Tripp Lite SM2200NAFTA Manual de usuario

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: SM2200NAFTA

Smart Pro line interactive UPS System - NAFTA assembled version of SMART2200NET

Highlights

2200VA / 2.2kVA line interactive, extended-run tower UPS

Maintains 120V nominal output over an input range of 87 to 140V

Network communications supported via 3 DB9 ports (1 serial / 2 contact

closure)

Input: NEMA 5-15P (120V 15A) / Output: 6 NEMA 5-15R (120V)

$250,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only)

Description

Tripp Lite's SM2200NAFTA intelligent, line interactive large tower UPS system protects servers, networking accessories and telecommunications

equipment from blackouts, voltage fluctuations and transient surges. Large internal batteries offer 27 minutes half load runtime and 11 minutes fully

loaded. Runtime is expandable with optional BP24V28-2U (limit 1) and BP24V70-3U external battery packs. 2200VA/1700 watt power handling

capability supports a variety of networking, telecom and other sensitive electronic applications. Includes 6 protected outlets. Supports remote

monitoring of UPS and site power conditions via built-in RS-232 enabled monitoring port, plus standard UPS monitoring via 2 built in contact closure

ports. Includes PowerAlert UPS monitoring and unattended shutdown software with complete cabling. Built-in audible alarm and front panel LEDs

indicate line power, battery power, battery charge level, load level, plus voltage regulation status. Network grade AC surge suppression protects

equipment from damage and performance problems resulting from transient surges. Attractive large gray tower housing. $250,000 connected

equipment insurance.

Package Includes

SM2200NAFTA UPS System

PowerAlert Software and three 6 foot network cables

Warranty information

Instruction manual

Features

SM2200NAFTA line interactive UPS offers battery derived AC output during power outages, voltage regulation during brownouts and

overvoltages, plus network-grade AC surge suppression

2200VA/1700 watt power handling capability supports a variety of networking, telecom and other sensitive electronic devices

Large internal batteries offer runtimes of 27 minutes at half load (1100VA/850 watts) and 11 minutes at full load (2200VA/1700 watts)

Runtime is further expandable with optional external BP24V28-2U (limit 1) and BP24V70-3U (multi-pack compatible) battery packs

Automatic Voltage Regulation (AVR) circuits maintain 120V nominal output over an input voltage range of 87-140V

Includes 6 fully protected NEMA 5-15R outlets with 2 single outlet load banks that can be individually powered off and back on again via

software interface

PowerAlert UPS monitoring and unattended shutdown software enables configurable network broadcast messaging, email notification,

event logging and running user defined script commands

Offers simultaneous monitoring of up to 3 directly connected devices through included DB9 contact closure and RS-232 enabled interfaces,

or the monitoring of any number of additional servers over IP with included PowerAlert monitoring software

In addition to the contact closure monitoring of on battery, low battery and power restored messaging, built-in RS-232 interface supports

messaging of UPS and line power status, including AC line voltage, DC battery voltage and remaining battery capacity

Supports activate self-test and UPS output power control for delayed or immediate reboot of connected equipment

Diagnostic LEDs (indicate 17 performance conditions)

UL (USA), cUL (Canada), NOM (Mexico), FCC Class A (Business) Listed

$250,000 Ultimate Lifetime Insurance (USA & Canada Only)

Specifications

OUTPUT

Output Volt Amp

Capacity (VA)

2200

Output kVA capacity

(kVA)

2.2

Output Watt Capacity

(watts)

1700

Output kW capacity 1.7

Output power factor 0.8

Nominal Output

Voltage(s) Supported

120V

Frequency compatibility 60 Hz

Output voltage

regulation (line mode)

-13% / +5%

Output voltage

regulation (Battery

mode)

+/- 5%

Built-in UPS output

receptacles

6 5-15R outlet(s)

Built-in controllable

switched load banks

Two switchable single outlet 5-15R load banks

Basic PDU options PDU1215 (1U / 13 5-15R outlets); PDUNV (1U / 2 C19, 12 C13 outlets); PDU1415 (0U / 14 5-15R outlets);

PDUV15 (0U / 12 5-15R outlets)

Metered PDU options PDUMH15 (1U / 13 5-15R outlets); PDUMH15AT (1U / 8 5-15R outlets)*; PDUMV15 (0U / 16 5-15R outlets)

Switched PDU options PDUMH15ATNET (1U / 8 5-15R outlets)*; PDUMV15NET (0U / 16 5-15R outlets)

External PDU

redundancy options

*Auto Transfer Switch features utilizing the secondary PDU input cord are compatible with Smart Online UPS

models only

Output AC waveform

(AC mode)

Sine wave

Output AC waveform

(battery mode)

PWM sine wave

INPUT

Rated input current (at

maximum load)

15A

Nominal Input

Voltage(s) Supported

120V AC

UPS input connection

type

5-15P

Input circuit breaker 20A

UPS Input cord length

(ft.)

UPS Input cord length

(m)

2.4

Recommended

Electrical Service

20A 120V

BATTERY

Full load runtime

(minutes)

11 min. (1700w)

Half load runtime

(minutes)

27 min. (850w)

External battery pack

compatibility

BP24V28-2U (limit 1); BP24V70-3U (multi-pack compatible)

DC system voltage

(VDC)

Battery recharge rate

(included batteries)

Less than 9 hours from 10% to 90%

VOLTAGE REGULATION

Voltage regulation

description

Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 87 to 140

Overvoltage correction Input voltages between 127 and 140 are reduced by 12%

Undervoltage correction Input voltages between 95 and 105 are boosted by 10%

Severe undervoltage

correction

Input voltages between 87 and 94 are boosted by 22%

LEDS ALARMS & SWITCHES

LED Indicators 5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status

Alarms Audible alarm indicates power-failure and low-battery conditions

Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate

low-battery status

Switches 2 Switches control off/on power status and alarm-cancel/self-test operation; set of 4 rear-panel switches control

system enable and contact closure port inverter shutoff commands

SURGE / NOISE SUPPRESSION

UPS AC suppression

joule rating

480

UPS AC suppression

response time

Instantaneous

EMI / RFI AC noise

suppression

Yes

PHYSICAL

Installation form factors

supported with included

accessories

Tower

Primary form factor Tower

UPS / Power Module

dimensions in primary

form factor (height x

width x depth / inches)

17 x 9 x 12.5

UPS / Power Module

dimensions in primary

form factor (height x

width x depth / cm)

43.2 x 22.9 x 31.8

UPS / Power Module

weight (lbs)

UPS / Power Module

weight (kg)

36.3

UPS Shipping

dimensions (height x

width x depth / inches)

22.2 x 12.8 x 16.5

UPS Shipping

dimensions (height x

width x depth / cm)

56.5 x 32.4 x 41.9

Shipping weight (lbs) 87

Shipping weight (kg) 39.5

UPS housing material Polycarbonate

ENVIRONMENTAL

Operating Temperature

Range

+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature

Range

+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC mode BTU / hr. (full

load)

58.4

Battery mode BTU / hr.

(full load)

863.7

COMMUNICATIONS

Communications

interface

DB9 Serial; Contact closure

Network monitoring

port description

Supports detailed monitoring of UPS and site power conditions; contact closure communications via two

additional DB9 ports (3 total)

PowerAlert software Included

Communications cable 3 DB9 cables included

LINE / BATTERY TRANSFER

Transfer time 2-4 milliseconds

Low voltage transfer to

battery power (setpoint)

High voltage transfer to

battery power (setpoint)

140

SPECIAL FEATURES

Cold Start (startup in

battery mode during a

power failure)

Cold-start operation supported

Green & high efficiency

features

Greater than 95% efficiency - GREEN UPS; Individually controllable load banks

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A

(EMI); ROHS (Restriction of Hazardous Substances)

WARRANTY

Product Warranty

Period (Worldwide)

2-year limited warranty

Connected Equipment

Insurance (U.S., Canada

& Puerto Rico)

$250,000 Ultimate Lifetime Insurance

Related Items

Optional Products

Product Type Related Model Description Qty.

Audio Cables CT120 Instant-Read- AC Outlet Circuit Tester 1

Extended Warranties WEXT3-2200-3000 3-Year Extended Warranty - For Smart Line-Interactive and Online

Tower or Rack models, 2200-3000VA

Extended Warranties WEXT5-2200-3000 5-Year Extended Warranty - For Smart Line-Interactive and Online

Tower or Rack models, 2200-3000VA or less

External Battery Packs BP24V28-2U BP24V28-2U - External Battery Pack for UPS System 1

External Battery Packs BP24V70-3U BP24V70-3U - External Battery Pack for UPS System 1

Power Distribution PDU1215 Basic PDU / Power Distribution Unit - Safe, reliable power distribution

for critical networking equipment

Power Distribution RS-1215 Tripp Lite Power Strip - Multiple outlets wherever you need them 1

Surge Protectors DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial

lines

Surge Protectors DNET1 Network Surge Suppressor - Essential protection for data and

communication lines

Surge Protectors DTEL2 Network Surge Suppressor - Essential protection for data and

communication lines

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3539.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
