Turck LTX Series Manual de usuario

Your Global Automation Partner

Operating instructions

LTX

Linear Position Sensors

with Analog Output

2 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com



Contents

2019/03

1 About These Instructions 5

1.1 Target groups 5

1.2 Explanation of symbols 5

1.3 Other documents 5

1.4 Feedback about these instructions 5

2 Information About the Product 6

2.1 Product identication 6

2.2 Scope of delivery 6

2.3 Legal requirements 6

2.4 Manufacturer and service 7

3 For your Safety 7

3.1 Intended use 7

3.2 General safety information 7

4 Product Description 8

4.1 Device overview 8

4.1.1 Display elements 8

4.2 Properties and features 8

4.3 Operating principle 9

4.4 Functions and operating modes 9

4.4.1 Automatic signal control 9

4.4.2 Current output 9

4.4.3 Voltage output 9

4.4.4 Preferred types LTX…M-F10-LI0-X3-H1151 – Measuring range 9

4.5 Technical accessories 10

5 Mounting 13

5.1 Mounting the device in a hydraulic cylinder 14

5.1.1 Mounting the sensor 14

5.2 Fastening the device externally with a mounting bracket 15

5.2.1 Fitting additional mounting elements (for external mounting) 16

5.2.2 Mounting positioning elements (for external mounting) 16

6 Connection 17

6.1 Wiring diagram 17

7 Commissioning 18

8 Operation 19

8.1 LED display 19

8.2 Diagnostics 19

9 Setting 20

9.1 Setting via manual bridging 20

9.2 Setting via teach adapter RP-Q21 20

10 Troubleshooting 20

10.1 Replacing the sensor head and measuring element 21



Contents

4 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com

11 Maintenance 21

12 Repair 22

12.1 Returning devices 22

13 Disposal 22

14 Technical Data 23

14.1 Update time 23

2019/03

1 About These Instructions

These operating instructions describe the structure, functions and the use of the product, and

will help you to operate the product as intended. Read these instructions carefully before using

the product. This will prevent the risk of personal injury or damage to property or the device.

Retain these instructions for future use during the service life of the product. If the product is

passed on, ensure that these instructions are handed over as well.

1.1 Target groups

These instructions are intended for qualified personnel and must be read carefully by anyone

mounting, commissioning, operating, maintaining, dismantling or disposing of the device.

1.2 Explanation of symbols

The following symbols are used in these instructions:

DANGER

DANGER indicates an imminently hazardous, high-risk situation which, if not avoided,

will result in death or serious injury.

WARNING

WARNING indicates a potentially hazardous, medium-risk situation which, if not

avoided, could result in death or serious injury.

CAUTION

CAUTION indicates a situation that may result in property damage if not avoided.

NOTE

NOTE indicates tips, recommendations and important information. The notes will facili-

tate work, provide more information on specific actions and help prevent additional

work due to incorrect processes.

CALL TO ACTION

This symbol denotes action steps that the user must perform.

ACTION RESULT

This symbol denotes the relevant results of actions and action sequences.

1.3 Other documents

In addition to this document, the following material can be found on the Internet at

www.turck.com:

■Data sheet

■EU declaration of conformity

1.4 Feedback about these instructions

We make every effort to ensure that these instructions are as informative and as clear as pos-

sible. If you have any suggestions for improving the design or if any information is missing from

the instructions, please send your suggestions to techdoc@turck.com.

6 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com

Information About the Product

2 Information About the Product

2.1 Product identication

NOTE

■Designs with manufacturer-compatible connectors as well as models with customer-

specific blind zones are available on request.

■The preferred types are the LTX…M-F10-LI0-X3-H1151 devices.

2.2 Scope of delivery

The following are included in the scope of delivery:

■Linear position sensor (without positioning element)

■Quick Start Guide

2.3 Legal requirements

The device is subject to the following EU directives:

■2014/30/EU (electromagnetic compatibility)

LTX 100 M Magnetostrictive

position sensor –

Unit

MMillimeter

EInch

Measuring range

100 from 25 to 7600 mm

or 1 to 300"

Operating principle

LTX Linear position sensor

F10 Design –

Design

F10 Flat face, rod Ø 10.3 mm, sensor

head made from aluminum*

R10 Raised face, rod Ø 10.3 mm,

sensor head made from

aluminum

EF10 Flat face, rod Ø 10.3 mm, sensor

head made from stainless

ER10 Raised face, rod Ø 10.3 mm,

sensor head made from

stainless steel

H1 1 5 1 Electrical connection:

Male

Assignment

1Standard assignment

Number of contacts

55-pin

Connector type

1straight

Connector type

H1 Male connector M12 × 1

* Preference type

LTX 100 M – F10 – LI0 – X3 – H1 1 5 1

LI0 – X3 Electrical version –

Number of LEDs

X3 3-color LED

Output type

LI0 4…20 mA*

LI1 20…4 mA

LU0 0…10 V

LU1 10…0 V

LU2 -10…10 V

LU3 10…-10 V

LU4 0…5 V

LU5 5…0 V

LU6 -5…5 V

LU7 5…-5 V

2019/03

2.4 Manufacturer and service

Turck provides you with support and assistance for your projects — from the initial analysis to

commissioning your application. The Turck product database contains software tools for pro-

gramming, configuration and commissioning, as well as data sheets and CAD files in numerous

export formats. You can access the product database at the following address:

www.turck.de/products/

Should you have any further questions, please contact the sales and service team in Germany

on the following telephone numbers:

Sales: +49 208 4952-380

Technology: +49 208 4952-390

Outside Germany, please contact your Turck representative.

Hans Turck GmbH & Co. KG

Witzlebenstraße 7

45472 Mülheim an der Ruhr

Germany

3 For your Safety

The product is designed in accordance with the latest standards. However, residual risks still

exist. Observe the following warnings and safety information to prevent personal injury or

damage to property. Turck accepts no liability for damage caused by failure to observe these

warning and safety instructions.

3.1 Intended use

The devices are intended solely for use in industrial areas.

The magnetostrictive linear position sensors are used for contactless and wear-free linear posi-

tion detection. The devices are suitable for use in hydraulic cylinders. By adding float magnets

(available as an option), the devices can also be used for level measurement. The measuring

range is adjustable.

The devices must be used only as described in these instructions. Any other use is not in accor-

dance with the intended use. Turck accepts no liability for any resulting damage.

3.2 General safety information

■The devices are not safety components and must not be used for personal or property

protection.

■The device must be mounted, installed, operated, parameterized and maintained only by

trained and qualified personnel.

■The device complies exclusively with the EMC requirements for industrial applications and is

not suitable for use in residential areas.

8 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com

Product Description

4 Product Description

The linear position sensors with an analog output are available with a current or voltage output.

An M12 connector is available for the connection. All devices feature a rod design with IP68

protection. The devices operate without contact, which requires the use of a positioning ele-

ment approved by Turck (see Accessories). The measuring range is adjustable.

The devices operate on an absolute basis; power outages do not necessitate renewed zero off-

set adjustment or recalibration. All position values are determined as absolute values; reference

runs after a voltage drop are unnecessary.

4.1 Device overview

Fig. 1: Device dimensions of LTX…M… with standard blind zones (in mm)

4.1.1 Display elements

Each device has a 3-color LED for indicating the operating state and for diagnostics (see 8.1 LED

display).

4.2 Properties and features

■Analog output

■Adjustable measuring range with adjustment protection

■Automatic signal control

■7…30 VDC supply voltage

■Low power consumption

■High shock and vibration resistance

■Protection class IP68

■16-bit resolution

■Status display via 3-color LED

■Sensor and pressure pipe can be replaced separately

■M12 connector

44.5

ø 44.5

ø 10.3

M18 x 1.5 x 25

M12 x 1

81.3

63.5

Blind zone

50.8

Blind zone

Measuring

range

2019/03

4.3 Operating principle

Turck LTX sensors utilize the magnetostrictive principle. A "waveguide" is located in the measur-

ing probe of the linear position sensor. If a current signal generated at the waveguide encoun-

ters the externally applied magnetic field of the positioning element, mechanical feedback is

produced in the waveguide. This feedback is evaluated in the sensor head and output as posi-

tion information.

4.4 Functions and operating modes

The devices feature a current or voltage output. The device output provides a current or voltage

signal proportional to the position of the positioning element (see output characteristics).

I [mA]

U [V]

Fig. 2: Output characteristics – devices with

4…20 mA current output

Fig. 3: Output characteristics – devices with

0…10V voltage output

4.4.1 Automatic signal control

The device is automatically adjusted to the signal strength of the positioning element as soon

as the sensor is supplied with power. The automatic signal control fully compensates for any

tolerances.

4.4.2 Current output

LTX…LI… devices feature a current output, which outputs a current signal in line with the posi-

tion of the positioning element (e.g. 4…20 mA, depending on design). The measuring range is

adjustable.

4.4.3 Voltage output

LTX…LU… devices feature a voltage output, which outputs a voltage signal in line with the

position of the positioning element (e.g. 0…10V, depending on design). The measuring range

is adjustable.

4.4.4 Preferred types LTX…M-F10-LI0-X3-H1151 – Measuring range

Preferred types LTX…M-F10-LI0-X3-H1151 are available with the following measuring lengths

as standard:

Measuring range congured

100…500mm in 25mm increments

500…2000mm in 50mm increments

2000…7600mm in 500mm increments

10 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com

Product Description

4.5 Technical accessories

The following accessories are not supplied with the device:

Dimension drawing Type Ident no. Description

Positioning element

ø 32,8

ø 23,8

ø 4,7

ø 13,5

16,8

7,9

STM-AL-R10 6900409 Standard 4-hole positioning element, alu-

minum, suitable for mounting in hydraulic

cylinders

ø 25,4

7,9

ø 13,5

CM-R10 6900416 Standard positioning element, suitable for

mounting in hydraulic cylinders



















LSPM-AL-R10 6900414 Ring-type positioning element with slot,

aluminum, can be used for external mount-

ing with mounting clamp RB-R10

50,8

ø 14,1

ø 50,8

max.

ø 52,1

EF-R10 6900417 Float-positioning element, stainless steel,

specific weight 0.62 kg/m³, for external

mounting for level monitoring

Spacer

ø 32,8

ø 23,8

ø 4,7

ø 13,5

16,8

6,4

STS-R10 6900411 Standard spacer produced from non-ferritic

material for separating the positioning ele-

ment from the ferritic base of the hydraulic

piston rod, suitable for installation in hydrau-

lic cylinders

Otros manuales para LTX Series

Tabla de contenidos

Otros manuales de Accesorios de turck

turck

turck LTX-R10 Series Manual de usuario

turck

turck S1102 Manual de usuario

turck

turck FCS-G NAEX Series Manual de usuario

turck

turck LRS510 Series Manual de usuario

turck

turck RU50-S18 Series Manual de usuario

turck

turck FCS-G1/2A4-NAEX0-H1141 Manual de usuario

turck

turck High-End Series Manual de usuario

turck

turck FS101 Series Manual de usuario

turck

turck RU40-AP Series Manual de usuario

turck

turck FCS-G1/2A4-NAEX/D024 5M Manual de usuario

turck

turck LPRE-M30-AP6X2-H1141 Manual de usuario

turck

turck RU10 M08 Series Manual de usuario

turck

turck FCS-GL1/2HC22-NAEX-H1141 Manual de usuario

turck

turck RU Series Manual de usuario

turck

turck FS100 L Series Manual de usuario

turck

turck RI360P1-DSU35-CNX4 Series Manual de usuario

turck

turck CMTH Series Manual de usuario

turck

turck BC3-M12-AP6X 15M Manual de usuario

turck

turck RU D UPN8X2 Series Manual de usuario

turck

turck PK01VR N Series Manual de usuario

turck

turck FCS-G1/2A4-NAEX/L065/D100 Manual de usuario

turck

turck BI2-M12-Y1X-H1141 Manual de usuario

turck

turck PS Series Manual de usuario

turck

turck DR Series Manual de usuario

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario

Axminster

Axminster Tooling Stylus Tip Ballpoint Pen Kit Manual de usuario

turck LTX Series Manual de usuario

Manuales populares de Accesorios de otras marcas
