Tripp Lite TLP606 Manual de usuario

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: TLP606

6-outlet, 6-ft cord, 790 joule strip - Protect It! Surge Suppressor

Highlights

6 outlet / 6-ft. cord

790 joule rating

$20,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)

Description

Tripp Lite's TLP606 offers economical AC surge suppression for protection of workstations, desktop PCs, telecom systems and other sensitive

electronics. Built-in AC surge suppression shields connected equipment from damage and performance problems due to transient surges. TLP606

offers 6 total outlets, 6 foot cord and diagnostic LED to warn of suppressor damage. AC suppression rated at 790 joules shields equipment from

surges and line noise. Attractive white suppressor housing with keyhole mounting tabs offer convenient protection of desktop computer equipment

and accessories. $20,000 Ultimate Lifetime Insurance (USA & Canada Only).

PLUG/OUTLETS: Input: NEMA5-15P/Output: 6 NEMA5-15R/6-ft. AC line cord

ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA5-15R wall receptacle)

FORMAT: Corded multi-outlet strip with 1 transformer spaced outlet

SUPPRESSION: AC: 150V RMS Clamping/790 joules/400V UL1449 3rd Edition

Applications

Ideal for any desktop, network or home computing application requiring AC line protection

Package Includes

TLP606 surge suppressor

Instruction manual with warranty information

Features

6 outlets

6-ft. cord

Surge suppression rating: 790 joules

EMI/RFI noise filtering

15 amp resettable circuit breaker

Green protection LED

Includes full normal mode (H-N) and common mode (N-G/H-G) line surge suppression

Can accommodate 1 large transformer plug without covering remaining outlets, 3 total transformers

Keyhole support for wall mounting

Lighted power switch

$20,000 Ultimate Lifetime Insurance (USA and Canada Only)

Specifications

OVERVIEW

Intended Application Home/Office

OUTPUT

Frequency compatibility 50 / 60 Hz

Output watts 1800

Circuit Breaker (amps) 15

Overload protection 15A resettable illuminated combo switch / circuit breaker

Outlet quantity / type 6 NEMA 5-15R

Transformer accommodation Supports 1 large transformer plug accessory without covering remaining outlets, accepts up to 3

transformers total

Outlet orientation Single row of 6 outlets

INPUT

Recommended Electrical

Service

120V (110-125V)

Input connection type NEMA 5-15P

Input cord length (ft.) 6

Input cord length (m) 1.83

Input cord gauge, type 14 gauge, SJT

Voltage compatibility (VAC) 120

Maximum Surge Amps 35500

LEDS ALARMS & SWITCHES

Switches Combination AC circuit breaker and 2 position red illuminated on/off power switch

Diagnostic LEDs Built-in LED confirms suppressor "protection present" (green) status

SURGE / NOISE SUPPRESSION

AC suppression joule rating 790

AC suppression response

time

< 1 ns

Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression

Clamping voltage (RMS) 150

UL1449 let through rating 400V

DATALINE SURGE SUPPRESSION

Cable (Coax) Protection No

Network (Ethernet)

Protection

PHYSICAL

Shipping weight (lbs) 1.20

Shipping weight (kg) 0.53

Unit Dimensions (HWD/in) 10.8 x 1.85 x 1.23

Unit Dimensions (HWD/cm) 3.20 x 4.19 x 26.29

Shipping Dimensions

(HWD/in)

13.2 x 5 x 1.80

Shipping Dimensions

(HWD/cm)

30.99 x 11.99 x 3.78

Unit weight (lbs) 1.01

Unit weight (kg) 0.48

Material of construction Plastic

Integrated keyhole mounting

tabs

Keyhole mounting tabs enable wall mounting

AC line cord color Gray

Style Strip

Outlets center to center

measurement

28.5mm

Keyhole slot center to center

measurement

Distance between slots = 101mm; Distance between slot height = 28mm

CERTIFICATIONS

UL1449 3rd Edition (AC

Suppression)

UL1449 3rd EDITION

UL1363 (Power Tap) UL1363

cUL / CSA (Canada) cUL

Approvals Exceeds IEEE 587 category A&B specifications

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Connected Equipment

Insurance (U.S., Canada &

Puerto Rico)

$20,000 Ultimate Lifetime Insurance

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=2632.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
