Tripp Lite IBAR4 Manual de usuario

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: IBAR4

Isobar Surge Suppressor- Premium surge, spike and line noise protection

Highlights

4 outlets/6-ft. cord

2200 joule rating

All metal housing

Isolated filter banks

$50,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only

Description

For more than 20 years, America's leading companies have trusted Tripp Lite's Isobar Premium surge and noise suppressors to protect sensitive

computer, networking and telecom equipment. With more than 14 million satisfied customers, the Isobar remains the world's #1 selling premium

surge suppressor. Loaded with a generous combination of high quality components, near indestructible all-metal case and unique noise filtration

system, the isobar offers the highest level of protection attainable in a multi-outlet strip. Robust surge suppression circuits with sine-wave tracking

offer extreme levels of protection against the heaviest surge conditions exceeding IEEE 587 category A & B specifications and reducing 6,000V test

surges to harmless levels under 35 volts. Isobar's unique protection system combines large torroidal chokes, ferrite rod-core inductors, HF/VHF

capacitors and multiple layers of metal oxide varistors into exclusive isolated filter banks that remove EMI/RFI interference, even noise generated by

other pieces of connected equipment. IBAR4 offers 4 outlets arranged in two filter banks to prevent system crashes, reboots and performance

problems common as noisy system peripherals are powered off and on. Surge suppression rated at 2200 joules / 85,000 amps offers network-grade

protection. Widely spaced NEMA5-15 outlets accommodate up to 2 large transformer plugs without blocking outlets. Includes 6 foot AC line cord

with space-saving angled input plug and keyhole mounting tabs. Lifetime warranty with $50,000 Ultimate Lifetime connected equipment Insurance

(USA & Canada Only).

PLUG / OUTLETS: Input: NEMA 5-15P / Output: 4 NEMA5-15R / 6 ft. AC line cord

ELECTRICAL: 120V AC, 50/60Hz (Requires NEMA 5-15R wall receptacle)

SUPPRESSION: AC: 140V RMS Clamping / 2200 joules / 85,000 amps

FORMAT: Corded all-metal strip with transformer spaced outlets

Applications

Ideal for premium protection of personal computers with peripherals, network and CAD / CAM / CAE workstations, internetworking

accessories, telecommunications systems, point of sale equipment, audio / video and home theater systems in any home, office or industrial

application

Package Includes

IBAR4 Surge Suppressor

Set of 4 outlet safety covers

Instruction manual with warranty information

Features

Tripp Lite's ISOBAR is the world's #1 selling premium suppressor series with more than 14 million satisfied customers and a safety-tested

history of 20+ years

Robust surge suppression with sine-wave tracking protects against the heaviest of surge conditions, exceeding IEEE category A&B

specifications and reducing 6,000V test surges to harmless levels less than 35 volts.

Multi-component suppression circuits combine torroidal chokes, ferrite rod-core inductors, HF/VHF capacitors and multiple layers of metal

oxide varistors into exclusive isolated filter banks that remove EMI/RFI interference, even noise from other pieces of connected equipment.

4 outlets arranged in two filter banks prevent system crashes, reboots and performance problems common as noisy peripherals are

powered off and on.

Network grade surge suppression rated at 2200 joules / 85,000 amps

Widely spaced outlets accommodate up to 2 large transformer plugs without blocking outlets

Lighted power switch confirms power on/off status

6 foot AC line cord with space-saving angled input plug

Keyhole mounting tabs allow permanent installation

120V AC, 50/60Hz electrical compatibility

$50,000 Ultimate Lifetime Insurance (USA & Canada Only)

Lifetime product warranty

UL1449 listed - surge suppression (330V let-through), UL1283 listed - EMI protection, UL1363 listed - power tap, cUL approved to Canadian

standards

Specifications

OVERVIEW

Intended Application Home/Office, Computer Networks

SYSTEM OVERVIEW

Voltage compatibility 120 VAC

Frequency compatibility 50/60 Hz

OUTPUT

Output volt amp

capacity (amps)

Output watts 1440

Outlet quantity / type 4 NEMA 5-15R

Transformer

accommodation

Supports up to 2 large transformer plug accessories without covering remaining outlets

INPUT

Input connection type NEMA 5-15P input plug

Input cord length (ft.) 6 ft.

Input cord length (m) 1.8

Recommended

Electrical Service

120V (110-125V)

LEDS ALARMS & SWITCHES

Switches Two position red illuminated on/off power switch

SURGE / NOISE SUPPRESSION

Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression

AC suppression joule

rating

2200 joules

Clamping voltage (RMS) 140V

AC suppression

response time

NM = 0 ns. CM =

AC suppression surge

current rating

85,000 amps (36,000 NM / 49,000 CM)

AC suppression

components used

Metal oxide varistors, toroidal balanced chokes, ferrite rod-core inductors and VHF capacitors.

Safe thermal fusing Prevents unsafe conditions during extreme extended overvoltages and catastrophic occurences

UL1499 let through

rating

330V - UL Verified

IEEE587 Cat. A

ringwave let through

Less than 35 volts

EMI / RFI filtering 40-80 dB

Isolated filter banks Unique isolated filter bank design offers additional filtering between each duplex pair of outlets on the strip to prevent

electrical noise interference between connected loads. Includes 2 filter banks.

Immunity Conforms to IEE 587 / ANSI C62.41

DATALINE SURGE SUPPRESSION

Telephone/DSL

Protection

Cable (Coax) Protection No

Network (Ethernet)

Protection

PHYSICAL

Unit Dimensions

(HWD/in)

2.5 x 6 x 3.5

Unit Dimensions

(HWD/cm)

6.4 x 15.2 x 8.9

Material of construction Metal

Integrated keyhole

mounting tabs

Metal end caps are fitted with keyhole mounting tabs for wallmount installation

Housing Color Gray

Receptacle Color Black

AC line cord color Gray

Style Strip

SPECIAL FEATURES

Appearance Rugged all-metal corded strip format with high quality duplex receptacles

CERTIFICATIONS

UL1449 1998 Rev. (AC

Suppression)

UL1449

UL1283 (EMI Filter) UL1283

UL1363 (Power Tap) UL1363

cUL / CSA (Canada) cUL

Approvals Exceeds IEEE 587 category A&B specifications

WARRANTY

Product Warranty

Period

Lifetime

Connected Equipment

Coverage

$50,000

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3950.
