONENT] button you want to

store in the [ALL OFF] button and then the [POWER]

button. Repeat this for other Components until you

have stored all the desired power commands into the

[ALL OFF] button.

STEP4 Press the [CH+] button to save the power commands

you stored. The [CBL] button will blink twice to con-

firm the commands have been saved.

I. Pr

I. Programming for Advanced Functions.

ogramming for Advanced Functions.

If your remote model has custom-programmable Macro but-

tons available, they can be programmed to act as a ‘Macro’ or

Favorite Channel button in CABLE mode. This allows you to pro-

gram up to five 2-digit channels, four 3-digit channels or three 4-

digit channels that can be accessed With one button press.

**Note : The FAV button is not programmable if you have a

Digital Cable Box made by Pace, Pioneer or

CISCO/SA.

STEP1 Press the [CBL] button to select the CBL mode.

STEP2 Press the [MACRO] button and [OK/SEL] button

simultaneously for 3 seconds. The [CBL] button will

turn on for 30 seconds.

STEP3 Enter the the 2, 3 or 4-digit code for the channel you

want programmed first (for example, 007) using the

Number Pad, then press the [STOP] button. Then

enter the code for the next channel (for example,

050), then press the [STOP] button. Repeat this

process for the third channel. The [CBL] button will

blink once for each channel entered.

STEP4 Press the [CH+] button to store the channels that

were selected. The [CBL] button will blink twice to

confirm the storage of commands.

To access the programmed channels, press the [MACRO]

button once. This will bring up the first channel. Press once

again and it will bring up the second channel. Press again

and it will bring up the third channel.

To erase the Macro programming and return to the original

function:

STEP1 Press the [CBL] button to select the CABLE mode.

STEP2 Press a [MACRO] button and the [OK/SEL] button

simultaneously for 3 seconds. The CBL device LED

will turn on for 30 seconds. The next step must be

performed while the LED is on.

STEP3 Press the [CH+] button to erase the functions stored

in the button. The CBL device LED will blink twice to

confirm that the memory button has been erased.

J. Assigning the V

Assigning the Volume and Mute keys to a

olume and Mute keys to a

Dif

Differ

ferent Device

ent Device

CBL : TV TV : TV DVD : TV

STEP1 Press the [OK/SEL] button and [CBL] button simulta-

neously for three seconds. The device LED Will turn

on for 30 seconds. The next step must be performed

while the LED in on.

STEP2 Press the [VOL+] button. The device LED will blink.

STEP3 Press the [CBL] button corresponding to the device

that you would like the volume and mute buttons to

control. The device LED will blink twice to confirm

the programming.

Example : If you wish to have the volume and mute keys oper-

ate your TV, press the [TV] button in Step3.

K. Assigning the Channel keys to a Dif

Assigning the Channel keys to a Differ

ferent

ent

Device

CBL : CBL TV : CBL DVD : DVD

STEP1 Press the [OK/SEL] button and [TV] button simultane-

ously for three seconds. The device LED Will turn on

for 30 seconds. The next step must be performed

while the LED in on.

STEP2 Press the [VOL-] button. The device LED will blink.

STEP3 Press the [TV] button corresponding to the device

that you would like the volume and mute buttons to

control. The device LED will blink twice to confirm

the programming.

*Note : If you wish to have the channel keys operate your Cable Box,

press the [CBL] button instead of the [TV] button in Step3.

Otros manuales para Easy Clicker UR3L-SR4

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Control remoto universal de Universal Remote Control

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8700 Manual de usuario

Universal Remote Control

Universal Remote Control omega MX-650 Manual de usuario

Universal Remote Control

Universal Remote Control COMPLETE CONTROL MX-450 Manual de usuario

Universal Remote Control

Universal Remote Control Easy Clicker UR2-211 Manual de usuario

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8700L Manual de usuario

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8700L-IP Manual de usuario

Universal Remote Control

Universal Remote Control Total Control TRC-1280 Manual de usuario

Universal Remote Control

Universal Remote Control URC-L-1870 Manual de usuario

Universal Remote Control

Universal Remote Control UR2-DTA Manual de usuario

Universal Remote Control

Universal Remote Control MRF-260i Manual de usuario

Universal Remote Control

Universal Remote Control CLIKR-5 UR5L-8700L Manual de usuario

Universal Remote Control

Universal Remote Control UR17E - CODE BOOK Manual de usuario

Universal Remote Control

Universal Remote Control MX-900 Manual del propietario

Universal Remote Control

Universal Remote Control OCE-0085A Manual de usuario

Universal Remote Control

Universal Remote Control COMPLETE CONTROL MX-880Z Manual de usuario

Universal Remote Control

Universal Remote Control AVEX R6 - SPECS SHEET Manual de usuario

Universal Remote Control

Universal Remote Control Easy Clicker OCE-0009D Manual de usuario

Universal Remote Control

Universal Remote Control Universl Remote Manual de usuario

Universal Remote Control

Universal Remote Control Complete Control MX-880 Manual de usuario

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8500 Manual de usuario

Universal Remote Control

Universal Remote Control UR4-DSR Manual de usuario

Universal Remote Control

Universal Remote Control Complete Control MX-810 Manual de usuario

Universal Remote Control

Universal Remote Control Customizer URC-300 Manual de usuario

Universal Remote Control

Universal Remote Control total control TRC-780 Manual de usuario

Manuales populares de Control remoto universal de otras marcas

Pronto

Pronto Peel Manual de usuario

GE 24929 Manual de usuario

Radio Shack

Radio Shack Wireless Remote Control System Manual de usuario

AUVIO

AUVIO Universal Home Theater Remote Manual de usuario

Philips

Philips Icon SRU4106 Manual de usuario

THOMSON

THOMSON ROC4309 Manual de usuario

Philips

Philips pm625S Manual de usuario

GE RM94931 Manual de usuario

RCA

RCA RCU600WMS - Universal Remote Control Manual de usuario

Blackweb

Blackweb BWB17AV002 Manual de usuario

Marmitek

Marmitek DoorGuard 300 Manual de usuario

Chunghop

Chunghop RM-L618 Manual de usuario

GE RM24965 Manual de usuario

Anderic

Anderic KTN828 Manual de usuario

Sunwave Tech.

Sunwave Tech. Touch Screen Remote Control Manual de usuario

Medion

Medion E74023 Manual de usuario

intensity

intensity RM02A Manual de usuario

GE RM24950 Manual de usuario
