Tripp Lite TLP604 Manual de usuario

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: TLP604

Protect It! Surge Suppressor

Highlights

6 outlets / 4-ft. cord

720 joule rating

$20,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)

Description

Tripp Lite's TLP604 offers economical AC surge suppression for protection of workstations, desktop PCs, telecom systems and other sensitive

electronics. Built-in AC surge suppression shields connected equipment from damage and performance problems due to transient surges. TLP604

offers 6 total outlets, 4 foot cord and diagnostic LED to warn of suppressor damage. AC suppression rated at 720 joules shields equipment from

surges and line noise. Attractive white suppressor housing with keyhole mounting tabs and 1 designated transformer plug outlet offers convenient

protection of desktop computer equipment and accessories. $20,000 Ultimate Lifetime Insurance (USA & Canada Only).

PLUG/OUTLETS: Input: NEMA5-15P/Output: 6 NEMA5-15R/4-ft. AC line cord

ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA5-15R wall receptacle)

FORMAT: Corded multi-outlet strip

SUPPRESSION: AC: 150V RMS Clamping/720 joules/330V UL1449 Let-through

Applications

Ideal for any desktop, network or home computing application requiring AC line protection.

Package Includes

TLP604 Surge Suppressor

Instruction manual with warranty information

Features

720 joules AC surge suppression shields equipment from the strongest surges and line noise

6 AC outlets with room for 1 transformer plug without blocking outlets covers computers and peripherals

4 foot AC line cable

Built-in power switch and 15 amp circuit breaker offers power control and overload protection over all outlets

Fail-safe thermal fusing protects against fire and other damage in the event of an extreme, extended overvoltage or surge condition

Diagnostic LED confirms surge suppression status

Attractive white suppressor housing with keyhole mounting tabs allow versatile placement options

UL1449 Rated (330V all modes), UL1363 (Power Tap), cUL (Canada)

Exceeds IEEE 587 category A & B surge suppression specifications

Lifetime warranty with $20,000 Ultimate Lifetime Insurance (USA & Canada Only)

Specifications

OVERVIEW

Intended Application Home/Office

SYSTEM OVERVIEW

Voltage compatibility 120 VAC

Frequency compatibility 50/60 Hz

OUTPUT

Output volt amp capacity

(amps)

Output watts 1800

Outlet quantity / type 6 NEMA 5-15R

Outlet orientation Single row

Transformer accommodation Supports 1 large transformer plug accessory without covering remaining outlets, accepts up to 4 transformers

total

INPUT

Input connection type NEMA 5-15P

Input cord gauge, type 14 gauge, SJT

Input cord length (ft.) 4 ft.

Input cord length (m) 1.2

Recommended Electrical

Service

120V (110-125V)

LEDS ALARMS & SWITCHES

Diagnostic LEDs Built-in LED confirms suppressor "protection present" (green) status

Switches Combination AC circuit breaker and 2 position on/off power switch

SURGE / NOISE SUPPRESSION

Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression

AC suppression joule rating 720 joules

Clamping voltage (RMS) 150V

AC suppression response

time

< 1 ns

UL1499 let through rating 330V - UL Verified

DATALINE SURGE SUPPRESSION

Telephone/DSL Protection No

Cable (Coax) Protection No

Network (Ethernet) Protection No

PHYSICAL

Shipping weight (lbs) 0.8

Shipping weight (kg) 0.4

Shipping Dimensions

(HWD/in)

1.5 x 12 x 3.75

Shipping Dimensions

(HWD/cm)

3.8 x 30.5 x 9.5

Unit weight (lbs) 0.8

Unit weight (kg) 0.4

Unit Dimensions (HWD/in) 1.2 x 10.5 x 1.6

Unit Dimensions (HWD/cm) 3 x 26.7 x 4.1

Material of construction Plastic

Integrated keyhole mounting

tabs

Keyhole mounting tabs enable wall mounting

AC line cord color Gray

Style Strip

CERTIFICATIONS

UL1449 1998 Rev. (AC

Suppression)

UL1449

UL1363 (Power Tap) UL1363

cUL / CSA (Canada) cUL

Approvals Exceeds IEEE 587 category A&B specifications

WARRANTY

Product Warranty Period Lifetime

Connected Equipment

Coverage

$20,000

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=123.
