ASSEMBLY MANUAL
Original manual V3.0 2016
Ultimaker
ULTIMAKER ORIGINAL+
DISCLAIMER
Please read and understand the contents of this assembly manual. Failure to read the manual may lead to
personal injury, inferior results or damage to the Ultimaker. Always ensure that anyone who assembles the 3D
printer knows and understands the contents of the manual.
We can not control the conditions in which you assemble the Ultimaker Original+. For this and other reasons, we do not
assume responsibility and expressly disclaim liability for loss, injuries, damage, or expense arising out of or in any way
connected with the assembly, handling, storage, use or disposal of the product.
The information in this document was obtained from sources which we believe are reliable. However, the information is
provided without any warranty, express or implied, regarding its correctness.
Copyright © 2016 Ultimaker. All rights reserved worldwide.
This language version of the manual is verified by the manufacturer (Original manual). No part of this publication, including pictures may be
reproduced and/or made public, whether by printing, photocopying, microfilm or by any other means whatsoever, without the prior written
permission of Ultimaker.
3
1. INTRODUCTION ..................................................................................................................................................................................... 5
What’s in the box? 6
2. FRAME .................................................................................................................................................................................................... 13
Preparing the panels 14
Assembling the frame 19
Attaching various parts 23
3. X/Y AXLES ............................................................................................................................................................................................ 27
Sliding blocks 28
Attaching the caps 31
Placing the X and Y axles 34
4. Z STAGE ................................................................................................................................................................................................. 39
Assembling the Z stage 40
Installing the Z stage 49
4. PRINT HEAD ........................................................................................................................................................................................ 54
Print head assembly 55
Placing the print head in the frame 63
Aligning the print head 66
6. FEEDER .................................................................................................................................................................................................. 69
Assembling the feeder 70
Bowden tube 80
Spool holder 82
7. ULTICONTROLLER .............................................................................................................................................................................. 84
8. ELECTRONICS ..................................................................................................................................................................................... 88
Mounting the main board 89
Connecting 91
Cover 96
TABLE OF CONTENTS
4
PREFACE
This is the assembly manual for the Ultimaker Original+.
The manual guides you through the steps to successfully assemble the 3D printer.
Please read all information and follow the instructions and guidelines in this manual carefully. This ensures that possible
accidents and injuries will be prevented and that you will obtain great quality prints.
Every eort has been made to make this manual as accurate and complete as possible. The information is believed to
be correct but does not purport to be all inclusive and shall be used only as a guide. Should you discover any errors
or omissions, please bring this to our attention, so that we can make amendments. This will enable us to improve our
documentation and service to you.
5
INTRODUCTION
Your Ultimaker Original+ kit consists of several parts. This chapter describes the
components (quantities, article numbers and names) that are part of the Ultimaker
Original+ kit. Check if all parts are included before you start assembling.
Assembling the Ultimaker Original+ takes about 8 - 16 hours and requires the
following tools: hex key 2 mm (included), hex key 2.5 mm (included), a flat
screwdriver, crosshead screwdriver and socket wrench or pliers.
1
6
0,75 kg filament
Power cord
Serial number sticker
1
1
1
LAYER 1
LAYER 2
Additional pack
Bearing pack
Belts pack
WHAT’S IN THE BOX?
Short timing belt
Long timing belt
2
4
1085
1086
Ball bearing 8 mm
Sintered bushing
Linear bearing
Small ball bearing
Square flanged linear bearing
10
4
2
1
2
1021
1056
1065
1142
1170
USB cable
Blue tape
Hex key 2 mm
Glue stick
Hey key 2.5 mm
SD card
1
1
1
1
1
1
1144
1225
1227
1228
1402
1250
7
Heated bed cable
Double flat cable 10 wire
PT100 B sensor
Heater cartridge
1
1
1
1
1171
1183
1185
1513
Cable pack
Velcro parts
Short cable duct
Long cable duct (you will only need 1)
4
2
3
1010
1131
1132
Cable management pack
Feeder quick fit coupling
Clamp clip
Knurled wheel
Cap nut M8
Washer M8
Nut M8
Feeder spring
1
1
1
1
2
1
1
1016
1071
1133
1134
1136
1137
1143
Feeder pack
Warning sticker
Metal fan duct
Print head fan
1
1
1
1326
1501
1512
Fan pack
8
Grease
Copper grease
1
1
1226
1524
Grease pack
Aluminium hot end holder
Aluminium heater block
Hot end isolator tube
Nozzle
Teflon coupler
PEEK isolator
Tube coupling collet
Clamp clip
1
1
1
1
1
1
1
1
1048
1049
1053
1054
1055
1067
1069
1071
Hot end pack
Injection molded set
Motor spacer
Heated bed cable clip
1
1
1
1030
1241
1243
Injection molding pack
Black wired limit switch
Blue wired limit switch
Red wired limit switch
1
1
1
1023
1025
1026
Limit switch pack
9
Spacer 16 mm
Table spring
Washer M3
M3x10 bolt
M3x12 bolt
M3x16 bolt
M3x14 bolt
M3x20 bolt
M3x25 bolt
M3x30 bolt
Hex nut
Set screw
Lock nut
M4x10 bolt
4
3
19
28
16
80
12
17
17
21
120
17
35
10
1139
1152
1201
1202
1203
1204
1205
1206
1207
1208
1209
1211
1214
1217
Glass retainer clip
Knurled nut
Washer M6
M3x4 bolt
Countersunk bolt M3x8
Countersunk bolt M3x20
Self tapping bolt
Spacer 8 mm
Metal cable clamp
Nylon hex nut
Nylon M3x12 bolt
Nylon M3x25 bolt
Spacer 3 mm
Print head thumb screw
4
3
3
2
6
5
2
8
1
12
8
6
2
4
1256
1257
1288
1348
1355
1356
1362
1502
1514
1540
1541
1542
1545
1680
Nuts & bolts pack
10
Pulley 5 mm
Pulley 8 mm
2
10
1084
1085
Pulley pack
Knob
UltiPanel rev 1.1
UltiController window
1129
1146
1522
UltiController pack
LAYER 3
Y linear shaft
X linear shaft
Z linear shaft
Print head shaft X, Y
Z motor with trapezoidal lead screw
Trapezoidal lead nut
2
2
2
2
1
1
1011
1012
1028
1046
1159
1187
Axle pack
Spiral sleeve
Bowden tube
1
1
1097
1266
Bowden pack
